Harman Kardon AVR 745 User manual

harman/kardon
AVR745
A/V DOLBY DIGITAL RECEIVER
SERVICE MANUAL
CONTENTS
ESD WARNING........................ 2 ELECTRICAL PARTS LIST.... 11
LEAKAGE TESTING.................. 3 SEMICONDUCTOR PINOUTS 36
BASIC SPECIFICATIONS.......... 4 PCB DRAWINGS.................. 87
TROUBLESHOOTING GUIDE..... 5 SERVICE PROCEDURE....... 100
PROCESSOR RESET............... 5 BLOCK DIAGRAM................. 103
PACKAGING............................ 6 CIRCUIT DESCRIPTION......... 105
PACKING PARTS LIST.............. 7 WIRING DIAGRAM................ 106
UNIT EXPLODED VIEW............. 8 SCHEMATIC DIAGRAMS....... 107
EXPLODED VIEW PARTS LIST.. 9
harman/kardon, Inc.
250 Crossways Park Dr.
Woodbury, New York, 11797
harman/kardon
Service manual AVR745EU
Page 1 of 118

Each precaution in this manual should be followed during servicing.
Components identified with the IEC symbol in the parts list are special significance to safety. When replacing a component identified with
, use only the replacement parts designated, or parts with the same ratings or resistance, wattage, or voltage that are designated in the
parts list in this manual. Leakage-current or resistance measurements must be made to determine that exposed parts are acceptably
insulated from the supply circuit before retuming the product to the customer.
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field effect transistors and
semiconductor "chip" components.
The following techniques should be used to help reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any electrostatic charge on
your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging wrist strap device,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to
prevent electrostatic charge build-up or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static" can generate electrical charges
sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical change sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most replacement
ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable conductive material.)
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material to the
chassis or circuit assembly into which the device will be installed.
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the brushing together
or your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity sufficient to damage an ES devices.
CAUTION :
harman/kardon
Service manual AVR745EU
Page 2 of 118

SAFETY PRECAUTIONS
The following check should be performed for the continued
protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground (water
pipe, conduit, etc.) by connecting a leakage current tester
between the earth ground and all exposed metal parts of the
appliance (input/output terminals, screwheads, metal
overlays, control shaft, etc.). Plug the AC line cord of the
appliance directly into a 120V AC 60Hz outlet and turn the
AC power switch on. Any current measured must not exceed
o.5mA.
ANY MEASUREMENTS NOT WITHIN THE LIMITS
OUTLINED ABOVE ARE INDICATIVE OF A
POTENTIAL SHOCK HAZARD AND MUST BE
CORRECTED BEFORE RETURNING THE APPLIANCE
TO THE CUSTOMER.
Device
under
test
Test all
exposed metal
surfaces
Also test with
plug reversed
(Using AC adapter
plug as required)
AC Leakage Test
Leakage
current
tester
Reading should
not be above
0.5mA
Earth
ground
harman/kardon
Service manual AVR745EU
Page 3 of 118

ENGLISH
Technical Specifications
Audio Section
Stereo Mode
Continuous Average Power (FTC)
100 Watts per channel, 20Hz–20kHz,
@ < 0.07% THD, both channels driven into 8 ohms
5/7 Channel Surround Modes
Power Per Individual Channel
Front L&R channels:
85 Watts per channel,
@ < 0.07% THD, 20Hz–20kHz into 8 ohms
Center channel:
85 Watts, @ < 0.07% THD, 20Hz–20kHz into 8 ohms
Surround (L & R Side, L & R Back) channels:
85 Watts per channel,
@ < 0.07% THD, 20Hz–20kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High Level) 200mV/47kohms
Signal-to-Noise Ratio (IHF-A) 95dB
Surround System Adjacent Channel Separation
Analog Decoding 40dB
(Pro Logic, etc.)
Dolby Digital (AC-3) 55dB
DTS 55dB
Frequency Response
@ 1W (+0dB, –3dB) 10Hz–130kHz
High Instantaneous
Current Capability (HCC) ±60 Amps
Transient Intermodulation
Distortion (TIM) Unmeasurable
Rise Time 16 µsec
Slew Rate 40V/µsec**
FM Tuner Section
Frequency Range 87.5–108MHz
Usable Sensitivity IHF 1.3 µV/13.2dBf
Signal-to-Noise Ratio Mono/Stereo: 70/68dB (DIN)
Distortion Mono/Stereo: 0.15/0.2%
Stereo Separation 40dB @ 1kHz
Selectivity ±400kHz: 70dB
Image Rejection 80dB
IF Rejection 90dB
AM Tuner Section
Frequency Range 520–1710kHz
Signal-to-Noise Ratio 45dB
Usable Sensitivity Loop: 500µV
Distortion 1kHz, 50% Mod: 0.8%
Selectivity ±10kHz: 30dB
Video Section
Video Format PAL/NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency Response
(Composite and S-Video) 10Hz–8MHz (–3dB)
Video Frequency
Response (Component) 10Hz-50MHz (-3dB)
HDMI Version 1.1
General
Power Requirement AC 220-240V/50Hz
Power Consumption 120W idle, 1400W maximum
(7 channels driven)
Dimensions (Max)
Width 440mm
Height 165mm
Depth 435mm
Weight 19.9 kg
Depth measurement includes knobs, buttons and terminal connections. Height measurement
includes feet and chassis.All features and specifications are subject to change without notice.
Harman Kardon and Power for the Digital Revolution are registered trademarks of
Harman International Industries, Incorporated.
and are trademarks of Harman International Industries, Incorporated.
(Patent No. 5,386,478).
*Manufactured under license from Dolby Laboratories.
“Dolby,” “Pro Logic,” “Pro Logic II,” "Pro Logix IIx" and the Double-D symbol are trademarks of
Dolby Laboratories. Confidential Unpublished Works. ©1992–1999 Dolby Laboratories, Inc.
All rights reserved.
DTS and DTS Surround, DTS-ES and DTS Neo:6 are trademarks of Digital Theater Systems, Inc.
Logic 7 is a registered trademark of Harman International Industries, Incorporated.
A-BUS and A-BUS/
READY
®Ready are registered trademarks of Leisure Tech Electronics Pty Ltd
Australia.
TiVo is a registered trademark of TiVo, Inc.
SACD is a trademark of Sony Corporation.
iPod is a registered trademark of Apple Computer, Inc.
DLP and Texas Instruments are trademarks of Texas Instruments.
Faroudja and DCDi by Faroudja are trademarks of Genesis Microchip, Inc.
HD-DVD is a trademark of the DVD Format/Logo Licensing Corporation (DVD FLLC).
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing, LLC.
Microsoft, Windows and Windows Media are registered trademarks of Microsoft Corporation in
the United States and other countries.
**Without input anti slewing and output isolation networks.
The
Brid
g
eTM
Supplied Accessories
The following accessory items are supplied with the AVR 745.
If any of these items are missing, please contact Harman Kardon
customer service at www.harmankardon.com.
• TC 30 remote control
• Battery for the TC 30
• USB cable for the TC 30
• TC 30 charging cradle
• Charger for the TC 30
• TC 30 software CD-ROM
• TC 30 installation guide
• ZR 10 remote control
• Two AAA batteries for ZR 10
• microphone
• Extender rod for microphone
• AM loop antenna
• FM wire antenna
harman/kardon
Service manual AVR745EU
Page 4 of 118

ENGLISH
Troubleshooting Guide
Processor Reset
In the rare case where the unit’s operation or the
displays seem abnormal, the cause may involve
the erratic operation of the system’s memory or
microprocessor.
To correct this problem, first unplug the unit from
the AC wall outlet and wait at least three
minutes. After the pause, reconnect the AC
power cord and check the unit’s operation. If the
system still malfunctions, a system reset may
clear the problem.
To clear the AVR’s entire system memory includ-
ing tuner presets, output level settings, delay
times and speaker configuration data, first put
the unit in Standby by pressing the System
Power Control button
2 . Next, press the
Surround Mode
5 and the RDS ^ buttons
simultaneously for three seconds.
The unit will turn on automatically and display
the RESET message in the Main Infor-
mation Display
˜ . Note that once you have
cleared the memory in this manner, it is necessary
to re-establish all system configuration settings
and tuner presets.
NOTE: Resetting the processor will erase any
configuration settings you have made for
speakers, output levels, surround modes, digital
input assignments as well as the tuner presets.
After a reset the unit will be returned to the
factory presets, and all settings for these items
must be reentered.
If the system is still operating incorrectly, there
may have been an electronic discharge or severe
AC line interference that has corrupted the
memory or microprocessor.
If these steps do not solve the problem, consult
an authorized Harman Kardon service depot.
SYMPTOM CAUSE SOLUTION
Unit does not function when Main • No AC Power • Make certain AC power cord is plugged
Power Switch
1 is pushed into a live outlet
• Check to see if outlet is switch controlled
Display lights, but no sound • Intermittent input connections • Make certain that all input and speaker
or picture connections are secure
• Mute is on • Press Mute button
B K
• Volume control is down • Turn up volume control
Units turns on, but Front-Panel • Display brightness is turned off • Follow the instructions in the Display Brightness section
Display does not light on page 53 so that the display is set to VFD FULL
No sound from any speaker; • Amplifier is in protection mode • Check speaker-wire connections for shorts at receiver
light around Power switch
2 is red due to possible short and speaker ends
• Amplifier is in protection mode • Contact your local Harman Kardon service depot
due to internal problems
No sound from surround or • Incorrect surround mode • Select a mode other than Stereo
center speakers • Input is mono • There is no surround information from mono sources (except with
Theater and Hall surround modes)
• Incorrect configuration • Check speaker mode configuration
• Stereo or Mono program material • Some surround modes may not create rear-channel information
from nonencoded programs
Unit does not respond to • Weak batteries in remote • Change remote batteries
remote commands • Wrong device selected • Press the AVR Selector B
• Remote sensor
¯ is obscured • Make certain front-panel sensor is visible to remote or
connect remote sensor
Intermittent buzzing in tuner • Local interference • Move unit or antenna away from computers, fluorescent lights,
motors or other electrical appliances
Letters flash in the Channel Indicator • Digital audio feed paused • Resume play for DVD
Display Ú and Digital Audio stops • Check that Digital Signal is fed to the Digital Input selected
harman/kardon
Service manual AVR745EU
Page 5 of 118

