AVR230Audio/VideoReceiver
SERVICE MANUAL
Power for the Digital Revolution™
®

TECHNICAL SPECIFICATIONS 43
Technical Specifications
Audio Section
Stereo Mode
Continuous Average Power (FTC)
65 Watts per channel, 20Hz–20kHz,
@ < 0.07% THD, both channels driven into 8 ohms
5/7 Channel Surround Modes
Power Per Individual Channel
Front L&R channels:
50 Watts per channel,
@ < 0.07% THD, 20Hz–20kHz into 8 ohms
Center channel:
50 Watts, @ < 0.07% THD, 20Hz–20kHz into 8 ohms
Surround (L & R Side, Back) channels:
50 Watts per channel,
@ < 0.07% THD, 20Hz–20kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High Level) 200mV/47kohms
Signal-to-Noise Ratio (IHF-A) 95dB
Surround System Adjacent Channel Separation
Analog Decoding 40dB
(Pro Logic, etc.)
Dolby Digital (AC-3) 55dB
DTS 55dB
Frequency Response
@ 1W (+0dB, –3dB) 10Hz–100kHz
High Instantaneous
Current Capability (HCC) ±30 Amps
Transient Intermodulation
Distortion (TIM) Unmeasurable
Rise Time 16 µsec
Slew Rate 40V/µsec**
FM Tuner Section
Frequency Range 87.5–108MHz
Usable Sensitivity IHF 1.3 µV/13.2dBf
Signal-to-Noise Ratio Mono/Stereo: 70/68dB (DIN)
Distortion Mono/Stereo: 0.2/0.3%
Stereo Separation 40dB @ 1kHz
Selectivity ±400kHz: 70dB
Image Rejection 80dB
IF Rejection 90dB
AM Tuner Section
Frequency Range 522–1611kHz
Signal-to-Noise Ratio 45dB
Usable Sensitivity Loop: 500µV
Distortion 1kHz, 50% Mod: 0.8%
Selectivity ±10kHz: 30dB
Video Section
Video Format PAL/NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency Response
(Composite and S-Video) 10Hz–8MHz (-3dB)
Video Frequency
Response (Component) 10Hz-30MHz (-3dB)
General
Power Requirement AC 220-240V/50Hz
Power Consumption 118W idle, 890W maximum
(6 channels driven)
Dimensions (Max)
Width 440mm
Height 165mm
Depth 382mm
Weight 12.4 kg
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.
All features and specifications are subject to change without notice.
Harman Kardon is a registered trademark, and Power for the digital revolution is a trademark, of
Harman International Industries, Inc.
is a trademark of Harman International Industries, Inc.
(Patent No. 5,386,478).
*Manufactured under license from Dolby Laboratories.
“Dolby,” “Pro Logic,” “Pro Logic II” and the Double-D symbol are
trademarks of Dolby Laboratories. Confidential Unpublished
Works. ©1992–1999 Dolby Laboratories, Inc. All rights reserved.
DTS and DTS Surround, DTS-ES and DTS Neo:6 are trademarks of Digital Theater Systems, Inc.
VMAx is a trademark of Harman International Industries, Inc., and is an
implementation of Cooper Bauck Transaural Stereo under patent license.
Logic 7 is a registered trademark of Harman International Industries, Incorporated.
Crystal is a registered trademark of Cirrus Logic Corp.
**Without input anti slewing and output isolation networks.
TM

