Hamwells Loopz User manual

v1.0
Quick Start Guide

Enjoy your Loopz!
*
* UV-C LED is only included with the Loopz Plus
Please read the quickstart guide before using the Loopz. We would
like to point out the safety instructions which are included in the
box. Allmanuals are available at www.hamwells.com.
Save water, have a better shower

How to start?
1. POSITION THE MODULE
Position the Loopz in such a way that there is a slope
towards the drain to allow the water to ow towards it.
2. THE CONTROL UNIT
Place the control unit and guide the power
supply cable out the module through its cable
duct.
3. PLACE THE FILTER
Please note, the raised edge of the lter should point
upwards and make contact with the front end (the side
with the drain) of the module.
1 °

5. PLACE THE DECK
Make sure the deck falls into the recess. Please note,
theLoopz’s maximum load is 100 kg / 220 lbs.
6. CONNECT THE ADAPTER
Connect the Loopz’s 12V power supply cable to the
power adapter cable. Connect the power adapter to a
power source. Please note, the power adapter should
be placed in a dry environment.
4. CONNECT THE SHOWER HEAD
Screw the hose coupler onto the thread on to the
control panel.

LED signal
The LED on the control panel has three distinct patterns
giving feedback on the usage of the Loopz. These are: blinking,
continuously on and fading in and out.
7. PLACE THE PLUG
Place the plug in the reservoir.
Remove theplug after use to drain
the reservoir.
8. CHECK THE WATER LEVEL
Fill the reservoir at least to the indicated level. Please
check the LED on the control panel, it should be
continuously on.
ready for use in usefill the reservoir
Filling the reservoir
Please note, do not leave
harmful substances in the
environment.
!

Hamwells Nederland B.V.
Pelgrimsstraat 3, 3029 BH Rotterdam,
The Netherlands
hamwells.com/loopz
Questions? Mail us at [e-mail]
9. USING THE LOOPZ
Once the LED is continuously on, the Loopz is
ready for use.
Press the push button to start the shower,
push it again to stop.
10. MAINTENANCE
Please note to rinse the microlter after each shower using an external
water source.
We advise to frequently clean the shower by adding a mild detergent to
the water reservoir. Let the shower run for a few minutes and empty the
reservoir afterwards. Furthermore, remove the lid of the shower head once
in a while to get rid of any obstructions in the nozzles.
Please note, the recycled water is not
drinking water.
Please, limit the amount of soap used.
Showering
!
!
