Technical Manual
JBL VTX-F18S
SPECIFICATIONS
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• System Input Power Rating: 2000 W Continuous, 8000 W Peak
(AES / 2 hour)
• Frequency Response (±3 dB): 32.5 Hz – 300 Hz
SYSTEM COMPONENTS:
• Low Frequency Driver: One 2269H, 460 mm (18 in) dia.,100
mm (4 in) dual voice coil, dual neodym-
ium magnet, Differential Drive®, Direct
Cooled™
• Nominal Impedance: 8 Ohms
• Bandpass Sensitivity: 92 dB, 1W / 1m (2.83 Vrms at 3.3 ft)
• D.C.Resistance: 4.8 Ohms +/- 10%
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test (±1): 15V Input, 20 Hz to 500 Hz
(with DSP)
Component Fee Air Sweep Test:
B. L.F.Aural Sweep Test (±1): 20V Input, 10 Hz to 300 Hz
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions: 640.1 x 548.6 x 713.7 mm (H x W x D)
(25.2 x 21.6 x 28.1 in.)
• Net Weight: 45.4 kg (100 lb)
• Shipping Weight: 51.7 kg (114 lb)
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
JBL VTX-F18S REV A
9-15
PACKAGE WIRING DIAGRAM
Warranty Card
59660
Carton
5038958
Filler (2)
5038959
PKG, Microfoam (14)
49790P
2269H
(354096-001X)
Cone Replacement
C8R2269
Input Plate Assy.
5038889
Wire Harness
413622-001
PCB Assy NL4,8
5022291
Yellow
Black

JBL VTX-F18S
INPUT CONNECTOR ASSEMBLY
5038665
JBL VTX-F18S

JBL VTX-F18S
COMPONENT EXPLODED VIEW
COMPONENT PARTS LIST:
JBL VTX-F18
Item Part No. Qty Description
9 354096-001 1 M/I, 2269H
10 5037767 1 GRILLE, VTX-F18S
11 445201-001 2 BRACKET, GRILLE, L/R
12 445202-001 8 BRACKET, GRILLE, TOP/BOTTOM
13 446372-001 4 HANDLE ASSY
14 445327-001 4 GASKET, HANDLE
15 353445-001 4 FOOT
16 381-00023-01 4 MOUNTING SUPPORT, 90 DEG 2 X M10
17 353683-001 1 PLATE, POLE MOUNT
19 446375-001 1 LOGO
20 61860 42 T-NUT 8-32X11/32
21 5026065 32 #8-32 CHEESE HD, TORX, W/PATCH
22 882-41110-08 20 SCR,PB,PPH,#6x.5,BLK
23 803-52011-16 12 SCR,8-32 X 1 ,OVAL.,TORX,BLK ZINC,LCS
24 804-12111-16 4 SCR,10-32 X 1,FLT,TORX,BLK ZINC,LCS
25 836-44800-00 8 T-NUT,M10,CLR ZINC
33 61861 12 T-NUT,10-32 (Woofer/Bottom)
34 5038889 1 INPUT CONNECTOR ASSY, VTX-F18S
35 443622-001 1 NL4 WIRE ASSEMBLY
36 883-41110-08 16 SCR,8 X 1/2,PAN,PH,PB,BLK ZINC,LCS (L Brkt)
Item Part No. Qty Description
38 816-13510-25 4 SCR,M6 X 25MM,FL,SOC,BLK ZINC,LCS
39 803-12011-12 10 SCR,8-32 X 3/4,FLT,TORX,BLK ZC, LCS
40 804-72111-20 8 SCR, 10-32X1-1/4,SOCKET, TORX,BK
41 60578 4 GASKET 2240H ( 4pcs = 1 gasket )
43 840-72810-07 2 M3 Din 125A Metric Flat Washer (Standard)
44 830-30910-00 2 M3-0.5 Metric Class 8 K Lock Nut (Kep nut)
45 813-11210-12 2 M3-0.5 X 12 Din 965 Metric Phillips Flat
48 818-11710-25 16 SCR,M10 X 25MM,FLT,PH,BLK ZINC,LCS
50 444453-001 1 JUMPER ASSY
51 804-42111-16 4 SCR,10-32X1,PAN,TORX,BLK
52 353682-001 1 GASKET, POLE MOUNT PLATE
