Harbinger V2300 Series User manual

V2300 SERIES
OWNER’S MANUAL
V2312 V2315 V2318S

V2300 SERIES OWNER’S MANUAL 2
TABLE OF CONTENTS
WELCOME
VARI V2312 and V2315 .......................................................3-5
VARI V2318S .................................................................6-7
Specifications .................................................................8-9
Safety ..................................................................... 10-11
Warranty/Customer Support ................................................... 12
The Harbinger VARI 2300 Series Powered Speakers each combine at least 2000 watts of peak power with sound optimizing DSP and versatile inputs,
outputs and controls, delivering premium sound reproduction with great flexibility.
V2312 12-inch 2-way Powered Speaker with Bluetooth Audio Input
- 12-inch speaker plus high precision high frequency compression driver
- Bluetooth audio input, dual mic/instrument inputs, dedicated stereo line input and aux input -- all available simultaneously
- DSP providing selectable Voicings, easily adjustable Bass and Treble, a transparent and dynamic limiter, and high precision crossover for extremely
accurate, high fidelity sound
- Innovative Smart Stereo™ capability, with easy volume and tone control for both speakers from the master unit
- Versatile cabinet allowing free-standing, pole mounted, and lay-flat floor monitor placement
V2315 15-inch 2-way Powered Speaker with Bluetooth Audio Input
- All the same DSP, input, output, control and usage capabilities as the V2312
- A larger 15-inch speaker, delivering additional volume
V2318S 18-inch Powered Subwoofer with Easy-Roll Casters
- Add a V2318S to bring high impact to your powered speaker setup, compatible with V2312, V2315 and all other powered speakers
- DSP provides a transparent and dynamic limiter, and high precision crossover for extremely accurate, high fidelity sound
- Includes adjustable crossover and phase for optimal pairing with any powered speakers

V2300 SERIES OWNER’S MANUAL
3
QUICK START GUIDE: SINGLE V2312/V2315
SETTING UP / HELPFUL TIPS
• Position the VARI speaker in the desired location, and ensure the speaker
is stable.
• Make sure the Power Switch is off.
• Turn Channel 1, 2, and 3 knobs to minimum.
• Turn Bass and Treble to center/straight up.
MAKING THE CONNECTIONS
• Connect sources to Channel 1, 2 and 3 input jacks as desired. (All these
input jacks can be used at once, along with Bluetooth audio input.)
CHECK SWITCHES
• Check that Mono / Stereo Master / Link In switch
is set to Mono.
• Check that Channel 1 and Channel 2 switches
match sources: Mic for microphones, Guitar for
acoustic guitar or pedalboard output, Line for mixers,
keyboards and other electronics.
POWERING UP
• Power on any devices connected to input jacks.
• Turn up the output volume of all sources.
• Turn Channel 1, 2 and 3 knobs to desired levels.
BLUETOOTH AUDIO INPUT
• From your Bluetooth audio source device, look for V2312 or V2315 and
select it.
• See next page for Bluetooth Troubleshooting in case of difficulty.
FRONT LED LIGHT
• Check that rear panel button for FRONT LED is pressed in (On/Limit
position)
• When front LED lights red, limiter is being triggered, and Channel 1, 2,
and 3 knobs may need to be turned down
FOR FLOOR MONITOR USE
• Press rear panel VOICINGS button to light Floor Monitor/Wall LED.
VARI Series speakers can be used as Main Speakers
or Monitor Speakers.
Speaker stand not included
Main
Floor Monitor

V2300 SERIES OWNER’S MANUAL 4
SMART STEREO™ WITH V2312/V2315
A pair of VARI 2312 or 2315 speakers can operate together as a Smart
Stereo™ system, giving you control of the sound and volume of both
speakers from the first master speaker, and optimally distributing all audio
inputs to both speakers for rich stereo sound.
