Harman Kardon AVR 130 Instruction Manual


•
¢∞§¶
‚
⁄
¤
fi
°
b
c
d
e
g
h
ª
¡
™
£
f
a
·‡
fl›
‹
AVR 130 REAR-PANEL CONNECTIONS
NOTE:To assist in making the correct connections for
multichannel input, output and speaker connections, all
connection jacks and terminals are color-coded in
conformance with the latest CEA standards as follows:
Front Left:White
Front Right: Red
Center: Green
Surround Left: Blue
Surround Right: Gray
Subwoofer: Purple
Coaxial Digital Audio: Orange
Composite Video:Yellow
¡CD Audio Inputs
™Tape Outputs
£Tape Inputs
¢Subwoofer Output
∞Front Speaker Outputs
§Surround Speaker Outputs
¶Center Speaker Outputs
•Optical Digital Inputs
ªCoaxial Digital Inputs
·Video 2 S-Video Input
a6-Channel Direct Inputs
bVideo Monitor Output
cDVD Audio/Video Inputs
dVideo 1 Audio/Video Inputs
eVideo 1 Audio/Video Outputs
fVideo 2 Audio/Video Inputs
gAM Antenna Terminals
hFM Antenna Jack
‚AC Power Cord
⁄Switched AC Accessory Outlet
¤Unswitched AC Accessory Outlet
‹Optical Digital Output
›Coaxial Digital Output
fiS-Video Monitor Output
flDVD S-Video Input
‡Video 1 S-Video Input
°Video 1 S-Video Output
