Introduction
Column speakers
The LINO series are column speaker series designed for a wide variation of general-
purpose applications in acoustic difficult environments, ranging from speech and
announcement applications to background music systems. Typical applications are
houses of worship, auditoria, presentation rooms, public transportation hubs, … and
many more. They are solid constructed using solid aluminum materials and finished
through a rigid finely perforated front grill.
They come in two different models (LINO4 and LINO10) in terms of length and driver
count, consisting of 2” low/mid-frequency drivers with a 1” central positioned tweeter
for the high frequencies. Both models are having a specific pattern in terms of disper-
sion and throw distance. They offer solutions for uniform acoustic performance in any
type of system in reverberant venues, while reducing echo and microphone feedback to
optimizes the intelligibility of music & speech.
Mounting is done through an L-shaped bracket on top and bottom, offering optimal
flexibility for fixation and directional placement. Connections are made through multi-
tapping terminal block connector and A multi-tapping line transformer allows them to
be connected to 70/100V public address systems with various power tapping settings,
while connections in low impedance systems are also possible.

4
Precautions
READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY
• ALWAYS KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. NEVER
THROW THEM AWAY
• ALWAYS HANDLE THIS UNIT WITH CARE
• CLEAN ONLY WITH DRY CLOTH
• HEED ALL WARNINGS AND FOLLOW ALL INSTRUCTIONS
• NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR
SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON
TOP OF THIS DEVICE
• DO NOT INSTALL THIS UNIT NEAR ANY HEAT SOURCES SUCH AS RADIATORS
OR OTHER APPARATUS THAT PRODUCE HEAT
• DO NOT PLACE THIS UNIT IN ENVIRONMENTS WITH A HIGH LEVEL OF DUST,
HEAT, MOISTURE OR VIBRATION
• THIS UNIT IS DEVELOPED FOR INDOOR USE ONLY. DO NOT USE IT OUTDOORS
• ONLY USE ATTACHMENTS & ACCESSORIES SPECIFIED BY THE
MANUFACTURER.
• ONLY INSTALL THE SPEAKER IN LOCATIONS THAT CAN STRUCTURALLY
SUPPORT THE WEIGHT OF THE SPEAKER. IGNORING THIS CAN BRING THE
SPEAKER DOWN.
• DO NOT USE ANY OTHER METHOD THAN SPECIFIED TO MOUNT THE
SPEAKER. IF EXTREME FORCE IS APPLIED TO THE SPEAKER, IT COULD FALL
DOWN
• ATTACH A SAFETY WIRE TO THE SPEAKER WHEN IT IS MOUNTED HIGH UP.
ONLY USE INDUSTRY-ACCEPTED RIGGING TOOLS AND METHODS
• CAREFULLY CHECK THE UNIT’S CONDITION AFTER UNPACKING.
IF THERE IS ANY DAMAGE TO THE CARTON BOX OR THE UNIT ITSELF,
INFORM YOUR VENDOR IMMEDIATELY.

5
CAUTION
• USE CABLES OF THE RIGHT GAUGE TO CONNECT THE LOUDSPEAKER
• USE CABLES WITH CLEAR COLOR CODING INDICATING THE POLARITY AND
MAINTAIN THE SAME POLARITY THROUGHOUT THE WHOLE SYSTEM.
• ONLY USE THE CORRECT AMPLIFIER OUTPUT VOLTAGE AND IMPEDANCE.
EXCEEDING THESE LIMITS COULD CAUSE FIRE OR OTHER FAILURES.
AVOID EXPLOSIONS: DO NOT USE THE SPEAKER AROUND GASOLINE,
THINNER OR OTHER COMBUSTIBLES
• AVOID ELECTRIC SHOCKS: SWITCH OFF THE AMPLIFIER WHEN CONNECTING
THE LOUDSPEAKER
• DO NOT USE THE LOUDSPEAKER FOR AN EXTENDED PERIOD OF TIME AT
DISTORTED SOUND. THIS COULD CAUSE PERMANENT DAMAGE.
CAUTION - SERVICING
This product contains no user serviceable parts. Refer all servicing
to qualified service personnel. Do not perform any servicing
(unless you are qualified to do so.)
EC DECLARATION OF CONFORMITY
This product conforms to all the essential requirements and further
relevant specifications described in following directives: 2014/30/
EU (EMC) and 2014/35/EU (LVD)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)
The WEEE marking indicates that this product should not be
disposed with regular household waste at the end of its product
life. This regulation is created to protect both the environment
and human health.
This product is developed and manufactured with high quality
materials and components which can be recycled and/or reused.
Please dispose this product to your local collection point or
recycling centre for electrical and electronic waste. This will
make to sure that it will be recycled on an environmentally friendly
manner, and will help to protect the environment in which we all
live.

