Haoxiang HXC-A02 User manual

ADJUSTABLE BED
（Item No.: HXC-A02)
USER’S MANUAL

Table of Contents
Remote Pairing / Trouble Shooting ………………………
Safety Instructions ……………………………………………
Parts List ………………………………………………………
Under Bed View ………………………………………………
Electronics Overview ………………………………………
Installation ……………………………………………………
Wireless Remote Control …………………………………
01
03
04
14
05
06
12

Safety Instructions
This product is designed to be used by an adult. Do not allow children to operate this bed without adult
supervision. Immediately dispose of all packing materials as they can pose a smothering risk to children and pets.
Injury could occur if children or pets are permitted to play on or under the bed.
Attention:
In-Home use only:
The control box, motors, and remote (except battery compartments) should not be opened or tampered with.
Opening or tampering with these components without authorization will void the warranty, and may cause
danger
Pacemaker Notice:
This bed base is intended to be used only as described in this manual. Do not use any accessories/attachments
that are not recommended by the manufacturer. Close supervision is required when the bed base is used by or
near children, convalescents, or disabled persons.
Unplug the base from the electrical outlet before servicing any part of the base.To prevent the risk of electric
shock, always unplug the base before cleaning. For your safety, ensure the base is in a flat position with all
motors turned off and disconnected from the power source prior to servicing. Keep the power cord away from
heated surfaces.
Thank you for purchasing our adjustable bed base. For your safety, please read all instructions carefully
before using this adjustable bed base. Save this instruction for future reference.
If the power cord or plug becomes damaged, or if the bed base is wet or not working properly, stop using the bed
base and contact customer service.
Children and Pets:
Electrical Safety: Connect to a surge protector (not included).
Safety Disclaimer
Please ensure you connect the base properly to the power supply. Any incorrect power connection may cause
electric shock or fire. For optimal safety, your adjustable bed should be plugged into a surge protector (not
supplied with this adjustable bed). Always unplug this adjustable bed frame from the electrical outlet before any
cleaning or maintenance of the bed frame. To safely disconnect, remove the plug from the outlet. Keep cord away
from heated surfaces. Use only indoors.
This product are designed exclusively for in-home use.
Do not use this base with oxygen therapy equipment or near explosive gases.
This bed base contains neodymium magnets which may interfere with magnetic fields of devices such as
pacemakers, ICDs etc. Some pacemakers may falsely interpret the optional massage vibrations as movement or
exercise. The owner of such medical devices should consult their physician before using this product.
01

02
The lift motors are not designed to operate continuously for more than (2) minutes in an (18) minute time period.
Attempting to circumvent or exceed this rating will shorten the life expectancy of the product and may void the
warranty.
The massage function will emit a noticeable tone during operation. As the massage intensity level is increased,
the tone will intensify. The volume of this tone is directly related to the location environment. For example, when
demonstrated in a show room, the surrounding environmental noise will cover some of massage noise. However,
when installed in a home setting with wooden floors, carpeted or not, the massage volume will be more
noticeable. In normal base operation, the support legs of the base will create a contact noise with floor. When
entering, exiting, or shifting weight on the base, this contact noise may be louder as the legs make contact. This is
normal.
Fabric Care:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Product Ratings:
Weight Limits:
Acoustics (This model do not have message function):
To prolong the life of your fabric, protect it from direct sunlight whenever possible. For spot cleaning, wipe area
with a light damp sponge or vacuum with a soft brush attachment to remove particles. Keep at a minimum of
30cm (12 inches) away from direct heat sources. For deeper cleaning, blot liquid spills with a clean dry cloth. Wipe
with a clean cloth dampened with warm water. Do not moisten excessively. A soft bristle brush may be used to
remove ingrained soil. Avoid scratching by brushing gently. Wipe with a clean cloth dampened with warm water to
remove residues. Dry in a shaded area away from direct heat. If persistent marks remain visible after cleaning,
seek professional advice.
This product is not rated to support weights exceeding 700 pounds including the mattress and bedding. The base
will structurally support this weight, provided it is evenly distributed across the bed base. The adjustable base is
not designed to support or lift this amount in the head or foot sections alone. Exceeding this weight restriction
could damage the bed and/or cause injury and will void the warranty.
FCC Compliance:
To comply with the FCC RF exposure requirements, no change to the antenna or the
device is permitted. Any change to the antenna or the device could result in the device
exceeding RF exposure requirement and void user's right to operate the device.
During the use, all lift or dwon should be powered by electric. Please DO NOT lift the base by hand,
both for head and foot. This may cause danger and damage to the product.
No power handling:
Safety Instructions

