Harbor Mate OMC-F130 User manual
Page 1Rev. 111319 DiscountRamps.com •1-888-651-3431
Outboard Motor Cart
Instructions for Part # OMC-F130
General Guidelines
• It is the user’s responsibility to read and follow all instructions.
• Keep these instructions with the product at all times and review before each use.
• It is the responsibility of this product’s owner to furnish the instructions to any person that borrows
or purchases the product.
• Inspect the product before use to ensure it is assembled properly and all parts are in safe working
order and free of defects.
• Never modify this product in any way.
• All circumstances cannot be addressed in these instructions. Please use common sense and prac-
tice general safety measures when using this product.
• Parts and/or instructions are subject to change without notice.
Safety
• Check that all hardware is properly tightened before use.
• Lubricate the wheels periodically.
• Never exceed the 130 lb. weight limit.
• This carrier is designed for moving motors short distances, for storage, and while performing main-
tenance. Do not use for anything other than its intended purpose.
• Securely chock the wheels while in storage or working on a motor mounted on the motor carrier.
• When storing a motor, it is recommended to securely chock the wheels and position it against a
wall with the handle facing outward.
• Never leave a motor and/or motor carrier unattended. Do not use on uneven ground.
• Keep away from children.
• Never run the motor while on the stand.
• Never tow the carrier behind any kind of vehicle.
• When carrying any heavy motor and positioning it on the carrier, it is recommended to use two
people.
Page 2Rev. 111319 DiscountRamps.com •1-888-651-3431
Parts
Outboard Motor Weight Reference Chart
Part Description Quantity
AHandle Tube 1
BSupport Tube 1
C Vertical Straight Tube - 32”L 2
D Handle Straight Tube - 29-3/4”L 2
E Bottom Straight Tube - 14-3/4”L 2
F Axle 1
GGas Tank Strap 1
HFoot Tube 1
I Plastic Foot 2
Horsepower Weight
8 60 lbs
9.9 79 lbs
15 79 lbs
25 105 lbs
50 189 lbs
70 228 lbs
90 261 lbs
Horsepower Weight
8 83 lbs
9.9 99 lbs
15 113 lbs
20 113 lbs
30 172 lbs
40 183 lbs
50 or 60 237 lbs
Part Description Quantity
J Turn Knob M8x40 2
K Wheel 2
L Plastic Block 1
M M6x85 Bolt 2
N M6x70 Bolt 4
O M6x60 Round Head Bolt 6
P M6x40 Round Head Bolt 4
Q M6 Lock Washer 16
R M6 Nut 16
Tools Required: 10mm wrenches, 19mm wrench, screwdriver, hammer (optional)
ABC
D
E
F G
HI
J
KL M N O P Q R
This chart has been created as a reference for determining the weight of your outboard motor. The weight between a
2-stroke and 4-stroke outboard motor can vary signicantly. These weights are only estimates that are to be used for de-
termining what size outboard motor carrier you should purchase. Before placing your outboard motor onto the motor carri-
er, it is highly recommended to refer to the owner’s manual you received with your outboard motor for the exact weight. If
the manufacturer’s listed weight exceeds the rated weight capacity of the motor carrier, do not try to mount - serious injury
or damage may result.
2-Stroke Motor 4-Stroke Motor
Page 3Rev. 111319 DiscountRamps.com •1-888-651-3431
Note: First, only hand-tighten parts. When assembly is complete, tighten all hardware with tools.
Step 1. Connect the bottom straight
tubes (E) to the axle (F) using
M6x40 bolts (P), lock washers (Q),
and nuts (R).
Step 2. Connect the vertical straight
tubes (C) to the assembly using
M6x40 bolts (P), lock washers
(Q), and nuts (R). Make sure the
indentations on the bars are facing
inward.
Step 3. Slide the gas tank strap
(G) onto the vertical straight tubes.
Then, attach the plastic block (L)
with the M6x70 bolts (N), lock
washers (Q), and nuts (R). If it
is dicult to t the bolts into the
indents in the plastic block, you may
use a hammer or mallet.