AVR230 EXPLODED VIEW
Y
G
10ZE
G
G
G
G

1/1
Pos Part number 1st part name 2nd part name
CPG1A732Q BOX , OUT CARTON
HARTAVR230/230 REMOCON ASS'Y
HARTZONE2 REMOCON ASS'Y
CPP1A081Z BAG,POLY SET
CPS4A564 PAD , SNOW L
CPS4A565 PAD , SNOW R
CPB1061Y BAG , POLY
CQE1A180Z BOOKLET , IMFORMATIONS
CQX1A850Z MANUAL , INSTRUCTION
CQX1A866Y MANUAL , SETUP
CSA1A018Z FM 1 POLE ANT
CSA3A012Z AM LOOP ANTENNA ASS'Y
HABAAAM1.5V BATTERY
HABAAAM1.5VHK BATTERY
CQXAVR230/230 INSTRUCTION MANUAL ASS'Y
1/2
Pos Part number 1st part name 2nd part name
CNVKSTM9014MS17 TUNER MODULE(EUR)
CKC1B145S46 CABINET , TOP
CGWAVR507 FRONT PANEL ASS'Y
CGW1A366RDYH43 PANEL , FRONT
KBC1A147MBZC22 KNOB , MOMS
KBT1A903MMZC22 KNOB , POWER
KBT1A904MBZC22 KNOB , SET
KBT1A905MBYC22 KNOB , FUNCTION
KBN1A174MBC22 KNOB , ROTARY
CBT1A819K128 KNOB , DELAY
KGB1A111X BADGE , HARMAN/KARDON
CMH1A214 HOLDER , VOLUME
CGL1A222 INDICATOR , VOLUME
KGX1A338MBC22 CAP , VOLUME
CMZ1A090 SHEET , VOLUME
CGU1A318Z ORNAMENT , VOLUME
CGU1A317YWINDOW , FIP
CGL1A221 INDICATOR , POWER
CMH1A215 HOLDER , LED
CMX1A148 INSULATOR , FUBCTION
CMX1A149 INSULATOR , SET
CMZ1A088 FILTER , FIP
CUA1A229 CHASSIS , BOTTOM
HDMKD1206PTS3 MOTOR , FAN(60X60X25MM)
BN72 CWZAVR230BN72 WIRE ASS'Y
CLZ9Z028Z FERRITE CORE(21.2X6.4X12.7)
CQB1A549Z LABEL , ATTENTION
AVR230 MECH
AVR230 PACKING

2/2
Pos Part number 1st part name 2nd part name
CQB1A551Z LABEL , BAR CODE
CHE170 HOLDER , PCB
CHG1A104 CUSHION , EVA
CHG1A157 CUSHION , RUBBER
CJA2B043ZA CORD , POWER(EUR)
CKF5A254Y PANEL , REAR
CKL1A069H43 FOOT
CMC1A200 PLATE , SHIELD
CLZ9W003Z FERRITE , RING
CMD1A443 BRACKET , SIDE
CMK1A010 BRACKET , PCB
CMD1A487 BRACKET , TRANS
CMD1A506 BRACKET , FAN
KHE36-3 CLAMPER , WIRE
KHG1A050 RUBBER , CUSHION
KHR1A028 BUSHING , AC CORD
KHR301 CLAMPER
KHR301 CLAMPER
CTB3+8JFC SCREW
CTB4+6FFC SCREW
CHD1A012Z SCREW , SPECIAL
CHD1A023 SCREW , TRANS
CHD1A036FZ SCREW , SPECIAL
CHD2A012 SCREW , TR
CTB3+10G SCREW
CTB3+16GFZ SCREW
CTWS3+10G SCREW
AVR230 MECH

1/10
Pos Part number 1st part name 2nd part name
COP11578GFRONT PCB ASS'Y
C701 HCBS1H390JT CAP , CERAMIC 39PF 50V J
C702 HCBS1H390JT CAP , CERAMIC 39PF 50V J
C703 HCBS1H821KBT CAP , CERAMIC 820PF 50V K
C704 HCEA1VH100T CAP , ELECT 10UF 35V
C705 HCBS1H102KBT CAP , CERAMIC 1000PF 50V B
C706 HCBS1H561KBT CAP , CERAMIC
C708 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C709 HCEA1CH101T CAP , ELECT 100UF 16V
C710 HCEA1HH2R2T CAP , ELECT 2.2UF 50V
C711 HCBS1H102KBT CAP , CERAMIC 1000PF 50V B
C712 HCEA1HH1R0T CAP , ELECT 1UF 50V
C713 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C714 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C715 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C716 HCEA1CH331T CAP , ELECT
C717 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C718 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C719 HCBS1H181KBT CAP , CERAMIC 180PF 50V K
C720 HCBS1H181KBT CAP , CERAMIC 180PF 50V K
C721 HCBS1H181KBT CAP , CERAMIC 180PF 50V K
C722 HCEA1CH101T CAP , ELECT 100UF 16V
C723 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C724 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C725 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF
C726 HCEA0JH102T CAP , ELECT 1000UF 6.3V
C727 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C728 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C729 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF
C730 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C731 HCEA1HH100T CAP , ELECT 10UF 50V
C732 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C733 HCEA1EH470T CAP , ELECT 47UF 25V
C735 HCEA1VH100T CAP , ELECT 10UF 35V
C736 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C737 HCBS1H180JT CAP , CERAMIC
C738 HCBS1H180JT CAP , CERAMIC
C770 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C771 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C773 HCEA1VH100T CAP , ELECT 10UF 35V
C774 HCEA1VH100T CAP , ELECT 10UF 35V
C775 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C776 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C777 HCEA1VH100T CAP , ELECT 10UF 35V
C778 HCEA1VH100T CAP , ELECT 10UF 35V
AVR230 FRONT

