INSTALLATION
EN ⁄ Instructions for use ⁄ Assembly instructions 02
DE ⁄ Gebrauchsanleitung ⁄ Montageanleitung 03
Lesezeichen
English 02
Deutsch 03
AXOR One Select
4 8112 X X 9
02
ASSEMBLY (see page 04)
EN
SAFETY NOTES
Gloves should be worn during installation to prevent
crushing and cutting injuries.
The product may only be used for bathing, hygienic
and body cleaning purposes.
The hot and cold supplies must be of equal pressures.
INSTALLATION INSTRUCTIONS
⁄ Prior to installation, inspect the product for transport
damages. After it has been installed, no transport or
surface damage will be honoured.
⁄ The pipes and the fixture must be installed, flushed and
tested as per the applicable standards.
⁄ The plumbing codes applicable in the respective
countries must be observed.
⁄ The drain valve must only be used as intended. It is not
allowed to attach other objects to the drain valve, for
example a semi-pedestal.
⁄ If the instantaneous water heater causes problems or if
you wish to increase the water flow, the EcoSmart®
(flow limiter) located behind the aerator can be
removed.
Special information for UK If installing this product with a
pump, please be aware that it has to have negative head
switching. This product will not function with a positive
head pump.Technical Data
This mixer series-produced with EcoSmart® (flow limiter)
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 60°C
Thermal disinfection: 70°C / 4 min
The product is exclusively designed for drinking water!
SYMBOL DESCRIPTION
Do not use silicone containing acetic acid!
MAINTENANCE (see page 09)
The check valves must be checked regularly
according to EN 806-5 in accordance with
national or regional regulations (at least once a
year).
DIMENSIONS (see page 08)
FLOW DIAGRAM (see page 08 )
SPARE PARTS (see page 13 )
XX = Colors
00 = Chrome Plated
67 = Matt Black
SPECIAL ACCESSORIES
(see page 13 )
order as an extra
⁄ face plate extension 22 mm #13610XX0
⁄ face plate Ø 90 mm #13611XX0
CLEANING (see page 12 )
OPERATION (see page 12 )
Hansgrohe recommends not to use as drinking
water the first half liter of water drawn in the
morning or after a prolonged period of non-use.
FAULT CAUSE REMEDY
⁄ Insufficient water ⁄ Aerator calcified, dirty ⁄ Clean aerator, replace as necessary
⁄ Insufficient water ⁄ check valve hasn't moved back ⁄ Exchange check valves
⁄ Mixer stiff ⁄ Cartridge defective, calcified
(#94317000)
⁄ Exchange cartridge (#94317000)
⁄ Mixer dripping ⁄ Cartridge defective (#94317000) ⁄ Exchange cartridge (#94317000)
⁄ Instantaneous heater didn’t work ⁄ check valve hasn't moved back ⁄ Exchange check valves
03
MONTAGE (siehe Seite 04)
DE
SICHERHEITSHINWEISE
Bei der Montage müssen zur Vermeidung von
Quetsch- und Schnittverletzungen Handschuhe
getragen werden.
Das Produkt darf nur zu Bade-, Hygiene- und
Körperreinigungszwecken eingesetzt werden.
Große Druckunterschiede zwischen den Kalt- und
Warmwasseranschlüssen müssen ausgeglichen
werden.
MONTAGEHINWEISE
⁄ Vor der Montage muss das Produkt auf Transportschä-
den untersucht werden. Nach dem Einbau werden
keine Transport- oder Oberflächenschäden anerkannt.
⁄ Die Leitungen und die Armatur müssen nach den
gültigen Normen montiert, gespült und geprüft werden.
⁄ Die in den Ländern jeweils gültigen Installationsricht-
linien sind einzuhalten.
⁄ Das Ablaufventil darf nur zum bestimmungsgemäßen
Gebrauch verwendet werden. Das Befestigen von
anderen Gegenständen z. B. einer Halbsäule an dem
Ablaufventil ist nicht zulässig.