PACKING PARTS LIST FOLLOWING PAGE
harman/kardon
Service manual AVR745EU
Page 6 of 118

AVR 745 EU Packing PartsList
NO PART NUMBER DESCRIPTION QT'Y
1ZKD2873HA00-R-A LABEL BARCODE AVR745EU TF PRINT 2
2ZKD2804HA00-R-8 BOX CARTON AVR745EU 1
3ZKD2801HA00-R-9 MANUAL AVR745EU 1
4 ZQD1201HAWH CUSHION POLY EPS RIGHT AVR635 1
5 ZHC1201AAWH FILM SHEET PE 920 X 1000 1
6H03-WAD022000BK-R-A WR002 H05VVF 0.75MMSQ 2G BLACK 2000MM 1
7 ZQD1202HAWH CUSHION POLY EPS LEFT AVR635 1
8 ZKD2802HA04 AVR745 TOTAL ACCESSORY BOX 1
9 See invidual parts REMOCON W/ ACCESSORY BOX AVR745EU UK 1
9a 501673-0000 USB PC LINK CABLE 1
9b 190304-0002 BATTERY TC 30 1
9c 602279-0900 SOFTWARE CD TC 30 1
9d TC 30 BATT DOOR BATTERY COVER TC30 1
9e TC 30 OM OWNERS MANUAL TC30 1
9f 866176-0000 BASE STATION CHARGER TC 30 1
9g 190254-A042 POWER SUPPLY TC 30 EU 1
9h 190254-A043 POWER SUPPLY TC 30 UK 1
9i 657316-0914 CARTON TC 30 EU UK 1
9j 190254-A044 REMOTE HANDSET TC30 1
10 ZBP00122051 BAG PE 330 X245 T0.05 1
11 ZKD2716HA00 QUICK SETUP GUIDE AVR745US 1
12 ZKC1214HA00 LABEL SAFETY LEAFLET 1
13 ZKC1113HA00 CARD WARRANTY 1
14 ZKD1263HA00 BROCHURE AVR US 1
15 ZKC1263HA00 INSERT RS232 NOTE PAPER 1
16 H03-ZPD1212INBK MICROPHONE ASSY EXTENSION PIECE 1
17 ZKD2802HA01 BOX ANTENNA 1
18 ZBP00161851 BAG PE 160X180MM 1
19 H03-WAD01200303-R-0 ANTENNA WIRE 75 OHM WIRE T15011F-1 1
20 H03-ATALF039ABK ANTENNA WIRE ANTENNA LOOP-300 1
21 ZBP00020350 POLYBAG BATTERY 1
22 BTA3A1511SF BATTERY ALKALINE 1.5V AAA 2
23 ZKD2802HA03 BOXZONE I1 REMOTE CONTROLLER 1
24 H03-RYD2702HA00 REMOCON ZONE 2 AVR745 1
25 ZKD2802HA02 BOX MIC 1
26 H03-MCD12TWBKNN
A
VR635 MICROPHONE ASSY 1
harman/kardon
Service manual AVR745EU
Page 7 of 118

harman/kardon
Service manual AVR745EU
Page 8 of 118

AVR 745EU EXPLODED VIEW PARTS LIST
NO. PART NO. DESCRIPTION Q'T
Y
1 H03-ZMC11S00200 AL DOOR AVR430/630 1
2 H03-ZMD2702GAGY AL PANEL FRONT AVR745 1
3 H03-ZMD2703GAGY BADGE FRONT AL AVR745 GREY HOT STAMPING 1
4 H03-ZMD27S20A00 BADGE harman/kardon COVER TOP AVR745 1
5 H03-ZMD27S08A00 COVER TOP AVR745 1
6 H03-ZVC11DWT200 TAPE PANEL 1
7 H03-ZVC11DWT100 TAPE DOOR 1
8 H03-ZMD12S01A00 SHIELD IR 1
9 H03-SOSS9CKX3NN JACK PHONE 6.35 H70980110S 9P BK 1
10 H03-ZMB01S00100 BKT HEADPHONE 1
11 H03-SWA2B21PDA& SW PUSH POWER SDDLB15700 1
12 ZPC1006GAWH BUTTON STANDBY 1
13 ZPC1003GAGY BUTTON POWER 1
14 ZPC1007GAMW INDICATOR STAND-BY 1
15 H03-ZMC11S12A00 CAP BUTTON STAND-BY AVR430/630 1
16 ZFD122062SB RUBBER TOP AVR635 1
17 ZPD2801GAGY PANEL FRONT AVR745EU 1
18 H03-ZMC11S14A00 BRACKET DOOR 1
19 ZPC1002GAGY DOOR AVR430/630 1
20 H03-ZMD05S16A00 BKT HINGE AVR7300 2
21 H03-ZPC1018GART FILTER VFD 1
22 H03-ZPD2719GABT WINDOW DISPLAY AVR745+BADGE NAME AVR745 1
23 H03-ZPD0317GACR CAP KNOB VOLUMN 1
24 H03-ZPD0316GASG COVER KNOB 1
25 H03-ZPD0315GAMW VOLUMN KNOB 1
26 H03-ZVC11GEAR01 DAMPER GEAR DP120 1
27 ZPC1102GAMW INDICATOR VIDEO 2
28 ZPC1005GAGY BUTTON 8 KEY 1
29 H03-ZPD1004GASG BUTTON 7 KEY EU 1
30 ZFNR19720SB RUBBER FOOT 19.7X19.7X2T BK 4
31 ZPC1103GAGY FOOT 50MM 15.8MM 4
32 H03-ZMD27S13A00 CHASSIS MAIN AVR745 1
33 H03-SORA3313PNN CON PHONOSCKT RCA-313P3PINS 1
34 H03-SORA8OSC5N8 JACK S-VIDEO 1P C40160261N 1
35 H03-ZMC12S17A00 AC PUN SHIELD DIGITAL ET 1
36 H03-SORA1JE01NN JACK RCA 1P JE010003MN GND OR 1
37 H03-SOTORX177LT FIBER OPTIC RECEIVING TORX177L (F, T)
38 H03-SO3P5179NNN JACK PHONE 3.5PI PJ0435179N 1
39 ZFD122072SB RUBBER TOP AVR635 3
40 H03-ZMC11S06A00 SPRING STOPPER AVR430/630 1
41 H03-SWE3A0505S1 SWIROT EC 16B24204A9 5V 500UOA 10T 3P 00 1
42 H03-ZMB01S02200 SPRING PLATE GND C5212 0.2T 9
43 H03-ZMD12S01B00 SHIELD MICROPHONE 1
44 H03-XD18BT19GNA VFD 18-BT-19GINK 1
45 ZPC1017GABK HOLDER VFD AVR430/630 1
46 H03-ZMC11S07A00 CHASSIS FRONT AVR430/630 1
47 H03-ICROMN338EC REMOCON RECEIVER MODULE ROM-N338TEC
48 H03-ZVJF0925S00-R DC FAN JF0925S1M-003C651R 12V 92x92x25mm
49 H03-ZMC11S09A00 BKT FAN FRONT AVR430/630 1
50 H03-ZMD27HS0200 H/SINK MAIN AVR745 1
51 H03-ZMC12S08B00 BKT TRANS BOTTOM 1
52 H03-TXPWMEI96B0 POWER TRANSFORMER AVR745EU MAIN TRANS 230V 50Hz 1
53 H03-ZMC12HS0100 AC HEATSINK 17x15x30 AVR520--ME 1
54 H03-ZMC11HS0400 HEATSINK DIODE 47x26x12 AVR630 1
55 H03-SOXA27014NN CON MAINS INLETAIC A/C INLET7014-NGP 1
56 H03-ZMC12S19A00 BKT AC INLET 2
57 H03-SOXA2202DNN-R A302D0061P AC Out Let (1P) 1
58 H03-ZMD27S06A00 BKT VIDEO 1
59 H03-ZMD27S04A00 BKT FRAME GUIDE AVR745 1
60 H03-ZMD27HS0100 H/SINK AMP AVR745 1
61 H03-ZMC12S09A00 BKT HEATSINK 5
62 H03-SOPA61M707G JACK SPEAKER 6P SH061M707G GN BN TA 1
63 H03-ZMD27HS0300 HEATSINK AMP SMALL 1
64 H03-SORA10003GN JACK RCA 1P JE010003SG GND YELLOW GOCD COLOR 1
65 SOPA96063NN JACK D-SUB 9P 87204-6063 W/DUST COVER BK 1
66 H03-SOJW2350SNN-R JACK PHONE 3.6 EP-1401A 1P BK 6
67 H03-ZMC12S16A00 BKT GROUND 1
68 H03-ZMC11S10A00 BKT FAN REAR AVR430/630 1
69 H03-SOYKF457009 JACKI HDMI YKF45-7009 JALCO 3
70 H03-SOR12BJ12GN JACK RCA 12P BJ120154JG R4 BU4 G4 GOLD COLOR 1
71 H03-SORA60031GN JACK RCA+S-VIDEO 6P C80300312GGOLD COLOR 2
72 H03-ZMD28S02A00 PANEL REAR AVR745EU 1
73 H03-SOUSB45810B JACK R41-5810B (Mitsumi) XM/DT connector 1
74 H03-SOUSB5005K0 AU6-EC-005K0 1
harman/kardon
Service manual AVR745EU
Page 9 of 118

