Hamilton Beach HBFR1504 User manual

1
REFRIGERATOR
USER MANUAL
Model No.: HBFR1504
Forserviceassistanceand productinformation, pleasecall:1-800-968-9853.
Pourobtenirassistance et information appelez: 1-800-968-9853.CurtisInternationalLtd.7045
BECKETTDRIVE,UNIT15, MISSISSAUGA, ON, L5S2A3 www.curtisint.com
Hamilton Beach est une marque déposéede Hamilton BeachBrands, Inc.
utilisésouslicence parCurtisInternationalLtd.
Hamilton Beach isa registered trademarkofHamilton
BeachBrands, Inc.used underlicensebyCurtisInternationalLtd.
Dearusers, thismanualcontainstheproduct s
basic knowledge, howto use it, fault diagnosis
and basic troubleshootingmethods.Inorderto
betterunderstand and use thisproduct, please
takegood careofthismanualand readit
carefully.

2
APPLIANCE
SAFETY
Your safetyand thesafetyofothersareveryimportant.
Wehave provided manyimportantsafetymessagesinthismanualandon yourappliance. Always
read and obeyallsafetymessages.
Thisisthe SafetyAlertSymbol.Thissymbol
alertsyou to potentialhazardsthat can kill
orinjureyou and others.
Allsafetymessageswillfollowthe Safety
AlertSymboland eitherthewards”
DANGER”, “WARNING”or “CAUTION”.
Danger meansthat failure to heed this
safetystatement mayresultin severe
personalinjuryordeath.
Warning meansthat failureto heed this
safetystatement mayresultinextensive
product damage, seriouspersonalinjury, or
death.
Caution meansthat failure to heed this
safetystatement mayresultin minoror
moderate personalinjury,orpropertyor
equipment damage.
Allsafetymessageswillalert you to what the potentialhazardis,tell youhow toreducethe chance
ofinjury, and let you knowwhat can happen ifthe instructionsare not followed.
PROP.65 WARNINGFORCALIFORNIARESIDENTS
WARNING:
CancerAnd ReproductiveHarm
www.p65warnings.ca.gov

IMPORTANTSAFEGUARDS
Before the
refrigerator
describedinthismanual,soreadthemanualcarefully.Toreducetheriskoffire,
electricalshockorinjurywhen using the
including the following:
Pluginto agrounded 3-
prong outlet, do not removegroundingprong, do not usean adapter, and do
not usean extension cord
•Replaceallpanelsbeforeoperating
•It isrecommended that aseparatecircuit, serving onlyyour
that cannotbe turned off bya switchorpull chain
•Neverclean appliancepartswith flammablefluids.Thesefumescan create afirehazardorexplosion.
And do not store orusegasoline orotherflammablevapors and liquidsin the vicinityo
otherappliance. The fumescan create a fire hazard orexplosion.
•Before proceeding with cleaning and maintenance operations, make sure the powerline ofthe unit is
disconnected.
•Do not connect ordisconnect the electricplug when yourh
•Unplugtheapplianceordisconnectthepowerbeforecleaningorservicing. Failureto dosocanresult
in electricalshockordeath.
•Donotattempt torepairorreplaceanypartofyourapplianceunless itisspecificallyrecommended in
th
ismaterial.All otherservicing should bereferred to a qualified technician.
•Usetwoormorepeople tomoveandinstallthe appliance. Failuretodosocan result in backorother
injury.
•To ensure properventilation foryourappliance,the unit must be completelyunobstructed. Choosea
well-
ventilated areawith temperaturesabove55
installed in an area protected fromthe elements, such
•The appliance should notbe located nextto ovens, grillsorothersourcesofhigh heat.
•The appliance must be installed with allelectrical,waterand drain connectionsin accordancewith
state and localcodes.
Astandardelectricalsupply(115VAC only, 60 Hz), properlygrounded in
accordancewith the NationalElectricalCodeand localcodesand ordinancesisrequired.