2/10
Pos Part number 1st part name 2nd part name
C779 HCEA1CKS470T CAP, ELECT
C780 HCEA1CKS470T CAP, ELECT
C781 HCEA1CKS100T CAP , ELECT
C782 HCEA1CKS100T CAP , ELECT
C785 HCBS1H470JT CAP , CERAMIC 47PF 50V J
C786 HCBS1H470JT CAP , CERAMIC 47PF 50V J
C787 HCEA1CKS100T CAP , ELECT
C788 HCEA1CKS100T CAP , ELECT
C789 HCEA1CKS100T CAP , ELECT
C790 HCEA1CKS100T CAP , ELECT
C791 HCEA1CKS470T CAP, ELECT
C792 HCEA1CKS470T CAP, ELECT
C793 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C794 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C795 KCFE1J823JBT CAP , FILM 0.082UF 63V J
C796 KCFE1J823JBT CAP , FILM 0.082UF 63V J
C797 KCFE1J332JBT CAP , FILM 0.0033UF 63V J
C798 KCFE1J332JBT CAP , FILM 0.0033UF 63V J
C799 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C800 KCFE1J183JBT CAP , FILM 0.018UF 63V J
C805 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C806 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C807 CCKT1H104ZF CAP , CERAMIC 50V 0.1UF
C808 CCKT1H181KB CAP , CERAMIC 180PF 50V KB
C809 HCEA1AH471T CAP , ELECT 470UF 10V
C810 HCEA1CH101T CAP , ELECT 100UF 16V
C811 HCEA1CH101T CAP , ELECT 100UF 16V
C812 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C813 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C814 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C815 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C816 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C850 HCBS1H471KBT CAP , CERAMIC
C851 HCBS1H471KBT CAP , CERAMIC
C852 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C855 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C856 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C857 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C858 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C859 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C860 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C861 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C862 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C863 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C864 HCEA1VH100T CAP , ELECT 10UF 35V
C865 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF
AVR230 FRONT

3/10
Pos Part number 1st part name 2nd part name
C866 HCEA1CKS100T CAP , ELECT
C867 HCEA1CKS100T CAP , ELECT
C868 HCEA1CKS470T CAP, ELECT
C869 HCEA1CKS470T CAP, ELECT
C870 HCBS1H681KBT CAP , CERAMIC
C871 HCBS1H681KBT CAP , CERAMIC
C872 HCEA1CH331T CAP , ELECT
C873 HCEA1CH331T CAP , ELECT
C874 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C875 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C876 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C877 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C878 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C880 HCEA1AH221T CAP , ELECT
C882 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C886 HCEA0JH102T CAP , ELECT 1000UF 6.3V
C889 HCBS1H220JT CAP , CERAMIC
C890 HCBS1H220JT CAP , CERAMIC
C891 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C892 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C893 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C894 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C895 HCEA1AH471T CAP , ELECT 470UF 10V
C896 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C897 HCEA1AH471T CAP , ELECT 470UF 10V
C900 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C902 HCEA1HH2R2T CAP , ELECT 2.2UF 50V
D724 HVD1SS133MT DIODE 1SS133T-77
D725 HVD1SS133MT DIODE 1SS133T-77
D726 HVD1SS133MT DIODE 1SS133T-77
D727 HVD1SS133MT DIODE 1SS133T-77
D728 HVD1SS133MT DIODE 1SS133T-77
D729 HVD1SS133MT DIODE 1SS133T-77
D730 HVD1SS133MT DIODE 1SS133T-77
D761 HVD1SS133MT DIODE 1SS133T-77
D774 HVD1SS133MT DIODE 1SS133T-77
D775 HVD1SS133MT DIODE 1SS133T-77
D776 KVD1N4003ST DIODE 1N4003
D777 HVD1SS133MT DIODE 1SS133T-77
D778 KVD1N4003ST DIODE 1N4003
D779 HVD1SS133MT DIODE 1SS133T-77
D783 HVD1SS133MT DIODE 1SS133T-77
D784 HVD1SS133MT DIODE 1SS133T-77
D785 HVD1SS133MT DIODE 1SS133T-77
D786 HVDMTZJ5.6BT DIODE , ZENER
D787 HVDMTZJ5.6BT DIODE , ZENER
AVR230 FRONT

