Hanyoung PY Series User manual

MJ09E41203
Before you use, read safety precautions carefully, and use this product
properly. The precautions described in this manual contains important
contents related with safety; therefore, please follow the instructions
accordingly. The precautions are composed of DANGER, WARNING
and CAUTION.
Do not touch or contact the input/output terminals because they may
cause electric shock.
1. This product is not for outdoor use. (It is the cause of weakening
the product durability and possible electric shock.)
2. Since this product is not designed with explosion-protective
structure, do not use it at any place with flammable or explosive
gas.
3. Do not use this product at any place with direct vibration or impact.
1. When the lens of the photo sensor is contaminated by foreign
substance, use a dry cloth to wipe off the substance. Never use
thinner or organic solvents.
2. Separate high voltage cable and power line from sensor wire. Be
cautious since using a same pipe arrangement for the wire could
cause malfunction.
3. This product is equipped with a structure (IP67), which allows
partial waterproof but do not use this product under water at all
times.
4. If the cable needs to be extended, use over 0.3 and be cautious
of a possible sudden drop in voltage.
5. When using the sensor under the light such as fluorescent lighting
or mercury lamp with high frequency, block it with a light trap and
avoid the lens from facing the light directly.
6. Malfunction can occur due to mutual interference when using the
through beam type photo sensor more than 2 pairs. Therefore,
leave a plenty of space for the mutual distance length and place the
light transmitter section and light receiver section in alternating
positions.
7. Using inductive load (relay, coil) for the output of power can cause
an immediate increase in load by twice and damage the TR of the
output of power. Therefore, set up half of the maximum load.
8. There is an over-current protection circuit within the output side that
breaks the output when the current is higher than the regular load
current. Use within the 70% of the maximum load.
9. Refrain from using the product in such locations with heavy dust or
foreign substances that can contaminate the lens since there is a
chance of malfunction.
10. The contents of the instruction manual can be modified without
prior notification or advance announcement.
11. When using the product with the methods other than those
established by the manufacturer, injury or loss in assets can occur.
12. When using the Switching Power Supply as the power source,
earth the Frame Ground (F.G) terminal and be sure to connect the
noise-eliminating condenser between OV and F.G.
Please keep the contents mentioned above as cautions for safety
since they can cause the product to breakdown.
Be cautious since the response time can differ in accordance with
the size, external appearance, or glossiness of the object to be
detected.
Total weight excludes the weight of the package box
Safety information Ordering Information
Specification
WARNING
CAUTION
DANGER
Model
Detectable object
Operating mode
Range
Response time
Power supply
Consumption
Light source
Output
Protection circuit
LED indicator
Connetor
Insulation resistance
Dielectric strength
Vibration
Impact
Ambient light
Ambient temperature
Humidity
Case protection
Material
Flying lead
Weight
NPN output type PNP output type
PY-T3N PY-T3P
PY-T3N-D PY-T3P-L PY-T3P-D PY-T3P-L
PY-TL3(Trns) PY-TL3(Trns) PY-TL3(Trns) PY-TL3(Trns)
PY-TR3N-D(Rcvr) PY-TR3N-L(Rcvr) PY-TR3P-D(Rcvr) PY-TR3P-L(Rcvr)
Opaque material over 5 mm
Dark ON Light ON Dark ON Light ON
3 m
Max. 1 ms
12 - 24 V DC 10 % (Ripple P-P : Max. 10 %)
Trns. : Max. 23 mA, Rcvr. : Max. 18 mA
Infrared lighting diode (Modulated)
NPN Open collector output PNP Open collector output
Load voltage:Max. 30 V DC Output voltage:Min. 2.0 V
Load current:Max. 100 mA Load current:Max. 100 mA
Residual voltage:Max. 1 V
Stable output current
:Max. 50 mA
Surge and reverse polarity protection
(excepting stable output)
Transmitter : Power indicator (Red LED)
Receiver : Operation (Red), Stability (Green)
Flying lead 2 m length
20 Min. (At 500 V DC mega)
1000 V AC (50/60 Hz) 1 minute
10 ~ 55 Hz, 1.5 mm Amplitude 2HR,
X Y Z directions
500 (50 G), 2 times, X Y Z directions
Sun light : 11000 lx Max.
