Harman JBL TUNE 115BT User manual

S M L
WHAT’S
IN THE
BOX
quick
start
guide
how
to
wear
power
on &
connect
MULTI-POINT
CONNECTION
Charging
led
behaviors
BUTTON
COMMAND
1
2
3
To switch music source, pause the music on the
current device and select play on the 2nd device.
Phone call will always take priority.
If one device goes out of bluetooth range or powers
off, you may need to manually reconnect the
remaining device.
4SELECT “forget this device” on your bluetooth
devices to disconnect multi-point.
1st
bluetooth device
2nd
bluetooth device
ON
Choose "JBL TUNE115BT" to connect
Settings Bluetooth
Bluetooth
DEVICES
JBL TUNE115BT
Now Discoverable
Connected
×2
TUNE
115
BT
Driver Size: 8.6 mm Dynamic Driver
Frequency Response: 20 Hz – 20 kHz
Sensitivity: 102dB SPL@1kHz 1mW
Microphone Sensitivity: - 25dBV/Pa @1kHz
Impedance: 16 ohm
Bluetooth transmitted power: 0-4 dbm
Bluetooth transmitted modulation: GFSK/DQPSK/8DPSK
Bluetooth frequency : 2.402 GHz - 2.480 GHx
Bluetooth profile version: HFP V1.6,HSP V1.2,VRCP V1.5, A2DP V1.2
Bluetooth version: 4.2
HEADSET BATTERY TYPE: LITHIUM-ION BATTERY (3.7 V/160 MAH)
Power Supply: 5 V 1 A
Charging time: ＜2 hrs
Music playtime with BT on: ＞8 hrs
Weight: 19.02 g
TECH
SPEC
1H
15MIN
3. Wear behind the neck
2. ATTACH EAR TIP
Mix and match for a perfect fit
and audio performance
1. Select the right ear tips
4. Use the magnets
S M L
Choose "JBL TUNE115BT" to connect
ON
Settings Bluetooth
Bluetooth
DEVICES
JBL TUNE115BT
Now Discoverable
Connected
power on and
enterpairing mode Automatically
>2S
>2S
>2S
>2S
×1
×1
×1
×1
×1 ×2 BIXBY/SIRI®/OTHERS
(Maximum 2 devices)
*Enter pairing mode with the 2nd device
>5S
