HAMPTON BAY WHITFIELD 3022-CM4-SW User manual

THANK YOU
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item #1004 415 336
Model # 3022-CM4-SW
WHITFIELD 2PC ALL MOTION CHAIRS

2
Table of Contents
Table of Contents ................................... 2
Important safety instructions ......................... 2
Read All Instructions Before Use ......................2
Save These Instructions ............................
2
What is Covered...................................
3
What is Not Covered ...............................
3
Warranty .......................................... 3
Planning Assembly.................................
3
Tools and hardware required ........................
3
Hardware included.................................
3
Pre-assembly ..................................... 3
Pre-assembly ..................................... 4
Assembly ......................................... 5
Car and Cleaning ................................... 7
READ ALL INSTRUCTIONS BEFORE USE
CAUTION: Do not locate the product near any
heat source.
CAUTION: When not in use, secure the product in a
cool and covered location.
WARNING: This swivel chair unit is heavy, and may
require two adults for safe assembly.
WARNING: Do not place heavy objects on the chair.
WARNING: Weight limit for the chairs is 250 lbs
(113.39 kg) for each seat.
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: This chair was made for the explicit purpose of providing outdoor functions and is not to be used as a toy.
This product is intended for normal outdoor use; however, the manufacturer recommends storing and / or covering this chair
when any formidable / severe weather is approaching.
WARNING: Do not locate this product near open ames. Do not use this product as a support. Do not shake, lean or climb on the
product. Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is
NOT intended for commercial use. Commercial use will void the warranty.
s

3 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-assembly
PLANNING ASSEMBLY
TOOLS AND HARDWARE REQUIRED
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA Long bolt 4
BB Rectangle gasket 4
CC Round gasket 8
DD Nut 8
EE
FF
Bolt cover
Wrench
8
1
AA BB CC
DD EE FF
2 YEAR FRAME WARRANTY
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, re, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit HAMPTONBAY.COM.
NOTE: Read all instructions before assembly. To avoid damaging
this product, assemble it on a soft, non-abrasive surface such as
carpet or cardboard.
Warranty

4
Pre-assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A Chair frame 2
B Base 2
C Seat cushion 2
D Back cushion 2
A B
C D

5 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly
1
□Place the chair frame (A) on a at, solid surface.
□
□
□
Set the swivel base (B) on the chair frame (A). Guide two long bolts (AA) through the holes in the U bar,
and through the holes in the rocker plate. Place the rectangle gasket (BB) add a round gasket (CC) and a nut (DD)
to the bottom of each long bolt (AA). Hand tighten the nuts (DD) 3-4 revolutions only.
Connecting the support bar to the chair bucket
Repeat the same procedure on the other side of the rocker assembly.
Fully tighten all bolts including screws preassembled by factory. Cover all bolts with bolt covers (EE).
B
EE
DD
CC
BB
AA
Rocker plate
U bar
A

B
A
2 Tightening all bolts and connecting the support bar to the swivel
base
□
□Insert the chair frame (A) into the swivel base (B).
Once all bolts are in place, fully tighten all bolts, including screws preassembled by the factory.
C
D
□Ensure the chair is tightly assembled and stable before use.
□Add seat cushion (C) and back cushion (D).
3 Attaching the cushion and checking the chair
6
Assembly (continued)
NOTE: Repeat steps 1-3 for the second chair.

7 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Care and Cleaning
□ For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
□ Do not clean with abrasive materials, bleach, or solvents.
□ Store the chair in a dry, sheltered place when not in use.
□ Keep the chair away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
WARNING: FUELS USED IN WOOD OR CHARCOAL BURNING
APPLIANCES, AND THE PRODUCTS OF COMBUSTION OF SUCH FUELS,
CAN EXPOSE YOU TO CHEMICALS INCLUDING CARBON BLACK, WHICH
IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, AND
CARBON MONOXIDE, WHICH IS KNOWN TO THE STATE OF
CALIFORNIA TO CAUSE BIRTH DEFECTS OR OTHER REPRODUCTIVE
HARM. For more information go to: www.P65Warnings.ca.gov.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