Channel 1 and 2 inputs are routed mono to both VARI’s, while all Channel 3
inputs are routed in split stereo to the VARI’s.
1Connect all inputs and make all sound settings on the first (left) unit only.
The second (right) unit’s inputs and controls are all disabled when it is
set to Link In.
2Set the switch on first unit to Stereo Master.
3Set the switch on second unit to Link In.
4Connect an XLR (microphone) cable from the first unit’s OUT jack to the
second unit’s LINK IN.
1
2 3
4
BLUETOOTH®TROUBLESHOOTING
These steps should resolve any Bluetooth trouble you may encounter:
• Power off the V2312 or V2315 and leave it off
• On your Apple iOS device
1. Open Settings app, select Bluetooth
2. If V2312 or V2315 is listed under MY DEVICES, touch info button, tap
to Forget This Device
3. Turn off Bluetooth, wait 10 seconds, turn on Bluetooth
• On your Android device
1. Open Settings, select Bluetooth
2. If V2312 or V2315 is listed under Paired Devices, touch gear Icon, and
tap to Unpair
3. Turn off Bluetooth, wait 10 seconds, turn on Bluetooth
• Then power on your V2312 or V2315, and Bluetooth LED should flash
• You should now be able to connect to V2312 or V2315 via Bluetooth

V2300 SERIES OWNER’S MANUAL
5
V2312/V2315 BACK PANEL
1VOICINGS
Pressing the button selects from the available voicings (tunings) for
different applications:
- Standard: for general use including music playback
- Vocal Boost: for public speaking, may also be helpful for solo
performers who are singing along with acoustic guitar
- Live: for live band main PA speakers
- Floor Monitor/Wall: for enhanced clarity and reduced feedback
potential for floor monitors, also may be helpful to avoid excessive bass
from wall mounted speakers
2CHANNEL 1 AND 2 KNOBS
These knobs set the volume for the inputs below them
3MIC/GUITAR/LINE SWITCHES
Set these to match the type of source connected to the input below them
- Mic: for microphones, or line level sources with low output volumes
- Guitar: for acoustic guitar or guitar pedal board
- Line: for line level sources
4CHANNEL 1 AND 2 INPUT JACKS
Connect XLR or 1/4-inch cables
5CHANNEL 3 KNOB
Sets the volume for all the inputs below, including Bluetooth audio, aux
and line inputs
6BLUETOOTH AUDIO INPUT
Bluetooth audio input is automatically enabled each time you turn the
speaker on, will automatically reconnect to the previous Bluetooth audio
source if it is available, and will otherwise be available for Bluetooth
pairing from a source audio device such as a smartphone.
- To pair, look for V2312 or V2315 from your Bluetooth audio
source device.
- LED is lit solid when currently paired, blinking when available for
pairing, and off if Bluetooth has been disabled by a press of the
Bluetooth Off button.
- On/Pair button forces any currently connected Bluetooth audio source
to disconnect, and makes the speaker available for pairing.
- Off button disables Bluetooth. (Bluetooth will be re-enabled next time
you turn power off and on, or if you press the On/Pair button.)
7AUX INPUT
Audio from smartphones, computers and other consumer audio devices
can be connected here
8BALANCED LINE INPUTS
Balanced or unbalanced line level sources can be connected here
9BASS AND TREBLE KNOBS
Adjust the sound of your speaker
10 MONO / STEREO MASTER / LINK IN SWITCH
- Mono: This speaker will output mono audio, and send mono audio to
the OUT jack so it’s available for any other speaker or sound system.
- Stereo Master: This speaker will operate as the master speaker of a
Smart Stereo(TM) pair. Use a mic cable to connect this speaker’s OUT
to the LINK IN jack of a second speaker of the same type. All inputs
should be connected to the first master speaker, which will also set the
volume and tone of both speakers.
