Harman EASY Touch Control User manual

1
Owner’s Manual
EASY Touch Control
Easy,Accurate, Smart and providesYearly savings.

Harman EASY Touch Control Owners Manual2
EASY Touch Control Overview .............................3
Quick Start: Starting Your Pellet Stove ........................4
Menus .................................................5
Menu I Overview ......................................6
Burn Mode ..........................................7
Cleaning Prompts .....................................8
Diagnostics ..........................................9
Feed Limit ..........................................12
Igniter .............................................13
Room Fan ..........................................15
Schedule ...........................................16
Test ...............................................18
Menu 2 Overview .....................................19
Home Screen Options ................................20
Screen Brightness ....................................21
Day/Time...........................................22
Fuel Calibration......................................23
Lock...............................................24
Languages & Units....................................25
Menu 3 Overview .....................................26
Dealer Information ...................................27
Factory Defaults .....................................28
USB ...............................................29
Video/Manual........................................30
Prompts, Messages & Errors...............................31
Software Updates .......................................32
FAQ ..................................................33
Table of Contents

Harman EASY Touch Control Owners Manual3
The EASY Touch Control home screen manages the essential functions of
your Harman pellet stove.
Day/Time
Current day/time
when set
Power Icon
Turns unit
on/off
Whisper Mode
Shows if
“Whisper”
mode is on
or off
Blue Arrow
Press to
decrease the
desired room
temperature
Schedule Icon
Appears if “Scheduling” is
turned on.
Lock Icon
Appears if the
control is locked
Setting
Displays
current
temperature
setting
Menu
Allows you to
scroll through
3 additional
menus
Red Arrow
Press to
increase the
desired room
temperature
Message Area
Prompts and messages will
appear in the top center of
the screen
Actual Room
Temperature
EASY Touch Control Overview

Harman EASY Touch Control Owners Manual4
Your EASYTouch Control automatically runs at our factory default settings
which is the most convenient way to heat with a Harman pellet stove.
Factory default settings include but are not limited to:
• Room Sensing Mode
• Automatic Ignition
• Automatic Fan
Note:
• The rst time the unit is plugged in, you will need to choose the
preferred language, then hit the “Home” icon
• The temperature setting must be 3 degrees higher than the room
temperature for the stove to light
Fill the Hopper
with Pellets
Use the Up and Down
Arrows to set desired
room temperature
Touch the Power Icon
1
2
3
Quick Start: Starting Your Pellet Stove

Harman EASY Touch Control Owners Manual5
You can easily heat your home
using just the home screen
functions.
Using the “Menu”,“Home”,“Left”
and “Right” arrow icons you can
get to any function.
When more customization is
desired the “Menu” icon allows
you to scroll through 3 pages
of icons to access controls for
individual features.
We have organized the menu pages
in order of most frequent use.
Menus
Home Screen
Menu 1
Menu 2
Menu 3

Harman EASY Touch Control Owners Manual6
The rst menu gains access to the most used options.
A - Burn Mode: Select “Room Sensing” or “Constant Burn Sensing”
B - Cleaning: Displays current cleaning percent accumulated and allows
for reset
C - Diagnostics: 6 pages of data showing how the stove is performing
D - Feed Limit: Adjust the amount of pellets being fed to the burn pot
E - Igniter: Select method of ignition and shut down, automatic or disabled
F - Fan: Choose automatic or manual fan
G - Schedule: Program when you want your temperatures to change,
7 days a week
H -Test: Test individual functionality of motors and igniter
Note: You cannot cause harm to the unit by changing settings, however,you may not achieve
your ideal temperature. If you are unsure of what you have set,you can always go to“Factory
Default” on page 3 to revert to factory settings.
A B C D
E
F
H
G
Menu 1Overview

Harman EASY Touch Control Owners Manual7
“Burn Mode” allows you to select how you want the stove to operate. Refer
to the stove owner’s manual for detailed description.
Room Sensing utilizes the onboard sensor
or optional wireless remote sensor to monitor
temperatures and automatically adjusts the stove
to maintain your desired temperature setting.
The home screen will display your actual room
temperature on the center of the screen in this
mode.
Constant Burn allows you to manually control
heat output. In Constant Burn you will set the
heat level at a number between 1(low) to 7(high)
using the slider bar on the home screen.For your
reference,the room temperature is displayed to
the right of the slider bar on the home screen.
The stove will not shut down regardless of room
temperature, until you manually turn it off.
Burn Mode

Harman EASY Touch Control Owners Manual8
The “Cleaning” screen displays the percentage of time that has
accumulated since the last cleaning.When it reaches100%, you will get
messages on the home screen to perform that specic maintenance. Press
the checkmark on the home screen to reset. Resetting the maintenance
sets it back to 0% and tells the control to start calculating until the next
cleaning is needed.
In the case you clean your stove before prompted, this menu allows you to
manually reset the percent accumulated.You can expect to see messages at
the following intervals:
Burn Pot: You will be prompted to scrape the burn pot
approximately every ve days*
Ash Pan: You will be prompted to empty it every 5 days*
Total Clean: You will be prompted to completely clean
the unit and venting after each ton*
It is important to perform these maintenance tasks to keep your Harman
pellet stove/insert warming your home as efciently as possible.
*Depending on stove model and quality of the pellets burned
** See “Fuel Calibration” screen for more details
Cleaning Prompts

