HANYOUNG NUX UP 12RM-4 Series User manual

1 2
Safety information
DANGER indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury
Before using the product, please read the safety information thoroughly and use it properly.
Alerts declared in the manual are classified to Danger, Warning and Caution by their criticality
DANGER
WARNING
CAUTION
• Pay attention that it is possible to damage a proximity sensor by a short circuit when wiring load.
• Wiring to an applicable device shall be certainly connected by using compressing
terminals or soldering.
• Do not use PNP type or NPN type indiscriminately.
• Please wire after ensuring whether input conditions are accepted to an applicable device.
• When there is a power or high voltage line close to the cord of the proximity sensor, wire
the cord with shielding such as an independent metal conduit to prevent against proximity
sensor’s damage or malfunction.
• Although the proximity sensor has a surge absorption circuit, if there is any machine that
has a large surging one (e.g., a motor, welding machine, etc) near the proximity sensor,
connect a varistor, surge absorber, noise filter to a surge generating area.
• Effect of Consumption Current : When AC type of proximity sensor is OFF, the proximity
sensor has little consumption current for an operation of the circuit. Because of this fact,
the little voltage left in the load may be a cause of load reset defective, so please make
sure this voltage is less than the load reset voltage before using.
• In case of a load current is small : When a loaded current of AC type of proximity sensor is
less than 5 mA, wire a bleeder resistor with the load in parallel so that make the residual
voltage of the proximity sensor be less than the loaded reset voltage.
• Make the ripple content of the rated voltage which supplied into DC (NPN, PNP) type of
proximity sensor be less than the maximum ± 10 % of the ripple content.
• In case of using a condenser as a load, wire a current-limiting resistor in series so that set
the peak current shall be within the loaded current of the proximity sensor.
• In case of an inductive load (e.g., a motor, relay, magnet, etc), connect the load with surge
bsorbing diode in parallel.
• Pay attention at a position of attachment, divergence, slack and distortion of a sensing
surface or proximity sensor.
• In the place of possibly occurring metal particles, make sure whether a sensing distance is
properly working since it can be affected if metal particles stick to the sensing surface.
• Pay attention on using or storing the proximity sensor outdoors.
• Do not use the proximity sensor in an environment with chemical, solvent or corrosive.
• Please avoid as much as possible to put the proximity sensor in hot water or to use them
in a place where generates high pressure steam.
• The contents of this manual may be changed without prior notification.
• The maximum cable extension length shall be within 200 m.
CAUTION
• If the user use the product with methods other than specified by the manufacturer, there
may be bodily injuries or property damages.
• If there is a possibility of an accident caused by errors or malfunctions of this product,
install external protection circuit to prevent the accident.
WARNING
▒ D.C 2wire type
1381-3, Juan-Dong, Nam-Gu Incheon, Korea.
TEL:[phone]
FAX:[phone]
http://www.hynux.net
HANYOUNGNUX CO.,LTD
HEAD OFFICE
Jl. cempaka blok F16, No.02 Delta Silicon II
Cikarang Bekasi Indonesia
TEL : [phone]~4
FAX : [phone]
PT. HANYOUNG ELECTRONIC INDONESIA
INDONESIA
FACTORY
•8RM •12RM •18RM •30RM
•8RD •12RD •18RD •30RD
MJ0604E140416
Model UP 12RM-4 ☐ ☐
UP 12RD-8 ☐ ☐
UP 18RM-7 ☐ ☐
UP 18RD-14 ☐ ☐
UP 30RM-15 ☐ ☐
UP 30RD-25 ☐ ☐
Snesing distance 4 ㎜, 8 ㎜ 7 ㎜, 14 ㎜ 15 ㎜, 25 ㎜
Setting distance 0-3.2 ㎜, 0-6.4 ㎜ 0-5.6 ㎜, 0-11.2 ㎜ 0-12 ㎜, 0-20 ㎜
Response frequency 500, 500 ㎐ 300, 300 ㎐ 100, 100 ㎐
Standard
sensing object (㎜)
Iron 12×12×1
Iron 25×25×1
Iron 20×20×1
Iron 40×40×1
Iron 45×45×1
Iron 75×75×1
Hysteresis Less than 15 % of sensing distance
Power supply voltage 12 V - 24 V d.c (5 - 35 V d.c)
Control output Resistive load : 200 ㎃ max
Residual voltage 1.5 V max
Current consumption 6 ㎃ max
Operation indication Red LED
Protection circuit Power reversely connected protective circuit, surge protective circuit and
over current protective circuit are built in.
Ambient temperature -25 ~ 70 ℃ (Less than ±15 ％ of sensing distance at temperature 20 ℃)
Ambient humidity 35 ~ 85 ％ R.H.
Degree of protection IP67 (IEC standard)
Vibration resistance 10 - 55 ㎐ (cycle 1 min, double amplitude : 1.5 ㎜ 2 hours for each of X, Y
and Z directions)
Dielectric strength For 1 min at 1500 V a.c 50/60 ㎐ (between the recharging part and case)
Shock resistance 500 ㎨ 3 times to each, X, Y and Z directions
Insulation resistance 50 ㏁ min (500 V d.c mega standard)
Material CASE : Brass (Chrome plating), Sensing surface : PBT
Model UP 12RM-4 ☐ ☐
UP 12RD-8 ☐ ☐
UP 18RM-7 ☐ ☐
UP 18RD-14 ☐ ☐
UP 30RM-15 ☐ ☐
UP 30RD-25 ☐ ☐
Snesing distance 4 ㎜, 8 ㎜ 7 ㎜, 14 ㎜ 15 ㎜, 25 ㎜
Setting distance 0-3.2 ㎜, 0-6.4 ㎜ 0-5.6 ㎜, 0-11.2 ㎜ 0-12 ㎜, 0-20 ㎜
Response frequency 500, 500 ㎐ 300, 300 ㎐ 100, 100 ㎐
Standard
sensing object (㎜)
Iron 12×12×1
Iron 25×25×1
Iron 20×20×1
Iron 40×40×1
Iron 45×45×1
Iron 75×75×1
Hysteresis Less than 15 % of sensing distance
Power supply voltage 12 V - 24 V d.c (10 - 30 V d.c)
Control output Resistive load : 100 ㎃ max
Residual voltage T(Polarity) : max 3.5 V, U(No polarity) : 5 V max
Current consumption 1 ㎃ max
Operation indication Red LED
Protection circuit surge protective circuit and over current protective circuit are built in.
