Harley Benton Powerplant Junior User manual

Powerplant Junior
power supply
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
19.05.2016, ID: 264101

Table of contents
1 General notes............................................................................................................................................... 4
2 Safety instructions..................................................................................................................................... 6
3 Installation and starting up................................................................................................................ 10
4 Components and functions................................................................................................................ 15
5 Technical specifications....................................................................................................................... 17
6 Protecting the environment.............................................................................................................. 18
Table of contents
Powerplant Junior
3

1 General notes
This user manual contains important information on safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to other users, be sure
that they also receive this manual.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
This section provides an overview of the symbols and signal words used in this user manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Symbols and signal words
General notes
power supply
4

Warning signs Type of danger
Warning – high-voltage.
Warning – danger zone.
General notes
Powerplant Junior
5

2 Safety instructions
This device transforms mains voltage into safety extra-low voltage, e.g. for the voltage supply
of effects pedals. Use the device only as described in this user manual. Any other use or use
under other operating conditions is considered to be improper and may result in personal
injury or property damage. No liability will be assumed for damages resulting from improper
use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
power supply
6

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Safety
Safety instructions
Powerplant Junior
7

DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis‐
tered electrician.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
power supply
8

NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
Powerplant Junior
9

3 Installation and starting up
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Make all connections when the device is not connected to the mains voltage. Use the supplied
cables for all connections.
The following cable types are available:
n5 standard cables (1:1), length 30 cm, each to supply one effects pedal
n5 standard cables (1:1), length 60 cm, each to supply one effects pedal
n1 Y-cable to supply one effects pedal that has a higher power consumption
n1 serial cable to supply a maximum of 5 effects units from one 9 V outlet socket of the
power supply unit
Wiring
Installation and starting up
power supply
10

Connect – as shown in the drawing – the plug of one of the standard cables to the 9 V power
supply input of an effects pedal. Connect the other plug to a 9 V output socket of the power
supply unit. In order to avoid an overload of the power supply, the current draw of each con‐
nected pedal must not exceed 120 mA.
1:1-Wiring
Installation and starting up
Powerplant Junior
11

Connect – as shown in the drawing – the single plug to the 9 V power supply input of an
effects pedal. Connect the plug pair of the Y-cable to two 9 V output sockets of the power
supply. In order to avoid an overload of the power supply the current draw of the connected
pedal must not exceed 240 mA.
Y-cable for devices with higher
current supply
Installation and starting up
power supply
12

The serial cable is used to power several effects pedals standing next to each other in a clear
way. Connect – as shown in the drawing – the five output jacks of the serial cable to the DC
inputs of the effects units. Connect the input jack of the cable to one of the 9 V outlets of the
power supply. The total current draw of all connected pedals must not exceed 120 mA, thus
leaving a maximum of 24 mA to each pedal when using devices of the same kind..
Serial cable
Installation and starting up
Powerplant Junior
13

Installation and starting up
power supply
14

4 Components and functions
Components and functions
Powerplant Junior
15

1…5DC 9 V outlet sockets
6 Red pilot light. Indicates that the device is powered by mains voltage.
Components and functions
power supply
16

5 Technical specifications
Voltage supply 230 V 50 Hz
Current draw 30 mA
Output voltage 5 × DC 9 V
Output current 5 × 120 mA
Dimensions (W × D × H) 116 mm × 77 mm × 38 mm
Weight 920 g
Technical specifications
Powerplant Junior
17

6 Protecting the environment
For the transport and protective packaging, environmentally friendly materials have been
chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that
they are collected for recycling. Please follow the notes and markings on the packaging.
This product is subject to the European Waste Electrical and Electronic Equipment Directive
(WEEE). Do not dispose with your normal household waste.
Dispose of this device through an approved waste disposal firm or through your local waste
facility. When discarding the device, comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.
Disposal of the packaging mate‐
rial
Disposal of your old device
Protecting the environment
power supply
18