4/10
Pos Part number 1st part name 2nd part name
D788 HVDMTZJ5.6BT DIODE , ZENER
D789 HVDMTZJ5.6BT DIODE , ZENER
IC87 HVIRE5VL28CATZ IC , RESET
L702 HLQ02C100KT COIL , AXAIL
Q701 HVTKRC107MT T.R KRC107M
Q702 HVTKRC107MT T.R KRC107M
Q703 HVTKRC107MT T.R KRC107M
Q704 HVTKRC107MT T.R KRC107M
Q705 HVTKRC107MT T.R KRC107M
Q706 HVTKRC107MT T.R KRC107M
Q722 HVTKRA107MT T.R KRA107M
Q723 HVTKRC107MT T.R KRC107M
Q724 HVTKRC107MT T.R KRC107M
Q725 HVTKRC107MT T.R KRC107M
Q726 HVTKRC107MT T.R KRC107M
Q727 HVTKRC107MT T.R KRC107M
Q728 HVTKRC107MT T.R KRC107M
Q729 HVTKRC107MT T.R KRC107M
Q731 KVTKSA1175YT T.R KSA1175Y
Q732 HVTKRC107MT T.R KRC107M
Q733 KVTKSC2785YT T.R KSC2785Y
Q734 HVTKTC2874BT T.R , MUTE KTC2874B
Q735 HVTKTC2874BT T.R , MUTE KTC2874B
Q736 HVTKTC2874BT T.R , MUTE KTC2874B
Q737 HVTKTC2874BT T.R , MUTE KTC2874B
Q738 HVTKRC107MT T.R KRC107M
Q739 HVTKTA1271YT T.R KTA1271Y
Q740 HVTKRC107MT T.R KRC107M
Q741 HVTKRC107MT T.R KRC107M
Q743 HVTKRA107MT T.R KRA107M
R701 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R702 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J
R704 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R705 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R706 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R707 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R708 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R709 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R710 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R711 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R712 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R713 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R714 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R715 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R716 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R717 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
AVR230 FRONT

5/10
Pos Part number 1st part name 2nd part name
R718 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R719 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R720 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R721 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R723 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R724 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R725 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R726 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R727 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R728 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R729 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R730 CRD20TJ112T RES,CABON
R731 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R732 CRD20TJ202T RES , CARBON
R733 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R734 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R735 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R736 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R737 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R738 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R739 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R740 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R741 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R742 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R743 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R744 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R745 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R746 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R747 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R750 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R751 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R752 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R753 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R754 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R755 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R756 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R757 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R758 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R759 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R760 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R761 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R762 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R763 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R764 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R765 CRD20TJ752T RES , CARBON 7.5K OHM 1/5W J
R766 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
AVR230 FRONT

6/10
Pos Part number 1st part name 2nd part name
R767 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R768 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R769 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R770 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R771 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R772 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R773 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R774 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R775 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R776 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R777 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R808 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R809 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R810 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R811 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R813 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R814 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R820 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R821 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R822 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R824 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R825 CRD20TJ181T RES , CARBON 180 OHM 1/5W J
R826 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R827 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R829 CRD20TJ184T RES , CARBON
R830 CRD20TJ184T RES , CARBON
R831 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R832 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R833 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R834 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R835 CRD20TJ184T RES , CARBON
R836 CRD20TJ184T RES , CARBON
R837 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R838 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R839 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R840 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R841 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R842 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R843 CRD20TJ105T RES , CARBON 1M OHM 1/5W J
R844 CRD20TJ105T RES , CARBON 1M OHM 1/5W J
R845 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R846 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R847 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R848 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R849 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R850 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
AVR230 FRONT

7/10
Pos Part number 1st part name 2nd part name
R851 CRD20TJ392T RES , CARBON
R852 CRD20TJ392T RES , CARBON
R853 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R854 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R855 CRD20TJ681T RES , CARBON 680 OHM 1/5W J
R856 CRD20TJ681T RES , CARBON 680 OHM 1/5W J
R857 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R858 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R864 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R865 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R866 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R868 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J
R869 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R871 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R872 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R873 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R874 CRD20TJ471T RES , CARBON 470 OHM 1/5W J
R875 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R876 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R877 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R878 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R881 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R882 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R883 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R884 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R885 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R886 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R887 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R888 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R889 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R890 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R891 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R892 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R893 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R895 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R896 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R897 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R898 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R899 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R900 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R901 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R902 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R903 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R904 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R905 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R906 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
AVR230 FRONT

