GENERAL SAFETY INFORMATION
1. PRESSURIZED DEVICES:
This equipment is a pressure containing
device.
• Do not exceed maximum operating
pressure as shown on equipment
serial number tag.
• Make sure equipment is depressurized before working
on or disassembling it for service.
2. ELECTRICAL:
This equipment requires electricity to
operate.
• Install equipment in compliance with all
applicable electrical codes.
• Standard equipment is supplied with electrical
enclosures not intended for installation in hazardous
environments.
• Disconnect power supply to equipment when
performing any electrical service work.
3. BREATHING AIR:
• Air treated by this equipment may not
be suitable for breathing without further
purification.
Refer to applicable standards and specifications for the
requirements for breathing quality air.
RECEIVING, MOVING, AND UNPACKING
A. RECEIVING
This shipment has been thoroughly checked, packed and
inspected before leaving our plant. It was received in
good condition by the carrier and was so acknowledged.
Check for Visible Loss or Damage. If this shipment
shows evidence of loss or damage at time of delivery to
you, insist that a notation of this loss or damage be made
on the delivery receipt by the carrier’s agent.
B. UNPACKING
Check for Concealed Loss or Damage. When a
shipment has been delivered to you in apparent good
order, but concealed damage is found upon unpacking,
notify the carrier immediately and insist on his agent
inspecting the shipment. Concealed damage claims are
not our responsibility as our terms are F.O.B. point of
shipment.
C. MOVING
In moving or transporting dryer, do not tip dryer onto its
side.
D. STORAGE/SHUT DOWN
Dryer should not be stored outside (either
packed or unpacked) or exposed to the weather. Damage to
electrical and control components may result.
IMPORTANT: WATER-COOLED UNITS - If unit is shut down
below freezing temperatures, the water-cooled condenser
may freeze and cause permanent damage. Condenser must
be drained when the unit is shut down.
IMPORTANT: Do not store dryer in temperatures above
130°F, 54.4°C.

3
IMPORTANT: READ PRIOR TO STARTING THIS EQUIPMENT
1.0 INSTALLATION
1.1 Location
A. For typical placement in a compressed air system, see
drawing.
B. Air compressor intake – Locate air compressor so that
contaminants potentially harmful to the dryer (e.g.
ammonia) are not drawn into the air system.
C. Clearances Free air flow
Front 36 inches (914 mm)
Back 6 inches (152 mm)
Sides 36 inches (914 mm)
Service - To facilitate maintenance leave 36 inches
(914 mm) of clearance in front of dryer.
D. Standard units are designed to operate in ambients:
Air-cooled: 45 to 110°F (7 to 43°C).
Water-cooled: 45 to 130°F (7 to 54°C).
E. Installations in altitudes above 4500 feet (1370 meters) –
Dryer is adjusted to operate in altitudes up to 4500 feet
(1370 meters). If dryer is installed in an altitude above
this, and has not been preset at the factory for this
altitude, contact manufacturer’s Service Department.
F. The installation of a flexible connection prior to the dryer is
recommended to prevent possible damage from vibration.
NOTE: Outdoor installation – Standard units are designed for
indoor installation. Contact manufacturer if installing outdoors.
Aftercooler
Separator
Dryer
Oil Removal
Filter
Compressor
Moisture Separator
Coalescing Filter
(Option)
Float Drain
(Standard)
Condenser
Drain Outlet
Electrical Entry
(230 VAC)
Air Outlet
Air Inlet
Control Panel
Models 100, 125, & 150
Electric Demand Drain (EDD)
3-Way Valve
Moisture Separator
Coalescing Filter
(Option)
Control Panel
RS232 Entry
Electrical Entry
Air Outlet
Air Inlet
Condenser
Drain Outlet
Models 200, 250, 300, 400, 500, 600, & 750

4
1.2 Mounting
Mount the dryer on a level solid surface. Holes are provided in
the dryer base to permanently mount the dryer to the floor.
1.3 Piping connections
A. Air Inlet - Connect compressed air line from air source to
air inlet. (Reference markings on dryer or see callout
drawing on page 14 for air inlet/outlet connection loca-
tions.)
Refer to Serial Number Tag for maximum
working pressure. Do not exceed dryer’s Maximum Working
Pressure.
NOTE: Install dryer in air system at highest pressure possible
(e.g. before pressure reducing valves).
NOTE: Install dryer at coolest compressed air temperature
possible. Maximum inlet compressed air temperature: 120°F
(49°C). If inlet air exceeds this temperature, precool the air
with an aftercooler.
B. Air Outlet – Connect air outlet to downstream air lines.
C. Bypass piping – If servicing the dryer without interrupting
the air supply is desired, piping should include inlet and
outlet valves and an air bypass valve.
D. Water cooled models – cooling water inlet and outlet
1. Connect cooling water supply to cooling water inlet.
2. Connect cooling water return line to cooling water
outlet connection.
NOTE: Strainer and water regulating valve are supplied on
water cooled models.
1.4 Electrical connections
IMPORTANT: Use copper supply wires only.
A. Dryer is designed to operate on the
voltage, phase, and frequency listed on the
serial number tag.
B. If dryer is supplied with a cord and plug,
install in a receptacle of proper voltage.
C. Electrical entry on larger dryers is through a hole in the
cabinet. It is located on the right side panel when facing
the front of the unit. Connect power source to terminal
strip in electrical enclosure as shown on the wiring
diagram included with the dryer.
NOTE: Refrigeration condensing unit is designed to run
continuously and should NOT be wired to cycle on/off with the
air compressor.
1.5 Moisture separator
A. Models 100-150:
Separator (and Oil Removal Filter where
applicable) has an internal drain which
automatically discharges condensate.
Models 200-750:
Separator (and Oil Removal Filter where applicable) has
an electronic demand drain (EDD) which automatically
discharges condensate.
NOTE: It may be desirable to pipe the condensate from
the Automatic Drain outlet to a suitable drain.
B. Models 100-150:
Separator has a knurled fitting with flexible drain tubing
attached. Be sure knurled fitting is tightened by turning
counter-clockwise before operating dryer.
TO CLOSE
TURN COUNTERCLOCKWISE
C. Models 200-750
For manual draining, convenient dryer depressurization,
and EDD service, a three-way valve assembly has been
installed at the bottom of the moisture separator (and cold
coalescing filter where applicable). Review the following
for proper drain function:
• Automatic Draining - Valve handle should be positioned
parallel to the valve body (as shown), with the arrow on
the handle pointing toward the EDD. In this position,
condensate will flow from the bowl to the EDD.
• Drain Isolation (Shutdown) - Valve handle shall be
turned perpendicular to the valve body (rotate 90°). In
this position, condensate flow is shutoff.
• Manual Draining - Drain valve handle shall be rotated
slightly past the drain isolation position to allow throt-
tling through the valve for manual discharge and
depressuruzation.
• Note: The quick disconnect fitting allows removal of the
entire drain assembly. However, the unit must be
depressurized prior to disassembly or serious injury
may occur.
NOTE:Discharge is at system pressure. Drain line should be
anchored.
NOTE:Condensate may contain oil. Comply with applicable
laws concerning proper disposal.
1.6 Operation
A. Verify that isolation valves are open. If the drain fails to
discharge after the valve is energized, the electronic control
circuit will repeatedly energize the valve in an attempt to
clear the discharge port. If, after 60 seconds, the drain still
fails to discharge, the control circuit then switches to the
alarm mode. In this mode the valve is de-energized and
the red alarm light is activated on the drain and the dryer
controller. The valve is then automatically energized every
4 minutes for 5 seconds. Check the drain operation. Push
drain (push-to-test) button on the Energy Management
Monitor control board to energize drain. A flow of conden-
sate and/or air should be present at the drain outlet. The
alarm mode automatically clears after the drain returns to
normal operation.

