Hans Grohe AXOR Citterio 39456 1 Series User manual

Installation / Warranty
Citterio
39456XX1
10/2003 9.05015.01

Axor Citterio four-hole roman tub set with plate
39456XX1
Technical Data
Flow rate @ 45 psi 6.0 gpm per side
Handshower 2.5 gpm max.
Maxim m water press re 145 psi
Recommended water press re: 14.5 - 75 psi
Recommended hot water temp.: 120oF - 140oF*
*Some municipalities limit the maximum water temperature from the water heater to 120o or
below. Please know and follow all applicable local codes when setting the temperature on the
water heater.
nstallation Considerations
•Roman t b ro gh 13444181 and mo nting plate 39449001 m st be
installed, and the finished deck s rface m st be complete before this
trim kit can be installed.
•Backflow preventer cartridge 94146000 is incl ded with this kit, and
m st be sed to provide protection from back siphonage. It is already
installed on the 94148000 inner Sec -flex hose.
The 13444181 roman tub rough is listed by IAPMO.

nstallation nstructions
The water supply must be turned o at the main prior to
installation o this kit.
•Remove the plastic plaster shields from
the valves and the spo t tee. Use a
phillips head screwdriver to remove the
screws from the white plastic handle
snap connectors. Remove the snap
connectors.
•Press the diverter firmly into place in the
spo t tee. Remove the cold cartridge.
•Install the new cold cartridge incl ded
with the trim kit.
•P ll pward on the handshower holder
plaster shield. P ll the o ter Sec -flex hose
completely away from the deck. Unscrew
the white plastic winged n t from the
bottom of the Sec -flex hose. P t the o ter
hose away in a safe location. Be ex-
tremely caref l to prevent the high press re
hose from falling back beneath the t b.

•Remove the brass pl g from the end of
the high press re hose. Attach the
chrome inner Sec -flex hose. Use the
enclosed Hansgrohe Color towelette to
clean and l bricate the inner hose.
Have a co-worker se the towelette to
clean and l bricate the ends of the
o ter hose. If the towelette is missing,
se a soft cloth sprayed with a silicon
l bricant.
•Disassemble the handshower holder as
shown in the diagram. Feed the inner
hose thro gh the o ter hose. Sec re
the o ter hose at the bottom with the
white plastic winged n t. Remove the
plaster shield. Compress the o ter
hose so that the hose end connection
can be grasped.
•Feed the hose end connection thro gh
the handshower holder. Snap the two
halves of the white plastic retainer over
the inner hose. Slide the finished hose
retaining ring over the end of the hose
and the white plastic hose retainer.
Screw it into the handshower holder.

•Lower the handshower holder onto the
handshower tee, feeding the hose assembly
nder the t b. The hole on the rear of the
handshower holder sho ld go over the
positioning pin on the handshower holder
tee.Install the handshower holder esc tcheon
over the handshower holder. Screw it down
over the tee.
•Position the plate over the valve and
handshower assembly. Press gently into
place.
•Place the hot and cold handle esc tch-
eons in the recesses in the plate - hot on
the left, cold on the right. Position each
handle over the valve. Grasp the barrel
of the handle, and t rn it clockwise to
tighten it.
•Inspect the handles, making s re that they
are aligned properly.
•If the handle is not straight, remove it from the valve
by grasping the barrel and t rning it co nter
clockwise.

•Use a phillips head screwdriver to loosen the screw
inside the handle assembly 3 complete t rns co nter-
clockwise.
•P ll pward on the lever to remove it.
T rn it approximately 60o. Reinsert it.
Tighten the screw.
•Reinstall the handle.

•Place the spo t over the diverter
assembly. Insert the diverter knob and
tighten. Tighten the set screw, sing the
enclosed 3 mm allen wrench.
•P ll o tward on the inner Sec -flex
hose. Install a screen washer in the
hose end connector. Install the
handshower.
•G ide the handshower back into the
handshower holder.

User nstructions
•T rn the left handle to obtain hot water, the
right handle to obtain cold water.
•When the water comes on, it will come
thro gh the spo t. P ll the diverter lever p
to divert the water to the handshower.
When the water is t rned off, the diverter
will a tomatically reset to the spo t position.
Troubleshooting
Replacement Parts
1 handle 39294XX0
2 hot escutcheon 96778XX0
3 cold escutcheon 96779XX0
4 spout
5 aerator
6 diverter knob 96774XX0
7 spout escutcheon
8 plate
9 diverter
10 handshower holder
11 inner Secu lex hose 94148000
12 back low prevention 94146000
cartridge
13 screen washer
14 Uno handshower 38850XX1
XX = color
00 = chrome
42 = platinum