- Link In: Use this setting for the second speaker of a Smart Stereo(TM)
pair. The audio from the LINK IN will be routed directly to the power
amp and speaker, with all other inputs and controls being ignored. This
can also be used to accept mono audio from a previous speaker, with
that previous speaker determining volume and tone.
11 OUT JACK
Configured by 10 switch
- Mono: sends out mono audio
- Stereo Master: sends out right audio, for second speaker’s LINK IN
- Link In: sends out the same audio received at the LINK IN jack
12 LINK IN JACK
Activated only when 10 switch is set to LINK IN
13 FRONT LED SWITCH
- On: Front LED is lit white when power is on
- On/Limit: LED lights red when limiter is active, and otherwise is lit white
If limiter is continuously or frequently active, turn down Channel 1, 2 or 3
knobs to reduce volume
14 Connect power cable here.
15 If the speaker will not power on and you suspect its fuse may have blown,
turn off the power switch, and open the fuse compartment using a small
flat blade screwdriver. If metal strip in fuse is broken, replace with T5AL
250V fuse.
16 Switches the power on and off
1
2
3
4
5 9
10
11
16
12
14 15
13
6
7
8

V2300 SERIES OWNER’S MANUAL 6
V2318S QUICK START GUIDE
SETTING UP / HELPFUL TIPS
• Position the VARI speaker in the desired location, and ensure the speaker
is stable.
• Make sure the Power Switch is off.
• Make certain Level knob is turned down.
MAKING THE CONNECTIONS
• Plug connections to Input 1 and 2 from Outputs of signal source.
POWERING UP
• Turn on the power to any devices plugged into Input 1 or Input 2.
• Power ON the speaker.
• Slowly turn the Level knob to 12 o’clock.
• Slowly turn up the source volume to the desired level.
SIGNAL/LIMIT
• The SIGNAL/LIMIT LED will light up WHITE when the speaker is receiving
a signal. If the limiter is triggered, the LED will turn RED and the MASTER
VOLUME should be turned down.
LINKING MULTIPLE SUBWOOFERS
• If linking multiple subwoofers, plug the Line Output connection of the first
subwoofer to the INPUT connection of second subwoofer, and continue
the daisy chain to the next speaker.
• Switch Output Crossover Off.
• Turn the Power On in the order of the audio signal to prevent unwanted
“pops”. First On / Last Off.
HOOK UP DIAGRAMS
SMART STEREO™WITH VARI V2318S
To operate a pair of VARI V2312 or V2315 speakers in Smart Stereo™
along with VARI V2318S sub(s):
• Connect your main stereo audio source directly to VARI V2318S inputs
• Set V2318S OUTPUT crossover to 120Hz
• Connect VARI V2318S OUTPUT 1 to Channel 3 LEFT(MONO) input on
first V2312 or V2315 (this is the speaker you have set up as the Stereo
Master unit)
• Connect VARI 2318S OUTPUT 2 to Channel 3 RIGHT input on that
same speaker
• Note that volume for the V2318S is set from its own knob, it is not affected
by the Stereo Master unit’s volume
• Note that you can use the other inputs on the Stereo Master unit, but they
will not be routed through the sub

V2300 SERIES OWNER’S MANUAL
7
V2318S BACK PANEL
1INPUTS 1 AND 2
These combo inputs are designed for either TRS or XLR balanced plugs at
line level, either from a mixer or another speaker. The source can be either
mono or stereo.
2OUTPUTS 1 AND 2
These outputs feed through the signal(s) received from the input(s). If the
crossover is not switched off, the output signal(s) will be altered by the
crossover, which removes audio below the selected frequency, to allow
your speakers that are fed by the sub to focus all their energy and fidelity
on reproducing signals above the selected frequency.
3OUTPUT CROSSOVER
This switch controls the high precision DSP crossover. Select 120Hz or
90Hz to have the audio below the selected frequency filtered out of the
output signals. Select Off to disable the crossover, and output the same full
range audio received at the outputs.