5
B. Condensate enters the reservoir (1) through the inlet port.
When the condensate level in the reservoir covers the
capacitance sensor, an electronic signal is sent to the solid
state countdown processor. The processor delays the
opening of the solenoid valve for a given period of time.
Once the time has elapsed, the solid state processor
transmits information to energize the coil in the solenoid
valve (2). The magnetic force of the coil causes the
solenoid core (3) to move, closing the pilot air supply line
and opening the pilot air exhaust line. After the pilot air
above the diaphragm (4) is vented, pressure in the reser-
voir opens the discharge port and forces the condensate
through the discharge port and outlet piping.
C. Program Monitor
Press and hold Program Mode button until Main Menu screen
appears. Use the Up and Down arrow buttons to scroll
through the list of submenu choices. Press Enter button to
view the submenu that is displayed. Press ESC to exit the
Main Menu and return to Display mode.
1. Language selection
a. Use the ‘Up’ and ‘Down’ arrow buttons to scroll through
the list of languages (choice of 10 available: English,
Deutsch, Francais, Espanol, Italiano, Polski, Dansk,
Dutch, Norsk and Suomi).
b. Press ‘Enter’ button to select the language that is
displayed.
c. Push ‘ESC’ at any time to return to the Main Menu.
2. Setting Date & Time
a. Use the ‘Up’ and ‘Down’ arrow buttons to set minutes
(00 to 59). Press ‘Enter’ to accept new value.
b. Use the ‘Up’ and ‘Down’ arrow buttons to set hours (00
to 23). Press ‘Enter’ to accept new value.
c. Use the ‘Up’ and ‘Down’ arrow buttons to set year (00
to 99 representing 2000 to 2099). Press ‘Enter’ to
accept new value.
d. Use the ‘Up’ and ‘Down’ arrow buttons to set month
(three letter abbreviation). Press ‘Enter’ to accept new
value.
e. Use the ‘Up’ and ‘Down’ arrow buttons to set day (01 to
maximum for the month and year selected). Press
‘Enter’ to accept new value.
f. Push ‘ESC’ at any time to return to the Main Menu.
3. Setting Schedule
a. Use the ‘Up’ and ‘Down’ arrow buttons to select desired
“Dayof week + on/off”. Press‘Enter’toaccept newvalue
b. Use the ‘Up’ and ‘Down’ arrow buttons to set hour (00 to
23). Press ‘Enter’ to accept new value
Note: Ifthehour setting is‘IGNORE’,Press ‘Enter’again
to move the cursor under the “Day of week + on/off”.
Repeat steps a through b (or c) as needed.
c. Use the Up and Down arrow buttons to set minutes (00,
10,20, 30, 40,50;not shown ifhour setting is ‘IGNORE’).
Press ‘Enter’ to accept new value and return to “Day of
week + on/off”. Repeat steps a through c as needed.
d. Push ‘ESC’ at any time to return to the Main Menu.
NOTE: Scheduler will ignore programmed commands
for 10 minutes after exiting program mode.
4. Hours To Service
a. Use the ‘Up’ and ‘Down’ arrow buttons to scroll through
therange ofpermissiblevalues (0to8760) beforeservice
reminder is initiated. Press ‘Enter’ to accept new value.
(Only hours that refrigeration compressor is operating
are counted).
b. Press ‘ESC’ at any time to return to the Main Menu.
NOTE: On dryers with air-cooled condensers, regular
condenser cleaning is recommended. Dirtiness of
ambient air at installation site will determine frequency
of service. Typically once a month is recommended.
Dryers contain an integral 3 micron filter. As the filter
element accumulates solid contaminants, differential
1
2
3
4
2.0 OPERATION
2.1 Minimum/Maximum operating conditions
A. Maximum inlet air pressure: refer to dryer serial number
tag
B. Minimum inlet air pressure: 30 psig (2.1 kgf/cm2)
C. Maximum inlet air temperature: 120°F (49°C)
D. Maximum ambient temperature:
Air-cooled models: 110°F (43°C)
Water-cooled models: 130°F (54°C)
E. Minimum ambient temperature: 45°F (7°C)
2.2 Start-up
A. Models 100-150:
Energize compressor by positioning the on/off switch in
the on (I) position. Compressor on light will illuminate.
On/Off Switch Power-On Light Dewpoint Indicator (Green)
B. Models 200-750:
Energize dryer. Green power on light will illuminate.
IMPORTANT: Energize dryer disconnect switch (provided
by others, see NEC) 24 hours before refrigeration com-
pressor is started! Never use the disconnect switch to
shutdown the dryer for a extended period of time (except
for repair). Failure to follow these instructions may result
in a non-warrantable compressor failure.
NOTE: If there is no power to the control board for a
period of two weeks or more, it may return to the default
mode.

6
1. Temperature Indicator
2. Operator Interface Display
3. Power-on Light
4. Compressor-on Light
5. Alarm / Service Light
6. Schedule On/Off and Enter Button
a. In display mode: Press to toggle between
SCHEDULE RUNNING and MANUAL OVER-
RIDE.
b. In program mode:
i. Press to move to a lower level menu.
ii. Press to accept a value that has been edited.
7. Program Mode (i) and Esc
a. In display mode: Press and hold to enter
program mode.
b. In program mode: Press to move to a higher
level menu.
8. Up Arrow
a. In display mode: No function
b. In program mode:
i. Press to view the next item in a list or to
increment a variable to a higher value. Press
and hold for accelerated incrementing.
ii. When the top of the list (or highest value) is
displayed, pressing the up button will cause
the display to wrap to the bottom of the list (or
lowest value).
9. Down Arrow
a. In display mode: No function
b. In program mode:
i. Press to view the previous item in a list or to
increment a variable to a lower value. Press
and hold for accelerated incrementing.
ii. When the bottom of the list (or lowest value) is
displayed, pressing the down button will cause
the display to wrap to the top of the list (or
highest value).
10. 1/0: Press at any time to turn the dryer on/off.
11. Drain test: Press at any time to momentarily the
open drains (like the current emm).
12. Reset: Press at any time to clear the alarm/service
message (if shown) and the alarm LED.
CONTROL PANEL
12345
678910 11 12
pressure increases. Solid particulate load in the
compressed air supply will determine frequency of
service. Typically element changeout is recommended
at least annually.
5. Push ESC button to exit program mode
NOTE: If after 60 seconds no button is pressed while in
Program Mode, the audible alarm sounds for five (5)
seconds. Dryer will resume previous operating mode.
6. Manual Operation
a. To manually turn the refrigeration system on or off use
‘On/Off’button;Push‘Schedule On/Offand Enter’button
to return to schedule.
NOTE: After power interruption dryer will reenergize in
Manual override, refrigeration system off. To restart
Schedule: Push ‘Schedule On/Off and Enter’ button.
C. Starting dryer
IMPORTANT: Dryer must be energized 24 hours before starting
refrigeration compressor.
NOTE:It is recommendedthat dryerbestarted15minutes before
compressed air flow begins.
1. On water-cooled models: after 24 hours, begin cooling wa-
ter flow.
2. Check for proper electrical voltage.
3. Slowly pressurizeunit airside byopening inletisolation valve.
Check for leaks.
4. After 15 minutes, open outlet isolation valve slowly.
5. Close air bypass valve.
6. Dryer may be operated in Manual or scheduled modes.
NOTE: Check for correct phasing of unit. On air-cooled models:
check fan rotation (air must be pulled through the condenser).
Fansmay notstart immediatelyor maycycle onandoff. Ifrotation
is in the wrong direction follow the procedure below. On water-
cooled models: After starting dryer if an unusual noise is heard
and the discharge line does not get hot, stop the dryer, reverse
two power leads, restart, and verify discharge line gets hot.
Manual mode - push On/Off button - refrigeration compres-
sor will start and run, green Compressor-on light will illumi-
nate. In this mode compressor will run continuously and
willnot be turnedonand offby the monitor. MANUALOVER-
RIDE will appear on interface panel.
Schedule mode - push Schedule On/Off and Enter button.
SCHEDULE RUNNING will appear on the interface panel.
The refrigeration compressor will continue to be on or off
(as selected in the Manual Override Mode) until the next
scheduled event. The compressor will then turn on or off as
programmed.
NOTE: Schedule may be returned to the manual mode at any
time using the ‘Schedule On/Off and Enter’ button. MANUAL
OVERRIDE will appear on interface panel. To reinstitute
Schedule, push the ‘Schedule On/Off and Enter’ button again.
NOTE: Restart after the power interruption. Unit will be in
MANUAL OVERRIDE mode, refrigeration compressor, off when
power is restored after power interruption.
7. To reinstitute SCHEDULE RUNNING, push ‘Schedule On/
Off and Enter’ button.
IMPORTANT: Dryer must be energized 24 hours before
refrigeration compressor is started

