HAMPTON BAY GCS09120C User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chair. We strive to continually
create quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
COLLAPSIBLE GREY HANGING EGG CHAIR WITH BASE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
Item # 0000 000 000
Model # GCS09120C

2
Table of Contents
Table of Contents................................... . 2
Important Safety Instructions.......................... 2
What is covered ...................................3
What is not covered ................................3
Warranty ................................... . . . . . . . 3
Pre-Assembly..................................... . . 3
Planning Assembly ............................... . . 3
Hardware Included ............................... . . 3
Package Contents . ................. . . . . . . . . . . . . . . . . 4
Care and Cleaning .................................. . 8
Assembly . . . . . . . .......................... . . . . . . . . .
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: THIS CHAIR IS MADE FOR THE EXPLICIT PURPOSE OF PROVIDING OUTDOOR FUNCTIONS AND IS NOT TO BE USED AS A TOY.
THIS PRODUCT IS INTENDED FOR NORMAL OUTDOOR USE; HOWEVER, THE MANUFACTURER RECOMMENDS STORING AND/OR COVERING THIS
PRODUCT WHEN ANY FORMIDABLE/SEVERE WEATHER IS APPROACHING.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this furnishing is used by
or near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chair while it is occupied. Failure
to obey this caution could result in injury.
WARNING: DO NOT LOCATE THIS PRODUCT NEAR OPEN FLAMES. DO NOT USE THIS PRODUCT AS A SUPPORT. DO NOT SHAKE, LEAN OR CLIMB
ON THE PRODUCT. CHILDREN UNDER THE AGE OF 10, NEAR THE PRODUCT, SHOULD BE SUPERVISED BY A COMPETENT ADULT AT ALL TIMES.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE AND WILL VOID THE WARRANTY.
WARNING: This chair unit is heavy, and may
require two adults for safe assembly.
WARNING: Never use this product as a support. Do not
shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the chair.
WARNING: Weight limit for the chair is 250lbs
(113.39Kg) for each seat.
WARNING: Please keep children out of the assembly
area before assembly.
CAUTION: When not in use, secure the product in a
cool and covered location.
CAUTION: Do not locate the product near any heat
sources.
Save These Instructions .............................2
Read All Instructions Before Use.......................2
5

Warranty
1 YEAR FRAME AND 1 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for one year, and a one year limited warranty for the fabric.
WHAT IS NOT COVERED
Its remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HOMEDEPOT.ca.
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to assemble this product.
3 HAMPTONBAY.CA
Please contact 1-855-HD-HAMPTON for further assistance.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
2+1 EE
FF
Hex Wrench
M8x60 Combination Bolt
M8x30 Combination Bolt
1+1
4+1
AA
BB
M6x15 Combination Bolt
2
CC
Part
Description Quantity
1
M8x20 Combination Bolt
DD
AA
Wrench
M8x20 Bolt, Spring Washer and Washer
GG
2+1
4+1
BB CC DD
GG
HH II
FF
EE
HH
II
1
1
Hook
Plastic Muffler

PACKAGE CONTENTS
Pre-Assembly (continued)
4
1
E
F
Right Base
Left Base
1
1
A
B
Upper Hanging Bar 1
C
Part Description Quantity
Straight Base Tube
D
Basket
Lower Hanging Bar 1
2
A
B
C
C
D
E
F
G
H
G
H
Back Cushion
Seat Cushion
1
1
I Safety Rope 1
I

Assembly
1Connecting The Right Base To The Left Base
2Connecting The Straight Base Tubes To The Right Base And The Left Base
Place the right base (A) and the left base (B) upside down on a soft surface.
Attach the right base (A) to the left base (B) using M8x20 combination bolts (CC).
5
Insert the straight base tubes (C) to the right base (A) and left base (B) using M6x15 combination bolts (EE).
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
Do not tighten all the bolts until step 2 is completed.
Fully tighten all the bolts at this step.
B
B
A
A
CC
C
B
A
C
EE
B
C

Assembly (continued)
3Attaching The Lower Hanging Bar To The Assembled Base
4Insert The Upper Hanging Bar Into The Lower Hanging Bar And Put On The
Plastic Muffler
Turn the assembled base right side up.
Attach the lower hanging bar (D) to the assembled base using M8x20 bolts, spring washers and washers (DD) and M8x30
combination bolts (BB).
6
Insert the upper hanging bar (E) into the lower hanging bar (D) using an M8x60 combination bolt (AA).
Fully tighten all the bolts at this step.
Put the plastic muffler (GG) on the upper hanging bar (E) and fit by rotating it.
BB
DD
D
B
A
E
D
E
D
E
D
AA
GG

Assembly (continued)
5Put On The Plastic Muffler And Attach The Hook To The Basket
6Attach The Basket To Upper Hanging Bar And Attach The Safety Rope
7HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
Place the basket (F) right side up on a soft surface and unfold.
Put the plastic muffler (GG) on the basket (F) and fit by rotating, as shown below.
Loosen the one side of the hook (FF) by turning clockwise, attach to the basket (F) and tighten it counterclockwise.
Loosen the other side of the hook (FF) clockwise, attach it to the upper hanging bar (E) and tighten it counterclockwise.
Loosen the safety rope on the seat of the basket by turning counterclockwise, put the safety rope (I) through the lower hanging
bar (D) and tighten the safety rope (I) back clockwise, as shown below.
NOTE: Always use caution. The safety rope (I) must be properly attached before using this egg chair.
GG
F
FF
I

Assembly (continued)
7Checking The Egg Chair
8
Put the back cushion (G) and the seat cushion (H) into the basket (F).
Care Care and Cleaning
For best results, clean the frame and cushions with adamp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrrasive materials, bleach or solvents.
Store the chair in a dry sheltered place when not in use.
Keep the chair out of fire, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Ensure that all connections are secure before use.
G
H
F

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
Retain this manual for future use.
For certification use only
Factory ID# GCS09120C
