AVR 630 FRONT-PANEL CONTROLS
The following controls and jacks are located behind the front-panel door.To open the door, place the edge
of your finger on the left or right edge of the panel and gently swing the door down towards you.
The following controls and indicators are available on the AVR 630’s front panel:
1Standby/On Switch
2Surround Mode Group Selector
3Surround Mode Selector
4Tuning Selector
5Tuner Band Selector
6Preset Station Selector
7Input Source Selector
8Tuning Mode Selector
9Front-Panel Control Door
)Volume Control
!Input Indicators
@Speaker/Channel Input Indicators
#Upper Display Line
$Lower Display Line
%Surround Mode Indicators
^Remote Sensor Window
AMain Power Switch
BHeadphone Jack
CTone Mode Button
DSpeaker Selector Button
EChannel Adjust Selector
FDigital Input Selector
GDelay Adjust Selector
H‹/›Buttons
ISet Button
JOptical 3 Digital Input
KInput/Output Status Indicators
LCoaxial 3 Digital Jack
MVideo 4 Audio/Video Jacks
