Hammerhead Stingray Installation and operating manual


Stingray Mini Kart Kit
Installation Reference
WARNING: The instructions in this book should be used as a
reference on how to set up your engine on the chassis. Steps might
vary on different engines. Hammerhead off-Road,Inc is not liable for
any injuries resulting from improper installation. Seek professional
assistance if you have any questions about how to set up this unit.*
Hammerhead Off-Road
877-857-7678

Installation Instructions
***You will need a 3-5 HP horizontal shaft gas engine of your
choice. It needs to have a 3/4in. shaft tapped with a 5/16in. -24
bolt, and have a 3/16in. keyway***
1) Place uncrated frame on flat stable surface.
2) Skip to step 7 if you have not purchased you engine yet.
3) Install clutch to engine and tighten bolt.

4) Attach engine to frame and leave bolts loose until drive wheel has been installed.
Let chain hang on clutch sprocket so when the drive wheel is installed you can put
chain around wheel sprocket.

5) Attach throttle cable to carburetor. Most will have a saddle for the barrel to sit in,
but some will have a clamp to pinch the wire. Adjust so no slack is in the cable.

6) Attach kill switch wires to engine. One wire goes to ground and one to the power
wire for the stator. Its does not matter which one goes where.

7) Attach front spindles to kart. Tie rod arm should be on the top side and facing
forward. Slide spacer into spindle and slide spindle in frame. Put the bolt from
the top down and put nut on the bottom.
8) Attach rod end to the tie rod arm on the spindle with the stud on the bottom.

9) Put washers and nut on each rod end and tighten. Lock washer should sit against
the nut and the flat washer will sit against the tie rod arm. Make sure to use cotter
pin once the nut is tight. Refer to picture above.
10)Slide wheels onto spindles and tighten nut. Push rubber cap over the nut.

11)Attach rectangle rubber cover to the top of the chain guard and the silver metal L
bracket to the bottom side. Leave bolts loose.
12)Attach chain guard to the frame and use the other bolt to attach to the frame
mount above axle. If engine is installed use the other 2 bolts to attach the metal L
bracket to the engine.

13)Slide rear wheels onto rear axle. The wheel with the sprocket goes on the left
(driver) side. Make sure to put chain around wheel sprocket. Tighten both nuts
and make sure to use cotter pins when the nut is tight.
14)When nut is tight and cotter pin is installed push rubber cap over the nut.

15)If engine is on unit, tighten all bolts and slide engine till the chain is snug. You
should have no more than 3/8in. of play in chain.
16)With front wheels straight, install the steering wheel and tighten bolts. Make sure
to use both the flat washer and the lock washer. Install lock washer first so that it
is against the head of the bolt then the flat washer second.
17)After bolts are tight push plastic cap till it snaps into place.

18)Now with a rolling chassis attach top railing to main frame but leave each bolt
loose. Once all railings are on unit tighten all bolts.
