Hans Grohe AXOR Carlton 17454XX1 Installation guide

Installation Instructions / Warranty
90883904-01 08/2005
4-Hole Roman Tub Trim
Carlton 17454XX1
Terrano 37447XX1
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

2
Installation Considerations
•This trim kit must be used with rough-in
13444-18. The handshower must be
used.
•Backflow protection is provided by a
check valve in the handshower
connection hose. Additionally, the
diverter will automatically spring back to
the "spout" position if a backflow
condition exists.
Roman tub rough 13444181 is listed by UL.
Product Specifications
Recommended operating pressure 45 - 80 psi
Recommended hot water temperature 120o- 140oF*
Flow rate - handshower 2.5 gpm
Flow rate - valves approx. 6 gpm each
Hole sizes - see template included with rough-in for placement
Valves 1 3/16”
Spout 1 3/8”
Spout Adapter Pin 3/16”
Handshower 2”
Maximum mounting surface thickness 2"
90oCeramic cartridge operation.
* Some governing agencies require that the water heater be set to 120o F or less. Please know and follow all applicable local codes when
setting the temperature on the water heater.
Carlton 17454XX1 Terrano 37447XX1
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

3
Replacement Parts
1 diverter knob 96335XXX
2 aerator 13956000
3 escutcheon 94052XXX
4 screen washer
5 check valve
6 hose 94148000
7 spout escutcheon 96236XXX
8 hot handle 37292XXX
9 diverter 96616000
10 cold handle 37291XXX
11 handshower holder 92380XXX
12 spout 96334XXX
13 handshower 36850XXX
14 insert 96942XXX
1
2
3
4
5
6
7
8
9
10
11
12
13
1 cold handle 17291XXX
2 hot handle 17292XXX
3 escutcheon 94052XXX
4 handshower holder 92380XXX
5 handle escutcheon 94035XXX
6 diverter 94037000
7 aerator 13485XXX
gold aerator 94981990
8 hose 94148000
9 check valve
10 screen washer
11 diverter knob 94086XXX
12 spout 96164XXX
13 handshower 17850XXX
1
234
5
6
7
8
910
11
12
13
14
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

4
2
3
•Remove the white plastic handle snap
connectors. Turn the valve stems
clockwise to make sure that they are "off"
(1, 2).
•Carlton only - install the handle
escutcheons by threading them onto the
mounting plates..
•Push the hot handle over the hot stem.
While holding the cross steady with one
hand, turn the bell clockwise.(1) to secure
it to the valve. Repeat with the cold
handle (2)
•Unscrew and remove the brass plug in
the spout tee with a 27 mm wrench (3)
1Installation
•Remove the plastic plaster shields from
the valves and the spout tee.
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

5
4•Lightly lubricate the o-rings on the diverter
with the enclosed lubricant. Push the
diverter firmly straight down into the
spout tee.
6
5
•Pull the outer SecuflexTM hose through the
handshower mount .
•Lubricate the handshowr mount and outer
SecuflexTM hose with spray silicon
lubricant or with a tablespoon or so of
water.
•Terrano only - install the spout
escutcheon(1)
•Push the spout over the diverter. Tighten
the spout set screw (2). Thread on the
diverter knob.
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

6
8
9•Feed the inner SecuflexTM hose through
the outer SecuflexTM hose (1)
•Attach the inner SecuflexTM hose to the
handshower connector hose (2).
•Remove the plaster guard from the outer
SecuflexTM hose (3).
7
•Use the enclosed cleaning towelette to
thoroughly clean the outer SecuflexTM
hose.
•Pull the outer SecuflexTM hose completely
from the handshower mount. Unscrew the
outer SecuflexTM hose (1) from the
handshower connector hose and remove
the brass plug (2) Do not allow the
handshower connector hose to fall back
through the hole!
•Install the check valve (3) to the
handshower connector hose. Connect the
handshower connector hose to the inner
SecuflexTM hose (4)
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

7
•Remove the end cap and the liner from
the handshower holder.
•Compress the outer hose until you can
grasp the end of the inner hose
•Feed the inner hose through the
handshower holder (1), liner (2), and end
cap (3).
•Screw the end cap (4) over the end of the
handshower holder.
•Continue pulling „out“ on the inner hose
(5).
10
11
12 •Place the handshower holder retainer ring
(1) over the hose and the handshower
holder.
•Install the screen washer and the
handshower on the hose (2).
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

8
•Secure the handshower holder to the
handshower mount with the retainer ring.
13 •Use a knife to cut the o-rings at the end of
the outer hose.
•Feed the hoses back through the
handshower mount .
•Place the handshower holder onto the
handshower mount so that the pin on the
mount engages the corresponding hole
on the handshower holder.
14
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

9
Troubleshooting
User Instructions
•Turn the right handle for cold water, the left handle for hot.
•To divert the water to the handshower, pull up on the diverter knob. When the water is
turned off, the diverter will automatically reset to the spout position.
•The handshower has two spray modes: full spray and
soft. To change spray modes, turn the face ring until the
indexing mark is next to the name of the desired function.
•The handshower uses the Quick-Clean!TM cleaning system.
When the spray mode is changed, pins push through the
regular spray channels, clearing them of any scale
deposits.
•If scale deposits build up on the spray face, pour about 3/4" of a commercial scale
remover, such as Lime-AwayTM or CLRTM, into a shallow dish. Soak just the gray spray face
in the remover for the time specified on the remover label. Do not allow the remover to sit
on the finished surfaces. When finished, rinse the handshower with clear water before
using.
Hansgrohe Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890
Hansgrohe Faucets & More www.NeedPlumbingSupplies.com 800-728-8890

10
Cleaning Recommendation for Hansgrohe Products
Modern faucetry and shower products utilize a combination of materials to comply with the needs of the
market with regard to design and functionality.
To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper
treatment is not covered under the Hansgrohe warranty.
Cleaning Materials for Faucets and Showers
•To remove lime scale, use only products made specifically for that purpose. Always follow the
manufacturer’s instructions when using.
•Do not use cleaners that contain hydrochloric, formic, acetic, or phosphoric acids, as these will cause
considerable damage to finishes and to plastic components.
•Never mix cleaning materials.
•Never use cleaners containing abrasives. Do not use abrasive cleaning cloths, pads, or sponges.
Cleaning Procedures
•Clean your faucets and shower products as and when required. Regular cleaning will prevent scale
buildup and water spotting.
•Follow the label instructions. Do not allow any cleaner to remain on the product for longer than
necessary.
•When using spray cleaners, spray first onto a sponge or cloth – do not spray directly onto the product.
•After cleaning, rinse thoroughly with clear water to remove any cleaner residue.
Important
•Soap and shampoo residue can also cause damage to the product. Rinse well with clean water after
use.
•If the surface is already damaged, harsh cleaning materials will cause further damage.
