THANK YOU
USE AND CARE GUIDE
ROCK CLIFF 3-PC SEATING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item #1005 609 609
Model #FRS60605IS-ST-2
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this seating set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

2
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: THIS SET WAS MADE FOR THE EXPLICIT PURPOSE OF PROVIDING OUTDOOR SEATING AND IS NOT TO BE USED AS A TOY.
THIS PRODUCT IS INTENDED FOR NORMAL OUTDOOR USE. HOWEVER, THE MANUFACTURER RECOMMENDS STORING AND/OR COVERING THIS
PRODUCT WHEN ANY FORMIDABLE/SEVERE WEATHER IS APPROACHING.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this furnishing is used by
or near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the set while it is occupied. Failure
to obey this caution could result in injury.
WARNING: DO NOT LOCATE THIS PRODUCT NEAR OPEN FLAMES. DO NOT USE THIS PRODUCT AS A SUPPORT. DO NOT SHAKE, LEAN OR CLIMB
ON THE PRODUCT. CHILDREN UNDER THE AGE OF 10, NEAR THE PRODUCT, SHOULD BE SUPERVISED BY A COMPETENT ADULT AT ALL TIMES.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE, AND COMMERCIAL USE WILL VOID THE WARRANTY.
WARNING: This set is heavy and may require two adults
for safe assembly.
WARNING: Never use this product as a support. Do not
shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the set.
WARNING: Weight limit for each chair is 250 lbs
(113.39 kg) for each seat.
WARNING: Please keep children out of the assembly
area before assembly.
CAUTION: When not in use, secure the product in a
cool and covered location.
CAUTION: Do not locate the product near any heat
sources.
Table of Contents
Pre-Assembly....................................... 3
Planning Assembly ................................. 3
Hardware Included ................................. 4
Package Contents . .................................4
Assembly. . . . . . .....................................5
Table of Contents....................................2
Important Safety Instructions ..........................2
What is covered ................................... 3
What is not covered ................................3
Warranty .......................................... 3
Save These Instructions..............................2
Read All Instructions before Use .......................2
Care and Cleaning ...................................8

3 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Warranty
Pre-assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to assemble this product.
3 YEAR FRAME AND 3 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
warranty for the fabric.
WHAT IS NOT COVERED
Its remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HAMPTONBAY.com.
We warrant the frames to be free of manufacturing defects to the original purchaser for three years, and offer a three year limited

4
Pre-assembly (continued)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
PACKAGE CONTENTS
AA BB
M6x20 Combination Bolt
M6x40 Combination Bolt
16+1
4+1
AA
BB
M6x30 CountersunkBolt 8+1
CC
Plastic Washer 8+1
DD
Hex Wrench 1
EE
Part Description Quantity
CC DD EE
Backrest
Seat
Right Arm
2
2
2
A
B
C
Left Arm 2 D
Back Cushion 2 E
Seat Cushion 2 F
Glider Base 2 G
Swivel Base 2 H
Part Description Quantity
D
A
B
G
H
C
F
E

5 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly
1Attaching the Seat to the Backrest
2Attaching the Backrest and the Seat to the Right Arm
Place the backrest (A) on a soft surface.
Attach the seat (B) to the backrest (A) using
M6x40 combination bolts (BB).
Do not tighten any of the bolts at this step.
Attach the backrest (A) and the seat (B) to the
right arm (C) using M6x20 combination bolts (AA).
Do not tighten any of the bolts at this step.
BB
B
A
A
B
AA AA
C

6
Assembly (continued)
3Attaching the Backrest and the Seat to the Left Arm
4Attaching the Backrest to the Left Arm and the Right Arm
Attach the backrest (A) and the seat (B) to the
left arm (D) using M6x20 combination bolts (AA).
Do not tighten any of the bolts at this step.
Attach the backrest (A) to the left arm (D) and the
right arm (C) using M6x20 combination bolts (AA).
Once all of the bolts are in place, fully tighten all the
bolts using the hex wrench (EE).
A
D
B
AA AA
AA
A
D
C

7
Assembly (continued)
5Attaching the Glider Base to the Two Arms
6Attaching the Swivel Base to the Glider Base
Place the chair upside down.
Place the glider base (G) through the plastic washers (DD) and attach it to the two arms (C and D).
Fully tighten using M6x30 countersunk bolts (CC), as shown below.
Attach the swivel base (H) to the glider base (G).
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
CC
G
D
C
DD
H

Assembly (continued)
7Checking the Chair
Turn the chair right side up.
Ensure all connections are secure before use.
8
Care Care and Cleaning
E
F
For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach or solvents.
Store the set in a dry, sheltered place when not in use.
Keep the set away from fire, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Place the seat cushion (F) and the back cushion (E) to finish the chair assembly.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
For certification use only
Factory Chair ID #FRS60605IRS
Factory Table ID #FWS60640