4PHASE
This switch lets you “flip” (reverse) the phase on the power amp 180
degrees when needed to match the polarity of speakers that may operate
with opposite polarity to the V2318S, or to account for a phase difference
due to the physical distance between the sub and the full range speakers
it is operating with. When set to 0, phase is uneffected. When set to 180,
the phase of the power amp and internal speaker will be reversed.
5FRONT LED
- ON: front LED lights white when power is on.
- ON/L: front LED lights red when limiter is triggered, and otherwise is lit
white when power is on.
- OFF: front LED is disabled.
6POWER LED
Lights when power is on.
7SIGNAL/LIMIT LED
Lights white when the speaker is receiving signal, and red when the limiter
is triggered. If the limiter is triggered continuously, the 8Level knob
should be turned down.
8LEVEL KNOB
Sets volume of internal speaker.
9IEC POWER INPUT
Plug in the IEC AC cable here.
10 FUSE CARRIER
If the speaker will not power on and you suspect its fuse may have blown,
turn off the power switch, and open the fuse compartment using a small
flat blade screwdriver. If metal strip in fuse is broken, replace with T6.3AL
250V fuse.
11 POWER SWITCH
Turns the VARI subwoofer on or off.
1
2
3 4
5910 11
6 7
8

V2300 SERIES OWNER’S MANUAL 8
HARBINGER VARI Series V2312 V2315
Amplifier
DSP
Selectable Voicing (Standard, Vocal Boost, Live, Floor
Monitor/Wall) and Bass and Treble knobs all control the
internal DSP to customize the sound
Selectable Voicing (Standard, Vocal Boost, Live, Floor
Monitor/Wall) and Bass and Treble knobs all control
the internal DSP to customize the sound
Limiter Transparent, dynamic DSP limiter for ideal sound quality
and system protection at maximum volume
Transparent, dynamic DSP limiter for ideal sound quality
and system protection at maximum volume
Smart Stereo
A pair of speakers can be connected for unified volume
and tone control from the first master speaker, with
optimal distribution of mono and audio signals between
both speakers
A pair of speakers can be connected for unified volume
and tone control from the first master speaker, with
optimal distribution of mono and audio signals between
both speakers
Input 1
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
Input 2
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
Input 3
Stereo Line: Left/mono and right 1/4-inch TRS
balanced/unbalanced compatible audio line inputs
Aux: 1/8-inch mini TRS unbalanced input (-10dB)
Bluetooth Audio: with On/Pair and Off buttons plus LED
Stereo Line: Left/mono and right 1/4-inch TRS
balanced/unbalanced compatible audio line inputs
Aux: 1/8-inch mini TRS unbalanced input (-10dB)
Bluetooth Audio: with On/Pair and Off buttons plus LED
Link In XLR balanced +4dBv audio input XLR balanced +4dBv audio input
Out Jack XLR balanced +4dBv audio output XLR balanced +4dBv audio output
Power Output 2000 Watts Peak 2000 Watts Peak
Bass EQ Knob +/-12dB Shelf, 100Hz +/-12dB Shelf, 100Hz
Treble EQ Knob +/-12dB Shelf at 10kHz +/-12dB Shelf at 10kHz
Volume volume control per channel volume control per channel
Power Input 115V/60 Hz 115V/60 Hz
Features
Removable AC Power Cord Removable AC Power Cord
Front LED, configurable to indicate power or power/
limiter
Front LED, configurable to indicate power or power/
limiter
Voicing button and 4 voicing indicator LEDs Voicing button and 4 voicing indicator LEDs
Speaker
Type 12˝ 2-way vented design 15˝ 2-way vented design
Frequency Response 40-20K Hz 40-20K Hz
Max SPL@1M 126dB 127dB
HF Driver Compression Driver, 8 Ohm Compression Driver, 8 Ohm
LF Driver 12˝ Driver, 4 Ohm 15˝ Driver, 4 Ohm
Cabinet Polypropolene, with rubber surfaced handles and feet Polypropolene, with rubber surfaced handles and feet
Grille 1.2mm steel 1.2mm steel