8/10
Pos Part number 1st part name 2nd part name
R907 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R908 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R909 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R910 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R911 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R912 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R913 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R914 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R915 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R917 CRD20TJ123T RES , CARBON 12K OHM 1/5W J
R918 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R919 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
S701 HST1A020ZT SW , TACT
S702 HST1A020ZT SW , TACT
S703 HST1A020ZT SW , TACT
S704 HST1A020ZT SW , TACT
S705 HST1A020ZT SW , TACT
S706 HST1A020ZT SW , TACT
S707 HST1A020ZT SW , TACT
S708 HST1A020ZT SW , TACT
S709 HST1A020ZT SW , TACT
S710 HST1A020ZT SW , TACT
S711 HST1A020ZT SW , TACT
S712 HST1A020ZT SW , TACT
S713 HST1A020ZT SW , TACT
S714 HST1A020ZT SW , TACT
S715 HST1A020ZT SW , TACT
S716 HST1A020ZT SW , TACT
S717 HST1A020ZT SW , TACT
S718 HST1A020ZT SW , TACT
S719 HST1A020ZT SW , TACT
S720 HST1A020ZT SW , TACT
C8ESM800 FLUX
H2K31161 SOLDER , WIRE SN60/PH40
H2K50301 SOLDER , BAR S63S-W3.0
K2K4110 SOLDER , ALMIT SM:60%
K4FH300 TAPE , PROTECTIVE
K4FM073 TAPE , BOTH SIDE 3M #4920
BAT1 HABGP40BVH3A3H BATTERY , RECHARGEABLE GP40BBVH3A3H
BK71 CMD1A209 BRACKET , FLT A4-92-1739
BK72 CMD1A209 BRACKET , FLT A4-92-1739
BK73 CMD1A387 BRACKET , PCB
BK74 CMD1A209 BRACKET , FLT A4-92-1739
BN10 CWZAVR230BN10 WIRE ASS'Y (SHIELD)
BN15 CWB2B906150EN WIRE ASS'Y
BN16 CWZAVR2550BN16 WIRE ASS'Y (SHIELD)
AVR230 FRONT

9/10
Pos Part number 1st part name 2nd part name
BN18 CWZAVR125BN18 WIRE ASS'Y (SHIELD)
BN41 CWZAVR130BN41 WIRE ASS'Y (SHIELD)
BN80 CWB2B911420EW WIRE ASS'Y
BN81 CWB2B908250BM WIRE , ASS'Y
BN84 CWB2B905080EN WIRE ASS'Y
BN85 CWB2B902090EN WIRE ASS'Y
BN87 CWZAVR2550BN87 WIRE ASS'Y (SHIELD)
BN88 CWB2B904070EN WIRE ASS'Y
BN89 CWB2B905080EN WIRE ASS'Y
BN90 CWB2B902090EN WIRE ASS'Y
BN94 KJP13GB99ZM CONNECTOR MOLEX35237-1310
BN95 KJP08GB99ZM CONNECTOR , HOUSING MOLEX35237-0810
CN10 KJP04GB46ZM WAFER MOLEX 53015
CN11 KJP15GA98ZM WAFER MOLEX35336-1510
CN12 KJP15GA98ZM WAFER MOLEX35336-1510
CN15 KJP06GA19ZM WAFER MOLEX53014-0610
CN16 KJP08GB46ZM WAFER
CN72 KJP32GA161ZY WAFER YD200 SERIES
CN79 KJP05GA19ZM WAFER MOLEX53014-0510
CN82 KJP06HA37ZM WAFER MOLEX42140-2206
CN84 KJP05GA19ZM WAFER MOLEX53014-0510
CN85 KJP02GA19ZM WAFER
CN86 KJP02GA89ZM WAFER MOLEX35328-02
CN87 KJP06GA19ZM WAFER MOLEX53014-0610
CN88 KJP04GA19ZM WAFER
CN89 KJP05GA19ZM WAFER MOLEX53014-0510
CN90 KJP02GA19ZM WAFER
CN91 KJP06HA37ZM WAFER MOLEX42140-2206
C853 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC) 0.0047UF/2.5KV
D702 CVD52CSBBCEAB2 BLUE L.E.D
D703 CVD52CSBBCEAB2 BLUE L.E.D
D704 CVD52CSBBCEAB2 BLUE L.E.D
D706 CVD52CSBBCEAB2 BLUE L.E.D
D707 CVD52CSBBCEAB2 BLUE L.E.D
D723 CVD50BOGDWGA L.E.D , 2 COLOR
FIP1 HFLHCA18ML01 DISPLAY F.I.P
IC71 BVISAA6579TV1 I.C , RDS FILTER TW SAA6579T/V1
IC72 BVIMB90F482APFG-2 I C , FLASH U-COM Crontrol FUJITSU
IC73 HRVRPM6938H4 SENSOR , REMOTE RPM6938-H4
IC74 HVIS3F84BB-2 I.C , FLASH U-COM display S3F84BB
IC75 HVI74ACT04MTR I.C , HEX
IC76 HVITC74HCU04AFN IC , INVERTER TC74HCU04AFN
IC80 HVIHCF4053M013T I.C
IC81 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1
IC82 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1
IC83 HVI74ACT04MTR I.C , HEX
AVR230 FRONT