7
D. Operating check points
1. Check that green Power-on light is illuminated
2. Check that green Compressor-on light is illuminated if dryer
is on in the manual mode or it is a scheduled on time
IMPORTANT: Refrigeration compressor must be restarted after
power interruption.
3. Check interface panel
NOTE: Interface panel will scroll through three screens (Current
Time/Operating Status, Hours to Service and Total Operating
Hours).
a. Verify that current time is correct
b. CheckHRSTOSERVICE: thisindicatestime remaining
until service is required; allow time for required
maintenance items to be ordered
c. Check operating status:
MANUAL OVERRIDE - Dryer is either running
continuously (not being controlled by the scheduled on/
offtimes) ortherefrigeration compressor has beenshut
off using the ‘On/Off’ button.
SCHEDULE RUNNING - Refrigeration compressor
is being turned on and off by the monitor per-
programmed schedule (see B.3. to set schedule).
d. Check Temperature indicator - indicator should read in
the green area.
e. CheckAlarm/ServicelightIfilluminated, check Interface
panel.
1) If SERVICE DRYER appears, scheduled
maintenancetime has elapsed(HRSTOSERVICE
is 0). Perform needed service and reset service
interval (see B.3.).
2) If ALARM appears, a dryer fault is indicated; see
TroubleshootingGuide forpossible remedies. After
fault correction push Reset button to turn Fault
alarm off.
Type of FAULTS:
LOW PRESSURE - the refrigeration compressor
control circuit has opened because of low suction
pressure.
HIGH PRESSURE - the refrigeration compressor
control circuit has opened because of high head
pressure. The high pressure switch must be reset
manually once the fault is corrected. Red reset
button is located on pressure switch inside unit.
HIGH TEMPERATURE - compressed air
temperature is above the set point.
COMPRESSOR - Normally open (NO) auxiliary
contact on the compressor contactor is open when
the dryer is on.
HEATER - Normally closed (NC) auxiliary contact
onthe compressorcontactoris openwhen thedryer
is off.
TEMPSENSOR - Occursif the temperaturesensor
circuit is open or shorted. If open, the left-most
LED in the temperature display will be illuminated.
If shorted, all the LEDs in the temperature display
will be illuminated.
DRAIN - electric drain contains a high water level
alarm that activates if drain fails to discharge.
f. Checkdrain operation -push Drain (push-to-test)button
to energize electric drain. A flow of condensate and/or
air should be present at the drain outlet.
E. Using the RS-232 port
The RS-232 port is used to monitor dryer operation from a
host computer. A (1 to 1) DB-9 cable is required to
connect dryer and computer. For PC connections, data is
transmitted on pin 2, received on pin 3, ground is pin 5,
pins 7 and 8 are jumpered at dryer.
Operation is at fixed baud rate of 9,600; asynchronous
format is 8 bit, no parity, 1 stop bit (“8,N,1”). No check
sum or error correction values are provided. If required,
request status string two (or more) times and compare for
agreement.
Request data by sending ASCII ? character (3FH).
Response may take up to two seconds as certain pro-
cessing functions may require completion before serial
port is acknowledged.
Dryer responds with line feed (0AH), carriage return
(0DH), and character string:
(1), (2), (3), (4), (5), (6), (7), (8), (9)
(1) = STX (start-of-text character, may appear as a
smiley face or some other character
(2) = 108, Control board ID
(3) = 0 or 1, Compressor running status (0=off, 1=on)
(4) = M or S, Operating Mode (M= MANUAL OVERRIDE,
S = SCHEDULE RUNNING)
(5) = xxxx, HOURS TO SERVICE
(6) = xxxxxx, TOTAL HOURS
(7) = xx, Alarm or Service Code (0=no alarm, 30=LOW
PRESSURE ALARM, 31=HIGH PRESSURE ALARM,
32=COMPRESSORALARM, 36=HIGH EVAP TEMP
ALARM, 37=HEATER ALARM, 38=DRAIN ALARM,
39=SERVICE DRYER, 41=TEMP SENSORALARM)
(8) = xx.x, Evaporator temperature (°F)
(9) = ETX, (end-of-text character, may appear as a heart
or some other character)

8
SIZING
Determining dryer capacity at actual operating conditions
To determine the maximum inlet flow capacity of a dryer at
various operating conditions, multiply the rated capacity from
Table 1 by the multipliers shown in Table 2.
Example: How many scfm can an air-cooled model 400 handle
when compressed air to be dried is at 200 psig and 100°F;
ambient air temperature is 80°F?
Answer: 400 x 1.22 x 1.12 = 547 scfm.
3.0 MAINTENANCE
3.1 Condenser coil – Clean off accumulated dust and dirt
monthly.
3.2 Moisture separator – Replace filter element when
pressure drop across dryer is excessive or annually.
3.3 Check separator daily to be sure automatic drain is
discharging.
3.4 Blow down separator weekly by pushing test button
on control panel.
3.5 Rebuild drain mechanism annually.
To facilitate service, maintenance kits are available.
Models 100-150
Drain Line
PTC Swivel Elbow
Element
Wave Spring
Float Drain
Element O-Ring
Bowl O-Ring
Head
Models 200-750
Head
Element O-Ring
Bowl O-Ring
Element
Bowl
Drain Quick Disconnect
Bowl Support
*Models 500-750 Only.
INLET COMPRESSED AIR CONDITIONS
INLET INLET TEMPERATURES
PRESSURES 80°F 90°F 100°F 110°F 120°F
psig kgf/cm227°C 32°C 38°C 43°C 49°C
50 3.5 1.35 1.05 0.84 0.69 0.56
80 5.6 1.50 1.17 0.95 0.79 0.66
100 7.0 1.55 1.23 1.00 0.82 0.70
125 8.8 1.63 1.31 1.07 0.91 0.74
150 10.5 1.70 1.37 1.13 0.95 0.80
175 12.3 1.75 1.42 1.18 0.99 0.84
200 14.0 1.80 1.47 1.22 1.03 0.89
TABLE 2
Air capacity correction factors (Multipliers)
COOLINGMEDIUM*
AMBIENT
TEMPERATURE MULTIPLIER
°F °C
80 27 1.12
90 32 1.06
100 38 1.00
110 43 0.94
*Air-cooled models; water-cooled models use 1.15 multiplier if cooling water is
below 35°C, 95°F.
TABLE 1
Rated capacity (scfm) and pressure drop @ 100 psig inlet
pressure, 100°F inlet temperature, and 100°F ambient
temperature
MODEL 100 125 150 200 250
Ratedcapacity 60 Hz 100 125 150 200 250
ofair-cooled 50 Hz 84 105 125 170 210
models (scfm)
MODEL 300 400 500 600 750
Ratedcapacity 60 Hz 300 400 500 600 750
ofair-cooled 50 Hz 250 340 420 540 630
models (scfm)