•Do not kinkorpinch the powersupplycord ofthe appliance.
•The fuse (orcircuit breaker
)size should be15 amperes.
•It isimportant forthe applianceto be leveled inordertoworkproperly.You mayneed to makeseveral
adjustmentsto levelit.
•Allinstallation must be inaccordancewith localplumbing coderequirements.
•Make certaint
hat the pipesare not pinchedorkinked ordamaged during installation.
•Checkforleaksafterconnection.
•Neverallowchildren tooperate, playwith orcrawlinside the appliance
•Donotusesolvent-
basedcleaningagentsorabrasiveson the interior.
discolorthe interior.
•Do not usethisapparatusforotherthan itsintended purpose.
3
IMPORTANTSAFEGUARDS
refrigerator
isused, it must be properlypositioned and installed as
describedinthismanual,soreadthemanualcarefully.Toreducetheriskoffire,
electricalshockorinjurywhen using the
refrigerator
, followbasicprecautions,
including the following:
prong outlet, do not removegroundingprong, do not usean adapter, and do
•It isrecommended that aseparatecircuit, serving onlyyour
refrigerator
,be provided. Use
that cannotbe turned off bya switchorpull chain
•Neverclean appliancepartswith flammablefluids.Thesefumescan create afirehazardorexplosion.
And do not store orusegasoline orotherflammablevapors and liquidsin the vicinityo
fthisorany
otherappliance. The fumescan create a fire hazard orexplosion.
•Before proceeding with cleaning and maintenance operations, make sure the powerline ofthe unit is
•Do not connect ordisconnect the electricplug when yourh
andsarewet
•Unplugtheapplianceordisconnectthepowerbeforecleaningorservicing. Failureto dosocanresult
•Donotattempt torepairorreplaceanypartofyourapplianceunless itisspecificallyrecommended in
ismaterial.All otherservicing should bereferred to a qualified technician.
•Usetwoormorepeople tomoveandinstallthe appliance. Failuretodosocan result in backorother
•To ensure properventilation foryourappliance,the unit must be completelyunobstructed. Choosea
ventilated areawith temperaturesabove55
0F(130C)and below900F(32 0
C). Thisunit must be
installed in an area protected fromthe elements, such
aswind, rain, watersprayorsunlight.
•The appliance should notbe located nextto ovens, grillsorothersourcesofhigh heat.
•The appliance must be installed with allelectrical,waterand drain connectionsin accordancewith
Astandardelectricalsupply(115VAC only, 60 Hz), properlygrounded in
accordancewith the NationalElectricalCodeand localcodesand ordinancesisrequired.
•Do not kinkorpinch the powersupplycord ofthe appliance.
)size should be15 amperes.
•It isimportant forthe applianceto be leveled inordertoworkproperly.You mayneed to makeseveral
•Allinstallation must be inaccordancewith localplumbing coderequirements.
hat the pipesare not pinchedorkinked ordamaged during installation.
•Neverallowchildren tooperate, playwith orcrawlinside the appliance
basedcleaningagentsorabrasiveson the interior.
Thesecleaners maydamage or
•Do not usethisapparatusforotherthan itsintended purpose.
isused, it must be properlypositioned and installed as
describedinthismanual,soreadthemanualcarefully.Toreducetheriskoffire,
, followbasicprecautions,
prong outlet, do not removegroundingprong, do not usean adapter, and do
,be provided. Use
receptacles
•Neverclean appliancepartswith flammablefluids.Thesefumescan create afirehazardorexplosion.
fthisorany
•Before proceeding with cleaning and maintenance operations, make sure the powerline ofthe unit is
•Unplugtheapplianceordisconnectthepowerbeforecleaningorservicing. Failureto dosocanresult
•Donotattempt torepairorreplaceanypartofyourapplianceunless itisspecificallyrecommended in
•Usetwoormorepeople tomoveandinstallthe appliance. Failuretodosocan result in backorother
•To ensure properventilation foryourappliance,the unit must be completelyunobstructed. Choosea
C). Thisunit must be
aswind, rain, watersprayorsunlight.