10/10
Pos Part number 1st part name 2nd part name
IC84 HVI74ACT04MTR I.C , HEX
IC85 HVIRH5VT18C I.C , RESET
IC86 HVINJM4556AL I.C NJM4556AL
IC88 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1
IC89 HVIHCF4053M013T I.C
JK81 CJJ4M041Y JACK , BOARD (COAX)
JK82 HJSTORX179L MODULE , OPTICAL(RX) TORX179L
JK83 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE)
JK85 CJJ9M003Z JACK , S-VIDEO
JK86 CJJ4S023Y JACK , BOARD
JW82 CWZAVR2550JW82 WIRE , ASS'Y
JW84 CWE8202110RV WIRE, ASS'Y
JW85 CWE8202070AA WIRE ASS'Y
SW01 CSH1A008ZV SW , PUSH (MOMS)
VR71 CVV2X05M104Z RES , VARIABLE(BALANCE) RK14128030214Y
VR72 CVV2X07C104Z RES , VARIABLE(TONE) RK14128030214C
VR73 CVV2X07C104Z RES , VARIABLE(TONE) RK14128030214C
VR74 HSR2A026Z VR , ENCODER
X701 HOX05000E160C CRYSTAL
X702 HOX04332E200C CRYSTAL
X703 HOX10000E220C CRYSTAL
AVR230 FRONT

1/16
Pos Part number 1st part name 2nd part name
COP11579GMAIN PCB ASS'Y
C501 HCEA1VH100T CAP , ELECT 10UF 35V
C502 HCEA1VH100T CAP , ELECT 10UF 35V
C503 HCEA1VH100T CAP , ELECT 10UF 35V
C504 HCEA1VH100T CAP , ELECT 10UF 35V
C505 HCEA1VH100T CAP , ELECT 10UF 35V
C506 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C507 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C508 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C509 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C510 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C561 HCEA1CH101T CAP , ELECT 100UF 16V
C562 HCEA1CH101T CAP , ELECT 100UF 16V
C563 HCEA1CH101T CAP , ELECT 100UF 16V
C564 HCEA1CH101T CAP , ELECT 100UF 16V
C565 HCEA1CH101T CAP , ELECT 100UF 16V
C566 HCEA1CH101T CAP , ELECT 100UF 16V
C567 HCEA1CH101T CAP , ELECT 100UF 16V
C568 HCEA1CH101T CAP , ELECT 100UF 16V
C569 HCEA1CH101T CAP , ELECT 100UF 16V
C570 HCEA1CH101T CAP , ELECT 100UF 16V
C571 HCBS1H681KBT CAP , CERAMIC
C572 HCBS1H681KBT CAP , CERAMIC
C573 HCBS1H681KBT CAP , CERAMIC
C574 HCBS1H681KBT CAP , CERAMIC
C575 HCBS1H681KBT CAP , CERAMIC
C601 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C602 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C603 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C604 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C605 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C606 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C607 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C608 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C609 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C610 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C681 HCEA1HH100T CAP , ELECT 10UF 50V
C682 HCEA1HH100T CAP , ELECT 10UF 50V
C683 HCEA1HH100T CAP , ELECT 10UF 50V
C684 HCEA1HH100T CAP , ELECT 10UF 50V
C685 HCEA1HH100T CAP , ELECT 10UF 50V
C721 CCKT1H221KB CAP , MYLAR 220PF 50V KB
C722 CCKT1H221KB CAP , MYLAR 220PF 50V KB
C723 CCKT1H221KB CAP , MYLAR 220PF 50V KB
C724 CCKT1H221KB CAP , MYLAR 220PF 50V KB
AVR230 MAIN

