Hanwei GD Series User manual

GD Series
Gas Alarm Operation Manual
Hanwei Electronics Co.,Ltd

Hanwei Electronics Co., Ltd www.hwsensor.com
[e-mail] Fax: [phone] Tel: [phone]
1
Precautions:
To avoid personal safety injury, Instrument damage and potential dangerous accident; do
not use the product before reading this manual.
1. Description
GD gas alarm is a kind of wall-mounted household gas alarm designed to detect the
concentration of combustible and toxic gases or vapors using high quality air-sensitive
component and manufactured with advanced technology. It provides visual and audible
signals when the gas concentration reaches the presetting range, and reminds you to take
prompt favorable action.
2 Specifications
Model
□GD401 □GD601
Operating Power
AC220V/110V±15%/DC24V/DC12V ≤3W
Operating Conditions
Temperature: 0℃～55℃Humidity：＜95%
Response time
≤30s（GD701≤2.5min ）resume automatically
Gas Sampling
Diffuse naturally
Alarm Level
GD401：for natural gas 10%LEL
GD601：for propane 10%LEL
Alarm Method
Visual and audible
Sound level
≥80dB
Weight
270g
Dimension
l×b×h,mm:126×72×47.5
Optional function
□Gas shut off valve □relay output
Note: the power and the alarming level can be specified.

Hanwei Electronics Co., Ltd www.hwsensor.com
[e-mail] Fax: [phone] Tel: [phone]
2
3 Functions and Indications
4. Installation
4.1 Fix the appliance on the wall at a horizontal distance as 2~4m from the cooker or gas
source;
4.2 The vertical location of the appliance should be decided according to the type of gas
sort:
LPG：Fix it within 0.3 meters above the ground;
Natural Gas：Fix it within 0.3 meters below the Roof
Such location should be avoided：
Near the windows or passage with strong wind,
Water fog and drop or such moist place；
Easy polluted or high tem environment near Oven,
Covered by other things.
4.3 Choosing a proper installation way per conditions above.
Installation 1: Choose a suitable wall or place per the above 4.1, 4.2 requests. Fix the
hanging plate onto the wall with M5 or M3 screw through the screw hole (as the
following drawing, two optional types φ5 and φ3), then connect the appliance with the
hanging plate.
1
POWER Light (Green)
2
W-UP Light (Yellow)
3
FAULT Light (Yellow)
4
ALARM Light (Red)
5
TEST Button: press to test alarm function
6
W-UP Button: press to stop the warm up.
7
Air vents
1
2
3
4
5
6
7

Hanwei Electronics Co., Ltd www.hwsensor.com
[e-mail] Fax: [phone] Tel: [phone]
3
Installation 2: Choose a suitable wall or place per the above 4.1, 4.2 requests. Fix a nail
(size φ2) into the wall. Hang the appliance on the nail with the hanging hole as the
drawing below:
4.4 Connection drawing of gas detector with functions of gas shut off valve or relay output,
see above.

Hanwei Electronics Co., Ltd www.hwsensor.com
[e-mail] Fax: [phone] Tel: [phone]
4
5 Using Instructions:
5.1 GD401 /GD601
5.1.1. Plug in, (If ventilate fan, electro valve or other equipment is need to be connected,
please connect corresponding circuit firstly.), then the green POWER light and yellow
W-UP light will be on. The appliance assumes non-operating status for three minutes while
the sensor warms up. After warm up, the yellow W-UP light will be off automatically and the
appliance enters detecting status.
5.1.2. If the gas in the environment rises above the preset alarm level, the appliance will
enter alarm status, the red ALARM light will shine and the buzzer will give sound alarming.
Meanwhile, the alarm will activate the relay or the valve output; at the same time, please
cut off gas supply promptly and open the window. Don’t try to switch on or off any electric
appliance, including mobile phone and such communications tools. Ask professional
person to eliminate the gas leaking malfunction quickly (the alarm with function of gas shut
off valve shall output one close pulse signal each 10 seconds)
5.1.3. Once the gas concentration around drop under the preset alarming level, the
detector will stop alarming automatically and the ventilating fan will also stop automatically.
The detector gets into detecting state again.
5.1.4. If the yellow fault alarm light is on, it shows there is something wrong with the
detector and the detector can’t detect gas. Then please contact the distributor.
5.1.2 Button operation:
W-UP: press this button to stop the warm up and the detector get into detecting state
immediately.
Test button: The appliance will simulate alarming by pressing test button under
detecting status.
Once the gas concentration around drop under the preset alarming level, the detector will
stop alarming automatically and the ventilating fan will also stop automatically. The
detector gets into detecting state again.
6 Troubleshooting Guide
Problems…
Maybe caused by…
Solution
Green POWER light
is off
Plug in not correct
Plug in again
light broken
Contact the distributor
Press test button
without alarm sound
Circuit fault
Contact the distributor
Can’t detect the gas
The preheat is not finished
Wait until the preheat
finish

Hanwei Electronics Co., Ltd www.hwsensor.com
[e-mail] Fax: [phone] Tel: [phone]
5
Circuit fault
Contact the distributor
The alarm give alarm
after the warm up
Too much smoke, alcohol or
perfume or other volatility gas in
the air.
Move the clean air
and test again
Stored too long
Warm up for more than
2 hours
Circuit fault
Contact the distributor
or factory maintain
7. Notices:
7.1 It’s possible that the detectors give alarming in the conditions of long time smoking,
drinking, or using perfume, gasoline, paint and other volatile organic compound；
7.2 Please do not use or store the detectors in the corrosive gases(such as Cl2);
7.3 please do not use some non calibrated gas to test the detectors, If the gas
concentration is too high, it will damage the detectors, also is harmful for human’s health;
7.4 Clean the dust or dirt on the alarm frequently to keep air vent freely and the lights clear
7.5 The detector needs to be keeping power on for more than 24 hours after a long time
delivery of storage.
8 Gas Safety Knowledge:
8.1 Sorts of gases
Normal domestic gas：LPG: propane and butane；
Coal Gas：hydrogen and carbon monoxide；
Natural Gas：methane；
All of the normal domestic gases is combustible gas, whose LEL(lowest explode limited) is
below 10% of mixture with air.
When the concentration of the leaking gas in air, it will narcotize people’s centre nerve,
even cause suffocation.
8.2 When the gas burning, it need abundant air, such as 1m3 need about 30m3 .So the
placed with hearth such as kitchen has to be keep ventilate.
8.3 LEL Meaning:
LEL is Lowest Explode Level. That is the lowest concentration of the gas in the air,
which will cause exploding when meeting fire.
8.4 Reasons of gas leakage:
Wrong ignition.
The fire is put out with winds during the cooking.
Gas
Basis
Exploding Range
Toxicity
LPG
C4H10、C3H8
1.8%～9.5%
suffocation
Natural Gas
CH4
5%～15%
suffocation
Coal Gas
H2、CO
4%～75%
toxicosis

Hanwei Electronics Co., Ltd www.hwsensor.com
[e-mail] Fax: [phone] Tel: [phone]
6
Fire is out during the cooking because of the change of the gas pressure.
The gas valve is not shut off well.
Wrong operation to the cooking tools.
The gas pipe is destroyed.
Other reasons.
8.5 Solutions of gas leakage:
Put out the fire.
Shut off the gas valve.
Open the windows and doors.
Check the leakage source.
Don’t try to turn off any electric equipment when alarming continuously. Call the
gas company with the outdoor phone.
Please knock at the door instead of pressing the doorbell when find gas leakage
in your neighbors’ home.
Declaration
To keep continued product improvement, Hanwei reserves the right to change design
features without prior notice