•The appliance must be installed with allelectrical,waterand drain connectionsin accordancewith
Astandardelectricalsupply(115VAC only, 60 Hz), properlygrounded in
accordancewith the NationalElectricalCodeand localcodesand ordinancesisrequired.
•It isimportant forthe applianceto be leveled inordertoworkproperly.You mayneed to makeseveral
Thesecleaners maydamage or

4
Explosiveviewsand partslist
Due to technologicalinnovation, the descriptionsofthe product inthismanualmaynot be completely
consistent withyourrefrigerator. Detailsareinaccordancewith the materialitem.
PRODUCTSPECIFICATIONS
·CAPACITYOF FREEZER IN:5.86CU FT
·CAPACITYOF FRIDGEIN :9.75CU FT
·SHELFMATERIAL:Glass shelf
·TEMPERATURECONTROL TYPE:Electroniccontrol
·TEMPERATURERANGEIN FAHRENHEITAND CELSIUS: -22to 6(-8to 43)℉℉
·DIMENSIONS
ØDEPTH (EXCLUDINGHANDLES)(IN):26.77
ØDEPTH (INCLUDINGHANDLES)(IN):26.77
ØDEPTH (LESSDOOR)(IN):23.62
ØDEPTHWITH DOOR OPEN90 DEGREES(IN):39.72
ØHEIGHTTOTOPOF DOOR HINGE(IN.):71.46
ØHEIGHTTOTOPOF REFRIGERATOR (IN.): 71.14
ØPRODUCTDEPTH (IN.):26.77
ØPRODUCTHEIGHT(IN.):71.46
ØPRODUCTWIDTH (IN.):30.71
No
Description
1Light
2Egg Tray
3Bottle Rack
4Refrigerator GlassShelf
5Salad Crisper
6Upper Freezer Drawer
7BottomFreezer Drawer
8AdjustableFoot

5
IMPORTANTSAFETYINSTRUCTIONS
~WARNING~To reduce the riskoffire, electricalshock, or
injurywhen using yourrefrigerator
-freezer, follow these basicprecautions:
•Read allinstructionsbeforeusingtherefrigerator-freezer.
•DANGER orWARNING:Riskofchild entrapment.
Child entrapment and suffocation arenot problemsofthe past. Junked orabandoned
refrigerator-freezers are stilldangerous. . . even iftheywill “just sitin the garage afewdays.”
•Beforeyou throwawayyouroldrefrigerator-freezer: Take off the doors. Leave the
shelvesin place so that children maynoteasilyclimb inside.
•Neverallow childrento operate, playwith, orcrawlinside the refrigerator-freezer.
•Neverclean refrigerator-freezerpartswith flammable fluids. The fumescan create a fire
hazard orexplosion.
•Do not storeoruse gasoline oranyotherflammable vapors and liquidsin the vicinityofthisor
anyotherrefrigerator-freezer. The fumescan create afire hazard orexplosion.
-Save these instructions-
INSTALLATIONINSTRUCTIONS
ØBefore Using YourAppliance
lRemove the exteriorand interiorpacking.
lCheckto be sureyou have allthefollowing parts:
l2 Glass RefrigeratorShelveslEgg Tray
l1 Vegetable Crispers lRemovable FreezerDrawerTray
l1 Glass CrisperCover lInstructionManual
l6 RefrigeratorDoorBins
(4)StandardBins
(2)Gallon BottleBins
l
•Beforeconnectingtheunitto thepowersource, let itstand upright forapproximately2hours.
Thiswill reducethepossibilityofamalfunction inthecooling systemfromhandling during
transportation.
•Clean the interiorsurface with lukewarmwaterusing asoft cloth.
