Hanwha Techwin SBP-136B User manual

Product Overview
Package
Please make sure to install on an area which is strong enough to support more than 4 times of
the total weight of this product and the camera. Depending on some installation conditions,
this product can be connected to 0.75” PF which is a screw peak processed pipe.
Installation Precautions
This product is an adaptor used to install our Vandal Dome Camera in the electric gang box or
on the wall or ceiling.
Installation
1
Install the mount bracket on a desired position.
2
Remove the cap-bolt in the selected direction before inserting the pipe.
J
`However, take into consideration the pipe insertion direction.
There are three directions available for inserting the pipe.
Mount Bracket
SBP-136B (IVORY)
SBP-136BW (WHITE)
Pipe
CAP-BOLT
MOUNT-BRACKET
SCREW-SPECIAL SCREW-MACHINEANCHOR



Product Specications
Product Outline
3
Attach the case-bottom to the mount bracket.
Weight 345g
Material Aluminum
Operating
Temperature -50°C~60°C
Operating
Humidity 0~100%
