Thank you for purchasing a Harman Kardon AVR 7200.This Quick-Start
Guide will help you with a basic system installation. For detailed information
on any step, please refer to the Owner’s Manual pages referenced in this
guide.We strongly recommend that you read the Owner’s Manual for
complete details on how to install, configure and operate the AVR 7200,
as well as for the important safety information it contains.
Figure 1 – Speaker Placement
The colors shown for each speaker correspond to
the matching output terminal connection on the
back of the AVR 7200 (see page 8).
FRONT
LEFT
SPEAKER
(White)
SURROUND
BACK
LEFT
SPEAKER
(Brown)
SURROUND
BACK
RIGHT
SPEAKER
(Tan)
CENTER
SPEAKER
(Green)
SUBWOOFER
(Purple)
SURROUND
LEFT
SPEAKER
(Blue)
FRONT
RIGHT
SPEAKER
(Red)
SURROUND
RIGHT
SPEAKER
(Gray)
Step 1. Place your speakers in the listening room
(see page 18).
SPEAKER PLACEMENT
AVR 7200 QUICK-START GUIDE
Connections Color Guide
Audio Connections Left Right
Front
Center
Surround
Subwoofer
Surround Back
Digital Audio Connections
Coax
Optical
Video Connections
Composite
S-Video
Match the colored jacks on the AVR 7200 to the
appropriate jacks on your source equipment or speakers.
The colors are standardized, but not all equipment or
connectors use them.

AVR 7200 QUICK-START GUIDE
Step 2. Connect the speakers to the receiver: red (+) on speaker to colored (+) on receiver and black (–) to black (–)
(see page 15).
Step 3. Connect the Subwoofer Pre-Out jack to the Line-In jack on your subwoofer.
Adjust the settings on the subwoofer as needed (see page 15). Figure 3 – HowTo Use the Binding-Post
Speaker Terminal
SURROUND BACK
LEFT SPEAKER
SURROUND BACK
RIGHT SPEAKER
FRONT LEFT
SPEAKER
FRONT RIGHT
SPEAKER CENTER SPEAKER
SUBWOOFER
+
_
LINE IN/SUB/LFE +
_
SURROUND
LEFT SPEAKER
+
_
+
_
+
_
SURROUND
RIGHT SPEAKER
+
_
+
_
Figure 2 – Speaker Connections

SPEAKER AND AUDIO CONNECTIONS
CD PLAYER
AM Antenna
FM Antenna
AUDIO RECORDER
L R Optical Coax
REC/IN
PLAY/OUT
Step 4. ConnectAM and FM antennas (Fig. 4) (see page 15).
Step 5. Connect source components,as shown in Figures 4 and 5, and the
Device Connection Options chart on the back of this guide (see
pages 15–16).
AUDIO connections: Right channel (red) on source to right (red)
on AVR, and left channel (white) on source to left (white) on AVR.
DIGITAL AUDIO connections, if available: Choose either coax
(orange) to coax (orange) OR optical to optical for each device.
The Coax 1 input defaults to the DVD player, but may be reassigned.
Assign the other digital inputs and outputs as appropriate for your
equipment (see Step 7).
VIDEO connections: Choose component (Y/Pb/Pr – green/blue/
red), composite (yellow) or S-Video (4-pin) for each video source.
Connect the component, composite and S-Video Monitor outputs to
your Video Monitor (TV).Switch your TV set’s input to match the type
of video used for the currently selected source.
Step 6. Plug all components into AC power outlets.The outlets on the back
of the AVR 7200 should be used only for low-current products, such
as CD or DVD players, and the total should not exceed 100 watts.
Basic Receiver Configuration
Step 7. Select digital inputs: If your DVD is connected to Coax 1, no adjust-
ment is needed. For any other digital-device connections, use the
front-panel Digital Select button and the arrow buttons to select an
optical or coax digital input (see pages 20 and 30).
Step 8. Select a surround mode: Press the Surround Mode Group button
on the front panel to select a Dolby
®
mode, and the Surround Mode
Selector button to select a Dolby Pro Logic
®
mode. (You may select
other modes later; see pages 20–21 and 28–30.)
Step 9. Configure speakers: No action is needed if you have seven “small”
satellite-type speakers and a subwoofer. Otherwise, press the Speaker
button and then the Set and arrow buttons to select the correct
speaker choices for your system (see pages 21–23).
Step 10. Set the Output Levels with EzSet
™
:Set the Volume to –15dB.
Sit in the listening position and hold the remote in front of you at
shoulder level, pointing it at the receiver. Press the EzSet button on
the remote, and then the SET button when it lights red. Following
the instructions in the remote’s LCD display, press the
⁄ button on
the
remote until the display shows the number of speakers in your
system and then press the SET button again. Hold the remote steady
until the LCD display flashes a COMPLETE message (see pages 24–26).
Step 11. Your system is configured – sit back and enjoy!
Figure 4 –Audio Connections
Dashed lines (––––) indicate coax and optical
digital audio connections. Choose either type
(but not both) for each digital audio source.

DVD PLAYER
VCR (Video 1) TV or Video Monitor (Video 2)
In/Rec
Out/Play OUT
IN
L R VIDEO L R Video S-Video Component Video
Y Pb Pr Component Video
Y Pb Pr
Component Video
Y
Pb
Pr
Optical Coax
L R Video S-VideoL R Video S-Video
Cable or Sat or HDTV Set-Top Box (Video 3)
OUT
L R Video S-Video
Optical Coax
VIDEO CONNECTIONS
Device Connection Options:Recommended connections are shown in red, but connections may be made to best fit your system requirements.The Video 4,Coax 3 and Optical 3 inputs are on the front panel of the receiver.
Device Input Name Audio Input Connections Audio Output Connections Video Connections
CD Player CD CD L/R Inputs, Optical Digital 1 or 2,or Coaxial Digital 1 or 2Not required Not required
DVD Player DVD Coaxial Digital 1 or 2, Optical Digital 1 or 2,or DVD L/R Inputs Not required DVD Component, Composite or S-Video
VCR Video 1 Video 1 L/R Inputs Video 1 L/R Outputs Video 1 Composite or S-Video Input and Output
Cable Box or Satellite Receiver Video 3 Video 3 L/R Inputs, Optical Digital 3*,or Coaxial Digital 3*Inputs Not required Video 3 Composite or S-Video Input
Audio Recorder Tape Tape L/R Inputs, Optical Digital 1/2** or Coaxial Digital 1/2** Inputs Tape L/R Outputs,Digital Optical** or Coaxial Outputs** Not required
TV or Projector Video 2 or 3 Video 2 or 3 L/R Inputs Not required Monitor-Out Component, Composite and/or S-Video
*Check with your cable company to determine whether digital audio is available for all channels. It may be necessary to make BOTH analog and digital connections if it is not. **Digital audio recorders only.
250 Crossways Park Drive,Woodbury, NewYork 11797 www.harmankardon.com ©2003 Harman International Industries, Incorporated Part No.55738650
Power for the Digital Revolution.
®
®
Figure 5 –Video Connections
Dashed lines (––––) indicate coax and optical digital audio connections. Choose either type (but not both) for each
digital audio source.
Dotted lines (••••) indicate component, composite or S-Video connections.Component video is the preferred
connection when available, but you may use any of the three types (but not more than one).When component,
composite and S-Video sources are connected to the AVR you must also connect all outputs from the AVR to your TV.