Harman EASY Touch Control Owners Manual9
There are 6 pages of diagnostic information that will be helpful if you
ever have questions about your Harmanpellet product.The data on these
screens allows you to understand and reference how your unit is working.
Diagnostic information on Page 1 of 6 includes:
• Room Fan: Current room fan speed percent
• Combusion Fan RPM: Current fan RPMs
• Feed Motor: Displays if the feed motor is currently on or off
• Feed Rate: Current feed rate percentage
• Igniter: Displays if igniter is currently on or off
• Pressure Switch: Displays if the pressure switch is currently
open or closed
Diagnostics - Page 1

Harman EASY Touch Control Owners Manual10
Diagnostic information on page 2 of 6 displays temperature sensors
ESP Temperature: Displays the
current temperature of the Exhaust
Sensing Probe
Room Temperature: Displays
room temperature sensed from
the on-board or Wireless Remote
Sensor(optional).
Return Air Temperature:
Displays the room air temperature
returning to the unit.This
temperature becomes the set
point for the stove to achieve if the wireless sensor loses signal.You will see
“Using Back Up Sensor” on your home screen.
Wireless Sensor: Displays whether or not the optional wireless sensor is
disabled or enabled.
OutsideAirTemperature: Displays outside temperature when the optional
Outside Air Kit is installed.
Diagnostic information on Page 3 of 6 displays Limits and Fuel Usage.
Ignition ChargeTime (min):
This can only be altered by an
Authorized Harman Dealer.
Displays amount of time the auger
feeds fuel during the ignition cycle.
Feed Rate Limit (%):Displays the
maximum allowed percentage as set
in the “Feed Limit” screen.
ESPTemperature Limit: Displays
the maximum temperature of the
ESP allowed by the control, based
on current settings.
Fuel Used in 24 Hours: Displays the amount of pounds burned in the past
24 hours.
Fuel Used Since Cleaning: Displays how many pounds of fuel was used
since last total clean.
Fuel Remaining: Displays amount of fuel in hopper.To enhance accuracy,
fuel calibration should be completed, see Menu 2.
Diagnostics - Pages 2 & 3

Harman EASY Touch Control Owners Manual11
Diagnostic information on
page 4 of 6 displays
hardware information:
• Model Name
• Model Number
• Control Board Number
• Touch Display
• Date of Installation
• Hours of Operation
Diagnostic information on page
6 of 6 displays wireless sensor
information:
• Sensor Signal Strength (wireless)
• Communication Status:Enabled
or Disabled
• Sensory Battery
• Sensor ID
• Sensor Temperature
Diagnostic information on page
5 of 6 displays software version
information:
• Bootloader
• Touch Software
• Control Software
• Control Flash Image
• Wireless Sensor
• International Table
• Language Text
• Model Table
• Graphics Package
Diagnostics - Pages 4, 5 & 6

Harman EASY Touch Control Owners Manual12
The “Feed Limit” screen allows you to adjust the amount of fuel being fed to
the burn pot.The factory default for this is 75% which is best for most pellets.
To Adjust:
• Move the slider bar by tapping or sliding it to the desired adjustment
• Decrease your feed limit if you see unburnt pellets falling into the ash pan
• Increase your feed limit to maintain approximately 1” of completely burnt
pellets on the burn pot
The quality of pellets is what causes the need for this adjustment.
Feed Limit

Harman EASY Touch Control Owners Manual13
There are two ignition and shutdown modes for Harman pellet products:
“Automatic” and “Disabled”. Each can be used in conjunction with
Constant Burn Mode.
“Automatic” will automatically ignite and shut down.
“Disabled” requires the stove to be lit in Automatic and then switched to
Disabled. The stove will alter its ame size to keep at your set temperature.
Disabled allows your stove to continue to run without shutting down, even
once set temperature is achieved, keeping a continous heat without going
through the ignition cycle.
Igniter

Harman EASY Touch Control Owners Manual14
Automatic and Room Sensing Mode: The unit will automatically
ignite and shutdown. As long as there is fuel in the hopper, the stove will
automatically reignite when there is a demand for heat. Note: This is the
most common and recommended method of operation.
Automatic and Constant Burn Mode: The unit will automatically
ignite and will operate at your selected Constant Burn setting.The unit
will not shut down unless the “On/Off” icon is touched or if the hopper
runs out of fuel.
Disabled and Room Sensing Mode: The stove must be lit in
“Automatic” and then switched to “Disabled”. The stove will alter its
ame size to keep at your set temperature. However, if set temperature
is achieved, the unit can only go to minimum burn. The unit will not shut
down unless the“On/Off” icon is touched or if the hopper runs out of fuel.
Disabled and Constant Burn Mode: The stove must be lit in
“Automatic” and then switched to “Disabled”.The stove will operate at
your selected Constant Burn setting.The unit will not shut down unless
the “On/Off” icon is touched or if the hopper runs out of fuel.
Igniter