⁄ Bei Problemen mit dem Durchlauferhitzer oder wenn
mehr Wasserdurchsatz gewünscht wird, kann der
EcoSmart® (Durchflussbegrenzer), der hinter dem
Luftsprudler sitzt, entfernt werden.
Technische Daten
Armatur serienmäßig mit EcoSmart® (Durchflussbegrenzer)
Betriebsdruck: max. 1 MPa
Empfohlener Betriebsdruck: 0,1 - 0,5 MPa
Prüfdruck: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Heißwassertemperatur: max. 60°C
Thermische Desinfektion: 70°C / 4 min
Das Produkt ist ausschließlich für Trinkwasser konzipiert!
SYMBOLERKLÄRUNG
Kein essigsäurehaltiges Silikon verwenden!
WARTUNG (siehe Seite 09)
Rückflussverhinderer müssen gemäß EN 806-5
regelmäßig in Übereinstimmung mit nationalen
oder regionalen Bestimmungen auf ihre Funktion
geprüft werden (mindestens einmal jährlich).
MASSE (siehe Seite 08)
DURCHFLUSSDIAGRAMM
(siehe Seite 08 )
SERVICETEILE (siehe Seite 13 )
XX = Farbcodierung
00 = Chrom
67 = Mattschwarz
SONDERZUBEHÖR (siehe Seite 13 )
nicht im Lieferumfang enthalten
⁄ Rosette Verlängerung 22 mm #13610XX0
⁄ Rosette Ø 90 mm #13611XX0
REINIGUNG (siehe Seite 12 )
BEDIENUNG (siehe Seite 12 )
Hansgrohe empfiehlt, morgens oder nach
längeren Stagnationszeiten den ersten halben
Liter nicht als Trinkwasser zu verwenden.
STÖRUNG URSACHE ABHILFE
⁄ Wenig Wasser ⁄ Luftsprudler verkalkt, verschmutzt ⁄ Luftsprudler reinigen / austauschen
⁄ Wenig Wasser ⁄ Rückflussverhinderer sitzt fest ⁄ Rückflussverhinderer austauschen
⁄ Armatur schwergängig ⁄ Kartusche defekt, verkalkt
(#94317000)
⁄ Kartusche austauschen (#94317000)
⁄ Armatur tropft ⁄ Kartusche defekt (#94317000) ⁄ Kartusche austauschen (#94317000)
⁄ Durchlauferhitzer schaltet nicht ein ⁄ Rückflussverhinderer sitzt fest ⁄ Rückflussverhinderer austauschen
04
AXOR Select
13625180
1.
2.
SW 3 mm
1-2 mm
Silicone
1
2 3
4 5
Montage
05
ca. 5 mm
ca. 10 mm
SW 3 mm
3x M5x45
SW 3 mm
3x M5x40
6 7
8 9
10 11
Montage
06
1. 2.
SW 3 mm
2.
Armaturenfett
Grease
䀵滑油
1.
1.
2.
SW 3 mm
(0,1 Nm)
SW 3 mm
(0,1 Nm)
SW 3 mm
3x M5x45
3x M5x40
12
13
14
Montage
07
> 2 min
1.
2.
0 mm
15 16
17 18
19
Montage
08
14
Ø80
220
229
Ø21
2 0
°
40
Ø80
60
620
AXOR One Select
4 8112 X X 9
bar
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
5,50,55
6,00,60
036912 15 18 21 24 27 30
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/min
Q = l/sec
Maße Durchflussdiagramm
09
1.
2.
SW 3 mm
1.
2.
SW 3 mm
(3 x)
3x M5x45
1
2 3
4 5
Wartung
10
2.
Armaturenfett
Grease
䀵滑油
1.
SW 3 mm
1.
2.
SW 3 mm
(0,1 Nm)
SW 3 mm
(0,1 Nm)
SW 3 mm
3x M5x45
3x M5x40
6
7
8
Wartung