9
ENGINEERING DATA (Models 100-250)
ataDmetsySriA
erutarepmeTtneibmAF°001,telnIgisp001,F°001tayticapaCwolFdetaR 001521051002052
)reyrdottelnitar
iadesserpmoc(erusserPriAtelnImuminiM/mumixaM )grab2(gisp03/)grab61(gisp232
)reyrdottelnitariadesserpmoc
(erutarepmeTriAtelnImuminiM/mumixaM )C°4(F°04/)C°94(F°021
erutarepmeTtneibmAmuminiM/mumixaM )C°4(F°04/)C
°34(F°011
)snoitidnocdetartalanimon(erutarepmeTriAteltuO )C°92(F°58
ataDmetsySnoitaregirfeR
)rh/UTB(tneibmAF°001&rotaropavEF°53@yticapaCnoitaregirfeRzH0602840306009800251
zH0502
040965024700721
epyTtnaregirfeR A431-R
egrahCtnaregirfeR reyrDnogaTataDeeS
)gisp(evlaVssapyBsaGtoH-gnitteSeru
sserPnoitcuS )grab1.2(gisp5.03
)ni-tuo(segnaRlortnoCrosserpmoChgiHA/N)grab1.31-4.91(gisp091-182
woLA/N)grab3.
2-5.1(gisp43-22
sresnednoCdelooC-riA
)sledomdelooc-ria()mfc(resnednoCssorcAwolFriAzH060030540170701
zH05052073095098
)tuo-ni(gnit
teShctiwSnaFresnednoC1naF)grab8.4-6.7(gisp07-011)grab4.5-8.7(gisp87-311
2naFA/N
sresnednoCdelooC-retaW
gnitteSevlaVgnitalugeRretaW )grab3.9(gisp531
laitnereffiDerusserPretaWelbaliavAde
riuqeR muminim-)grab8.2(gisp04
)etunimrepsnollag(retaWgnilooCF°58htiwderiuqeRwolFzH06A/N1.10.2
zH05A/N9.07.1
ataDlacirtcelE
egatloVlanimoN 06/1/51106/3/032-802
egatloV.xaM-.niM 721-401352-781
)sttaw(wolFdetaR@rewoPtup
nI 2390821892155212691
**spmAdaoLdetaR 2.012.515.74.01
**spmArotoRdekcoL 0.153.660.150.66
yticapmAtiucriCmuminiM 6.313.
815.019.51
)spma(eziSesuFtiucriChcnarB 02525102
)smho(ecnatsiseR R7.0/S3.4R4.0/S2.38.13.1
egatloVlanimoN 06/1/032-8
0206/3/064
egatloV.xaM-.niM 352-781605-414
)sttaw(wolFdetaR@rewoPtupnI 2390821892155212691
**spmAdaoLdetaR 4.50.96.
37.4
**spmArotoRdekcoL 0.035.330.520.33
yticapmAtiucriCmuminiM 3.75.012.55.7
)spma(eziSesuFtiucriChcnarB 51515151
trat
S/niaM)smho(ecnatsiseR R3.2/S0.9R6.1/S9.74.70.5
egatloVlanimoN 05/1/00106/3/575
egatloV.xaM-.niM 011-09336-815
)
sttaw(wolFdetaR@rewoPtupnI 086910119955212691
spmAdaoLdetaR 2.012.516.37.4
spmArotoRdekcoL 0.153.660.520.33
yticapmAt
iucriCmuminiM 6.313.812.40.6
)spma(eziSesuFtiucriChcnarB 02525151
)smho(ecnatsiseR R7.0/S3.4R4.0/S2.34.70.5
egatloVl
animoN 05/1/04205/3/024-083
egatloV.xaM-.niM 462-612264-243
)sttaw(wolFdetaR@rewoPtupnI 086910119920013161
**spmA
daoLdetaR 5.43.86.37.4
**spmArotoRdekcoL 0.120.350.520.33
yticapmAtiucriCmuminiM 2.69.92.55.7
)spma(eziSesuFtiucriCh
cnarB 51515151
)smho(ecnatsiseR R3.3/S5.91R8.1/S5.014.70.5
tneibmAF°77,rotaropavEF°53,zH05rof;tneibmAF°001,rota
ropavEF°53,zH06roF*
ylnOrosserpmoC**

10
ENGINEERING DATA (Models 300-750)
ataDmetsySriA
erutarepmeTtneibmAF°001,telnIgisp001,F°001tayticapaCwolFdetaR 003004005006057
)reyrdottelnitar
iadesserpmoc(erusserPriAtelnImuminiM/mumixaM )grab2(gisp03/)grab61(gisp232
)reyrdottelnitariadesserpmoc
(erutarepmeTriAtelnImuminiM/mumixaM )C°4(F°04/)C°94(F°021
erutarepmeTtneibmAmuminiM/mumixaM )C°4(F°04/)C
°34(F°011
)snoitidnocdetartalanimon(erutarepmeTriAteltuO )C°92(F°58
ataDmetsySnoitaregirfeR
)rh/UTB(tneibmAF°001&rotaropavEF°53@yticapaCnoitaregirfeR zH0600251002910002200503
z
H0500721000610038100452
epyTtnaregirfeR A431-R
egrahCtnaregirfeR reyrDnogaTataDeeS
)gisp(evlaVssapyBsaGtoH-gni
tteSerusserPnoitcuS )grab1.2(gisp5.03
)ni-tuo(segnaRlortnoCrosserpmoC hgiH)grab1.31-4.91(gisp091-182
woL)gr
ab3.2-5.1(gisp43-22
sresnednoCdelooC-riA
)sledomdelooc-ria()mfc(resnednoCssorcAwolFriA zH060701074208610712
zH05098060200410181
)tuo-
ni(gnitteShctiwSnaFresnednoC 1naF)grab4.5-8.7(gisp87-311
2naFA/N)grab6.8-6.21(gisp421-381
sresnednoCdelooC-retaW
gnitteSevlaVgnitalugeRretaW )grab3.9(gisp531
laitnereffiDerusserPretaWelbaliavAde
riuqeR muminim-)grab8.2(gisp04
)etunimrepsnollag(retaWgnilooCF°58htiwderiuqeRwolF zH060.21.29.48.6
zH057.18.11.46
.5
ataDlacirtcelE
egatloVlanimoN 06/3/032-802
egatloV.xaM-.niM 352-781
)sttaw(wolFdetaR@rewoPtupnI 99911302086201
920214
**spmAdaoLdetaR 4.014.119.311.22
**spmArotoRdekcoL 0.660.570.880.511
yticapmAtiucriCmuminiM 9.510.027.914.03
)s
pma(eziSesuFtiucriChcnarB 02520354
)smho(ecnatsiseR 3.11.10.17.0
egatloVlanimoN 06/3/064
egatloV.xaM-.niM 605-414
)
sttaw(wolFdetaR@rewoPtupnI 99911302086201920214
**spmAdaoLdetaR 7.41.51.76.9
**spmArotoRdekcoL 0.330.040.440.36
ytica
pmAtiucriCmuminiM 5.76.94.012.51
)spma(eziSesuFtiucriChcnarB 51515102
tratS/niaM)smho(ecnatsiseR 0.51.40.47.2
egatlo
VlanimoN 06/3/575
egatloV.xaM-.niM 336-815
)sttaw(wolFdetaR@rewoPtupnI 99911302086201920214
spmAdaoLdetaR 7.41.51.
76.9
spmArotoRdekcoL 0.330.040.440.36
yticapmAtiucriCmuminiM 0.67.73.82.21
)spma(eziSesuFtiucriChcnarB 51515102
)smho(
ecnatsiseR 0.51.40.47.2
egatloVlanimoN 05/3/024-083
egatloV.xaM-.niM 264-243
)sttaw(wolFdetaR@rewoPtupnI 2261766
1299104020682
**spmAdaoLdetaR 7.41.51.76.9
**spmArotoRdekcoL 0.330.040.440.36
yticapmAtiucriCmuminiM 5.71.84.012.51
)spm
a(eziSesuFtiucriChcnarB 51515102
)smho(ecnatsiseR 0.51.40.47.2
tneibmAF°77,rotaropavEF°53,zH05rof;tneibmAF°001,
rotaropavEF°53,zH06roF*
ylnOrosserpmoC**