ØInstallation of YourAppliance
•Placeyourrefrigerator-freezeron afloorthatisstrong enoughto supporttherefrigerator-
freezerwhen itisfullyloaded. Tolevelyourrefrigerator-freezer, adjusttheleveling legsat the
bottomofunit.
•ALLOW5INCHESOF SPACEBETWEENTHEBACKANDSIDESOF THEUNIT,WHICH
ALLOWSTHEPROPERAIR CIRCULATIONTOCOOL THECOMPRESSORAND
CONDENSER.
•Locatetheunitawayfromdirectsunlight andsourcesofheat(stove, heater,radiator,etc.).
Directsunlight mayaffectthe acryliccoating and heat sourcesmayincreaseelectrical
consumption. Extreme coldambient temperaturesmayalso cause the refrigerator-freezernot
to performproperly.
•Avoidlocating the unitinmoist areas.
•Plugtheunitinto anexclusiveproperlyinstalled-grounded walloutlet. Do notunderany
circumstancescut orremovethethird(ground)prongfromthe powercord.Anyquestions
concerningpowerand/orgroundingshouldbedirectedtowardacertifiedelectricianoran
authorized Productsservice center.

6
Electrical Connection
~
Warning
~
Improperuse ofthe grounded plugcan resultin the risk ofelectricalshock. Ifthe powercordis
damaged, have itreplaced byan authorized Productsservice center.
Thisapplianceshouldbeproperlygroundedforyoursafety.The powercordofthisapplianceis
equippedwithathree-prongplugwhichmateswithstandardthreeprongwall outletstominimizethe
possibilityofelectricalshock.
Do not underanycircumstancescut orremove the third ground prong fromthe powercord supplied.
Thisappliancerequiresa standard 115Volts~/60Hzelectricaloutlet with three-prong ground.
The cordshouldbesecuredbehind the applianceand not leftexposedordanglingtoprevent accidental
injury.
Neverunplug the appliancebypullingthe powercord. Alwaysgriptheplug firmlyand pullstraight out
fromthe receptacle.
Do notuseanextensioncordwiththisappliance. Ifthepowercordistooshort, haveaqualified
electrician orservice technician install an outlet nearthe appliance.
EXTENSION CORD
Becauseofpotentialsafetyhazardsundercertain conditions,itisstronglyrecommended that you do
not usean extension cord with thisunit. However,if you must use an extension cord itisabsolutely
necessarythat it be a UL/CUL-Listed, 3-wire grounding typeappliance extension cord having a
grounding typeplug and outlet andthat the electricalrating ofthecord be 115voltsand at least 10
amperes.
SURGEPROTECTOR
Most electricalappliancesuse a seriesofelectriccontrolboardsto operate. These boardsare very
susceptible to powersurgesand couldbe damaged ordestroyed.
Ifthe applianceisgoingtobeusedinanarea orifyourcity/countryispronetopowersurges/outages;
itissuggested thatyouuseapowersurgeprotectorforallelectricaldevices/appliancesyouuse. The
surge protectorthat you select must have a surge block high enough to protectthe applianceitis
connectedto.Ifyouhaveanyquestionsregardingthetype andsizeofsurge protectorneededcontact
a licensed electrician inyourarea.
Damagesdue to powersurgesare not considered amanufacturercovered defectand willvoidyour
productwarranty.
REFRIGERATOR-HOWTO LEVEL
Forunits with leveling legs:
1. Remove the basegrille. Somemodelhave screwsholding the grille in place, removescrews.
Somemodelshaveclipsthat snapout when the grilleis pulled out.
2. Insert a flat blade screwdriverinto the slotson the leveling leg and turn clockwiseto raise the
refrigeratororcounterclockwise tolowerit.
3. The front ofthe refrigeratorshould be1/4inchhigherthan the rear. Thisshould be measured
using a level.
4. Replace the grille.

8
PREPROGRAMMED FUNCTIONS:
•SABBATHMODE
The Sabbathmode isdesigned forthosewhosereligiousobservancesrequireturningoffthe lights.