75 H03-SOTX22073GN JACK RCA+ OPTICAL TX YKC22-0732N GOLD COLOR 1
76 H03-SORX22073GN JACK RCA+ OPTICAL RX YKC22-0733N GOLD COLOR 3
77 H03-SORA40RSAGN JACK RCA 4P JB040131ZG GN BN PP TA GOLD COLOR 2
78 H03-SORA40RSCGN JACK RCA 4P JB040131QG WH BU RD GY GOLD COLOR 1
79 H03-ZMD27S05A00 BKT IPOD 1
80 H03-SO1R018H91E DA1R018H91E 1
81 H03-SORA1J440GE JACK RCA 1P PPJ-440FEG PP GOLD COLOR 1
82 H03-SORA64105GN JACK RCA 6P JB060132PG WWWRRR GOLD COLOR 3
83 H03-ZVD01TUNE00 TUNER MODULE KST-MB114MW1-81 OEM EU
84 H03-ZMC11S04B00 BKT FRAME-GUIDE 1
85 ZMC12S13AYE STANDOFF HEX M4x0.7 6x31.9H 2
86 SO0A18P8CNN JACK-TELE SNAPG-IN GDLDEN TELECOM 1-8P8C 8T BK 1
87 H03-SOPA81M367G JACK SPEAKER 8P SH081M367G GY BU RD WH WH 1
88 ZMC12S14AYE STANDOFF HEX M4X0.7 6X61.9H 3
89 H03-ZMD27HS0400 H/SINK REG. TR AVR745 1
90 ZFNR13830SB RUBER SIDE 6
91 H03-ZMC12S07A00 COVER BOTTOM 1
92 ZUC1201AABK SPONGE 30X30X10T BK 3
93 H03-ZMD2701ZANI BRACKET POSISTOR,METAL,AVR745 2
94 H03-ZMD12S01C00 SHIELD DSP AVR745 1
96 H03-ZPD1019ZABK SPEAKER TERMINAL KNOB CORK B3M790BO 14
97 H03-ZMD27S07A00 SHIELD AL 1
98 H03-ZUD0301ABBK SPONGE-UL 30X30X12T BK 1
99 H03-ZMD27S09A00 BRACKET BKT XM 1
SW H03-SWC2A112FS1 SWITACT VERTICAL SKQNADD010 20
N1 ZNSSM4045HZ NUT M4 HEXAGON CIRCULAR EXTERNAL 4
N2 ZNSSM3023HZ NUT M3 ZN PLATED 1
S1 ZSTBM3010BB SCREW ST BH 3X10 65
S2 ZSTWM3008BY SCREW ST WPH 3X8 47
S3 ZSMCM4010BB SCREW BM 4X10 4
S4 ZSTWM4008BC SCREW ST WPH 4X8 SILVER CHROM 14
S5 ZSTWM3006BB SCREW ST WPH 3X6 7
S7 ZSTBM3012BY SCREW ST BH 3X12 PIVOT 43
S8 ZSMCM4008BY SCREW BM 4X8 5
S9 ZSMBM3014BZ SCREW M.S M3X14 ZN PLATED 1
S10 ZSMPM3006LB SCREW M.S.M3X6 P/HD BLACK 3
S11 ZSTBM3008BY SCREW ST BH 3X8 1
S12 ZSTBM3014BY SCREW ST BH 3X14 PIVOT 1
SG ZSTGM3010BB SCREW ST BH 3X10 GROUND 51
W1 ZWM623108SZ WASHER SPRING 3 42
W2 ZWM803305PZ WASHER PLAIN 3 19
W3 ZWM763109SZ AC SPRING WAS HER RT2250(PAV5005) 4
W4 ZWMC04810PZ WASHER PLAIN 4 4
harman/kardon
Service manual AVR745EU
Page 10 of 118

AVR745 Electrical Parts List
Ref. Designator Part Number Description
DSP PCB ASS'Y
Capacitors
C407 C408 C409 H03-CEHEC02275E-R CE 220UF +20% 10.0V D6.3XL11 P5MM 85C SK 220/10V 5 X11
C959 H03-CEHEC0477MN-R CE 470U0F +20% 10.0V 6.3X11 85C P5MM SK 470/10V 6.3 X11
C106 C107 C116 C117 C130
C131 C140 C141 C148 C149
C162 C163 C166 C167 C176
C177 C196 C197 C277 C284
C289 C308 C316 C350 C353
C362 C365 C373 C376 C423
C424 C448 C449 C450 C451
C452 C453 C492 C495 C595
C651 C654 C902
H03-CEHFC01062S-R CE 10UF +20% 16V D4XL7 P2.5MM 2000hours 85C
C101 C125 C153 C204 C205
C220 C221 C269 C271 C274
C357 C431 C482 C483 C484
C485 C515 C635 C682 C744
C745 C904 C912
H03-CEHFC01072S-R CE 100UF +20% 16V D6.3XL7 P2.5MM 2000hours 85C
C403 C412 C418 C436 C454
C465 H03-CEHFC01075E-R CE 100UF +-20% 16.0V D5XL11 P5MM 85C SK 100/16V 5 X11
C180 C211 C234 C238 C265
C305 C319 C514 C600 C609
C673 C687 C958
H03-CEHFC04762S-R CE 47UF +20% 16V D5XL7 P2.5MM 2000hours 85C
C821 C822 H03-CEHGC01075E-R CE 100U0F +20% 25.0V 6.3X11 85C P5MM SK 100/25V 6.3 X11
C520 CEHIC01042S-R CE 100NF +20% 50V SSE TYPE D4XL7 P2.5MM 85C
C207 C208 C583 C584 H03-CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C SK 1/50V 5 X11
C276 H03-CEHIC0474NN-R CE 0.47UF +20% 50.0V 85C 5X11 P5MM
C304 H03-CEHIC04755E-R CE 4U7F +20% 50.0V 85C P5MM SK 4.7/50V 5 X11
C503 C628 C629 CFIOC0104NN-R CPM 100N0F +10% 250.0V
C521 H03-CEMIC04752H-R CAP ELEC 4.7UF 50V M 5X11 SHL P2.5MM
C301 C311 C312 C313 C315
C327 C328 C330 C331 C419
C420 C429 C430 C434 C435
C444 C445 C456 C457 C462
C463 C472 C473 C478 C479
C801 C802 C803 C804 C805
C806 C807 C808 C809 C810
C811 C812 C813 C814 C815
C816
CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C223 CZJII0101CE-R CAP CERAMIC/CHIP 100PF 50V CH J NPO 0805
C222 CZJII0102CC-R CAP CHIP 1nF 50V X7R J 0805
C700 C702 C720 C743 CZJII0220BE-R CCCFMIC 22P0F +5% -5% 50.0V NP0
C224 C225 CZJII0270BE-R CAP CHIP 27P0F +5% -5% 50.0V NP0 0603
C263 C264 C309 C310 C632
C633 CZJII0330BE-R CAP CHIP 33P0F +5% -5% 50.0V NP0 0603
C326 C329 CZJII0470BE-R CAP CHIP 47P0F +5% -5% 50.0V NPO 0603
C194 C195 C198 C199 CZJII0471BE-R CCCFMIC 470P0F +5% -5% 50.0V NP0
C132 C332 C333 C425 C426
C438 C439 C466 C467 C468
C469
CZKII0102BC-R CAP CHIP 1N0F +10% -10% 50.0V X7R 0603
C701 C703 C706 C717 CZKII0103BC-R CAP CHIP 10N0F +10% -10% 50.0V X7R 0603
C229 C380 C382 C596 C597
C685 CZKII0122BC-R CAP CHIP 1N2F +10% -10% 50.0V X7R 0603
C104 C105 C108 C109 C114
C115 C118 C119 C128 C129
C133 C138 C139 C142 C143
CZKII0221BA-R CAP CHIP 220PF 50V K SL 0603
C652 C653 CZKII0222BC-R CAP CHIP 2N2F +10% -10% 50.0V X7R 0603
C182 C183 C200 C201 C598
C599 CZKII0272BC-R CAP CHIP 2N7F +10% -10% 50.0V X7R 0603
C102 C103 C110 C111 C112
C113 C120 C121 C126 C127
C134 C135 C136 C137 C144
C145
CZKII0821BC-R CAP CHIP 820P0F +10% -10% 50.0V X7R 0603
AVR745 harman/kardon
harman/kardon
Service manual AVR745EU
Page 11 of 118