11
WIRING DIAGRAM
Models 100, 125 & 150
Model 100 - 120/230 VAC
Models 125/150 - 120/230 VAC
COMPRESSOR HARNESS
PE
T2
T1
FAN 1 HARNESS
IO
PE
GROUND
STUD
L2
L1
L2
230 VAC
CUSTOMER SUPPLIED
L1 PE
PILOT LIGHT
POWER ON
T2
T2
T2
T1
T1
A
PE
T2
T1 T1
FPS 1
FAN 1
MTR2
START RELAY
SR
SR
L3
L3
M6
5
S
CAPACITOR
4
OVERLOAD
31 3
MTR1
COMPRESSOR
R
C
S
POWER CORD SUPPLIED
120 VAC
PILOT LIGHT
COMPRESSOR CONTACTOR
POWER ON
CONT 1
PE
-2NC
PE
L1
CONT 1
-1NC 6
L2
GROUND STUD
L2
L1
PE
230 VAC
CUSTOMER SUPPLIED
L1 L2
L2
L2
L3
L2
L1
L2
L1
L1
L1
T3
T2
T2
T2
T1
T1
T1
CONT 1
O
L1
N
4
I
55
A1
A
PE
6
FAN 1 HARNESS
HEATER HARNESS
PE
L2
T2
T1 FPS 1
H1 H2
HEATER 1
MTR2 FAN 1
COMPRESSOR HARNESS
PE
T2
T1
SR
L3
L3
SR M
S2
OVERLOAD
31
A2
4
C
3
1
R
COMPRESSOR
S
MTR1
120 VAC
POWER CORD SUPPLIED

12
WIRING DIAGRAM
Models 200-600 - 460 VAC
COMPRESSOR
Optional Fan
(for 500-600 models only)
TO LINE 22
21
20
18
19
17
16
15
14
13
L1 L3
L2 CONT 1
-1NC
PE
HEATER HARNESS
-2NC 1L2
L3
TB2
TB2
PE
T3
T2
H1 H2
HEATER 1
FAN 2 HARNESS
FPS 2
MTR3 FAN 2
REF SHEET 02 LINE 11
REF SHEET 02 LINE 10
REF SHEET 01 LINE 20
03
10
11
12
09
08
07
06
05
04
L3
L3
L3
L2
L2
L3
L2
T3
T2
02
01
00
PETB1 L1 L2 L3
L1
L1
460 VAC
3 PHASE 60 Hz
L1 L2 L3
L1
CONT 1
T1
PE
TB2
T1
T2
T3
T3
T2
T3
TB2
PE
T2
T3
T2
FAN 1 HARNESS
FPS 1
MTR2 FAN 1
MTR1
T1
T1
T1
COMPRESSOR HARNESS
TO SHEET 02
43
42
X
40
41
39
38
37
36
35
TO SHEET 02
N
XF
25
(4 Terminal Blocks)
TB2
32
33
34 X
31
30
X
29
28
27
26
X1
FU3
X3
X2
FU2
H6 H5
FU1
H4 H3 H2 H1
FROM LINE 21
L3
24
23 L1
22 L3
L1
L3
L1
(4 Terminal Blocks)
FACTORY SET TO 460V
N
460V
575V
400V
H6
H6
H6
TB2
N
H2
H1
H3
L2
230V
208V
H6
H6
L1
H4
H5
Drain Alarm #2 Input
13 21
W36
W28
W37
W34
W32
W30
FMD #1 In (RJ-11)
FMD #2 In (RJ-11)
J2 RS-232
RED
BLACK
WHITE
22
21
20
19
18
17
16
15
14
W38
Evaporator Thermistor
Evaporator Thermistor
Phase B xfmr Input
Phase A xfmr Input
Phase Com. xfmr Input
W4
N/A
N/A W7
W6
W5
N/A
W35
Gnd. (W28 thru W32)
Remote/Local Input
Remot Start/Stop Input
N/A
N/A
W33
W31
N/A
N/A
N/A
W29
W12
30
37
35
36
34
35
34
33
32
31
TCI
TB2
TB2
25
29
28
27
26
28
27
26
24
23
22
23
22
TB2
28
26
27
EMM INSTRUMENT BOARD
W20
W24
W26
W22
12
11
10
09
07
08
06
05
04
Gnd (W8 thru W14)
Drain Alarm #1 Input
Low Pressure Sw. Input
Heater #1 ON Input
High Pressure Sw. Input
Alarm A Com.
Compressor #1 ON Input
Alarm A N/C
Alarm A N/O
W15
W13
W14
W11
W10
W9
W8
W21
W19
Alarm B N/C
Alarm B Com.
Drain Test Output
Alarm B N/O
Drain Test Output
Compressor #1 Output
Compressor #1 Output
W27
W18
W17
W16
N/A
N/A W25
W23
FROM SHEET 01
01
03
02
00
Chassis Gnd.
TB2
X
24VAC IN
24VAC IN W3
W2
W1
X
TB2
3X
REMOVE JUMPER IF OPTIONAL DRAIN INSTALLED
-4NO
TB2
TB2
TB2
TB2
TB2
19
20
21
18
17
19
20
21
18
17
14
16
15
13
12
14
16
15
13
12
16 TB2
TB2
TB2
20
18
19
17
TB2
TB2
14
12
15 15
13
TB2
TB2
TB2
10
11
9
8
10
11
9
8
7
6
4
5
7
4
TB2
TB2
10
8
11
9
TB2
4
7
X
-3NO
CONT 1 19
16 -1NC
20
19
18
17
CONT 1 -2NC 19
4
8
7
BLU
TB2
CONNECTOR
PE
2
1
PE
2
1
PE
BRN
RED BRN
F1
LOAD
LINE
WHITE
PE
BLU
TERMINAL BLOCK LAYOUT
TB2
19
18
19
TB2
HPS/LPS SENSOR HARNESS
17
19
HPS
TB1
LPS
HPS
L1 L1
8 X X
4
N X X N N N
4 4 4
8 7 7
19
15
11
10
9
14
13 12 18 17
16 19 19 19
26
21
20 28 27 PE PE PE PE
L3 L2
PE
L3 L2
PE
4
6
3
1
1
3
6
4
TB2
19
TB2 PE
OPTIONAL DRAIN
DRAIN 2 HARNESS
X
N
20
19
7
8
5
3
2
8
7
19
20
N
X
5
3
2
DRAIN 1 HARNESS
4
24VAC
ALM
TEST
TEST
ALM
24VAC
CONTACTOR
COMPRESSOR
CONT 1
A1 A2 N
FROM SHEET 01
TB2 N
BLACK
WHITE
(Mounted in Enclosure)
DB9 MALE CONNECTOR
3
89
5
RED
4
67
21