Ambient temperature -25 ~ 70 ℃ (Less than ±15 ％ of sensing distance at temperature 20 ℃)
Ambient humidity 35 ~ 85 ％ R.H.
Degree of protection IP67 (IEC standard)
Vibration resistance 10 - 55 ㎐ (cycle 1 min, double amplitude : 1.5 ㎜ 2 hours for each of X, Y
and Z directions
Dielectric strength For 1 min at 1500 V a.c 50/60 ㎐ (between the recharging part and case)
Shock resistance 500 ㎨ 3 times to each, X, Y and Z directions
Insulation resistance 50 ㏁ min (500 V d.c mega standard)
Material 12R, 18R, 30R CASE : Brass (Chrome Plating), Sensing surface : PBT
▒ D.C NPN / PNP type
Model Code Description
UP ☐
- ☐ ☐ ☐ ☐ ☐ Inductive type proximity sensor
Sensing
area size
12 M12
18 M18
30 M30
Structure type
RM Round type shield
RD Round type None shield
Sensing distance ✽ Sensing distance(㎜)
Power supply
and output
N NPN type ※ Green body, (NO,NC)
P PNP type ※ Purple body, (NO,NC)
T D.C 2 wire type(Polarity), (NO : Green, NC : Purple)
U D.C 2 wire type(No polarity), (NO : Green, NC : Purple)
Output type A Normal open (NO)
C Normal close (NC)
Connection structure
✽ No indication (Cable type)
CR Relay connector type
C Connector type
Inductive type proximity sensor
Thank you for purchasing HANYOUNG product.
Please check whether the product is the exactly same as you ordered.
Before using the product, please read this instruction manual carefully.
Please keep this manual where you can view at any time
UP Long distance
sensing type
INSTRUCTION MANUAL
☐ Round
☐ Square
Suffix code
Specification

1 2
Model M A B C D E G H
UP 12RM-4 ☐ ☐ 12 13 17 21 32 59 - 4
UP 12RD-8 ☐ ☐ 12 13 17 21 24.5 51.5 7.5 4
UP 18RM-7 ☐ ☐ 18 19 24 29 29 57.8 - 4
UP 18RD-14 ☐ ☐ 18 19 24 29 19 47.8 10 4
UP 30RM-15 ☐ ☐ 30 31 35 43 38 66.8 - 5
UP 30RD-25 ☐ ☐ 30 31 35 43 28 56.8 10 5
▒ D.C NPN/PNP/2wire Type
[Unit : mm]
Connection diagram
Type Connection method Output state
N
P
N
P
N
P
Sensing object
LOAD
[Brown - Black]
Output voltage
Operation indicator
Sensing object
LOAD
[Brown - Black]
Output voltage
Operation indicator
Sensing object
LOAD
[Brown - Black]
Operation indicator
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
Black
Black
Brown
Brown
Blue
Blue
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
Black
Black
Brown
Brown
Brown
Brown
Blue
Blue
Blue
Blue
H
L
H
L
ON
OFF
Run
Return
Run
Return
Run
Return
Yes
No
Yes
No
Yes
No
ON
OFF
ON
OFF
D.C open / close
2 Wire
How to set distance
• When a proximity sensor is operating as a sensing object is approaching, a distance
between the sensing surface and the sensing object is the operating distance of the
proximity sensor.
• After measuring a maximum value of a perpendicular direction of a sensing object, install
it within 80 %.
• When testing a sensing distance of a proximity sensor, a standard sensing object was
used so a sensing distance can be varied by its shape, form or material. Please, consider
these facts.
Sensing object Sensing object
Moving
Direction Moving
Direction
Sn : Sensing distance
Sa : Setting distance
(80 % of Sn)
• Setting distance(Sa)Computing Equation :
Setting distance (Sa) = Sensing distance(Sn) × 80 %
Ex) Setting distance(Sa) = 10 ㎜ × 0.8 = 8 ㎜
Mutual interference and effects of surrounding metals
• When installing more than 1 proximity sensors in parallel direction or facing each other, it
can cause the malfunction. When there are metals around the proximity sensor, it can cause
malfunctions such as abnormal return due to the existence of metals around the proximity
sensor. In order to avoid the malfunction which caused by surrounding metals, please install
it with sufficient gap from each other. (Wider than the values written in below chart)
[Unit : mm]
Metal
Metal
Model UP12RM-
4
UP12RD-
8
UP18RM-
7
UP18RD-
14
UP30RM-
15
UP30RD-
25
List
a12 —21 —30 —
b — 24 —42 —75
c12 36 18 54 30 90
d 0 11 014 015
e24 36 36 54 60 90
f24 48 42 84 90 150
Dimension
Installation hole panel cutout Dimension
✽G : Only for shield type
Cable length
: 2 m