Ref. Designator Part Number Description
DSP PCB ASS'Y
C150 C154 C157 C161 C165
C168 C175 C178 C202 C206
C209 C210 C212 C213 C214
C215 C217 C218 C226 C230
C232 C233 C242 C246 C247
C248 C249 C250 C251 C252
C253 C256 C267 C268 C272
C273 C275 C278 C282 C283
C292 C303 C306 C307 C318
C320 C322 C324 C325 C340
C343 C346 C347 C348 C351
C352 C354 C355 C358 C360
C361 C363 C364 C367 C368
C371 C372 C374 C375 C378
C404 C405 C406 C411 C413
C414 C421 C422 C432 C433
C440 C441 C442 C443 C458
C459 C460 C461 C474 C475
C476 C477 C487 C490 C491
C493 C494 C497 C498 C513
C522 C525 C574 C580 C582
C589 C607 C610 C611 C634
C641 C642 C643 C644 C645
C663 C672 C674 C686 C708
C715 C824 C903 C910 C913
C918 C922 C925 C926 C927
C928 C929 C930 C946~C954
C956 C960~C978 C980 C981
C982 C983 C986 C987 C988
C989 C990 C991 C992 C931
C932
CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C240 C241 CSJIE0300BG-R CAP,CHIP FORM 30P +/-5% 50V C0G 0603
C314 C486 C825 CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C505 C506 CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603 EUROPE ONLY
C302 CZJII0220BE-R CCCFMIC 22P0F +5% -5% 50.0V NP0
C683 C684 CZJII0330BE-R CAP CHIP 33P0F +5% -5% 50.0V NP0 0603
C227 C228 CZJII0470BE-R CAP CHIP 47P0F +5% -5% 50.0V NPO 0603
C100 C122 C123 C124 C146
C147 C151 C152 C160 C169
C174 C181 C203 C216 C219
C235 C237 C239 C243 C244
C254 C266 C270 C286 C291
C293 C295 C297 C300 C317
C321 C323 C337 C338 C383
C417 C427 C428 C437 C446
C447 C455 C464 C470 C471
C480 C481 C504 C510 C581
C591 C604 C664 C689 C723
C742 C823 C826 C901 C905
C919 C920 C921 C945 C979
C984 C985
CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C395 CZKII0103BC-R CAP CHIP 10N0F +10% -10% 50.0V X7R 0603
C557 H03-CEZXA0479MN-R CM 47MI0F +80%-20% 5.5V 70C SCDA5R5473V
Semiconductors
Q851 H03-TRKTA107MNA-R TR-SLPSWA KRA107M PNP
Q511 H03-TRMPSA06NNA-R TR-SLPLF MPSA06 NPN 500MI0A TO-92
D403 D410 D507 D508 D603
D700 H03-DS1S50094NB-R D-SLP 1SS355 35.0V 225MI0A
D401 D402 H03-DSUDZ09V1NB-R D-ZENER UDZS 9.1B 9.1V 200MI0W
IC53 H03-IC24LC256D2-R IC CMOS SERIAL EEPROM 24LC256T-I/SNG SOIC-8P(150MIL)
IC16 H03-IC24LC64ID2-R 24LC64-I/SNG SOIC-8P(150mil) Serial EEPROM
IC45 H03-IC74AHC1G14-R 74AHC1G14 SOT753 Inverting Schmitt trigger
IC78 H03-IC74LVC254D-R ICSN74LVC257AD SOIC-16 Quadruple 2-Line To 1-Line Data
Selector/Multiplexer
IC50 H03-IC74VC244G5-R IC-LOGIC 74VHC244MX or 74VHC244MX_NL M20B INVERTER CMOS
AVR745 harman/kardon
harman/kardon
Service manual AVR745EU
Page 12 of 118

Ref. Designator Part Number Description
DSP PCB ASS'Y
IC23 H03-ICBU4094BD3-R IC CMOS BU4094BCF SOP16 8-bit compatible shift / store register
IC94 H03-ICM317TO252-R IC 3-TERMINAL POS VOL REG NJM317DL1-TE1 TO-252
Q401 Q407 Q408 Q411 Q502
Q503 Q505 Q506 Q509 Q512
Q700
H03-TSKRC107SND-R KRC107S SOT-23 NPN
D405 D406 D415 D416 H03-DS05GBUSCNB-R DIODE PG05GBUSC
D338 D404 D409 D414 D509
D510 H03-DS1S50094NB-R D-SLP 1SS355 35.0V 225MI0A
D339 H03-DSUDZ05V1NB-R DIODE ZENER UDZ5.1B 5.1V 200MI0W
IC22 H03-IC70F3261E1-R7UPD70F3261YGC-8EA-A LQFP100 32-bit single-chip microcontroller
IC96 H03-IC74CB3T3D2-R IC SN74CB3T3306DCTR SSOP-8 Dual Bus Switch Voltage Translator
IC57 IC59 H03-IC74LC1G1DL-R IC SINGLE SCHMITT BUFFERSN74LVC1G17DBVR SOT(SOT-23)DBV
IC17 IC18 IC19 H03-IC74LVC254D-R ICSN74LVC257AD SOIC-16 Quadruple 2-Line To 1-Line Data
Selector/Multiplexer
IC10 IC12 IC38 IC39 H03-ICAD1852JDA-R IC 192Khz 24bit DAC AD1852JRSZ SSOP28
IC20 H03-ICAK4114VE8-R IC 192Khz 24bit INTERFACEAK4114VQ LQFP48
IC25 IC26 IC27 IC37 H03-ICAK5385ADA-R IC A/D CONVERTORAK5385AVF VSOP28
IC92 H03-ICAT49BV163-R IC FLASH MEMORY AT49BV163DT(or AT)-70TU TS
IC21 H03-ICBU4051BD3-R IC ANALOG MPX/DEMPX BU4051BCF SOP16
IC35 H03-ICBU4053BB4-R IC BU4053BCF SOP16 ANALOG MPX/DEMPX
IC24 IC28 H03-ICBU4094BD3-R IC CMOS BU4094BCF SOP16 8-bit compatible shift / store register
IC40 H03-ICDS1233ADK-R IC 3.3V ECONO RESET DS1233AZ-15+TR SOT-223
IC93 H03-ICK4S1616UC-R K4S161622H-UC60 OR UC80 TSOP50 512K x 16Bit x 2 Banks SDRAM
IC13 IC41 IC42 IC43 IC44 IC49
IC60 IC61 IC62 IC63 IC64 IC65
IC66 IC67 IC68 IC69 IC71 IC72
H03-ICLM02068D2-R IC-OPERAMP NJM2068M-TE1 DUAL SOP8
IC74 IC75 H03-ICM74H04MD4-R IC-LOGIC M74HCU04M1R INVERTER HCT
IC11 IC31 H03-ICS4391AKZZ-R CS4391A-KZZ SOP20 24-BIT, 192 kHz STEREO DAC WITH VOLUME CONTROL
IC36 H03-ICTC9162CDA-R IC CMOS TC9162CFG SOP28 HIGH VOLTAGE ANALOG FUNCTION SWITCH
ARRAY
IC91 H03-ICTMS320DNN-R IC FLOATING-POINT DSPTMS320DA610-250 PQFP208
IC14 H03-ICTUSB320EB-R ICTUSB3200A TQFP52 USB Streaming Controller
IC15 H03-ICXMDIC00E8-R IC DIGITAL TRANCEIVERXMDIC QFP48
IC51 IC52 H03-ICC1G125DCK-R IC SINGLE BUS BUFFER GATE SN74LVC1G125DCKT SOT(SC-70)DCKT
Q710 Q188 Q200 Q405 Q409
Q500 Q501 Q504 Q507 Q508
Q510 Q513 Q514
H03-TSKRC107SND-R KRC107S SOT-23 NPN
IC30 H03-ICCJT1173N3-R IC VOLTAGE REGULATOR CJT117-3.3 SOT-223
D501 H03-DURS10040NA-R RS1004 RS-10
IC85 H03-ICPC17T10B1-R IC PHOTOCOUPLER PC-17T1 DIP4 KODENSHI
Resistors
RS14 RS16 RS17 RS18 RS19 RN3AY0220NA-R RES NETWORK RCA 22OHM 1/16W 5% CN34JT220
R271 RS1AD0183NA-R 18K ohm 1/16W 1% 0603
R234 RS1AD3091NA-R RES CHIP 3.09K OHM 1/16W 1% 0603
R213 RS1AD3321NA-R RES CHIP 3.32K OHM 1/16W 1% 0603
R214 RS1AD4751NA-R RES.CHIP 4.75K 1/16W +/-1% 0603
C290 C294 C296 C298 R219
R310 R311 R631 C603 R953
R954 J201 J202 J407 J408
J409
RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
R310 R311 RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603 USA ONLY
R244 R248 R274 R278 R302
R303 R503 R504 R505 R507
R508 R707 R708 R709
RS3AD0100NA-R RMGCFMIC 10R0 OHM +5% 0603
R254 R255 R289 R290 R291
R292 R316 R405 R417 R418
R424 R426 R445 R467 R478
R511 R512 R569 R609 R610
R611 R612 R932 R570
RS3AD0101NA-R RES CHIP,100R 1/16W +/-5%,0603
AVR745 harman/kardon
harman/kardon
Service manual AVR745EU
Page 13 of 118

