Harman Infinity PHI 5.1 / 230 User manual

Infinity Service Manual
PHI 5.1 / 230
PHI 2.1 / 230
Compact Movie and Music Systems
CONTENTS
SYSTEM CONTENTS 2
BASIC SPECIFICATIONS 3
2.1 PACKAGE LIST AND PARTS 4
5.1 PACKAGE LIST AND PARTS 5
SATELLITE EXPLODED VIEW / PARTS 6
CENTER EXPLODED VIEW / PARTS 7
SUB EXPLODED VIEW / PARTS 8
FLOOR STAND EXPLODED VIEW / PARTS 9
PARTS LIST 10
SUBWOOFER SYSTEM DIAGRAM 15
SUBWOOFER SCHEMATIC DIAGRAM 16
Released EU2010 Harman Consumer Group, Inc. Rev 0, 03/2010
8500 Balboa Boulevard
Northridge, California 91329
Infinity
PHI / 230 service Manual
Page 1 of 16

4PHI 51 - PHI 21
INTRODUCTION
Infinity PHI Series
The PHI Series of loudspeakers continues Infinity’s longstanding
commitment to accurate sound reproduction. Our drivers, precision dividing
networks and rigid, well-braced enclosures combine to deliver uncom-
promised performance in any stereo or multichannel home theater system.
In addition, PHI Series speakers, except for the powered subwoofers,
are magnetically shielded for safe placement adjacent to a television.
Unpacking the System
Carefully unpack the system. If you suspect damage from transit,
report it immediately to your dealer and/or delivery service. Keep the
shipping carton and packing materials for future use. Open the
package and verify the following contents for the:
PLANNING YOUR SYSTEM
Before deciding where to best place your speakers, survey your room an
study Figures 1 and 2.The illustrations depict how to position the PHI 51
system.The PHI 21 system should be positioned according to the same
principles, but of course without Center Channel and Surround speakers.
Figure 1. In this overhead view of a typical installation, satellite
speakers are used to reproduce sound for the front and surround channels.
The center channel reproduces sound and dialogue.The powered
subwoofer provides bass for effects and music.
Figure 2.This figure shows an alternative layout which may be more
suitable for some rooms.
Couch
Left
Front
Channel
Left
Surround
Channel
Right
Surround
Channel
Right
Front
Channel
Center
Channel
Subwoofer
Couch
Left
Front
Channel
Left
Surround
Channel
Right
Surround
Channel
Right
Front
Channel
Center
Channel
Subwoofer
5 m combined subwoofer signal cable/ trigger cable.
2 lengths of 12 m speaker cable for rear speakers.
3 lengths of 6 m speaker cable for front and center speakers
5 m combined subwoofer signal cable/ trigger cable.
2 lengths of 6 m speaker cable for satellite speakers
Wall brackets
Wall
brackets
Floor stands x 4
Floor stands x 2
Powered Sub
Powered Sub
Satellite Speakers
Satellite Speakers
Center
PHI 51
PHI 21
Infinity
PHI / 230 service Manual
Page 2 of 16

10 PHI 51 - PHI 21
PHI Satellite and Center
Enclosure type: Closed
Frequency Range: 200Hz-22kHz(±3dB)
Recommended Amp Power Range: 25-100Watts
Sensitivity (2.83V @ 1meter): 84dB
Nominal Impedance: 4 ohms
Crossover Frequency: 2500Hz, 12dB/Octave
Midrange Driver (S): 4 x 50mm (2 inch) neodymium woofer (Magnetically Shielded)
High-Frequency Driver: 19mm (3/4 inch) soft dome tweeter (Magnetically Shielded)
Dimensions (HxWxD): Satellite 367 x 85 x 120mm Center 345 x 107 x 120mm
Weight: 1.3Kg
PHI Subwoofer
Enclosure type: Bass Reflex
Frequency Range: 35Hz-250Hz
Power Rading: 100 Watts (RMS)
Amplifier Output: 100 Watts
Low-Frequency Driver: 210mm (8 inch) long throw shielded
Crossover Frequency: 50Hz-250Hz, 24dB/Octave,continuously variable
Dimensions (HxWxD): 296 x 296 x 296 mm
Weight: 9.7Kg
Infinity continually strives to update and improve existing products, as well as create new ones.
The specifications and construction details in this and related Infinity publications are therefore subject to change without notice.
The Infinity PHI system should not be used if the ambient temperature is higher than 45˚ C.”
SPECIFICATIONS
Infinity
PHI / 230 service Manual
Page 3 of 16