Cleaning Recommendation for Hansgrohe Products
Modern aucetry and shower products utilize a combination o materials to comply with the needs o
the market with regard to design and unctionality.
To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper
treatment is not covered under the Hansgrohe warranty.
Cleaning Materials for Faucets and Showers
•To remove lime scale, use only products made speci ically or that purpose. Always ollow the
manu acturers instructions when using.
•Do not use cleaners that contain hydrochloric, ormic, acetic, or phosphoric acids, as these
will cause considerable damage to inishes and to plastic components.
•Never mix cleaning materials.
•Never use cleaners containing abrasives. Do not use abrasive cleaning cloths, pads, or
sponges.
Cleaning Procedures
•Clean your aucets and shower products as and when required. Regular cleaning will prevent
scale buildup and water spotting.
•Follow the label instructions. Do not allow any cleaner to remain on the product or longer
than necessary.
•When using spray cleaners, spray irst onto a sponge or cloth  do not spray directly onto the
product.
•A ter cleaning, rinse thoroughly with clear water to remove any cleaner residue.
Important
•Soap and shampoo residue can also cause damage to the product. Rinse well with clean
water a ter use.
•I the sur ace is already damaged, harsh cleaning materials will cause urther damage.
Limited Lifetime Consumer Warranty
This product has been manu actured and tested to the highest quality standards by Hansgrohe, Inc.
(Hansgrohe). This warranty is limited to Hansgrohe products which are purchased by a consumer
in the United States a ter March 1, 1996, and installed in either the United States or Canada.
WHO IS COVERE BY THE WARRANTY
This warranty extends to the original consumer purchaser only.
WHAT IS COVERE BY THE WARRANTY
The warranty covers only your Hansgrohe manu actured product. Hansgrohe warrants this product
against de ects in material or workmanship as ollows: Hansgrohe will repair at no charge or parts
or labor or, at its option, replace any product or part o the product which proves de ective because
o improper workman ship and/or material, under normal installation, use, service and mainte-
nance. I Hansgrohe is unable to provide a replacement and repair is not practical or cannot be
timely made, Hansgrohe may elect to re und the purchase price in exchange or the return o the
product.
LENGTH OF THE WARRANTY
Replacement o repaired parts o products will be covered or the term o this warranty as stated in
the ollowing two sentences. I you are a consumer who purchased the product or use primarily or
personal, amily or household purposes, this warranty extends or as long as you own the product
and the home in which the product is installed. I you purchased the product or use primarily or
any other purpose, including, without limitation, a commercial purpose, this warranty extends only
(i) or 1 year with respect to Interaktiv products, and (ii) or 5 years, with respect to Axor and Pharo
products.

THIS WARRANTY OES NOT COVER, AN HANSGROHE WILL NOT PAY FOR:
A. Conditions, malfunctions or damage not resulting from defects in material or workmanship.
B. Conditions, malfunctions, or damage resulting from (1) improper installation, improper
maintenance, misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or
caustic cleaning agents or no rinse cleaning products, or the use of the product in any
manner contrary to the product instructions.
C. Labor and other expenses for disconnection or return of the product for warranty service, or
for installation or reinstallation of the product.
D. Accessories or related products not manufactured by Hansgrohe.
TO OBTAIN WARRANTY SERVICE
Contact your Hansgrohe retailer, or write to Technical ervice at:
Hansgrohe Inc.
1492 Bluegrass Lakes Parkway
Alpharetta GA 30004
Or call Hansgrohe toll-free at [phone].
In requesting warranty service, you will need to provide:
1. The sales receipt or other evidence of the date and place of purchase.
2. A description of the problem.
3. Delivery of the product or the defective part, postage prepaid, and carefully packed and
insured, to Hansgrohe Inc. 1492 Bluegrass Lakes Parkway, Alpharetta Georgia 30004,
Attention: Technical ervice, if required by Hansgrohe.
When warranty service is completed, any repaired or replacement product or part will be returned
to you postage prepaid.
EXCLUSIONS AN LIMITATIONS
REPAIR OR REPLACEMENT (OR, IN LIMITE CIRCUMSTANCES, REFUN OF THE
PURCHASE PRICE) AS PROVI E UN ER THIS WARRANTY IS THE EXCLUSIVE REME Y
OF THE PURCHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY
PERSON TO CREATE FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION
WITH THIS PRO UCT.
HANSGROHE SHALL NOT BE LIABLE TO PURCHASER OR ANY OTHER PERSON FOR
ANY INCI ENTAL, SPECIAL, OR CONSEQUENTIAL AMAGES, ARISING OUT OF A
BREACH OF THIS WARRANTY OR ANY IMPLIE WARRANTY (INCLU ING MERCHANT-
ABILITY).
ome tates do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
You may be required by law to give us a reasonable opportunity to correct or cure any failure to
comply before you can bring any action in court against us under the Magnuson-Moss Warranty
Act.
PRO UCT INSTRUCTIONS AN QUESTIONS
Upon purchase or prior to installation, please carefully inspect your Hansgrohe product for any
damage or visible defect. Prior to installing, always carefully study the enclosed instructions on the
proper installation and the care and maintenance of this product. If you have questions at any time
about the use, installation or performance of your Hansgrohe product, or this warranty, please call
or write to us at the toll-free number and address provided above.

Hansgrohe Inc.
1490 Bluegrass Lakes Parkway
Alpharetta GA 30004
770 360 9880
website: www.ha sgrohe-USA.com