Suspension Points V2312 Is Not Designed For Suspension V2315 Is Not Designed For Suspension
Pole Mount 35mm stand pole with M6 screw 35mm stand pole with M6 screw
Product Dimensions 14.2” x 14.2” x 24.1” 16.5” x 15.0” x 27.1”
Dimensions and
Weights
Packaging Size 18.1” x 18.1” x 28.1” 20.1” x 19.5” x 31.1”
Net Weight 35 pounds 41 pounds
Gross Weight 45 pounds 50 pounds
V2312/V2315 SPECIFICATIONS

V2300 SERIES OWNER’S MANUAL
9
HARBINGER VARI Series V2318S
Amplifier
Inputs 2 XLR / TRS LINE input
Outputs 2 XLR line output
Power Output 600 watts RMS @ 8 Ohms / 2400 watts Peak
Volume Main volume control
Power Input 100-120 Volt ~60Hz 500W power draw
Features
Class D+ switching power design
Defeatable front LED with selectable power/limiter indication
Rear panel power and signal/clip LEDs
High precision digital crossover
Transparent, dynamic DSP limiter
Speaker
Type Active vented subwoofer
Frequency Response 35-150Hz
Max Output SPL@1M 134dB
Impedance 8 Ohm
Woofer 18˝ subwoofer
Cabinet Plywood with black Polyurea painted finish
Grille 1.5mm steel
Pole 35mm stand pole
Features Rubber corner edge protection
(4) Easy-roll, lockable, rotating 3-inch casters
Dimensions and Weights
Unit Size 24.4 x 20.5 x 26.0 inches (without casters)
Package Size 28.3 x 24.4 x 32.1 inches
Unit Weight 86 pounds
Package Weight 99 pounds
V2318S SPECIFICATIONS

V2300 SERIES OWNER’S MANUAL 10
IMPORTANT SAFETY INSTRUCTIONS
Please keep this instruction manual for future reference and for the duration of
owning the VARI powered loudspeaker. Please carefully read and understand
the instructions inside this owner’s manual before attempting to operate your
new powered loudspeaker.
This instruction manual includes essential safety information regarding the
use and maintenance of the amplifier. Take special care to heed all warning
symbols and signs inside this manual and those printed on the amplifier on the
back of the loudspeaker.
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE AMPLIFIER
TO WATER/MOISTURE, NOR SHOULD YOU OPERATE THE AMPLIFIER
NEAR ANY WATER SOURCE.
The exclamation point triangular symbol is intended to alert the user to the
presence of important operating and maintenance(servicing) instructions in
the user manual accompanying the Amplifier.
The lightning flash with an arrow triangular symbol is intended to alert the
user to the presence of non-insulated “dangerous voltage” within the product’s
enclosure, and may be of sufficient magnitude to constitute a risk of electric
shock.
WARNING
Handle the power supply cord with care.
Do not damage or deform it as it may cause electric shock or malfunction
when used. Hold the plug attachment when removing from wall outlet. Do not
pull on the power cord.
IMPORTANT SAFETY PRECAUTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all Instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions. DO NOT turn on the VARI amplifier module
before connecting all other external devices.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of
the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachment/accessories specified by the manufacturer.
12. Use only the cart, stand, tripod, bracket or table specified
by the manufacturer, or sold with the apparatus. When
a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15. POWER SOURCES – This product should be operated only from the type
of power source indicated on the rating label. If you are not sure of the
type of power supply to your home, consult your product dealer or local
power company.
16. WALL OR CEILING MOUNTING – The product should never be mounted
to a wall or ceiling.
17. Where the mains plug or an appliance coupler is used as the disconnect
device, the disconnect device shall remain readily operable.
