HAMOKI EP-2 User manual

Pizza Oven Instruction
Manual
Model: EP1+1, EP2+2
1
Please read this instruction manual carefully before
operation

2
Control Panel
EP1+1
EP2+2

3
Instructions
A. The illuminating light switch controls the illuminating light in the oven.
B. Turn on the power switch. Regulate the bottom heater thermostat to
needed temperature to heat.（the timer just remind not interrupt）The
thermostat will keep a constant temperature when the temperature
reaches set temperature.
C. Turn off the power switch. Regulate the bottom heater thermostat to
the required temperature. Then regulate the timer to the time needed. It
will stop heating when it times out.(If using the timerplease increase the
temperature to a set temperature）
D. The bottom heater thermostat is to control both the bottom element
and the bottom indicator. The middle heater thermostat is to controlthe
middle element and the middle indicator. The top heater thermostat is
to control the top element and the top indicator.
E. The maximum temperature can reach 350℃and the temperature
increases rapidly.
F. You must preheat the temperature to 200-300℃before putting the
food in the oven.
Installation:
A. The used voltage must be the same as rated voltage.
B．You must pull in enough power for the unit.
C．There is a landing bolt at back of the oven. Connect the copper core
wire (>2.5mm2 ) with safe earth wire.
D. Inspect the wire, voltage, and the lading wire to be sure they are all
safe and properly installed.
Waste Disposal:
At the end of its service life the d device has to be disposed of in
accordance with the national regulations. It is advisable to contact a
company which specialises in waste disposal, or contact the local
disposal service in your community.
WARNING! To avoid danger, make the device unfit for use before
disposal. For that purpose, disconnect the device from the mains
supply and remove the mains connection cable from the device.
NOTE! For the disposal of the device please consider and act according
to the national and local rules and regulations.

4
Model Code Measurement Power Voltage Weight
EP
-2
171004
770
×720×270mm
2.2 kW
220V~240V
37kg
EP 2+2
171003
770
×720×430mm
3 kW
220V~240V
55kg
Troubleshooting
Fault
Cause
Solution
Power switch turned on with
indicator light but the
temperature is not
increasing in the oven
1. Thermostat is
damaged
2. element is
damaged
1.change thermostat
2. change element
Power switched on, unable
to turn the thermostat,
temperature cannot be
controlled.
The thermostat is
damaged
Change the thermostat
Power on, switch is pressed,
but indicator is not lighting
up
The indicator is
damaged
Change the indicator
Power on, indicator not
lighting up, temperature isn’t
increasing
Power not wired,
damaged fuse
Inspect power and
wire, change fuse

Warranty
5
WARRANTY Hamoki Ltd warrants the original purchaser of every new
product (under normal and proper use and maintenance service as
specified by Hamoki Ltd and upon proper installation and start-up in
accordance with the instruction packet supplied with each unit) a one
year parts warranty.
Hamoki Ltd’s obligation under this warranty is limited to a period of one (1)
year from the date of original installation.
WARRANTY CLAIMS:
All claims for parts must be made directly through the retailer in the first
instance. All claims raised with the retailer should include:
Your name:
Model number:
Your company:
Serial number of the product:
Address: Date of purchase:
Email: Proof of purchase :
Phone:
Information supporting the alleged defect.(A video/photo)
Photo of the dataplate.