13
COMPRESSOR
TO LINE 22
21
20
18
19
17
16
15
14
13
L1 L3
L2
CONT 1
-1NC
PE
HEATER HARNESS
-2NC 1L2
L3
TB2
TB2
PE
T3
T2
H1 H2
HEATER 1
FAN 2 HARNESS
FPS 2
MTR3 FAN 2
REF SHEET 02 LINE 11
REF SHEET 02 LINE 10
REF SHEET 01 LINE 20
03
10
11
12
09
08
07
06
05
04
L3
L3
L3
L2
L2
L3
L2
T3
T2
02
01
00
PE
L1
L1
L1
L2 L3
460 VAC
3 PHASE 60 Hz
TB1 L1 L3L2
L1
CONT 1
T1
DISCONNECT SWITCH
PE
TB2
T1
T2
T3
T3
T2
T3
TB2
PE
T2
T3
T2
FAN 1 HARNESS
FPS 1
MTR2 FAN 1
MTR1
T1
T1
T1
COMPRESSOR HARNESS
TO SHEET 02
43
42
X
40
41
39
38
37
36
35
TO SHEET 02
N
XF
25
(4 Terminal Blocks)
TB2
32
33
34 X
31
30
X
29
28
27
26
X1
FU3
X3
X2
FU2
H6 H5
FU1
H4 H3 H2 H1
FROM LINE 21
L3
24
23 L1
22 L3
L1
L3
L1
(4 Terminal Blocks)
FACTORY SET TO 460V
N
460V
575V
400V
H6
H6
H6
TB2
N
H2
H1
H3
L2
230V
208V
H6
H6
L1
H4
H5
Drain Alarm #2 Input
13
21
W36
W28
W37
W34
W32
W30
FMD #1 In (RJ-11)
FMD #2 In (RJ-11)
J2 RS-232
RED
BLACK
WHITE
22
21
20
19
18
17
16
15
14
W38
Evaporator Thermistor
Evaporator Thermistor
Phase B xfmr Input
Phase A xfmr Input
Phase Com. xfmr Input
W4
N/A
N/A W7
W6
W5
N/A
W35
Gnd.(W28 thru W32)
Remote/Local Input
Remot Start/Stop Input
N/A
N/A
W33
W31
N/A
N/A
N/A
W29
W12
30
37
35
36
34
35
34
33
32
31
TCI
TB2
TB2
25
29
28
27
26
28
27
26
24
23
22
23
22
TB2
28
26
27
EMM INSTRUMENT BOARD
W20
W24
W26
W22
12
11
10
09
07
08
06
05
04
Gnd (W8 thru W14)
Drain Alarm #1 Input
Low Pressure Sw. Input
Heater #1 ON Input
High Pressure Sw. Input
Alarm A Com.
Compressor #1 ON Input
Alarm A N/C
Alarm A N/O
W15
W13
W14
W11
W10
W9
W8
W21
W19
Alarm B N/C
Alarm B Com.
Drain Test Output
Alarm B N/O
Drain Test Output
Compressor #1 Output
Compressor #1 Output
W27
W18
W17
W16
N/A
N/A W25
W23
FROM SHEET 01
01
03
02
00
Chassis Gnd.
TB2
X
24VAC IN
24VAC IN W3
W2
W1
X
TB2
3X
REMOVE JUMPER IF OPTIONAL DRAIN INSTALLED
-4NO
TB2
TB2
TB2
TB2
TB2
19
20
21
18
17
19
20
21
18
17
14
16
15
13
12
14
16
15
13
12
16 TB2
TB2
TB2
20
18
19
17
TB2
TB2
14
12
15 15
13
TB2
TB2
TB2
10
11
9
8
10
11
9
8
7
6
4
5
7
4
TB2
TB2
10
8
11
9
TB2
4
7
X
-3NO
CONT 1 19
16 -1NC
20
19
18
17
CONT 1 -2NC 19
4
8
7
BLU
TB2
CONNECTOR
PE
2
1
PE
2
1
PE
BRN
RED BRN
F1
LOAD
LINE
WHITE
PE
BLU
TERMINAL BLOCK LAYOUT
TB2
19
18
19
TB2
HPS/LPS SENSOR HARNESS
17
19
HPS
TB1
LPS
HPS
L1 L1
8 X X
4
N X X N N N
4 4 4
8 7 7
19
15
11
10
9
14
13 12 18 17
16 19 19 19
26
21
20 28 27 PE PE PE PE
L3 L2
PE
L3 L2
PE
4
6
3
1
1
3
6
4
TB2
19
TB2 PE
OPTIONAL DRAIN
DRAIN 2 HARNESS
X
N
20
19
7
8
5
3
2
8
7
19
20
N
X
5
3
2
DRAIN 1 HARNESS
4
24VAC
ALM
TEST
TEST
ALM
24VAC
CONTACTOR
COMPRESSOR
CONT 1
A1 A2 N
FROM SHEET 01
TB2 N
BLACK
WHITE
(Mounted in Enclosure)
DB9 MALE CONNECTOR
3
89
5
RED
4
67
21
WIRING DIAGRAM
Model 750 - 460 VAC

14
DIMENSIONS / WEIGHTS
Dimensions
(inches)
Model 100 125 150 200 250 300 400 500 600 750
A37.56 37.56 37.56 38.60 38.60 45.38 45.38 58.06 58.06 58.06
B25.62 25.62 25.62 32.15 32.15 32.15 32.15 32.15 32.15 32.15
C1.63 1.63 1.63 1.88 1.88 2.63 2.63 2.77 2.77 2.77
D23.62 23.62 23.62 30.15 30.15 30.15 30.15 30.15 30.15 30.15
E17.62 17.62 17.62 30.15 30.15 30.15 30.15 39.62 39.62 39.62
F19.62 19.62 19.62 32.15 32.15 32.15 32.15 41.62 41.62 41.62
G9.58 9.58 9.58 7.64 7.64 13.51 16.25 20.44 20.44 20.44
H14.96 14.96 14.96 15.80 15.80 21.82 25.68 27.79 27.79 27.79
I28.54 28.54 28.54 30.19 30.19 29.98 36.89 49.06 49.06 49.06
J25.02 25.02 25.02 26.04 26.04 25.74 32.82 44.78 44.78 44.78
K0.31 0.31 0.31 0.31 0.31 0.31 0.31 0.63 0.63 0.63
L
Inlet/Outlet 1 1 1 1-1/2 1-1/2 1-1/2 2 2-1/2 2-1/2 2-1/2
Connections
Weights 251 273 279 425 463 527 571 684 691 734
(lbs)
NOTE: Dimensions and Weights are for reference only. Request certified drawings for construction purposes.
FRONT VIEW
BOTTOM VIEW
RIGHT SIDE VIEW
BACK VIEW
DETAIL A
A
"B"
"A"
"D"
"E" "F"
"G"
"H"
"I" "J"
"C"
Ø"K" MOUNTING HOLE
4-PLACES TYP.
"L” - I/O CONNECTIONS
2.500
CONDENSER AIR FLOW
6-FT (1.8 Meters) POWER CORD
MODELS 100-150 (115 VOLT)
ELECTRICAL ENTRY
MODELS 100-150 (230 VOLT)
0.25-NPT DRAINCONNECTION
MODELS 100-150
Ø1.00 (25mm) ELECTRICAL ENTRY
MODELS 200-750
Ø.750 (19mm) RS-232 ACCESS
MODELS 200-750
0.25-NPT DRAINCONNECTION
MODELS 200-600
0.25-NPT DRAINCONNECTION
MODEL 750 ONLY

