HAMPTON BAY THD338399.1a User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this bookcase. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
Elite 2-Door Wall Cabinet - White
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
OMSID # 205703188
Model # THD338399.1a

2
Table of Contents
Table of Contents ...................................2
Safety Information ..................................2
Warranty ..........................................2
Pre-Assembly ......................................
......................................
......................................
......................................
......................................
......................................
......................................
3
Planning Assembly
Tools Required
Hardware Included
Package Contents
Assembly
Weight Limits
3
3
3
4
5
11
Safety Information
Read and understand all instructions before assembly.
Warranty
LIMITED ONE YEAR PRODUCT WARRANTY
WHAT IS COVERED
This limited warranty covers the original purchase of this product used for normal commercial,
Personal, or household use. The supplier warrants its products will be free from defects in materials and workmanship (normal wear and
tear excepted) for a period of one (1) year from the date of purchase, except as provided below. The supplier, at its option, will replace with
a comparable product, free of charge, any product purchased from it that fails under normal use as a result of such defect.
Materials are warranted for one year from date of purchase. Proof of purchase is required in the form of a receipt (copy or original) to
validate the warranty.
The supplier provides this limited warranty in lieu of all other warranties either expressed or implied. Expressly excluded are all warranties
shall be limited to the repair, refund or replacement at the supplier’s sole discretion and cost, of product or components.
THIS WARRANTY APPLIES ONLY TO THE U.S. AND CANADA.
WHAT IS NOT COVERED
improper cleaning or other circumstances not directly attributable to defects in materials and workmanship.
Natural variations occurring in wood or other materials will not be considered defects, and the supplier does not warrant the color-fastness
the product not approved, and products that were not installed, used, or maintained in accordance with product instructions and warnings.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.Hamptonbay.com.

3 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
PLANNING ASSEMBLY
Compare all parts with the Hardware Included and Package Contents lists in this manual. If any part appears missing or damaged, do not
assemble this product. Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
TOOLS REQUIRED
Flathead
screwdriver
Phillips
screwdriver
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
a
a
a16
16
20
4
4
2
24
4
4
Cam Lock
Cam Bolt
Wood Dowel
Shelf Support
Bolt
Knob
3.5*14 mm Screw
Hinge
4*76 mm Screw
b
c
d
e
f
g
h
i
f g h
i
b c d e

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A Top/Bottom 2
B2
C
Side Panel
2
D
Cross Bars
1
E1
F1
Adjustable Shelf
Left Door
Right Door
A
A
B
B
D
E
F
C
C

5 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly
1Preparing the two top and two
side panel
□Screw four cam bolts (b) into the appropriate holes on the
two tops (A).
□Insert twelve wood dowels (c) into the two tops (A).
□Screw twelve cam bolts (b) into the appropriate holes on the
two side panel (B).
2Assembling the bottom
□Insert eight wood dowels (c) into the two cross bars (C).
□Place the cross bars (C) over the cam bolts (b) on the top/bottom (A).
Secure together by inserting two cam locks (a) into the appropriate
holes on the bottom cross bars (C) and turning clockwise until they
lock into place over the cam bolts (b).
□the same assembling step for the other cross bars (C) and
top/bottom (A).
c
c
c
c
b
b
b
b
a
c
c
b
b
a
A
C
C
C
C
A
A
A
B
B

6
Assembly (continued)
3Assembling the side panel
□Connection side panel (B) and two tops (A) and cross bars (C) ,
ensure that the wood dowels (c) and cam bolts (b) are fully
inserted into the appropriate holes.
□Insert six cam locks (a) into the holes to the two tops (A)
and two cross bars (C) , then turn all of the cam lock (a) clockwise
until they lock into place over the cam bolts (b).
4Assembling the other side panel
□Follow Step 3 to install other side panel (B).
a
a
b
C
C
B
B
B
A
A
A
A
C
C

7HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly (continued)
5Assembling the adjustable shelves
and hinge
□Insert four shelf supports (d) into the desired holes the cabinets
assembly and place inside the shelf (D) on top of the supports (d).
□Through four screws (g) with one hinge (h) to lock on the side
panel (B) , the same assembling step for the other three hinges (h).
6Assembling the door
□Through two screws (g) with one hinge (h) to lock on the door ,
the same assembling step for the other hinges (h).
□Through two bolts (e) connect knob (f) with the door (E and F) , the same
assembling step for the other knob (f).
d
d
g
g
h
h
A
A
A
A
B
B
B
C
B
D
D
D
E
F
e
e

8
Assembly (continued)
To adjust the vertical height.
Loosen the four screws "A" on both hinges.
Two of them are usually in slotted holes which
mean and you can adjust up or down by a few
mm. Then tighten back up
To adjust depth.
Loosen screw "B" and adjust door, if the door
can not be adjusted, please loosen screw "C",
then try again.
Tighten screw "B" and "C".
To adjust side ways.
Turning the screw "C" on BOTH hinges on
each door.

9
Assembly (continued)
7Installing wall cabinets to the
wood wall
□Drill 2/16" diameter holes (2.5mm) in the wood wall , height
corresponding with the cross bars (C) holes ,through cross bars
hole using four 3" screws (i) tightening the 2-door wall cabinet
into the wood wall hole.
WEIGHT LIMITS (option)
□This unit has been designed to support the maximum loads shown.
Exceeding these load limits could cause sagging, instability,
product collapse, and/or serious injury.
WARNING: Please ensure that all the objects are removed
before moving the assembled unit. The unit must be lifted
by more than one person, not dragged or pushed. Failure
to do so will cause product damage, instability, product
collapse, and/or serious injury.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
suggest the height of cabinet
above the ground is 60 inch to
70 inch height , if you are not
satisfied with the size of the
height , can be adjusted
according to the individual's
thoughts , finally in the same
way to the wall of the
cabinets.
H 60 in ~70 in
NOTE: Fasten cabinets to the dry wall using the appropriate 3"
screws and wall anchors (not supplied) through the hanging back
rails and into wood studs. First drill a pilot hole in the cabinet
hanging rails in line with location of the all wood studs.
0 lbs
15 lbs
30 lbs
A
C
C
C
i

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m.-6 p.m., EST, Monday-Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