Parts List
Ensure you have received all the parts listed below before discarding
the packing materials.
03
A) B) C) D)
E) F)
Long support leg X 6 pcsShort support leg X 6 pcs Power line x 1 pcs Adapter x 1 pcs
G)
Motor plug x 4pcs clip x 4 pcs Remote x 1 pcs
H)
mattress retainer x 1 pcs
I) J) K)
Control box x 1 pcs
HEAD motor x 1 pcs FOOT motor x 1 pcs
(2 pcs already fixed) (2 pcs already fixed)

Under Bed View
Control box
Head motor Foot motor
Corner support legs Middle support legs
04

Not to scale, only for illustration purposes.
Read all illustrations and instructions before beginning the
installation process.
Electronics Overview
05

Installation
STEP 1: Remove packing materials, and open the base as below pictures.
Two adult needed , please handle with care.
STEP 2: Fix the middle support leg base like below pictures.
When fully fixed, the buckle
will pop up and lock the base
06

Installation
STEP 3: Fix the support legs.
4” 7” 11”
A
+
BA B
Three levels for the height
are available, please choose
the suitable one
Screw the legs on the base
(four corners)
Screw the legs on the base
(two middle)
Important Notice: When you choose the height of the legs, please
make sure the motors could fully leave the ground.
07

Installation
STEP 4: Install the motors to the stand
Use motor plug to cross
the holes on motor and
stand.
Same way for foot motor
E)
Notice: The side with lable
should towards to your face
F)
Insert the clip into the
holes on the motor plugs,
make sure it will not come
out
Same way for foot motor
08

STEP 5: Connect power supply
Installation
Part 1-adapter connect with power line
D) Adapter C) power line
Part 2-control box connect with adapter
D) AdapterPlease make sure the
directions matched
H)Control box
Lock it when fully insert
09

Installation
Part 3-motors connect with control box
Take out the plug protector as
picture shows
Important Notice: When plug the motor power line into the control box,
please make sure the logo is MATCHED with the HEAD or FOOT logo on
the motors
Head motor Foot motor
Close out the plug protector as
picture shows
10
1 2
34
Plug the motor power line into the
control box with care

11
Insert the mattress retainer into the hooks at the foot
of the base. Slide the mattress retainer into place
Ensure it is securely tightened.
STEP 7: Install the mattress retainer
STEP 6: Turn over the base with care
After finish connecting all power supply, please turn over the base
carefully.
Please do not lay the base on its side to prevent damage to the fabric
or legs.
*Please check carefully and make sure no power lines was under the
legs before you use it.
Installation
Head Foot

Wireless Remote Control
Head Up
Foot Up
Remote Light
Memory A
Head Down
Foot Down
Flat Preset
Memory B
Remote overview
12

The HEAD UP button
raises head section of the base.
The one touch Light button turns
the remote flashlight on/off.
The one touch MEMORY B preset
button raises the head and foot to
an optional preset position B.
The one touch FLAT button returns
the head and foot sections to a
horizontal position.
Wireless Remote Control
The FOOT UP button
raises the foot section of the base
The one touch MEMORY A preset
button raises the head and foot to
an optional preset postion A.
The HEAD DOWN button
lowers head section of the base
The FOOT DOWN button
lowers the foot section of the base
Press the button and hold for 5 seconds
to memory the position
Press the button and hold for 5 seconds
to memory the position
P1
P2
FLAT
Adjust features
13

Trouble shooting
If one or more functions of the bed base have stopped operation, please check the bed
as below:
Check under the bed base to verify the wired connection are secure and there are no
cords or bedding obstructing the movement of the base.
Check to see if the bed base is connected to the power supply correctly. Make sure the
powder suppy is connected to the outlet.
Ensure the batteries in the remote are new and operable.
If the powder supply is working correctly, unplug the base for 1 hour to reset the
electronic components.
After the electronic components have been reset, follow the REMOTE PAIRING steps to
reset the base.
If the issue is not resolved by following the instructions above, please contact the
retailers for assistance.
Remote Pairing
When first time use, we need to pair the remote with control box. Make sure there is
power supply both for base and remote when you process the pairing.
Load the AAA batteries into the remote (battery not provided).Press the head down
button, foot up button and the small blue button on the control box power line in the
same time. When there is a warning tone, means pairing successfully.
