Hanwei VAN300 Series User manual

VAN300
Gas alarm system operation manual
HANWEI ELECTRONICS CO., LTD
ISO9001-2008

Hanwei Electronics Co., Ltd www.hwsensor.com
Tel: [phone] Email: [e-mail]
- 1 -
1 Brief introduction
VAN300 gas alarm system, consisting of VAN300 panel and 1～3pcs detectors, is
designed especially for detecting leakage of CO, combustible gas and aether inside the
recreational vehicles. It adopts high-quality air-sensitive component and advanced sensor
technology. When the gas concentration reaches the presetting alarm level, it gives out
visual and audible signals, which reminds the user to take prompt favorable action.
2 Technical specifications
2.1 VAN300
Power supply: DC12V or DC24V Consumption: ≤3W
Working condition: Tem. 0℃～55℃Humidity: ＜95%RH
Warm up time: 3min±30s
Alarm type: Sound and light Sound level: ≥85dB
Signal output: Free contact or DC9V relay output
Life: ＞5 years
Weight: Appr. 150g
Dimensions: L×W×H 107mm×95mm×50mm
2.2 Detector
Model
VAN300-CO
VAN300-LPG
Detecting gas
CO
Combustible gas and aether
Alarm type
Red LED flickering
Red LED flickering
Alarm level
50ppm-150ppm
500ppm-6000ppm
Response time
≤2.5min
≤30s
Power
DC9V
Consumption
≤3W
Working condition
Tem: 0℃～55℃Humidity: ＜95%RH
Sampling method
Natural diffusion
Life
>5 years
Weight
Appr. 48g
dimensions
L×W×H 82mm×50mm×37mm

Hanwei Electronics Co., Ltd www.hwsensor.com
Tel: [phone] Email: [e-mail]
- 2 -
3 System configurations
The system consists of1pc panel and 1～3pcs detectors. The configuration is as follows:
4. Appearance and function indication
4.1 Panel

Hanwei Electronics Co., Ltd www.hwsensor.com
Tel: [phone] Email: [e-mail]
- 3 -
4.2 Detector
5. Wire connection instruction
Please connect the panel and detectors with the USB cable attached inside the package,
and connect the USB with panel wire connection terminals as follows:
R --- Red line W --- White line G --- Green line B --- Black line

Hanwei Electronics Co., Ltd www.hwsensor.com
Tel: [phone] Email: [e-mail]
- 4 -
A. To connect the power of DC12V or DC24V
B. R, W, G and B to connect with red line, white line, green line and black line of the USB
cable. Each panel can connect at most 3pcs of detectors.
C. Relay output:
Voltage output: When all the DIP switches are on the position of “On”.
Free contact: When all the DIP switches are on the position of “Off”.
D. To connect external speaker
E. To connect external alarming light.
6 Operation instructions
6.1 VAN300-CO
6.1.1 Connect it with the power supply, and Power LED and Fault LED turn on. The system
starts warm-up: 3 minutes for panel and 5 minutes for detectors. During warm-up, the
detection function doesn’t work. After 5 minutes, Fault LED turns off, and the system
enters detection status. Power LED of the panel turns on, and the Power LED of the
detectors keep flickering.
6.1.2 When CO concentration reaches the presetting alarm level, Alarm LED of the
detectors flickers, and the detector sends alarming signal to the panel. Then the panel
gives alarming:Alarm LED flickers, buzzer gives sound alarming, and it drives relay output.
It can also drive the external speaker or alarming light if have.
6.1.3 When CO concentration is lower than the presetting alarming level, all the alarming
disappear and the system returns to the normal detection status.

Hanwei Electronics Co., Ltd www.hwsensor.com
Tel: [phone] Email: [e-mail]
- 5 -
6.2 VAN300-LEL
6.2.1 Connect it with the power supply, and Power LED turns on. The system starts
warm-up for 3 minutes. During warm-up, the detection function doesn’t work. After 3
minutes, the system enters detection status. Power LED of the panel turns on, and the
Power LED of the detectors keep flickering.
6.2.2 When LPG concentration reaches the presetting alarm level, Alarm LED of the
detectors flickers, and the detector sends alarming signal to the panel. Then the panel
gives alarming: Alarm LED flickers, buzzer gives sound alarming, and it drives relay output.
It can also drive the external speaker or alarming light if have.
6.2.3 When LPG concentration is lower than the presetting alarming level, all the alarming
disappear and the system returns to the normal detection status.
6.3 Fault alert
Once the wire connection is not good or short circuit occurs, Fault LED of the detectors
turn on, and the detectors send signal to the panel. The panel gives visible and audio
alarm. Fault LED of panel turns on, buzzer gives sound alarming. It can also drive the
external speaker or alarming light if have. When there is fault alarming, the system
detection function doesn’t work.
6.4 Button
Test button: In normal detection status, press the buttons of both panel and detectors, the
system simulates the basic functions.
7. Trouble shooting and solution
Problem
Possible reason
Solution
Power LED is not on
Bad wire connection
Connect the wire well
LED is defective
Contact the seller
No audio nor visible
alarming when pressing
the buttons
Circuit fault
Contact the seller
No response to the target
gas
Warm-up doesn’t finish
Wait till warm-up finish
Circuit fault
Contact the seller

Hanwei Electronics Co., Ltd www.hwsensor.com
Tel: [phone] Email: [e-mail]
- 6 -
The detector keeps
alarming after warm-up
There exists much
smoking, alcohol, perfume
etc. volatile gases
Move it to the clean air to test it
again
Not used for long time
Electrify it of more than 2 hours
Circuit fault
Contact the seller
Fault alert
Bad USB wire connection
Connect the wire well
8. Notices
8.1 It’s possible that the detectors give alarming in the conditions of long time smoking,
drinking, or using perfume, gasoline, paint and other volatile organic compound.
8.2 Please do not use non calibrated gas to test the detectors. If the gas concentration is
too high, it will damage the detectors, and it is also harmful to human’s health.
8.3 Please contact the seller for calibrating the system once per year.
8.4 Please do not use or store the detectors in the corrosive gases (such as Cl2).
8.5 Please clean away the dust or dirt from the alarm frequently to keep air vent freely and
the lights clear.
8.6 In order to assure the best performance, please electrify the system for at least 24
hours after long-time storage or shipping.
8.7 Working under normal detection condition, the life of the gas sensor is more than 5
years.
Declaration
To keep continued product improvement, Hanwei reserves the right to change design
features without prior notice.