15
TROUBLESHOOTING GUIDE (Models 100-150)
1. Residual free moisture remaining in
downstream pipelines
2. Air bypass system is open
3. Inlet and Outlet connections are reversed
4. Air lines downstream of dryer are exposed
to temperatures below the dew point.
5. Excessive free moisture (bulk liquid) at
dryer inlet.
6. Condensate not being drained
Drain mechanism is clogged or inoperative.
Drain line is restricted or frozen.
Electric drains-timer not set to allow for
sufficient condensate removal.
7. Dryer overloaded resulting in elevated dew
point.
8. Refrigeration system not functioning
1. Excessive air flow
2. Freezing of moisture in evaporator because
of refrigeration system fault
3. Separator filter element clogged
1. Dryer overloaded resulting in high air outlet
temperature
2. Refrigeration system not functioning
properly resulting in high air outlet
temperature
a. Power failure
b. Line disconnect switch open
c. Blown fuses, open breaker
d. Faulty wiring, loose terminals
a. High or low ambient conditions
b. Air-cooled - Dirty, clogged condenser fins,
obstructed flow across condenser, faulty
fan motor or fan control switch.
Blow out system with dry air
Check valve positions
Check for correct connection
Insulate or heat trace air lines exposed to
low ambients or dry air to lower dew point
Install separator ahead of dryer
Replace drain mechanism if inoperative.
Open drain line.
Electric drains-reset time so that all liquid is
discharged
Check inlet air temperature and pressure,
flow rate (compressor capacity) and
ambient air or water temperature.
See D below
Check flow rate
See D below
Replace filter element
See A 7
See D below
Check for power to unit
Close disconnect switch
Check for continuity
Have electrician check electrical connec-
tions.
Check min./max. temperature ranges
Clean condenser and check for free air flow,
if problem persists contact qualified
refrigeration repairman or manufacturer’s
service department.
SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION
A) Water downstream of dryer
B) High pressure drop across dryer
C) Dew point indicator in red area
D) Refrigeration system not functioning
properly
1. Power on light off
2. Refrigeration compressor cycles on
and off

16
TROUBLESHOOTING GUIDE (Models 200-750)
1. Residual free moisture remaining in
downstream pipelines
2. Air bypass system is open
3. Inlet and Outlet connections are reversed
4. Air lines downstream of dryer are exposed
to temperatures below the dew point.
5. Excessive free moisture (bulk liquid) at
dryer inlet.
6. Condensate not being drained
7. Dryer overloaded resulting in elevated dew
point.
8. Refrigeration system not functioning
1. Excessive air flow
2. Freezing of moisture in evaporator because
of refrigeration system fault
3. Filter loaded with solid particulates
a. Power failure; open circuit
a. Compressor commanded off by manual
switch or programmed schedule
b. Open circuit
c. Control circuit open on high or low pressure
cutout
a. Service interval specified has elapsed
a. Hot gas bypass valve requires adjustment
b. Low on refrigerant
a. Lack of condenser cooling
Air-cooled - Ambient temperature too high,
clogged condenser fins, obstructed flow
across condenser, faulty fan motor or fan
control switch.
Water-cooled - Cooling temperature too
high, flow too low, clogged strainer, faulty
water regulating valve
a. Dryer overloaded
b. Refrigeration system off or not cooling
sufficiently
a. Drain line restricted or frozen
b. Drain mechanism faulty
a. Faulty compressor contactor.
b. Faulty N.O. auxiliary contact on compressor
contactor.
a. Faulty compressor contactor.
b. Faulty N.C. auxiliary contact on compressor
contactor.
a. Temperature sensor or wiring to sensor is
open (only the left-most LED in the
temperature display will be illuminated).
b. Temperature sensor or wiring to sensor is
shorted (all of the LEDs in the temperature
display will be illuminated).
1. Blow out system with dry air
2. Check valve positions
3. Check for correct connection
4. Insulate or heat trace air lines exposed
to low ambients or dry air to lower dew
point
5. Install separator ahead of dryer
6. See C below
7. See C below
8. See C below
1. Check flow rate
2. See C below
3. Replace filter element
a. Check for power to dryer
a. Check current command status
b. Check power to compressor
c. Check display for fault
a. Perform scheduled service
a. Contact qualified technician or
manufacturer’s service department
Check air temperature 6” in front of
condenser; Clean condenser and check
for free air flow; Check fan and switch
operation
Check cooling medium temperature and
flow, clean strainer, check valve
operation
a. Check compressed air flow, temperature,
and pressure
b. Check power to unit, power to compres-
sor, Low or High pressure faults Have
qualified technician evaluate system
a. Open drain line
b. Turn 3-way valve to horizontal position
and open petcock for manual draining.
Rebuild drain mechanism.
a. Check wiring and operation of contactor.
b. Check wiring and operation of auxiliary
contact.
a. Check wiring and operation of contactor.
b. Check wiring and operation of auxiliary
contact.
a. Replace sensor or repair wiring.
b. Replace sensor or repair wiring.
SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION
NOTE: After fault correction, press reset button to clear display
A) Water downstream of dryer
B) High pressure drop across dryer
C) Checkpoint faults
1. Power on light off
2. Compressor on light off
3. Alarm/Service alert light on -check
Display for active conditions
SERVICE DRYER
LOW PRESSURE
HIGH PRESSURE
NOTE: If high refrigerant pressure
occurs, switch must be manually
reset
HIGH TEMPERATURE
(also observed as high reading on
temperature indicator)
DRAIN
COMPRESSOR
HEATER
TEMP SENSOR