6
Installing the LINO
Mounting bracket
Every LINO speaker comes delivered with two L-shaped brackets making it possible
to install the speaker at each location and focussing it into the desired direction. The
metal constructed L-brackets ensures a solid and secure mounting of the loudspeaker
to any possible surface or location.
The L-shaped brackets have to be fixed to the wall through
2 screws. The used fasteners are depending on the mounting
surface (brick, concrete, wood, ...) and should be chosen
accordingly.
Once the wall brackets are mounted to the installation position,
the speaker should get fixed to the brackets. This is done through
inserting both supplied bolts and tightening them. The slot shaped
holes allow vertical directional adjustments while horizontal
adjustments are possible through rotation.

7
Connecting the speaker
For connecting the LINO, the wires coming from the amplifier shall be connected to
the 6-pin terminal block connector on the rear of the speaker. Depending whether
the speaker will be used in a low impedance system or a constant voltage (70/100V)
system, the appropriate terminals of the connector should get connected as indicated
in the below drawing.
B
8 Ω
COM
C
A
D
When using in constant voltage 70/100V systems, the power taps can be adjusted in 4
steps of impedance through connecting the appropriate terminals of the 6-pin terminal
block connector. Each position corresponds with a specific impedance / power setting
indicated on a label attached to the speaker, and in the table below.
LINO4 LINO10
Tapping 100V 70V Imp. 100V 70V Imp
A20 W 250 Ω40 W 125 Ω
B20 W 10 W 500 Ω40 W 20 W 250 Ω
C10 W 5 W 1000 Ω20 W 10 W 500 Ω
D5 W 2.5 W 2000 Ω10 W 5 W 1000 Ω
Low-Z 8 Ω20 Ω

8
Additional Information
Technical specifications
LINO4 LINO10
Max Power 40 Watt 80 Watt
RMS Power 20 Watt 40 Watt
Nominal impedance 8 Ω20 Ω
Line transformer taps 250 Ω– 70V/20W 125 Ω– 70V/40W
500 Ω– 100V/20W - 70V/10W 250 Ω– 100V/40W - 70V/20W
1k Ω– 100V/10W - 70V/5W 500 Ω– 100V/20W - 70V/10W
2k Ω– 100V/5W - 70V/2.5W 1k Ω– 100V/10W - 70V/5W
Frequency response (± 3 dB) 170 Hz - 15 kHz 170 Hz - 15 kHz
Frequency range (- 10 dB) 120 Hz - 20 kHz 120 Hz - 20 kHz
Sensitivity (1W/1m) 88 dB 90 dB
Sound pressure (Max. W/1m) 101 dB 107 dB
Cross-over network Passive built-in Passive built-in
Drivers 4 x 2” + 1” HF 10 x 2” + 1” HF
Connectors 6-pin Terminal block (5.08 mm) 6-pin Terminal block (5.08 mm)
Mounting bracket Adjustable L-brackets (steel) Adjustable L-brackets (steel)
Construction Alu extrusion + end caps Alu extrusion + end caps
Front finish Fine perforated alu grill Fine perforated alu grill
Ingress protection IP3x IP3x
Operation temperature range -20°C to +50°C -20°C to +50°C
Colour White LINO4/W (RAL9003) LINO10/W (RAL9003)
Black LINO4/B (RAL9005) LINO10/B (RAL9005)
Dimensions (W x H x D) 72 x 414 x 68.3 mm 72 x 796 x 68.3 mm (excl bracket)
Weight 1.81 Kg 3.7 Kg
Packaging Carton box Carton box
Shipping weight & Volume 2.1 Kg - 0.008 Cbm 4.2 Kg - 0.014 Cbm
Accessories included 6-pin terminal block connector 6-pin terminal block connector
Adjustable L-brackets (steel) Adjustable L-brackets (steel)