Ref. Designator Part Number Description
DSP PCB ASS'Y
R104 R105 R256 R257 R284
R286 R293 R295 R337 R487
R604 R648 R655 R703 R704
R743 R803 R804 R807 R808
R811 R815 R816 R968
RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R281 R515 RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603 EUROPE ONLY
R101 R107 R108 R109 R110
R183 R187 R188 R190 R191
R193 R264 R267 R296 R304
R307 R308 R322 R323 R324
R326 R327 R328 R427 R428
R441 R442 R443 R444 R457
R458 R459 R460 R463 R464
R469 R470 R473 R474 R475
R476 R489 R490 R491 R492
R495 R496 R685 R923 R969
R991 R992 R993 R994 R995
RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R141 R142 R151 R152 R177
R178 R201 R202 R236 R419
R466 R556 R653 R702 R706
R724 R730 R801 R802 R805
R806 R809 R813 R814
RS3AD0104NA-R RES CHIP,100K 1/16W +/-5% ,0603
R319 RS3AD0105NA-R RES CHIP 1M 1/16W +5% 0603
R513 R514 R725 RS3AD0122NA-R RMGCFMIC 1K2 OHM +5% 0603
R571 RS3AD0151NA-R RMGCFMIC 150R0 OHM +5% 0603
R163 R285 R737 R740 RS3AD0153NA-R RES CHIP,15K 1/16W,+/-5%,0603.
R919 RS3AD0182NA-R RES CHIP,1.8K,1/16W,+-5%,0603.
R119 R120 R124 R125 R133
R134 R137 R138 R155 R156
R159 R160 R169 R170 R173
R174 R221 R222 R225 R226
R590 R591
RS3AD0202NA-R RMGCFMIC 2K0 OHM +5% 0603
R429 R430 R461 R462 R471
R472 R493 R494 RS3AD0203NA-R RMGCFMIC 20K0 OHM +5% 62MI5W 0603
R716 RS3AD0220NA-R RES CHIP,22R 1/16W +/-5%,0603
R639 RS3AD0221NA-R RMGCFMIC 220R0 OHM +5% 0603
R262 R263 R269 R270 R279
R309 R553 R554 R664 R924 RS3AD0222NA-R RMGCFMIC 2K2 OHM +5% 0603
R181 R182 R184 R189 R192
R194 R198 RS3AD022ANA-R RMGCFMIC 2R2 OHM +5% 0603
R723 R277 RS3AD0241NA-R RES CHIP 240 OHM 1/16W +/-5% 0603
R812 RS3AD0362NA-R RMGCFMIC 3K6 OHM +5% 0603
R247 RS3AD0390NA-R RES,CHIP 39 OHM 1/16W +/-5% 0603
R726 RS3AD0391NA-R RMGCFMIC 390R0 OHM +5% 0603
R920 R921 R922 RS3AD0392NA-R RMGCFMIC 3K9 OHM +5% 0603
R568 RS3AD0470NA-R RMGCFMIC 47R0 OHM +5% 0603
R637 R638 R931 RS3AD0471NA-R RMGCFMIC 470R0 OHM +5% 0603
R122 R123 R130 R135 R158
R166 R171 R224 R229 R240
R241 R245 R407 R408 R420
R425 R440 R588 R603 R967
RS3AD0472NA-R RES CHIP,4K7 1/16W +/-5%,0603
R301 R431 R432 R433 R434
R435 R436 R437 R438 R996 RS3AD0473NA-R RES CHIP,47K 1/16W +/-5%,0603
R113 R114 R143 R144 R149
R150 R179 R180 R199 R200
R299 R597
RS3AD0561NA-R RES CHIP,560R 1/16W +/-5%,0603
R810 RS3AD0682NA-R RMGCFMIC 6K8 OHM +5% 0603
R273 R619 R632 R633 R700
R701 R705 RS3AD0750NA-R RMGCFMIC 75R0 OHM +5% 0603
R821 R822 R823 R824 R825
R826 R827 RS3AD0823NA-R RES,CHIP 82K,1/16W,+/-5%,0603
R654 RS3AD0272NA-R RMGCFMIC 2K7 OHM +5% 0603
R651 RS3AD0680NA-R RMGCFMIC 68R0 OHM +5% 0603
RS11 RS12 RS13 RS15 RN3AY0220NA-R RES NETWORK RCA 22OHM 1/16W 5% CN34JT220
AVR745 harman/kardon
harman/kardon
Service manual AVR745EU
Page 14 of 118

Ref. Designator Part Number Description
DSP PCB ASS'Y
C716 R205 R206 R209 R211
R212 R238 R239 R258 R272
R381 R382 R383 R396 R397
R621 R622 R657 R712 R999
J301 J403 J404 J405 J406
RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
C299 R251 R252 R561 R562
R563 R564 R565 R566 R567
R572 R687
RS3AD0100NA-R RMGCFMIC 10R0 OHM +5% 0603
R102 R103 R111 R148 R197
R207 R208 R242 R243 R320
R385 R386 R387 R388 R598
RS3AD0101NA-R RES CHIP,100R 1/16W +/-5%,0603
R106 R294 R325 R334 R335
R336 R338 R339 R395 R558
R607 R661 R662 R663
RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R265 R266 R268 R298 R305
R306 R314 R315 R509 R516
R517 R559 R601 R602 R744
R997
RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R287 RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603 USA ONLY
R288 RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603 EUROPE ONLY
R115 R116 R237 R253 R259
R260 R261 R312 R313 R333
R595 R656 R979
RS3AD0104NA-R RES CHIP,100K 1/16W +/-5% ,0603
R321 RS3AD010ANA-R RES CHIP,1R 1/16W +/-5%,0603
R195 R196 R988 RS3AD0121NA-R RMGCFMIC 120R0 OHM +5% 0603
R389 RS3AD0151NA-R RMGCFMIC 150R0 OHM +5% 0603
R736 R738 R741 RS3AD0152NA-R RMGCFMIC 1K5 OHM +5% 0603
R727 R739 R164 RS3AD0153NA-R RES CHIP,15K 1/16W,+/-5%,0603.
R913 R914 R916 R917 R918 RS3AD0182NA-R RES CHIP,1.8K,1/16W,+-5%,0603.
R185 RS3AD022ANA-R RMGCFMIC 2R2 OHM +5% 0603
R711 RS3AD0241NA-R RES CHIP 240 OHM 1/16W +/-5% 0603
R447 R448 R449 R450 R451
R452 R453 R454 R479 R480
R481 R482 R483 R484 R485
R486
RS3AD0331NA-R RMGCFMIC 330R0 OHM +5% 0603
R161 R162 RS3AD0332NA-R RMGCFMIC 3K3 OHM +5% 0603
R231 R518 RS3AD033ANA-R RMGCFMIC 3R3 OHM +5% 0603
R246 R249 R250 RS3AD0390NA-R RES,CHIP 39 OHM 1/16W +/-5% 0603
R384 R686 R688 R689 RS3AD0330NA-R RMGCFMIC 33R0 OHM +5% 0603
R853 R915 RS3AD0392NA-R RMGCFMIC 3K9 OHM +5% 0603
R117 R118 R126 R127 R131
R132 R139 R140 R153 R154
R167 R168 R175 R176 R203
R204 R227 R228 R592 R593
RS3AD0432NA-R RMGCFMIC 4K3 OHM +5% 0603
R318 R669 RS3AD0470NA-R RMGCFMIC 47R0 OHM +5% 0603
R652 R852 R854 RS3AD0471NA-R RMGCFMIC 470R0 OHM +5% 0603
R121 R128 R129 R136 R157
R165 R172 R223 R230 R232
R233 R280 R282 R283 R439
R557 R589 R851
RS3AD0472NA-R RES CHIP,4K7 1/16W +/-5%,0603
R300 RS3AD0473NA-R RES CHIP,47K 1/16W +/-5%,0603
R510 RS3AD0474NA-R RMGCFMIC 470K0 OHM +5% 0603
R275 R989 RS3AD047ANA-R RES CHIP,4R7 1/16W +/-5%,0603.
R634 R683 R684 R276 RS3AD0750NA-R RMGCFMIC 75R0 OHM +5% 0603
R574 R981 RS1AD0750NA-R RES CHIP 75OHM 1% 1/16W 0603
R100 R499 RC3DI0331IN-R RCF 330R0 OHM +5% 250MI0W
Miscellaneous
L412 L416 L418 L424 L425
L436 L503 L533 H03-FB3012012CF-R FCM2012CF-301T04 0805
E901 H03-FYACF333TNN-R FILTER ACF451832-333-T
L222 L404 L408 L409 L410
L411 L417 L419 L422 L433
L435 L502 L686 L903 L904
L905 L906
H03-FB3012012CF-R FCM2012CF-301T04 0805
AVR745 harman/kardon
harman/kardon
Service manual AVR745EU
Page 15 of 118