17
PARTS LIST
Maintenance Kits
001521051
NOITPIRCSEDSTRAP 06/1/511
05/1/001 06/1/032-80205/1/042-022 06/1/511 05/1/001 06/1/032-80205/1/042-022 06/1/511
05/1/001 06/1/032-80205/1/042-022
ylbmessAtinUgnisnednoC10020052002005300200540020055002005600200540020
0550020056002005
)ylnO(rosserpmoC34220050522005652200505.801.031415.801.031425.801.031405.801.031415.801.031425.8
01.0314
daolrevO44220051522005752200531.875.529541.875.529551.875.529531.875.529541.875.529551.875.5295
yaleRtra
tS54220052522005 852200531.386.549541.386.549551.386.549531.386.549541.386.549551.386.5495
roticapaCtratS64220053
522005352200573.301.0195 83.301.019593.301.019573.301.0195 83.301.019593.301.0195
rotoMnaF74220054522005952200553
.832.501663.832.501663.832.501653.832.501663.832.501663.832.5016
edalBnaF 84220055522005552200512.722.041412.722
.041412.722.041412.722.041412.722.041412.722.0414
evlaVssaP-yBsaGtoH053200505320050532005053200505320050532005053
200505320050532005
resnednoC94220059422005942200522.111.031422.111.031422.111.031422.111.031422.111.031422.111.03
14
reyrD21.561.031421.561.031421.561.031441.561.031441.561.031441.561.031441.561.031441.561.031441.561.0314
hcti
wSerusserPnaF31.831.031431.831.031431.831.031431.831.031431.831.031431.831.031431.831.031431.831.031431.831.0314
rotcatnoCA/NA/NA/N062200526220052622005062200526220052622005
rotcatnoCyrailixuAA/NA/NA/N16220053622005362200516220053
6220053622005
retaeHesacknarCA/NA/NA/N 81.723.029591.723.029591.723.0295 81.723.029591.723.029591.723.0295
)neerG
(ylbmessAthgiLA/NA/NA/N52.754.053632.754.053632.754.053652.754.053632.754.053632.754.0536
rotacidnItnioPweD1.382
.58661.382.58661.382.58661.382.58661.382.58661.382.58661.382.58661.382.58661.382.5866
hctiwSffO-nO31.607.011631.
607.011631.607.011631.607.011631.607.011631.607.011631.607.011631.607.011631.607.0116
rosneSerutarepmeT2.333.0
5162.333.05162.333.05162.333.05162.333.05162.333.05162.333.05162.333.05162.333.0516
esuFdraoBCPlatigiD3492005349
20053492005349200534920053492005349200534920053492005
NOITPIRCSEDSTRAP
06/3/032-802 06/3/575dna,06/3/064,05/3/024-083
002004,003,052005006057002004,003,052005006057
ylb
messAtinUgnisnednoC70020059002005110200531020055102005 80020050102005210200541020056102005
)ylnO(rosserpmoC35.801
.031455.801.031475.801.0314129200546.801.031445.801.031465.801.0314 85.801.0314039200556.801.0314
rotoMnaF73.832
.501693.832.501693.832.5016229200593.832.5016 83.832.501604.832.501604.832.5016139200504.832.5016
edalBnaF22.722
.041432.722.041442.722.0414329200542.722.041422.722.041432.722.041442.722.0414329200542.722.0414
retaeHesacknar
C21.723.029521.723.029521.723.029521.723.029521.723.029531.723.029531.723.029531.723.029531.723.029531.723.0295
resnednoC32.111.031442.111.031452.111.03144292005 82.111.031432.111.031442.111.031452.111.03144292005 82.111.0314
hctiwSerusserPtnaregirfeRwoL22.831.031422.831.031422.831.031422.831.031422.831.031422.831.031422.831.031422
.831.031422.831.031422.831.0314
hctiwSerusserPtnaregirfeRhgiH52.831.031452.831.031452.831.031452.831.031452.8
31.031452.831.031452.831.031452.831.031452.831.031452.831.0314
1hctiwStuotuCnaF32.831.031432.831.031432.831.03
1432.831.031432.831.031432.831.031432.831.031432.831.031432.831.031432.831.0314
2hctiwStuotuCnaFA/NA/N42.831.031
442.831.031442.831.0314A/NA/N42.831.031442.831.031442.831.0314
)delooC-riA(evlaVssaP-yBsaGtoH0532005053200505320
051532005153200505320050532005053200515320051532005
)eniLdiuqiL(reyrDretliF5292005529200552920055292005529200552920
055292005529200552920055292005
rosneSerutarepmeT2.333.05162.333.05162.333.05162.333.05162.333.05162.333.05162.333
.05162.333.05162.333.05162.333.0516
rotcatnoC6292005629200562920056292005 82920056292005629200562920056292005 82920
05
stcatnoCyrailixuA7292005729200572920057292005929200572920057292005729200572920059292005
064/004/032remrofsnarT4
1.290.021641.290.021641.290.021641.290.021641.290.021641.290.021641.290.021641.290.021641.290.021641.290.0216
y
ramirPesuF82.472.0295 82.472.0295 82.472.0295 82.472.0295 82.472.029572.472.029572.472.029572.472.029572.472.029572.472.0295
yradnoceSesuF62.472.029562.472.029562.472.029562.472.029562.472.029562.472.029562.472.029562.47
2.029562.472.029562.472.0295
)IIMME(tiucriCdetnirP,draoB11.675.549511.675.549511.675.549511.675.549511.675.54
9511.675.549511.675.549511.675.549511.675.549511.675.5495
esuFdraoBCPlatigiD3492005349200534920053492005349200534
920053492005349200534920053492005
)V575(remrofsnarTrewoP1.772.02161.772.02161.772.02161.772.02161.772.02161.772.
02161.772.02161.772.02161.772.02161.772.0216
H(hctiwSerusserPhgiHtnaregirfeR
2
)O63.831.031463.831.031463.831.031463.831.031463.831.031463.831.031463.831.031463.831.031463.831.031463.831.0314
hctiwSffO-nO31.607.011631.607.011631.607.011631.607.011631.607.011631.607.011631.607.011631.607.011631.607.01
1631.607.0116
evlaVgnitalugeRretaWgnilooC22.541.031422.541.031422.541.031422.541.031422.541.031422.541.031422.
541.031422.541.031422.541.031422.541.0314
neercSreniartSretaWgnilooC5.537.13745.537.13745.537.13745.537.13745.
537.13745.537.13745.537.13745.537.13745.537.1374A/N
LEDOM001521051002052003004005006057
dradnatSS02KMRPHS12KMRPHS12KMRPHS22KMRPHS22KMRPHS32KMRPHS42KMRPHS42KMRPHS52KMRPHS62KMR
PH
reseslaoCdloClanoitpOhtiWS04KMRPHS14KMRPHS14KMRPHS24KMRPHS24KMRPHS34KMRPHS44KMRPHS44KMRPHS54KMRPHS64KMRPH

18
NOTES

19
NOTES

WARRANTY
AUTHORIZATION FROM THE SERVICE DEPARTMENT IS NECESSARY BEFORE MATERIAL
IS RETURNED TO THE FACTORY OR IN-WARRANTY REPAIRS ARE MADE.
The manufacturer warrants the product manufactured by it, when properly installed, operated, applied, and maintained in accor-
dance with procedures and recommendations outlined in manufacturer’s instruction manuals, to be free from defects in material or
workmanship for a period as specified below, provided such defect is discovered and brought to the manufacturer’s attention
within the aforesaid warranty period.
The manufacturer will repair or replace any product or part determined to be defective by the manufacturer within the warranty
period, provided such defect occurred in normal service and not as a result of misuse, abuse, neglect or accident. Normal
maintenance items requiring routine replacement are not warranted. The warranty covers parts and labor for the warranty period
unless otherwise specified. Repair or replacement shall be made at the factory or the installation site, at the sole option of the
manufacturer. Any service performed on the product by anyone other than the manufacturer must first be authorized by the
manufacturer.
Unauthorized service voids the warranty and any resulting charge or subsequent claim will not be paid. Products repaired or
replaced under warranty shall be warranted for the unexpired portion of the warranty applying to the original product.
The foregoing is the exclusive remedy of any buyer of the manufacturer’s product. The maximum damages liability of the manu-
facturer is the original purchase price of the product or part.
THE FOREGOING WARRANTY IS EXCLUSIVEAND IN LIEU OF ALL OTHER WARRANTIES, WHETHER WRITTEN, ORAL, OR
STATUTORY, AND IS EXPRESSLY IN LIEU OF THE IMPLIED WARRANTY OF MERCHANTABILITY AND THE IMPLIED WAR-
RANTY OF FITNESS FORA PARTICULAR PURPOSE. THE MANUFACTURER SHALL NOT BE LIABLE FOR LOSS OR DAM-
AGE BY REASON OF STRICT LIABILITY IN TORT OR ITS NEGLIGENCE IN WHATEVER MANNER INCLUDING DESIGN,
MANUFACTURE OR INSPECTION OF THE EQUIPMENT OR ITS FAILURE TO DISCOVER, REPORT, REPAIR, OR MODIFY
LATENT DEFECTS INHERENT THEREIN.
THE MANUFACTURER, HIS REPRESENTATIVE OR DISTRIBUTOR SHALL NOT BE LIABLE FOR LOSS OF USE OF THE
PRODUCT OR OTHER INCIDENTAL OR CONSEQUENTIAL COSTS, EXPENSES, OR DAMAGES INCURRED BY THE BUYER,
WHETHER ARISING FROM BREACH OF WARRANTY , NEGLIGENCE OR STRICT LIABILITY IN TORT.
The manufacturer does not warrant any product, part, material, component, or accessory manufactured by others and sold or
supplied in connection with the sale of manufacturer’s products.
Warranty Period
Parts and labor for two (2) years from the date of shipment from the factory; heat exchangers are covered (parts only) for an
additional three (3) years (total of five [5]). On units that manufacturer requests be returned to the factory, a one time removal/
reinstallation labor allowance as noted in the Service Warranty Policies and Procedures Handbook will apply. Freight to the
factory from the installation site and to the installation site from the factory will be paid by the manufacturer; means of
transportation to be specified by manufacturer.
SERVICE DEPARTMENT: [phone]
SPX Dehydration & Process Filtration
1000 Philadelphia Street
Canonsburg, PA 15317-1700 U.S.A.
Phone: [phone]
• Fax: [phone]
Email: hankison.service
@ dehydration.spx.com
www.hankisonintl.com
© 2006 SPX Corporation. All rights reserved. 3/03 Inv# 000 000