2/16
Pos Part number 1st part name 2nd part name
C725 CCKT1H221KB CAP , MYLAR 220PF 50V KB
C726 CCKT1H221KB CAP , MYLAR 220PF 50V KB
C727 CCKT1H221KB CAP , MYLAR 220PF 50V KB
C728 CCKT1H221KB CAP , MYLAR 220PF 50V KB
C801 HCEA1HH100T CAP , ELECT 10UF 50V
C802 HCEA1HH100T CAP , ELECT 10UF 50V
C803 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C804 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C805 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C806 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C811 HCEA1CH101T CAP , ELECT 100UF 16V
C812 HCEA1CH101T CAP , ELECT 100UF 16V
C813 HCEA1CH101T CAP , ELECT 100UF 16V
C814 HCEA1CH101T CAP , ELECT 100UF 16V
C815 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C816 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C817 HCEA1VH100T CAP , ELECT 10UF 35V
C818 HCEA1VKS100T CAP , ELECT 10UF 35V
C819 HCBS1H681KBT CAP , CERAMIC
C820 HCBS1H681KBT CAP , CERAMIC
C900 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C901 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C903 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C905 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V ZF
C907 HCEA1CH101T CAP , ELECT 100UF 16V
C908 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V ZF
C910 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C911 HCEA1CH471T CAP , ELECT
C912 HCEA1CH221T CAP , ELECT
C913 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF
C914 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C917 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C918 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C919 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C923 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C924 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C925 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C932 HCEA1CH101T CAP , ELECT 100UF 16V
C933 HCEA1CH221T CAP , ELECT
C934 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V ZF
C939 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C940 HCEA1AH471T CAP , ELECT 470UF 10V
C950 HCEA1CH101T CAP , ELECT 100UF 16V
C955 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C971 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C972 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
AVR230 MAIN

3/16
Pos Part number 1st part name 2nd part name
C973 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C974 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C975 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C980 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C981 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C989 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C990 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C991 HCEA1HH1R0T CAP , ELECT 1UF 50V
C992 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C993 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C994 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C995 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C996 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C997 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C999 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V ZF
C999 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
D501 HVD1SS133MT DIODE 1SS133T-77
D502 HVD1SS133MT DIODE 1SS133T-77
D503 HVD1SS133MT DIODE 1SS133T-77
D504 HVD1SS133MT DIODE 1SS133T-77
D505 HVD1SS133MT DIODE 1SS133T-77
D581 HVD1SS133MT DIODE 1SS133T-77
D582 HVD1SS133MT DIODE 1SS133T-77
D583 HVD1SS133MT DIODE 1SS133T-77
D584 HVD1SS133MT DIODE 1SS133T-77
D585 HVD1SS133MT DIODE 1SS133T-77
D601 HVD1SS133MT DIODE 1SS133T-77
D801 HVD1SS133MT DIODE 1SS133T-77
D802 HVD1SS133MT DIODE 1SS133T-77
D803 HVD1SS133MT DIODE 1SS133T-77
D804 HVD1SS133MT DIODE 1SS133T-77
D901 KVD1N4003ST DIODE 1N4003
D902 HVD1SS133MT DIODE 1SS133T-77
D911 HVD1SS133MT DIODE 1SS133T-77
D912 HVD1SS133MT DIODE 1SS133T-77
D914 HVD1SS133MT DIODE 1SS133T-77
D917 HVD1SS133MT DIODE 1SS133T-77
D951 HVD1SS133MT DIODE 1SS133T-77
D952 HVD1SS133MT DIODE 1SS133T-77
D953 HVD1SS133MT DIODE 1SS133T-77
D954 KVD1N4003SRT DIODE TW 1N4003
D955 KVD1N4003SRT DIODE TW 1N4003
D961 KVD1N4003ST DIODE 1N4003
D962 KVD1N4003ST DIODE 1N4003
D963 KVD1N4003ST DIODE 1N4003
D964 HVD1SS133MT DIODE 1SS133T-77
AVR230 MAIN