Ref. Designator Part Number Description
DSP PCB ASS'Y
Y112 H03-OSXNL4515B0-R CRYSTAL 45.1584MHz 22p SO22320D5-45.1584-T&R USA ONLY
N111 H03-SOUSB45810B-R JACK R41-5810B (Mitsumi) XM/DT connector USA ONLY
N101 H03-SOUSB5005K0-R AU6-EC-005K0
L414 L415 RS3AD0270NA-R RES,CHIP 27 OHM 1/16W +/-5% 0603
L413 R421 RS3AD0751NA-R RES.CHIP,750OHM,1/16W,+-5%,0603.
L401 L403 L405 L902 H03-FB05B3580NN-R BEAD AXIAL/TAP,HC3580 80.5ohm
L431 L432 L434 L702 H03-LAINB0470CR-R LF 47U0H +10% 5.8 OHM 500MI0A
L421 L426 L428 L429 L430
L501 H03-LAINB047ACR-R LF 4U7H +10% 1.7 OHM 190.0A
P091 H03-ICLM19CIZIE-R IC TEMPERATURE SENSOR LM19CIZ 2.4V TO-92
Y105 H03-OSCEM05M0RU-R CERAMIC RESONATORCSTLS_G 5.0MHz
Y413 H03-OSCEM24M5RU-R VCXO 24M576 HZ +50 PPM -50 PPM 0 OHM 3.3V
Y111 H03-OSX06M0HZ00-R CRYSTAL6MHz 2P WOOIN HC-49/S_22PF
K700 H03-RLL0516632B-R RELAY PWR 5.0V 166.0OHM 1.0A 24.0V
N802 H03-SORA40RSAGN-R JACK RCA 4P JB040131ZG GN BN PP TA ,GOLD COLOR
N801 H03-SORA40RSCGN-R JACK RCA 4P JB040131QG WH BU RD GY,GOLD COLOR
J411 J413 J414 H03-SORX22073GN-R JACK RCA+ OPTICAL RX YKC22-0733N,GOLD COLOR
J402 H03-SOTX22073GN-R JACK RCA+ OPTICAL TX YKC22-0732N,GOLD COLOR
N931 H03-WE03B012000-R WIRE ASS`Y UL1007#26 120MM 2.0MM 3P WHT
N119 H03-WN03SB00000-R CONNECT 2.0mm 3P GIL-S-3P-S2T2-EF
P711 P712 H03-WN03SE00000-R CON 3.96MM PITCH MOLEX 35313-0310
N707 H03-WN04AB100WH-R CONN WAFER 2.0MM 4P 35237-0410 WHT
P704 H03-WN05SB00000-R CONNECT 2.0mm 5P GIL-S-5P-S2T2-EF
N716 H03-WN07AB100WH-R CONN WAFER 2.0MM 7P 35237-0710 WHT
P715 H03-WN07SB100WH-R CONN WAFER 2.0MM 7P 35336-0710 WHT
N714 H03-WN09AB100WH-R CONNECT WAFER 2.0mm 9P 35237-0910 WHT
P703 H03-WN09SB00000-R CONNECT 2.0mm 9P GIL-S-9P-S2T2-EF
P713 H03-WN09SB100WH-R CONNECT WAFER 2.0mm 9P 35336-0910 WHT
N706 H03-WN15AB100WH-R CONNECT WAFER 2.0mm 15P 35237-1510 WHT
N705 H03-WN16AB100WH-R CONNECT WAFER 2.0mm 16P 35237-1610 WHT
P714 H03-WN16DI00000-R GF120-16S-TS 1.25mm 16P
N702 N710 H03-WN19AB00000-R CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910 0 0
P701 H03-WN22DI00000-R GF120-22S-TS 1.25mm 22P
P708 H03-WN29DI00000-R CONNECT 1.25MM 29PINGF120-29S-TS
BK10 H03-ZMD27S09A00-R BRACKET BKT XM
FRONT PCB ASS'Y
Capacitors
C127 CEHFC0107NN-R CE 100U0F +20% 16.0V 85C
C119 C128 C551 CCZID0104NA-R CC 100N0F +80% -20% 50.0V F
C517 H03-CEHEC02275E-R CE 220UF +20% 10.0V D6.3XL11 P5MM 85C SK 220/10V 5 X11
C718 H03-CEHFC04765E-R CE47UF +20% 16.0V D5XL11 P5MM 85C SK 47/16V 5 X11
C501 C502 C708 H03-CEHFC04762S-R CE 47UF +20% 16V D5XL7 P2.5MM 2000hours 85C
C503 C504 H03-CEHFC01062S-R CE 10UF +20% 16V D4XL7 P2.5MM 2000hours 85C
C125 C126 H03-CFHKA0473NN-R CAP POLYESTER METAL 47NF 100V 20% CPM
C701 C704 C706 CZDII0100CE-R CAP CERAMIC/CHIP 10PF 50V CH D N 0805
C120 C121 C122 C400 C401
C403 C404 C717 C725 C726
C727 C900
CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C702 CZJII0101CE-R CAP CERAMIC/CHIP 100PF 50V CH J NPO 0805
C703 C705 CZJII0122CC-R CAPCHIP 1n2F 50V SL J X7R 0805 +/-5%
C300 C301 CZJII0821CE-R CAP CHIP 820pF 50V SL J NP0 0805
C506 CZKII0221BA-R CAP CHIP 220PF 50V K SL 0603
C252 C253 CZKII0222BC-R CAP CHIP 2N2F +10% -10% 50.0V X7R 0603
C201 C211 CZKII0223BC-R CAP CHIP 22N0F +10% -10% 50.0V X7R 0603
C1 C2 C124 C251 C254 C405
C406 C407 C411 C521 C552
C553 C709 C723
CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
Semiconductors
Q821 H03-TRMPSA06NNA-R TR-SLPLF MPSA06 N 500MI0A TO-92 NPN
Q823 H03-TRMPSA56YNA-R TR-SLPLF MPSA56 Y PNP -500MI0A -300V
D301 H03-DG1N04148NB-R D-SLP 1N4148 100.0V 150E-3A
AVR745 harman/kardon
harman/kardon
Service manual AVR745EU
Page 16 of 118

Ref. Designator Part Number Description
FRONT PCB ASS'Y
D716 H03-DR1N04004NA-R D-SR 1N4004 400.0V 1.0A
D853 D854 D855 D856 H03-DL30B2015AA-R D-LEM 30B3-20-15 GaN SUPER BLUE WATER CLEAR 15 ML37B23H-CED
D831 H03-DL3BA05V0BA-R D-LEM BLUE/AMBER 3PIE RD RND L-3VYMBC
D800 D801 H03-DLRED3FRDBA-R D-LEM RED/GREEN 3F RD RND CL
D251 D252 D411 D412 D701
D715 D721 D722 H03-DS1S50094NB-R D-SLP 1SS355 35.0V 225MI0A
D110 H03-DSUDZ05V1NB-R DIODE ZENER UDZ5.1B 5.1V 200MI0W
IC50 H03-ICLM02068D2-R IC-OPERAMP NJM2068M-TE1 DUAL SOP8
Q703 H03-TRKTA1504ND-R TRANSISTOR PNP KTA1504Y(S)SOT-23
Q701 Q702 H03-TRKTC3875ND-R TRANSISTOR NPN KTC3875S SOT23
Q824 Q831 Q832 H03-TSKRA107SNI-R KRA107S SOT-23 PNP
Q800 Q801 Q802 Q803 Q820
Q822 Q833 H03-TSKRC107SND-R KRA107S SOT-23 PNP
Resistors
R505 R841 R842 R843 R844
C724 RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
R521 R522 R722 R746 RS3AD0101NA-R RES CHIP,100R 1/16W +/-5%,0603
R201 R211 R503 R515 R721
R824 RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R702 R704 R709 R822 RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R516 RS3AD0104NA-R RES CHIP,100K 1/16W +/-5% ,0603
R706 R707 RS3AD0105NA-R RES CHIP 1M 1/16W +5% 0603
R202 R212 RS3AD0122NA-R RMGCFMIC 1K2 OHM +5% 0603
R203 R213 RS3AD0152NA-R RMGCFMIC 1K5 OHM +5% 0603
R209 R219 RS3AD0183NA-R RMGCFMIC 18K0 OHM +5% 0603
R823 RS3AD0221NA-R RMGCFMIC 220R0 OHM +5% 0603
R204 R214 R510 R519 RS3AD0222NA-R RMGCFMIC 2K2 OHM +5% 0603
R205 R215 R703 RS3AD0272NA-R RMGCFMIC 2K7 OHM +5% 0603
R206 R216 R506 RS3AD0332NA-R RMGCFMIC 3K3 OHM +5% 0603
R509 RS3AD0472NA-R RES CHIP,4K7 1/16W +/-5%,0603
R520 RS3AD0473NA-R RES CHIP,47K 1/16W +/-5%,0603
R207 R217 RS3AD0562NA-R RMGCFMIC 5K6 OHM +5% 0603
R821 RS3AD0563NA-R RES CHIP, 56K 1/16W +/-5%, 0603.
R301 R302 R701 RS3AD0683NA-R RMGCFMIC 68K0 OHM +5% 0603
R208 R218 RS3AD0822NA-R RMGCFMIC 8K2 OHM +5% 0603
R508 RS3AD0911NA-R RMGCFMIC 910 OHM +5% 0603
R705 RS3BB0564NA-R RES,CHIP,560K OHM,1/10W +/-5%,0805
R461 R462 RS3AD0753NA-R RES CHIP 75K 1/16W +-5% 0603.
R119 R118 RC3DI0100IN-R RCF 10R0 OHM +5% 250MI0W
R122 R123 R501 R502 RC3DI0101IN-R RCF 100R0 OHM +5% 250MI0W
R831 RC3DI0151IN-R RCF 150 OHM 5% 1/4W
R518 RC3DI0182IN-R RCF 1K8 OHM 5% 1/4W
R801R803 RC3DI0201IN-R RCF 200R0 OHM +5% 250MI0W
R251 R252 RC3DI022AIN-R RCF 2R2 OHM +5% 250MI0W
R800 R802 RC3DI0271IN-R RCF 270R0 OHM +5% 250MI0W
R832 RC3DI0331IN-R RCF 330R0 OHM +5% 250MI0W
R120 R121 RC3DI0471IN-R RCF 470R0 OHM +5% 250MI0W
R751 RC3DI0473IN-R RCF 47K OHM +5% 250MI0W
R851 R852 RC3DI0561IN-R RCF 560R0 OHM +5% 250MI0W
VR10 H03-SWE3A0505S1-R SWIROT EC16B24204A9 5V 500U0A 10T 3P 0 0 ENCODER
Miscellaneous
L700 H03-FB2522012HF-R COIL FCM2012HF-252T02 2500ohm SURFACE MT 2012
ZFNR1SENSOR-R RUBBER SENSOR
RM71 H03-ICROMN338EC-R REMOCON RECEIVER MODULE ROM-N338TEC
N207 H03-WE11B041000-R WIRE ASS`Y UL1007#26 410MM 2.0MM 11P WHT
N201 H03-WG03AB80900-R WIRECONASY DL 2.0MM 03P 90MM ANG-DOWN UL1007 RIBBON 26 1 B20
N206 H03-WG05SB83500-R WIRE ASS'Y UL1007#26(TA) 350mm 2.0mm 5p GRY
N203 H03-WG13SB82000-R UL1007#26 STR 200mm 2.0mm 13P WHT
P213 H03-WN04SB00000-R CONNECT 2.0mm 4P GIL-S-4P-S2T2-EF
P215 H03-WN06SB01000-R CNT PLUG BD`BD PLUG 2.0mm 35336-0610
P209 H03-WN07AB00000-R CONNECT 2.0MM 7P GIL-S-07P-S2L2-EF
AVR745 harman/kardon
harman/kardon
Service manual AVR745EU
Page 17 of 118