18. OBJECT AND LIQUID ENTRY – Care should be taken so that objects do
not fall and liquids are not spilled into the enclosure through openings.
19. Water and Moisture: This product should be kept away from direct contact
with liquids. The apparatus shall not be exposed to dripping or splashing
and that no objects filled with liquids, such as vases, shall be placed on
the apparatus.
20. Keep the speaker system out of extended or intense direct sun light.
21. No containers filled with any type of liquid should be placed on or near
the speaker system.
22. SERVICING – The user should not attempt any service to the speaker
and/or amplifier beyond that described in the operating instructions. All
other servicing should be referred to qualified service personnel.
23. VENTILATION – Slots and openings in the amplifier are provided for
ventilation and to ensure reliable operation of the product and to protect
it from overheating. These openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should not be placed in a built-in
installation such as a bookcase or rack.
24. Protective earthing terminal: The apparatus should be
connected to a main socket outlet with a protective earthing
connection.
25. ACCESSORIES – Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury to a
child or adult, and serious damage to the product. Use only with a cart,
stand, tripod, bracket, or table recommended by the manufacturer, or sold
with the product.
26. When moving or not using the appliance, secure the power cord (e.g.,
wrap it with a cable tie). Be careful not to damage the power cord.
Before using it again, make sure the power cord has not been damaged.
If the power cord has been damaged at all, bring the unit and cord to a
qualified service technician for repair or replacement as specified by the
manufacturer.
27. LIGHTNING – For added protection during a lightning storm, or when it
is left unattended and unused for long periods of time, unplug it from the
wall outlet. This will prevent damage to the product due to lightning and
power-line surges.
28. REPLACEMENT PARTS – When replacement parts are required, be
sure the service technician has used replacement parts specified by
the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other
hazards.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED PERSONAL

V2300 SERIES OWNER’S MANUAL
11
IMPORTANT SAFETY INSTRUCTIONS
FCC STATEMENTS
To prevent electric shock, do not use a polarized plug with an extension cord,
receptacle or other outlet unless the blades can be fully inserted to prevent
blade exposure.
HEARING DAMAGE AND PROLONGED EXPOSURE TO
EXCESSIVE SPLs
Harbinger VARI Series powered loudspeakers are capable of producing
extremely loud volume levels that can cause permanent hearing damage
to performers, production crews or the audience. Hearing protection is
recommended during long-term exposure to high SPLs (sound pressure levels).
Remember, if it hurts, it is definitely too loud! Long term exposure to high SPLs
first causes temporary threshold shifts; limiting your ability to hear the actual
loudness and exercise good judgment. Repeated long term exposure to high
SPLs will cause permanent hearing loss.
Please note the recommended exposure limits in the accompanying table.
More information about these limits is available on the US government
Occupational Safety and Health (OSHA) website at: www.osha.gov.
WARNING: To reduce the risk of fire or shock do
not expose this equipment to rain or moisture.
AVERTISEEMENT: Pour réduire les risques
d’incendie et d’électrocution, ne pas exposer ce
matérial à la pluie ou à l’humidité.
RISK OF
ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC
ELECTRIQUE NE
PAS OUVRIR
RISK OF
ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC
ELECTRIQUE NE
PAS OUVRIR
CAUTION: To reduce the risk of electric shock, do not
remove chassis. No user-serviceable parts inside.
Refer servicing to qualified service personnel.
AVERTISEEMENT: Pour réduire les risques d’incendie et
d’électrocution, ne pas exposer ce matérial à la pluie ou
à l’humidité.
WARNING: To reduce the risk of fire or shock do
not expose this equipment to rain or moisture.
AVERTISEEMENT: Pour réduire les risques
d’incendie et d’électrocution, ne pas exposer ce
matérial à la pluie ou à l’humidité.
RISK OF
ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC
ELECTRIQUE NE
PAS OUVRIR
RISK OF
ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC
ELECTRIQUE NE
PAS OUVRIR
CAUTION: To reduce the risk of electric shock, do not
remove chassis. No user-serviceable parts inside.