Allinteriorlightsandcontrolpanelindicators will be disabled.
ToenabletheSABBATHMODE,press thefunction buttonuntiltheSABBATHMODEiconis
flashing and press the OKbuttonto activate. The controlpaneland interiorlightswill turnoff and
willremain in the SABBATH MODEuntilitisdeactivated on the controlpanel
TodisabletheSABBATHMODE,press andholdthefunction buttonforapproximately3seconds
untilthecontrolpanellightsup again.And youcan alsounplug the powercordforapproximately30
secondsthen, plug inthe powercord, therefrigeratorSABBATHMODEwillbe deactivated. The
icon willturn offand alllightsand indicators willreturnto thenormaloperation.
•FASTFREEZEMODE
Thismode willsetthefreezertemperatureto-26ºF/-32ºCforquicktemperaturedrop whenstoring
large amountsofwarmorroomtemperature foodsin the freezer.
The unitwill remaininFASTFREEZEmode untilthe temperaturereaches-26ºF/-32ºCandwill
then return to the originalsetting oruntil the function isturnedoffat thecontrolpanel.
Toenablethe FASTFREEZEmode, press thefunction button until the FASTFREEZEiconis
flashing andpress theOKbutton toactivate. The iconwill remainilluminated.
TodisabletheFASTFREEZEmode, press the functionbutton until theFASTFREEZEiconis
flashing andpress theOKbutton todeactivate. The icon willturnoff.
•VACATION MODE
Usethismode whenleavingforlongperiodsoftime, whereyouwillremovethe large majorityofthe
contentfromthe refrigeratorsection but leavethefreezercontent.
The Vacation mode willautomaticallyset the refrigeratorsectionat57ºFand thefreezersection
remain at yourcurrent setting.
The unitwill remainin the VACATION MODEuntil itisdeactivatedat the controlpanel.
ToenabletheVACATIONMODE,press the functionbuttonuntilthe VACATIONMODEiconis
flashing andpress theOKbutton toactivate. The iconwill remainilluminated.
TodisabletheVACATIONMODE,press the functionbuttonuntilthe VACATIONMODEiconis
flashing andpress theOKbutton todeactivate. The icon willturnoff.
•SMART(AUTOMATIC)MODE
Use thismode to automaticallysettheunit at normalaverage operatingtemperatures.
The SMARTMODEwill automaticallyset therefrigeratorsection at 38ºFand the freezersectionat
-0ºF. The unitwillremain in theSMARTMODEuntilitisdeactivated atthecontrolpanel.
The temperaturescannot be adjustedwhen in the SMART(AUTOMATIC)MODE.
Toenablethe SMARTMODE,press the function buttonuntiltheSMARTMODEiconisflashingand
press the OKbutton to activate. The icon will remainilluminated.
TodisabletheSMARTMODE,press thefunctionbutton untiltheSMARTMODEiconisflashing
and press the OKbuttonto deactivate. The iconwillturn off.
Onceyou havedisabled the SMARTMODE, setthe temperaturemanuallyasindicated previously
in thismanualto atemperature that bettersuitsyourneeds.

9
•CONTROL PANEL CHILD LOCK
The CONTROLPANELLOCKisdesigned toprevent anychangestothesettingstotherefrigerator.
ToenabletheCHILD LOCK,press andholdtheOKbutton forapproximately3seconds,theCHILD
LOCKicon will turnon. Thecontrolpanelwillbelocked until unlocked at the controlpanelorthere
isa loss ofpower.
TodisabletheCHILD LOCK,press and holdtheOKbutton forapproximately3secondsuntilthe
CHILD LOCKicon turnsoffand the controlpanelisworking in normaloperationmode.