Harman EASY Touch Control Owners Manual15
The “Room Fan” screen gives you two choices to control the way warm
air enters the room: “Automatic” and “Manual.” The default is set as
Automatic.
Automatic allows the stove to automatically adjust the amount of warm
air entering the room to achieve and maintain the set temperature.
In Manual, you can set the fan rate between off and maximum. For your
reference, the fan percentage rate is displayed on the lower right of the
screen.
Safety note:The unit will override the low Manual setting at high burn
rates.
Room Fan

Harman EASY Touch Control Owners Manual16
The“Schedule” screen gives you the ability to set temperatures you want
your home to be throughout the day.
Here’s how:
• Press “Set Schedule” to get to the scheduling screen (see instructions
on adjacent page)
• Set schedule for all 7 days of the week
• Return to scheduling screen
• Press “Schedule On” or “Schedule Off” icon
The “Schedule” icon will have a through it if schedule is on but the
time is not set.This also may occur due to power outage.
The Schedule icon will have a over it when temperatures are overridden
by adjusting the up and down arrows on the home screen. Scheduling
will resume at the next time period.
Notes:
• When scheduling is on, a small clock icon will show on top right of the
home screen
• You can choose to change any of these settings at any time
• If you unplug your stove at the end of the heating season, the EASY Touch
Control will remember your schedule setting
• Scheduling will not work in Constant Burn Mode—Constant Burn will
override scheduling to maintain the consistent burn you set
• The day/time must be set for scheduling to function
Schedule

Harman EASY Touch Control Owners Manual17
Step 1: Choose day
Step 2: Set wake time (highlighted by yellow box)
Step 3: Set temperature
Step 4: Choose “Whisper Mode” on/off
Step 5: Touch “Away”,“Home”, or “Sleep’ to highlight, then set time
and temperature
Copy Schedule
• Copy this day’s schedule
• Choose day for this schedule
• Paste into each day you want this schedule
Review Schedule
• Press any block to edit, if needed,
or select “Back” to return to previous menu
• Touch “Exit” when nished scheduling all 7 days
Set Schedule
Schedule

Harman EASY Touch Control Owners Manual18
“Test” screen allows you to test the individual functionality of the motors and igniter.
To test functionality, simply press the icon for the component you want to test.
The icon will change colors while testing.
During testing, the components will do the following:
Room Fan: (Is air moving?)
• First touch turns blower on maximum set point
• Second touch reduces blower to minimum set point
• Third touch turns off the fan
Combustion Fan: (Can you hear it?) A message will appear stating the RPM
• First touch turns on full voltage RPM
• Second touch goes to max RPM set point
• Third touch goes to minimum RPM set point
• Fourth touch turns off the fan
Note: A cold unit may show reduced RPM’s due to air density.
Feed Motor: (Is auger moving?)
• First touch starts the test, and automatically turns on combustion fan to
activate the pressure switch safety device in the auger circuit
• Second touch turns off the igniter
• Turn off the combustion fan (3 touches)
Igniter: This test only needs performed if you experience failed ignition. We
recommend contacting your Authorized Harman Dealer for assistance.
(After one minute, open the front door and check for heat. Be careful since they
burn pot can be hot.)
• First touch starts the test and automatically turns on combustion fan to
activate the pressure switch safety device in the igniter circuit
• Second touch turns off the igniter
• Turn off the combustion fan (3 touches)
Touch Test: The touch accuracy can be tested on the “Touch Test Area” by
pressing inside the rectangle. If circles appear outside of the area you touched,
calibration may need completed by your Authorized Harman Dealer.
The other data on this screen are factory tests that do not need to be accessed.
Test

Harman EASY Touch Control Owners Manual19
The second menu includes:
A - Home Screen Options: Add more data to your home screen
if desired
B - Screen Brightness: Change the brightness of the touch screen
C - Day/Time:Set the day and time that appears on the home screen
D - Fuel Calibration: Adjust low fuel indicator timing
E - Lock: Lock your screen to protect from others in your home
from changing temperature/setting
F - Languages: Choose the language you prefer
G - Units: Choose “Metric” or “English” units of measure
H -Wireless Room Sensor: Enable optional wireless room sensor
(see your authorized Harman dealer for availability)
A B C D
E
F
H
G
Menu 2 Overview

Harman EASY Touch Control Owners Manual20
If you prefer to see how your Harman pellet stove is performing without
going into the menus, you can elect to have information shown on your
home screen.
“Show Fuel Gauges” will display:
• Estimated pounds until empty: Turning this function on enables
the “Touch Here If Hopper Was Filled” prompt which noties the
calculator when a bag of pellets was added or the hopper is lled
Note:Fuel calibration is required to obtain accuracy.See page 23)
• Approximate fuel used in last 24 hours
• Outside air temperature (requires Outside Air Kit)
“Show Dashboard” will display status of:
• Room fan with percentage
• Combustion blower with RPMs
• Auger motor with percentage
• Igniter: On when color, ESP temperature when grey
This screen shot shows what the home
screen would look like if both “Show
Dashboard” and “Show Fuel Gauges” are
selected.
Home Screen Options
