Handy Dryers Dillo User manual

Dillo Hand Dryer
*Please read instructions carefully before
installation and retain instructions for
future reference.
*The Dillo Hand Dryeris manufactured from
sturdy aluminium witha sleek design to
complement any environment. W:www.handy-dryers.co.uk
T: 01279466500
Handy Dryers
12 Church Street
Bishops Stortford
Hertfordshire
Cm23 2LY
handydryers

Feature
Specification
Power supply
Sensing distance
Warm air temp.
Motor speed
Heating power
Overall unit power
Overall dimension
Finish
220V~50Hz
12+3cm
25000r.p.m
700W
1250W
210mmX182mmX270mm(LxWxH)
chrome paint
40 +10
Air speed 30m/s
Motor power 550W
1
Control:
The Dillo will automatically switch off after 50 seconds
The Dillo has a recommended drying time of between 8 -12 seconds
Speedy drying:
Choose between hotand cold airat the flick of aswitch
Heat Switch:
Ion generator:
Perfume holder:
The ion generatorprovides fresh andclean air during use
When included
Break down
Air outlet
Inner hexagon
screw
Sensor
Cover for air
tunnel
Cover of bottom
motor
Motor
Cover of upper
motor
Filter pad
Filter cover
Ion generator
Control box
Seat
5
6
7
8
9
10
Heating wire
2
Lens
Shell
Heat switch
Heat device
**

13cm
125-135cm
1
2
4
~
Motor
Heat switch
Ion
generator
Heater BKR
sensor board
Power board
flat cable
Wire drawing
3
Please note:
There must be a minimum of 1.1 meters allowance from the floor to the
base of the hand dryer.
Installation instructions
1.Use template to mark the required position on the wall. Do not mount
the Dillo over a shiny surface as it will activate the sensor.
2.Do not place anything in the area where the sensor is located.
3.Drill 4 holesas per thetemplate. Place theraw plugs inthe holes.
4.Loosen the screws from the Dillo and remove the cover.
5.Position the unitupon the templateand secure with the 4 screws.
6.Replace the cover and secure.
Usage instruction
Place hands underdyer. The unit willstart automatically andshut off after
50 seconds. This can bere-activated immediately if required.

Sensor board
Lens
Heat switch
5
Troubleshooting
1)This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they do
not play with the appliance.
2)If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a
hazard.
Notice:
6
Adjustment of sensor distance
Remove the coverand adjust thesmall
dial on thesensor board toprovide you
with the desiredsensitivity.
Turn clockwise to increase thedistance
and counter clockwiseto reduce the
distance.
Temperature control
The heat switchis located underneath
the unit. Turn on for heated air and off
for cool air.
Stopped working -Check power -Check sensor devise -Check sensing
distance
Only cold air-Check the temperatureswitch