Incandescent light : 3000 lx Max.
-25 ~ +65 (no icing)
35 ~ 85 % RH
IP 67 (IEC standard)
Lens case : PC
Trns : 3 mm, 2P
Rcvr : 3 mm, 3P (NPN type : 4P)
66 g
HEAD OFFICE
1381-3, Juan-Dong, Nam-Gu Incheon, Korea
TEL:[phone] FAX:[phone]
MAIN PRODUCTS
- DIGITAL : Temperature Controller, Counter, Timer,Speedmeter,
Tachometer, Panel Meter, Recorder
- SENSOR : Proximity Switch/Photo Electric Sensor,
Rotary Encoder, Optical Fiber Sensor,
Pressure Sensor
- ANALOG : Timer, Temperature Controller
Suffix Code
MODEL Description
PY series
Through beam (TL : Trns, TR : Rcvr)
3 m
NPN Open Collector Output
PNP Open Collector Output
Dark ON Operation
Light ON Operation
T
N
PD
L
3
PY
Detection
Range
Output
Operation
Frame
SMPS C(0.01 -0.1 /500 V)
- Noise eliminating
condenser-
Sensor
Photo Sensor
PY series
We appreciate you for purchasing HanYoung NUX Co.,Ltd
product. Before using the product you have purchased,
check to make sure that it is exactly what you ordered. Then,
please use it following the instructions below.
INSTRUCTION MANUAL

Dimension
Wiring
Control Output
Operation Mode
Indication Light
Transmitter
Receiver
(Brown)+V
(Brown)+V
(Block)Output
Load
Load
(Blue) 0 V
(Blue) 0 V
(White)Stability output
120 %
100 %
Receiver
light
Stability
level
Operation
level
ON
OFF
ON
OFF
ON
OFF
ON
OFF
Unit: mm
The output indication light (red LED) and the stability indication light
(green LED) indicate the level of the picture.
If there is the light penetration and light shield after adjusting the
optical axis, distinguish the location between the areas of stable light
penetration or stable light shield.
When setting up in the stable area, high reliability can be obtained in
regards to changes such as environmental changes after the set up.
(Brown) 12 - 24 V DC
?
?
?
?
?
?
@?he?
@?he?
@?he?
@?he?
@?he?
@?he?
?@@@@@@@@@@@@@@@f?
?@@@@@@@@@@@@@@@f?
@?he?
@?he?
@?he?
@?he?
@?he?
?
?
?@@@@@@@@@@@@@@@f?
?@@@@@@@@@@@@@@@f?
?
?
?
?
10 %
(Brown) 12 - 24 V DC
?
?
?
?
?
?
@?he?
@?he?
@?he?
@?he?
@?he?
@?he?
?@@@@@@@@@@@@@@@f?
?@@@@@@@@@@@@@@@f?
@?he?
@?he?
@?he?
@?he?
@?he?
?
?
?@@@@@@@@@@@@@@@f?
?@@@@@@@@@@@@@@@f?
?
?
?
?
10 %
(Black) OUT (Max.100 mA)
(Black) OUT (Max.100 mA)
(White) STA
(Stability idication output)
(Blue) 0 V
(Blue) 0 V
Stability indication light
Output indication light
Optical axis
Internal circuit
Protection
circuit
Transmitter
Receiver
Load
(Brown)+V
(Blue) 0 V
(Brown)+V
(Block)Output
(Blue) 0 V
Operation
Mode
Light ON
Control
Output
Sability
Output
Control
Output
Sability
Output
Dark ON
Output
Type
The stability output of power is used for checking convulsion changes
after setting the distance or level drop during use at the initial stage. If
the amount of light exceeds the operation level of 120% (stable level)
or get distant from the standard detection distance, the control output
of power will see it as being OFF and generate power. However, the
PY-T3P-D/L type has the stability indication function only and not the
stability output of power.
Protection
circuit
Internal circuit
NPN Open Collector Output
PNP Open Collector Output
NPN Open Collector Output
PNP Open Collector Output
