Argos Home Canterbury Dressing Table 483/2418 User manual

Canterbury DRESSING TABLE
Assembly Instructions - Please keep for future reference 496/3923
501/8798
483/2418
Dimensions
Width - 101.6cm
Depth - 42.5cm
Height - 80.8cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
71933 Version C Date 14/06/2016
max.
lbs
kg110
242
lbs
kg30
66
lbs
kg3
7

1
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• Check you have all the
components and tools listed on
the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to lay out the parts before
starting.
• During assembly, do not stand
or put weight on the product,
this could cause damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the use
of power drivers for
inserting screws, as
this could damage
the unit. Only use hand screw
drivers.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
Skin contact: Remove
contamination by washing with
soap and water. This procedure
should also be followed prior to
eating and drinking.
Eye contact: Rinse immediately
with clean water for 15 minutes
and seek medical advice.
If swallowed: Seek medical
advice immediately.
Glue safety - Take care when using glue, please follow the advice below

Components - Panels
Please check you have all the panels listed below
2
If you have damaged or missing components, call the
Customer Helpline: Argos = 0345 6400800
FA Left side panel (78.2 x 38cm)
H
Right side panel (78.2 x 38 cm)
LB
Top panel (101.6 x 41.6 cm)
A76319 Profile side (38.0 x 2.5 cm)
B76320 Profile side (38.0 x 2.5 cm)
SBack panel (91.8 x 29.5 cm)
FB Side panel L / R (48.5 x 34.1 cm) x2
G76322 Profile side (39.2 x 2.5 cm) x2
H76321 Profile front / back (59.2 x 2.5 cm) x2
GD
Divider panel
( 12.9 x 37.8 cm) C
07065
Drawer bottom
(42.8 x 29.7 cm) x2
D00256 Right drawer side (30 x 9.5 cm) x2
E00257 Left drawer side (30 x 9.5 cm) x2
F02629 Drawer back (41.7 x 9.5 cm) x2
EL
Drawer front (44.6 x 12.2 cm) x2
LC
Top panel (60 x 40 cm)
SA
Front / back panel (51.1 x 29.5 cm) x2
UC Shelf (91.8 x 37.9 cm)

3
Please check you have all the fittings listed below
Dowel (ø5 x 30 mm) x22
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Glue x1
Cam bolt x12
Floor Glider x4
Components - Fittings Chair Box 2 of 2
Tools required
Cross head screwdriver
(medium & large)
20203
31513 31687
33204
63008
Ruler
01 02 03 04 05 06 07 08 09 0 100 110 120 130 140 150
01 23 45 6
Eye protection
(when using a
hammer or glue)
Hammer
wooden block
22601
Cam x12
Wedges x4
Flathead screwdriver
(medium) Leveler

4
Assembly Instructions Chair Box 2 of 2
Step 1
Step 2
FB x 2
SA x 2
FB x 2
LC
Fittings you will need for this step:
Dowel
# 20203 X12 Cam
# 31687 X12
Insert dowels and cam
Insert dowels 20203 into
outer holes on the ends
of side panel FB and
front / back panel SA .
Then place cam 31687
into the large holes on
side panel FB and front /
back panel SA . Arrow
facing the edge of the
panel.
Insert cam bolts
Insert cam bolts 31513
into the side and top
panel FB and LC .
Cam bolts must be
screwed down flush.
Fittings you will need for this step:
Cam bolt
# 31513 X12

5
Assembly Instructions Chair
Step 3
Step 4
Gathering profiles
Insert dowels
Insert dowels 20203 into
holes on the gathering
profiles. Use glue 22601
as shown.
Add one small drop of
glue per hole.
Glue
# 22601 X1
G
G
G
GH
H
H
H
max
9
mm
Fittings you will need for this step:
Wedges
# 33204 X4
Fittings you will need for this step:
Dowel
# 20203 X10
Top
Bottom
Insert wedges 33204 into
slots on the angle ends of
profile side x2 Gand pro-
file front/back x2 H.
Use a hammer.

Step 6
Assembly Instructions Chair
6
Step 5
LC
SA
FB
FB
SA
H
H
G
G
Fittings you will need for this step:
Glue
# 22601 X1
Attaching side panels
Press the side panels FB
to the front / back panels
SA . Make sure the
finished edge is facing to-
ward the front and that the
unfinished side is facing
toward the bottom of the
case.
Tighten the cams with a
screwdriver, as shown.
Attaching panels
Add glue into holes and
then push the profile
down as it reaches the top
panel LC .
Add one small drop of
glue per hole.

Assembly Instructions Chair
7
Step 7
Step 8
FB
FB
SA
SA
LC
FB
SA
SA
FB
Fittings you will need for this step:
Floor glider
# 63008 X4
Attaching top panel
Place the side and front/
back down to the top
panel LC . Make sure the
finished edge is facing
toward the front and that
the unfinished side is
facing toward the bottom
of the case.
Tighten the cams with a
screwdriver, as shown.
Attaching floor gliders
Attach floor gliders 63008
in the bottom edge of the
side panels FB . Use a
piece of wood between
hammer and floor glider.