4/16
Pos Part number 1st part name 2nd part name
D965 HVD1SS133MT DIODE 1SS133T-77
D966 HVD1SS133MT DIODE 1SS133T-77
D967 HVD1SS133MT DIODE 1SS133T-77
D968 HVD1SS133MT DIODE 1SS133T-77
D969 HVD1SS133MT DIODE 1SS133T-77
D971 HVD1SS133MT DIODE 1SS133T-77
D972 HVD1SS133MT DIODE 1SS133T-77
D973 HVD1SS133MT DIODE 1SS133T-77
D974 HVD1SS133MT DIODE 1SS133T-77
D975 HVD1SS133MT DIODE 1SS133T-77
D976 HVD1SS133MT DIODE 1SS133T-77
Q501 HVTKTA1268GRT T.R KTA1268GR
Q502 HVTKTA1268GRT T.R KTA1268GR
Q503 HVTKTA1268GRT T.R KTA1268GR
Q504 HVTKTA1268GRT T.R KTA1268GR
Q505 HVTKTA1268GRT T.R KTA1268GR
Q511 HVTKTC3200GRT T.R KTC3200GR
Q512 HVTKTC3200GRT T.R KTC3200GR
Q513 HVTKTC3200GRT T.R KTC3200GR
Q514 HVTKTC3200GRT T.R KTC3200GR
Q515 HVTKTC3200GRT T.R KTC3200GR
Q516 HVTKTC3200GRT T.R KTC3200GR
Q517 HVTKTC3200GRT T.R KTC3200GR
Q518 HVTKTC3200GRT T.R KTC3200GR
Q519 HVTKTC3200GRT T.R KTC3200GR
Q520 HVTKTC3200GRT T.R KTC3200GR
Q541 HVTKTC3198YT T.R
Q542 HVTKTC3198YT T.R
Q543 HVTKTC3198YT T.R
Q544 HVTKTC3198YT T.R
Q545 HVTKTC3198YT T.R
Q556 HVTKTC3200GRT T.R KTC3200GR
Q557 HVTKTC3200GRT T.R KTC3200GR
Q558 HVTKTC3200GRT T.R KTC3200GR
Q559 HVTKTC3200GRT T.R KTC3200GR
Q560 HVTKTC3200GRT T.R KTC3200GR
Q561 HVTKTC3200GRT T.R KTC3200GR
Q562 HVTKTC3200GRT T.R KTC3200GR
Q563 HVTKTC3200GRT T.R KTC3200GR
Q564 HVTKTC3200GRT T.R KTC3200GR
Q565 HVTKTC3200GRT T.R KTC3200GR
Q601 HVTKTA1268GRT T.R KTA1268GR
Q602 HVTKTA1268GRT T.R KTA1268GR
Q603 HVTKTA1268GRT T.R KTA1268GR
Q604 HVTKTA1268GRT T.R KTA1268GR
Q605 HVTKTA1268GRT T.R KTA1268GR
AVR230 MAIN

5/16
Pos Part number 1st part name 2nd part name
Q681 KVTKSC2785YT T.R KSC2785Y
Q682 KVTKSC2785YT T.R KSC2785Y
Q683 KVTKSC2785YT T.R KSC2785Y
Q684 KVTKSC2785YT T.R KSC2785Y
Q685 KVTKSC2785YT T.R KSC2785Y
Q701 HVTKTC2874BT T.R , MUTE KTC2874B
Q702 HVTKTC2874BT T.R , MUTE KTC2874B
Q703 HVTKTC2874BT T.R , MUTE KTC2874B
Q704 HVTKTC2874BT T.R , MUTE KTC2874B
Q705 HVTKTC2874BT T.R , MUTE KTC2874B
Q706 HVTKTC2874BT T.R , MUTE KTC2874B
Q707 HVTKTC2874BT T.R , MUTE KTC2874B
Q708 HVTKTC2874BT T.R , MUTE KTC2874B
Q801 KVTKSC2785YT T.R KSC2785Y
Q802 KVTKSC2785YT T.R KSC2785Y
Q812 HVTKTA1268GRT T.R KTA1268GR
Q813 HVTKTC3200GRT T.R KTC3200GR
Q814 HVTKTA1268GRT T.R KTA1268GR
Q815 HVTKTC3200GRT T.R KTC3200GR
Q816 HVTKTA1268GRT T.R KTA1268GR
Q817 HVTKTA1268GRT T.R KTA1268GR
Q818 HVTKTC3200GRT T.R KTC3200GR
Q819 HVTKTC3200GRT T.R KTC3200GR
Q820 HVTKTC3200GRT T.R KTC3200GR
Q821 HVTKTC3200GRT T.R KTC3200GR
Q822 HVTKTC3200GRT T.R KTC3200GR
Q823 HVTKTC3200GRT T.R KTC3200GR
Q824 HVTKTC3198YT T.R
Q825 HVTKTC3198YT T.R
Q826 HVTKTC2874BT T.R , MUTE KTC2874B
Q827 HVTKTC2874BT T.R , MUTE KTC2874B
Q901 KVTKSC2785YT T.R KSC2785Y
Q902 HVTKRA107MT T.R KRA107M
Q903 HVTKRA107MT T.R KRA107M
Q904 HVTKRC107MT T.R KRC107M
Q911 HVTKTA1271YT T.R KTA1271Y
Q912 HVTKTA1271YT T.R KTA1271Y
Q913 HVTKTA1271YT T.R KTA1271Y
Q914 HVTKTA1271YT T.R KTA1271Y
Q915 KVTKSC2785YT T.R KSC2785Y
Q916 KVTKSC2785YT T.R KSC2785Y
Q917 KVTKSC2785YT T.R KSC2785Y
Q918 KVTKSC2785YT T.R KSC2785Y
Q938 HVTKRA107MT T.R KRA107M
Q939 HVTKRA107MT T.R KRA107M
Q942 KVTKSC2785YT T.R KSC2785Y
AVR230 MAIN