Assembly
(4a)
Step 4. Clip each foot (I) into place
on the foot tube (H). Connect the
handle straight tubes (D) to the foot
tube using M6x60 bolts (O). Make
sure the indentations on the bars
are facing inward. Do not attach the
washers and nuts yet.
(1b)
(2b)
(4b)
(2a)
(3b)
(4c)
(1a)
(3a)
Page 4Rev. 111319 DiscountRamps.com •1-888-651-3431
Step 5. Connect the two assemblies. Fit the bolts of the foot tube assembly into the holes of the
bottom straight tubes on the axle assembly. Secure in place with lock washers (Q) and nuts (R).
Step 6. Connect the handle tube (A) to the handle straight tubes on the assembly. First, t the M6x85
bolts (M) through the upper holes and secure with lock washers (Q) and nuts (R). Then t the turn
knobs (J) into the lower holes to x the handle in the upright position.
Step 7. Connect the support tube (B) to the assembly using M6x60 bolts (O), lock washers (Q), and
nuts (R). Make sure the gas tank strap is above the support tube.
(5a) (5b)
(6a)
(7a) (7b)
(6c)
(6b) (6d)
Page 5Rev. 111319 DiscountRamps.com •1-888-651-3431
Step 8. Attach the wheels (K) to the axle.
Remove the nut and one washer, slide
the tire on, and replace the washer and
nut. Secure with a 19mm wrench. Do not
overtighten - wheels should be able to
turn freely.
Step 9. After assembly is complete, make
sure all bolts and nuts are tightened using
appropriate tools.
Handle: To fold down the handle, loosen
the turn knobs.
(8a)
(9)
(8b)
(10)
Page 6Rev. 111319 DiscountRamps.com •1-888-651-3431
Product Warranty and Liability
GENERAL PRODUCT WARRANTY: Products purchased from the Authorized Dealer (original place
of purchase) or Merchant (“Dealer”) will be free of defects in material and workmanship at the time of
receipt, and will meet the specications stated at the place of purchase transaction or online at the
Dealer’s website, under normal use and service when correctly installed, operated and maintained.
This product warranty is eective for the period of time stated below, unless otherwise stated in the
product instructions or depicted in the product advertisement. All Authorized Dealer warranties are
NON-TRANSFERABLE and cover only the original end purchaser. This limited warranty does not
cover products purchased through non-authorized dealers. Non-authorized dealer receipts are not
accepted for warranty verication.
***Warranty claims must be made directly to the original place of purchase.***
WARRANTY PERIOD: This warranty remains in force for one year from the date of the product’s
accepted delivery. The Authorized Dealer oers a one year manufacturer’s warranty for most products
unless otherwise specied on the product advertisement.
WARRANTY SERVICE: The Authorized Dealer will replace any defective or malfunctioning part at
no charge, including payment of the shipping costs of parts or replacement product to and from the
manufacturer. The purchaser is responsible for labor charges. If the product does not meet specica-
tions as depicted in the advertisement, the Authorized Dealer will refund the full purchase price of the
product.
Questions regarding the warranty on a specic product and warranty claims should be directed to the
Authorized Dealer with whom the purchase transaction was made.
WARRANTY LIMITATIONS: The above warranty does not apply to products that are repaired, modi-
ed or altered by any party other than the Authorized Dealer; are subjected to unusual physical stress
or conditions (such as overloaded ramps or corrosion), natural disaster, governmental actions, wars,
strikes, labor disputes, riots, theft, vandalism, terrorism or any reason beyond reasonable control; are
damaged due to improper installation, misuse, abuse, accident or negligence in use, storage, trans-
portation or handling, or tampering; or to products that are considered consumable items or items
requiring repair or replacement due to normal wear and tear.
Product should be inspected prior to signing for delivery. Product damage incurred during shipping,
unless noted on the Bill of Lading at the time of delivery, renders this warranty void.
LIMITED LIABILITY: In no event shall THE AUTHORIZED DEALER be liable to the purchaser or any
third party for any indirect, incidental, consequential, special, exemplary or punitive damages arising
out of the use of the product, including, without limitation, property damage, loss of value of the prod-
uct or any third party products that are used in or with the product, or loss of use of the product or any
third party products that are used in or with the product.