•CONTROL PANEL STANDBY
The CONTROLPANELwill do darkafterapproximately5 minutesofno activity
Toactivatethecontrolpanel,press and holdthe OKbuttonforapproximately3seconds,the
CONTROLPANELAND CHILD LOCKiconwill turnon. The controlpanelwillbe locked until
unlocked at the controlpanelorthereisa loss ofpower.
TodisabletheCHILD LOCK,press and holdtheOKbutton forapproximately3secondsuntilthe
CHILD LOCKicon turnsoffand the controlpanelisworking in normaloperationmode.
NOTE:
•IFTHEUNITISUNPLUGGED, HASLOSTPOWER, ORISTURNEDOFF,YOUMUSTWAIT3
TO5MINUTES BEFORERESTARTINGTHEUNIT.IFYOUATTEMPTTO RESTARTBEFORE
THISTIMEDELAY, THEREFRIGERATOR-FREEZERWILL NOTSTART.
NOTE:
WEDONOTRECOMMEND THEINSTALLATION OFTHEREFRIGERATOR WHERETHE
TEMPERATUREWILL DROPBELOW50ºF(13ºC)OR RISEABOVE110ºF(43ºC). THE
COMPRESSOR WILL NOT BEABLETOMAINTAINPROPER TEMPERATURES INSIDETHE
REFRIGERATOR.
FOR INSTALLATIONSWHERETHETEMPERATURES WILL DROPBELOW50ºSETTHE
FREEZER TEMPERATURECONTROL TOTHE “COLDEST”SETTING. THISWILL IMPROVE
THEOPERATIONSOF THEREFRIGERATORUNDER THESE CONDITIONS.
ØAdjusting the Temperature inthe FreshZone /Crisper
Toadjustthe temperature inthe FreshZone/Crisper, simplymovethe temperaturecontrol(located at
the backofthe unit justabove the crisper) left to right.Temperature range isMAX to MIN.
MAXisthe coldest
MIN isthe Warmest

10
CAREAND MAINTENANCE
ØCleaning YourAppliance
•Unplug the unit, and remove thefood and baskets.
•Wash the inside with awarmwaterand baking soda solution. The solution shouldbe about 2
tablespoonsofbaking soda to a quartofwater.
•Wash the basketswith a mild detergent solution.
•The outsideofthe unit shouldbe cleaned with mild detergentandwarmwater.
CAUTION
Failure to unplug therefrigerator-freezercouldresultinelectrical shock orpersonalinjury.
ØPowerFailure
Most powerfailuresare corrected within afewhours and shouldnotaffect the temperature of your
refrigerator-freezerif you minimizethenumberoftimesthe doorisopened. Ifthe powerisgoing to be
off fora longerperiod oftime, youneed to take the properstepstoprotectyourfood.
ØVacation Time
Shortvacations: Leave the unit operating duringvacationsofless than three weeks.
Long vacations: Ifthe appliancewill not be used forseveralmonths,removeall food and unplug the
powercord.Clean anddrytheinteriorthoroughly.Topreventodorandmoldgrowth, leavethedoor
openslightly:blocking itopen ifnecessary
ØMoving YourAppliance
•Remove allthe food.
•Securelytape down allloose itemsinside yourunit.
•Turn the leveling screwsupto the base to avoid damage.
•Tape the doorshut.
•Be surethe unit staysinthe upright position during transportation.
ØEnergy Saving Tips
•The unitshouldbe locatedinthe coolestarea ofthe room,awayfromheat producingappliancesor
heatingducts, and out ofdirect sunlight.
•Let hot foodscoolto roomtemperaturebeforeplacing themintheunit. Overloadingtheunitforces
the compressorto run longer. Foodsthatfreeze too slowlymaylosequality,orspoil.
•Be sureto wrapfoodsproperly,and wipe containers drybefore placing themin the unit.Thiscuts
downon frost build-up inside thefreezer.
•Organizeandlabelfoodto reducedooropeningsand extendedsearches.Removeasmanyitems
asneeded at one time, andclose the doorassoon aspossible.