Please check you have all the fittings listed below
Dowel (ø5 x 30 mm) x16
Connector Bolt (ø7 x 50mm) x2
Drawer fastener x8
Machine screw (M4 x 9mm) x4
Bushing (ø9 x 15mm) x4
Machine screw (M4 x 23mm) x2
Leveller x4
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Flat head screw (ø5,8 x 9mm) x8
Endbolt x4
Flat head screw (ø6,3 x 27mm) x4
Cam bolt x14
Components - Fittings Table Box 1 of 2
Tools required
Cross head screwdriver
(medium & large)
20203 20228 22005
25610 26020
26033
26214 26232
31513
31561 31631
31666
62403 81040
97642
41404
Ruler
01 02 03 04 05 06 07 08 09 0 100 110 120 130 140 150
01 23 45 6
Eye protection
(when using a
hammer or glue)
Drawer runner x4
Allen key x1
Hammer
wooden block
Large cam x14 Small cam x4
Handle x2
Flathead screwdriver
(medium) Leveler
8

Assembly Instructions Table Box 1 of 2
Step 9
9
FA
H
Insert leveler
Insert bushing 22005 into
the ends of right side pan-
el Hand left side panel
FA .
Use a hammer.
Insert leveler 62403 into
bushing 22005 .
Bushing
# 22005 X4 Leveller
# 62403 X4
Fittings you will need for this step:

Assembly Instructions Table
Step 10
10
H
FA
Insert dowels and cam
Insert dowels 20203 into
outer holes on the ends
of left side panel FA and
right side panel H .
Then place large cam
31666 into the large holes
on left side panel FA
and right side panel H .
Arrow facing the edge of
the panel.
Dowel
# 20203 X4 Large cam # 31666 X4
Fittings you will need for this step:

Assembly Instructions Table
Step 11
11
FA
H
1.
2.
Attaching drawer runners
Extend drawer glide
41404 . Place flat head-
screw 26020 through the
correct holes at the back
of the drawer slide, into
the holes on the left side-
panel and right side panel
FA + H .Tighten screw
but do not over tighten.
Close slide until the front
hole is visible through
the oval slot on the glide.
Place flat head screw
26020 through the hole
in the slot and into the
holes on the side panels.
Tighten screws but do not
over tighten.
Fittings you will need for this step:
Flat head screw
# 26020 X4 Drawer runner # 41404 X2

Assembly Instructions Table
Step 12
Step 13
12
FA
H
UC
SGD
Insert cam bolts
Insert cam bolts 31513
into left side panel FA
and right side panel H .
Cam bolts must be
screwed down flush.
Insert dowels and cam
Insert dowels 20203 into
outer holes on the ends of
shelf UC and back panel
S and divider panel GD .
Then place large cam
31666 into the large holes
on shelf UC and back
panel S and divider panel
GD .
Arrow facing the edge of
the panel.
Fittings you will need for this step:
Fittings you will need for this step:
Cam bolt
#31513 X4
Dowel
#20203 X12 Large cam #31666 X10

Assembly Instructions Table
Step 14
13
2.
1.
GD
Attaching drawer runner
Extend drawer glide
41404 . Place flat head-
screw 26020 through the
correct holes at the back
of the drawer slide, into
the holes on divider panel
GD . Tighten screw, but
do not over tighten.
Close slide until the front
hole is visible through
the oval slot on the glide.
Place flat head screw
26020 through the hole
in the slot and into the
holes on the divider panel.
Tighten screws but do not
over tighten.
Repeat on the other side
of divider panel GD .
Fittings you will need for this step:
Flat head screw
# 26020 X4 Drawer runner
# 41404 X2

Assembly Instructions Table
Step 15
14
Step 16
Attaching divider panel
Press down divider panel
GD towards the top panel
LB . Make sure the
finished edge is facing
toward the front .
Tighten cams with a
screwdriver, as shown.
LB
LB
GD
Insert cam bolts
Insert cam bolts 31513
into top panel LB . Cam
bolts must be screwed
down flush.
Fittings you will need for this step:
Cam bolt
# 31513 X6

Assembly Instructions Table
Step 17
15
UC
FA
S
H
Unfinished face
Attaching panels
together
Place back panel S and
shelf UC between side
panel H+ FA . Make
sure the unfinished face
of Sis facing backwards.
Insert end bolt 31561 .
Tighten cams with a
screwdriver, as shown.
Fittings you will need for this step:
End bolt
# 31561 X4

16
Assembly Instructions Table
Step 18
Finished end
FA
UC
H
S
A
B
Fittings you will need for this step:
Flat head screw
# 26033 X4
Attaching side profilest
Inset flat head screw
26033 into holes of side
panel FA + Hand attach
side profile A + B .
Finished end must be
facing forward.

Assembly Instructions Table
Step 19
17
FA
SH
UC
LB
Fittings you will need for this step:
Connector Bolt
# 25610 X2 Allen key # 97642 X1
Attaching top panel
Place the cam bolts from
top panel LB into the
end holes on side panel
FA + H . Tighten cams.
Install connector bolt
25610 into holes on shelf
UC , using the allen key.

18
Assembly Instructions Table
Step 20
Step 21
E
D
EL x2
x2
E
F
D
Fittings you will need for this step:
Small cam
# 31631 X4 Cam bolt # 31513 X4
Fittings you will need for this step:
Drawer fasteners
# 20228 X8
Attaching drawers
Place small cam 31631
into the holes in left and
right drawer side D+
E . Arrow facing the edge
of the panel.
Screw the cam bolt
31513 in the drawer front
EL .
Attaching drawer
Align holes at back of the
drawer sides, D + Ewith
the holes on the draw-
er back. Make sure the
groove is facing inside of
the drawer.
Tap drawer fasteners
20228 into place with a
hammer.

Assembly Instructions Table
Step 22
19
Step 23
x2
x2
EL
F
D
E
C
F
D
E
C
Attaching drawer bottom
Press the drawer bottom
Csmoothly in the
grooves (finished side up).
Attaching drawer front
Attach the drawer front
EL by placing dowels
and cam bolt in the
correct holes. See the
detail drawing.
Tighten the cams.