Refer servicing to qualified service personnel.
AVERTISEEMENT: Pour réduire les risques d’incendie et
d’électrocution, ne pas exposer ce matérial à la pluie ou
à l’humidité.
THIS SYMBOL IS INTENDED TO ALERT THE USER TO THE PRESENCE
OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING)
INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE UNIT.
WARNING: To reduce the risk of fire or shock do
not expose this equipment to rain or moisture.
AVERTISEEMENT: Pour réduire les risques
d’incendie et d’électrocution, ne pas exposer ce
matérial à la pluie ou à l’humidité.
RISK OF
ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC
ELECTRIQUE NE
PAS OUVRIR
RISK OF
ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC
ELECTRIQUE NE
PAS OUVRIR
CAUTION: To reduce the risk of electric shock, do not
remove chassis. No user-serviceable parts inside.
Refer servicing to qualified service personnel.
AVERTISEEMENT: Pour réduire les risques d’incendie et
d’électrocution, ne pas exposer ce matérial à la pluie ou
à l’humidité.
APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING
AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHALL BE PLACED ON THE APPARATUS.
Permissible Noise Exposures (1)
Duration per day, hours Sound level dBA slow response
8 90
6 92
4 95
397
2100
1.5 102
1105
0.5 110
0.25 or less 115
1. Caution: Changes or modifications to this unit not expressly approved by
the party responsible for compliance could void the user’s authority to
operate the equipment.
2. Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generate, uses,
and can radiate radio frequency energy and , in not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help

V2300 SERIES OWNER’S MANUAL 12
WARRANTY/CUSTOMER SUPPORT
2 YEAR HARBINGER LIMITED WARRANTY
Harbinger provides, to the original purchaser, a two (2) year limited warranty
on materials and workmanship on all Harbinger cabinets, loudspeaker and
amplifier components from the date of purchase.
For warranty support, please visit our website at www.HarbingerProAudio.
com, or contact our Support Team at 888-286-1809 for assistance. Harbinger
will repair or replace the unit at Harbinger’s discretion.
This warranty does not cover service or parts to repair damage caused by
neglect, abuse, normal wear and tear and cosmetic appearance to the
cabinetry not directly attributed to defects in materials or workmanship. Also
excluded from coverage are damages caused directly or indirectly due to
any service, repair(s), or modifications of the cabinet, which has not been
authorized or approved by Harbinger. This two (2) year warranty does not
cover service or parts to repair damage caused by accident, disaster, misuse,
abuse, burnt voice-coils, over-powering, negligence, inadequate packing or
inadequate shipping procedures.
The sole and exclusive remedy of the foregoing limited warranty shall be limited
to the repair or replacement of any defective or non-conforming component. All
warranties including, but not limited to, the express warranty and the implied
warranties of merchantability and fitness for a particular purpose are limited to
the two (2) year warranty period. Some states do not allow limitation on how long
an implied warranty lasts, so the above limitation may not apply to you. There
are no express warranties beyond those stated here. In the event that applicable
law does not allow the limitation of the duration of the implied warranties
to the warranty period, then the duration of the implied warranties shall be
limited to as long as is provided by applicable law. No warranties apply after
that period.
Retailer and manufacturer shall not be liable for damages based upon
inconvenience, loss of use of product, loss of time, interrupted operation or
commercial loss or any other incidental or consequential damages including
but not limited to lost profits, downtime, goodwill, damage to or replacement
of equipment and property, and any costs of recovering, reprogramming,
or reproducing any program or data stored in equipment that is used with
Harbinger products. This guarantee gives you specific legal rights; you may
have other legal rights, which vary from state to state.
Harbinger
P.O. Box 5111, Thousand Oaks, CA 91359-5111
All trademarks and registered trademarks mentioned herein are recognized as
the property of their respective holders.
1901-18333938