Ref. Designator Part Number Description
FRONT PCB ASS'Y
N214 H03-WN19AB00000-R CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910 0 0
P216 H03-WN19SB00000-R CONN 2.0MM 19 MA ST NAT MOLEX 35336-1910 0 0
N205 H03-WN22AI00000-R GF120-22S-LS 1.25mm 22P
N204 H03-WS4261005FN-R WIRE ASS'Y UL2547/1007#26 100MM 4P 2.0MM WHT
N202 H03-WS4265913FN-R CNT ASSY 2.0MM 4P 590MM SHIELD 26AWG UL2547 1/3
N210 H03-WS5264823FN-R UL1533/2547#26 STR 480mm 2.0mm 5P WHT
N212 H03-WS5248505CW-R WIRE ASS'Y UL1007/1533#24(TA)850mm 2.0mm 5P WHT
N208 H03-WS6265105EN-R WIRECONASY DL 2.0MM 6P 510MM UL1533 SHIELD 26 1
N211 H03-WS7260805EN-R WIRE ASS'Y UL1533/1007#26 80MM 2.0MM 7P WHT SHILED
FL1 H03-XD18BT19GNA-R 18-BT-19GINK
S1 S2 S3 S4 S5 S6 S7 S8 S9 H03-ZMB01S02200-R SPRING PLATE GND C5212 0.2T
J41 H03-ZMC12S17A00-R AC PUN SHIELD DIGITAL ET
J42 H03-ZMD12S01A00-R SHIELD IR
J43 H03-ZMD12S01B00-R SHIELD MICROPHONE
S201~S220 H03-SWC2A112FS1-R SWI TACT VERTICAL SKQNADD010
L251 H03-LAINB0470CR-R LF 47U0H +10% 5.8 OHM 500MI0A
L120 H03-LAINB047ACR-R LF 4U7H +10% 1.7 OHM 190.0A
RM72 H03-DPLP200LNNN-R PIN PHOTO DIODE LP-200TL
NJ71 H03-SO3P5179NNN-R JACK PHONE 3.5PI PJ0435179N
NJ70 H03-SORA1JE01NN-R JACK RCA 1P JE010003MN GND OR
NJ11 H03-SORA3313PNN-R CON PHONO SCKT RCA-313P 3 PINS
NJ12 H03-SORA8OSC5N8-R JACK S-VIDEO 1P C40160261N
NJ10 H03-SOSS9CKX3NN-R JACK PHONE 6.35 H70980110S 9P BK
NJ79 H03-SOTORX177LT-R FIBER OPTIC RECEIVING TORX177L (F, T)
MAIN PCB ASS'Y
Capacitors
C101 C102 C103 C104 C107
C108 C109 C110 C111 C112
C113 C114 C115 C116 C117
C118 C205
CCKID0101NA-R CC 100P0F +10% -10% 50.0V Y5P
C307 C308 C313 C314 C403
C404 C569 C570 CCKID0271NN-R CC 270P0F +10% -10% 50.0V 2B4
C433 CCMFD0103NN-R CC 10N0F +20% -20% 16.0V Y5S
C119 C120 C203 C212 C214
C527 C531 C709 C711 C712
C713
CCZID0104NA-R CC 100N0F +80% -20% 50.0V F
C315 C316 C409 C410 CCCIC0030NN-R CAP CERAMIC 3PF 50V C CH TAP
C317 C318 C411 C412 CCKIC0181NA-R CC 180P0F +10% -10% 50.0V Y5P
C329 C330 C425 C426 CCKIC0222NA-R CC 2N2F +10% -10% 50.0V Y5P
C707 CCZGC0104NA-R CAP CERAMIC 100NF 25V Z Z5U TAP
C331 C332 C407 C408 H03-CEHEC02275E-R CE 220UF +20% 10.0V D6.3XL11 P5MM 85C SK 220/10V 5 X11
C206 C208 C213 C309 C310
C405 C406 C526 C710 H03-CEHGC01075E-R CE 100U0F +20% 25.0V 6.3X11 85C P5MM SK 100/25V 6.3 X11
C210 H03-CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C SK 1/50V 5 X11
C301 C302 C401 C402 C518
C519 C521 C530 C708 C429 H03-CEHIC01065E-R CE 10U0F +20% 50.0V 85C P5MM 5X11 SK 10/50V 5 X11
C207 H03-CEHIC04755E-R CE 4U7F +20% 50.0V 85C P5MM SK 4.7/50V 5 X11
C303 C304 C305 C306 C421
C422 C423 C424 H03-CEHJA0477MN-R CE 470U0F +20% 63.0V 85C SK 470/63V 13 X21
C706 CEMFA0478BK-R CAP ELEC 4700UF 16V M 16X25 85C 120HZ ELITE
C432 H03-CEMGC04775E-R CE 470U0F +/-20% 25.0V 10X13 85C SK 470/25V 10 X13
C323 C324 C430 C431 CFLJC0683NN-R CPM 68N0F +5% 63.0V
C506 C507 C508 C516 C528
C529 C701 C702 C703 CPIKC0473NN-R CPF 47N0F +10% 100.0V
C211 C319 C320 C321 C322
C413 C414 C415 C416 H03-CEMKC0106AH-R CAP ELEC 10UF 100V M 6.3X11 SHL
C325 C326 C327 C328 C417
C418 C419 C420 H03-CPJJC0104NN-R CAP POLYESTER NON METAL 0.1uF 63V J TAP PCMT365 76104
C571 C572 H03-CEMJA0159KA-R CAP ELEC 15000uF 63V M 35x50 LSW153M1JQ50M
C573 H03-CEMDC0478KA-R CAP ELECTROYTIC 4700UF 6.3V M 12.5X21 (SKP472M0JI21R)I
C333 C335 C336 C434 CCKIC0103NA-R CC 10N0F +10% -10% 50.0V Y5P
C509 C510 H03-CEHHC0228MN-R CE 2200UF +20% 35.0V 85C 16X25
AVR745 harman/kardon
harman/kardon
Service manual AVR745EU
Page 18 of 118

