HAMPTON BAY HOUSTON FSS10036R-ST User manual

THANK YOU
We appreciate the trust and condence you have placed in Hampton Bay through the purchase of this conversation set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Item #1000-000-000
Model #FSS10036R-ST
USE AND CARE GUIDE
HOUSTON 5-PIECE FIREPIT CONVERSATION SET
Questions, problems, missing parts? Before returning to the store call
Hampton Bay Customer Service.
8 a.m.- 6 p.m., EST, Monday -Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Table of Contents
Table of Contents..........................................................2
Warranty ........................................................................2
What is Covered ...................................................................... 2
What is Not Covered ................................................................ 2
Pre-Assembly ................................................................2
Planning Assembly .................................................................. 2
Hardware Included .................................................................. 2
Chair Package Contents .......................................................... 3
Table Package Contents..........................................................4
Chair Assembly............................................................. 5
Table Assembly ............................................................ 8
Care and Cleaning........................................................11
Warranty
1 YEAR FRAME AND FABRIC WARRANTY
WHAT IS COVERED
We warrant the frame and fabric to be free of manufacturing defects to the original purchaser for one year.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, re, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
Part Description Quantity
AA M8x15 Bolt 48
BB M6 Washer 48
CC M8 Spring washer 32
DD M8 Washer 32
EE M8x28 Hex bolt 16
Part Description Quantity
FF M8x35 Hex bolt 16
GG Metal sheet 8
HH M8 Nut 16
II Hex wrench 1
JJ Wrench 2
JJ
AA BB CC DD EE FF GG HH
II
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.

3
Pre-Assembly (continued)
CHAIR PACKAGE CONTENTS
Part Description Quantity
A Right arm 4
B Left arm 4
C Support tube 4
D Support bar 8
E Chair back 4
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
B
E
A
C
D
KK Back cushion 4
LL Seat cushion 4
KK
LL
D

4
Pre-Assembly (continued)
TABLE PACKAGE CONTENTS
Part Description Quantity
F Table rim 1
G Table leg 4
H Leg connector 1
I Tile 4
J Barbecue grate 1
K Poker 1
L Log grate 1
M Fire bowl 1
N Lid 1
N
I
J
K
L
F
M
G
H
OR
O
O Cover 1

1
l
5
Chair Assembly
Place the right arm (A) on a soft surface.
Attach one end of the support tube (C) to the right arm (A) using M8x28 hex bolts (EE), M8 spring washers (CC), and
M8 washers (DD).
Attach the support bar (D) to the right arm (A) using M6x15 bolts (AA) and M6 washers (BB).
Repeat this step to attach the left arm (B) to the support tube (C) and support bar (D).
Connecting the support tube and support bar to the chair arms
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
NOTE: Loosely tighten all bolts using the hex wrench (II)
and wrench (JJ).
AA
BB
A
CC
DD
EE
D
C
CC
DD
EE
AA
BB

2
l
6
Chair Assembly (continued)
Connecting the chair back to the support tube
NOTE: Loosely tighten all bolts using the wrench (JJ).
Attach the bottom of the chair back (E) to the support tube (C) by inserting M8x35 hex bolts (FF) through the metal sheets (GG), the
chair back (E), the support tube (C), M8 washers (DD), M8 spring washers (CC), and into the M8 nuts (HH).
HH
DD
FF
GG
FF
CC
E
HH
DD
CC
E
C

3
l
7
Chair Assembly (continued)
Tightening the bolts
Once all the bolts are in place, fully tighten all bolts.
Ensure that all connections are secure before use.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Place the chair back (KK) and seat (LL) cushions to nish the assembly of the chairs.
KK
LL

l
8
Table Assembly
1
Connecting the table legs
Place the table rim (F) upside down on a soft surface.
Attach the table legs (G) to the table rim (F) using M6x15 bolts (AA), and M6 washers (BB).
NOTE: Loosely tighten the bolts using the hex wrench (II).
F
G
AA
BB
AA
BB

l
9
Table Assembly (continued)
HAMPTONBAY.COM
2
Connecting the leg connector to the table legs
NOTE: Loosely tighten all the bolts using the hex wrench (II).
Attach the leg connector (H) to the table legs (G) using M6x15 bolts (AA) and M6 washers (BB).
Please contact 1-855-HD-HAMPTON for further assistance.
H
AA
BB
AA
BB

l
10
Table Assembly (continued)
3
Tightening all the bolts and adding the tiles
Once all bolts are in place, fully tighten all bolts.
Turn the table right side up.
Carefully place the tiles (I) on the table.
I
ò

l
11
Table Assembly (continued)
HAMPTONBAY.COM
4
Adding the re pits
Carefully place the re bowl (M) in the table rim (F).
Then place the following in order, from bottom to top: the log grate (L), the barbecue grate (L) and the lid (N) or the cover (O).
When not in use, store the poker (K) under the log grate (L).
Please contact 1-855-HD-HAMPTON for further assistance.
N
J
K
L
M
OR
O
Care and Cleaning
For best results, clean the frames with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that
Do not clean with abrasive materials, bleach, or solvents.
Store the table and chairs in a dry, sheltered place when not in use.
Keep the table and chairs away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or
wind.
may accumulate.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 6 p.m., EST Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