Ref. Designator Part Number Description
MAIN PCB ASS'Y
C517 H03-CEHIA0228MN-R CE 2200UF +20% 50.0V 85C 16X35
C705 H03-CEMFA0688BK-R CAP ELEC 6800UF 16V M 16X25 85C 120HZ SK 6800/16V 16 X25
C105 C106 CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
Semiconductors
D205 D206 D301 D302 D303
D304 D305 D306 D307 D308
D401 D402 D403 D404 D405
D406 D407 D408 D409 D410
D411 D412 D603
H03-DG1N04148NB-R D-SLP 1N4148 100.0V 150E-3A
D101 D102 D103 D104 D508
D509 D703 H03-DR1N04004NA-R D-SR 1N4004 400.0V 1.0A
D204 H03-DZGE12V10MA-R MZ0.5GE12V-10 12V 10mA
D207 H03-DZGE3V320MA-R DIODE ZENER MZ0.5GE3V3-20 3.3V 20mA
Q309 Q310 Q411 Q412 H03-TR2SA1145YF-R TRANSISTOR PNP 2SA1145-Y(F) TO-92 HFE:120~240
Q443 H03-TRKRC107MNA-R TR-SLPSWA KRC107M NPN
Q315 Q316 Q319 Q320 Q417
Q418 Q421 Q422 Q442 H03-TRKTA1024NA-R TR-SLPLF KTA1024 Y PNP 50MI0A -150V
Q311 Q312 Q410 Q413 Q414 H03-TRKTA1268NA-R TR-SHPLF KTA1268BL PNP 100MI0A 120V
Q307 Q308 Q407 Q408 Q426
Q441 H03-TRKTC3198NA-R TR-SLPLF KTC3198BL NPN 150MI0A
Q301 Q302 Q303 Q304 Q305
Q306 Q313 Q314 Q337 Q338
Q401 Q402 Q403 Q404 Q405
Q406 Q409 Q415 Q416 Q425
H03-TRKTC3200NA-R TR-SHPLF KTC3200BL NPN 100MI0A 120V
Q317 Q318 Q321 Q322 Q419
Q420 Q423 Q424 H03-TRKTC3206NA-R TR-SLPLF KTC3206 Y NPN 50MI0A 150V
Q601 H03-TRKTD1302NA-R TR-SLPLF KTD1302 B NPN 300MI0A 20V
D502 D505 H03-DU2W04MMF00-R DIODE 2W04M-MF RC-2 Kink Type
D701 H03-DUKBU6GMF6N-R KBU6G-MF RS-6 Kink Type
IC73 H03-ICKIA278R06-R 4 TERMINAL 2A OUTPUT LOW DROP
VOLTAGE REGULATOR KIA278R06PI TO-220IS-4 +6V
IC71 H03-ICKIA278R33-R 4 TERMINAL 2A OUTPUT LOW DROP
VOLTAGE REGULATOR KIA278R33PI TO-220IS-4 +3.3V
IC72 H03-ICKIA7805I2-R IC-REGPOSFXD KIA7805API NORMAL TO-220IS +5V
IC59 H03-ICKIA7812I2-R IC-REGPOSFXD KIA7812API NORMAL +12V
IC54 H03-ICKIA7824I2-R IC-REGPOSFXD KIA7824API TO-220IS NORMAL +24V
IC51 IC60 H03-ICLM07815BD-R IC-REGPOSFXD KIA7815API NORMAL +15V
IC52 H03-ICLM07915BD-R IC-REGNEGFXD KIA7915API NORMAL TO-220AB -15V
Q329 Q330 Q433 Q434 H03-TR2SA1859BC-R TR-SHPLF 2SA1859A PNP -2.0A
Q335 Q336 Q439 Q440 H03-TR2SA1986AC-R TRANSISTOR PNP 2SA1986-R(AC,F) HFE:55~110 ADD MICA SHEET SIZ
Q331 Q332 Q435 Q436 H03-TR2SC4883BC-R TR-SHPLF 2SC4883A NPN 2.0A
Q333 Q334 Q437 Q438 H03-TR2SC5358AC-R TRANSISTOR NPN 2SC5358-R(AC,F) HFE:55~110 ADD MICA SHEET SIZ
Q327 Q328 Q431 Q432 H03-TRKTA1360BE-R TRANSISTOR PNP KTA1360 TO-126
Q701 Q702 Q703 Q704 H03-TRKTC3114NE-R TRANSISTOR NPN KTC3114 TO-126
Q323 Q324 Q429 Q430 H03-TRKTC3423BE-R TRANSISTOR NPN KTC3423 TO-126
D210 H03-DS05GBUSCNB-R DIODE PG05GBUSC
IC22 H03-ICLM02068D2-R IC-OPERAMP NJM2068M-TE1 DUAL SOP8
Resistors
R351 R352 R367 R368 R445
R446 R447 R448 H03-RM3EG0100LN-R RMF 10R0 OHM +5% 500MI0W
R303 R304 R388 R389 R473
R474 R477 R478 RC3DI0100IN-R RCF 10R0 OHM +5% 250MI0W
R213 R221 R353 R354 R369
R370 R457 R458 R459 R460
R717
RC3DI0101IN-R RCF 100R0 OHM +5% 250MI0W
R211 R508 R601 RC3DI0102IN-R RCF 1K0 OHM +5% 250MI0W
R485 R706 R714 RC3DI0103IN-R RCF 10K0 OHM +5% 250MI0W
R207 R214 R216 R217 R218
R219 R220 R309 R310 R479
R480 R602
RC3DI0104IN-R RCF 100K0 OHM +5% 250MI0W
R363 R364 R365 R366 R461
R462 R463 R464 RC3DI0150IN-R RCF 15R0 OHM +5% 250MI0W
AVR745 harman/kardon
harman/kardon
Service manual AVR745EU
Page 19 of 118

Ref. Designator Part Number Description
MAIN PCB ASS'Y
R380 R381 R386 R387 R481
R483 R488 R490 RC3DI0152IN-R RCF 1K5 OHM +5% 250MI0W
R341 R342 R343 R344 R384
R385 R437 R438 R439 R440
R482 R489
RC3DI0153IN-R RCF 15K0 OHM +5% 250MI0W
R311 R312 R313 R314 R405
R406 R407 R408 RC3DI0162IN-R RCF 1K6 OHM +5% 250MI0W
R339 R340 R345 R346 R347
R348 R349 R350 R433 R434
R435 R436 R441 R442 R443
R444
RC3DI0201IN-R RCF 200R0 OHM +5% 250MI0W
R215 R317 R318 R319 R320
R321 R322 R409 R410 R411
R412 R413 R414
RC3DI0221IN-R RCF 220R0 OHM +5% 250MI0W
R390 R391 R486 R492 RC3DI0223IN-R RCF 22K0 OHM +5% 250MI0W
R103 R104 R371 R372 R373
R374 R465 R466 R467 R468
R616
RC3DI022AIN-R RCF 2R2 OHM +5% 250MI0W
R497 RC3DI0271IN-R RCF 270R0 OHM +5% 250MI0W
R209 R498 R506 RC3DI0273IN-R RCF 27K0 OHM +5% 250MI0W
R224 RC3DI0274IN-R RCF 270K0 OHM +5% 250MI0W
R701 R707 R710 R711 RC3DI0282IN-R RCF 2K8 OHM +5% 250MI0W
R301 R302 R401 R402 RC3DI0331IN-R RCF 330R0 OHM +5% 250MI0W
R225 R305 R306 R403 R404
R509 R515 RC3DI0333IN-R RCF 33K0 OHM +5% 250MI0W
R107 R108 RC3DI033AIN-R RCF 3R3 OHM +5% 250MI0W
R382 R383 R484 R487 R491 RC3DI0393IN-R RCF 39K0 OHM +5% 250MI0W
R307 R308 R415 R416 RC3DI0433IN-R RCF 43K0 OHM +5% 250MI0W
R101 R102 R105 R106 R109
R110 R113 R114 R315 R316
R593 R594
R718
RC3DI0471IN-R RCF 470R0 OHM +5% 250MI0W
R223 RC3DI0513IN-R RCF 51K0 OHM +5% 250MI0W
R323 R324 R325 R326 R329
R330 R333 R334 R335 R336
R337 R338 R421 R422 R423
R424 R425 R426 R427 R428
R429 R430 R431 R432
RC3DI0561IN-R RCF 560R0 OHM +5% 250MI0W
R375 R376 R469 R470 RC3DI0820IN-R RCF 82R0 OHM +5% 250MI0W
R493 RC3DI0822IN-R RCF 8K2 OHM +5% 250MI0W
R331 R332 R419 R420 RM1DI0142IN-R RMF 1K4 OHM +1% 250MI0W
R327 R328 R417 R418 RM1DI0333IN-R RMF 33K0 OHM +1% 250MI0W
R702 R705 R708 R709 RC3DI0751IN-R RCF 750R0 OHM +5% 250MI0W
R378 R379 R471 R472 H03-RI3IC022BEN-R RW 220MI0 OHM +5% 5.0W 100PPM/`C -100PPM/`C
R392 R393 R475 R476 H03-RM3FC0100BN-R RES METAL OXIDE 10R OHM+5% 1.0W
R514 R517 R518 H03-RM3GC022ACN-R RESISTOR METAL OXIDE 2R2 OHM +5% 2.0W
R504 R507 R510 R703 R704
R715 R716 H03-RM3GC033ACN-R RESISTOR METAL OXIDE 3R3 OHM +5% 2.0W
R505 H03-RM3GC047ACN-R RESISTOR METAL OXIDE 4R7 +5% 2.0W
VR74 H03-RT7EA0201NB-R PR 200R0 OHM +20% 500MI0W
VR71 VR72 VR73 RT6BA0201NB-R PR 200R0 OHM +30% 100MI0W
Miscellaneous
G102 G103 H03-ZNMSA4004SN-R TERMLUG GND
F501 F502 F505 F506 H03-FURN22000SR-R FUSE SR-5 SERIES 3821200 SR-5- 2A 250V 35A
F701 F702 H03-FURN23150SR-R FUSE SR-5 SERIES 3821315 SR-5- 3.15A 250V 35A
P071 H03-ICLM19CIZIE-R IC TEMPERATURE SENSOR LM19CIZ 2.4V TO-92
L301 L302 L401 L402 H03-LCNNNA050NA-R LFA 1MM 10MM 5 LEFT 0.0MM NONE SP-2516
NJ81 H03-SOPA81M367G-R SH081M367G GY BU RD WH
NJ83 H03-SORA40RSAGN-R JACK RCA 4P JB040131ZG GN BN PP TA ,GOLD COLOR
NJ82 H03-SORA40RSCGN-R JACK RCA 4P JB040131QG WH BU RD GY,GOLD COLOR
N814 H03-WG03SE03700-R WIRE ASS'Y UL1007#16(TA) 370mm 3P GRY
N807 H03-WG05SB83000-R WIRE ASS'Y UL1007#26(TA) 300mm 2.0mm 5P WHT
P503 P805 P806 P809 P817
P818 H03-WN02SD00000-R CONN 2.5MM 2 MA ST NAT 5267-02A 0 0
AVR745 harman/kardon
harman/kardon
Service manual AVR745EU
Page 20 of 118