1
2
3
0
Checked ByDrawn By Approved By
PLHZ Model NO.
ize
heet 1/1
Item NO. Description Qty.
Part NO.
Part Name
00
AT Assembly
OFT BAG
Polyfoam bottom
OFT BAG
PE BAG
10
9
7
6
5
4
3
2
1
INFINITY 2.1
INFLZY001-0006
Frank
08.04.29
08.04.29
Frank
ITFA30054-0001
IVAA02054-0001
INFLZY001-0003
IVAA08008-0001
IVAA08007-0002
IVAA08007-0001
L872.0*W432.0*H200.0 EP 50
󱉖󱣼 1
L480.0*W170.0*T=0.5 2
L480.0*W200.0*T=0.038 2
2
2
2
1
1
1
L400.0*W300.0*T=0.5
L700.0*W600.0*T0.5
IVAA02056-0001
L700*W620*T=0.038
8
ANZAINF17-4310
PE BAG
UB Assembly
OFT BAG
1
2
3
4
5
6
7
8
9
10
11
12
13
14 15 16 17 18 19
Polyfoam TOP
11 ACCE ORY 1
12 tand Column Assembly
tand Base Assembly
13
14
15
16
17
OFT BAG
User Manual
PE BAG
PE BAG
peaker Cable
18
19
ACCE ORY 2
RCA-JACK Cable
20
21
23
24
20
21
22
23
24
POWER CORD
erial label UB
Back label
INFLZY001-0007
INFLZY001-0001
ITFA30054-0002 L872.0*W432.0*H200.0 EP 50
󱉖󱣼
IVA802004-0001
BPHA00022-0001
1
2
L135.0*W95.0*T0.04
2
L71.4*W37.7 AB
INFLZY001-0008
2
IVAA08008-0002
L900.0*W100.0*T=0.5 2
IVAA02035-0001
IVAA02036-0001
1
1
3
VW 312444-6000
L6000.0 2648#18 2
IVA802004-0001
1
L135.0*W95.0*T0.04
H F053123-4150
FM4.0*L15 P0.7 4
HOT008034-0001 BM6.0*L62 P1.0
2
VOT050005-0010
1
L5000.0 2547#24 GRAY
VPE003202-0020
L2000.0 2P 1
L280.0*W100.0*T0.038
L280.0*W180.0*T0.038
L296.0*W296.0*H296.0 MDF T=18
1
YLBA05088-0001
YLBA24030-0001
YLBA05086-0001
5
L20.4*W8.7 COPPER PAPER
L56.5*W35.4 COPPER PAPER 󰒄 1
25
22
26
25
26 Carton erial label
Date label
Trash can Label
erial label AT 1
󰒄
27
ICCA00128-0001
CARTON
1
1
F176-0725D
YLBA21001-0001
1
L20.4*W8.7 COPPER PAPER
YLBA07015-0001
YLAB07015-0003
27
25
Infinity
PHI / 230 service Manual
Page 4 of 16
Infinity PHI 2.1 Package List and Parts

1
2
3
0
Checked ByDrawn By Approved By
PLHZ Model NO.
ize
heet 1/1
Item NO. Description Qty.
Part NO.
Part Name
00
OFT BAG
tand Base Assembly
POLYFOAM BOTTOM
Back label B
10
9
7
6
5
4
3
2
1
INFINITY 5.1
INFLZY001-0005
Frank
08.04.29
08.04.29
Frank
1
1
7
4
4
1
1
5
4
8
ANZAINF17-4310
Trash can Label
CEN Assembly
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17 18 19 20 21 22 23
27
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Back label A
25
24
OFT BAG
PE BAG
AT Assembly
UB Assembly
POLYFOAM TOP
PE BAG
U ER MANUAL
PE BAG
POWER CORD
RCA-JACK Cable
peaker Cable
peaker Cable
ACCE ORY 1
IVA802004-0001
BPHA00022-0001
L135.0*W95.0*T0.04
L71.4*W37.7 AB
tand Column Assembly
INFLZY001-0008
OFT BAG
IVAA08008-0002
L900.0*W100.0*T=0.5
ACCE ORY 2
IVA802004-0001
L135.0*W95.0*T0.04
H F053123-4150
FM4.0*L15 P0.7
HOT008034-0001
BM6.0*L62 P1.0
PE BAG
IVAA08007-0001
L700.0*W600.0*T0.5
IVAA02056-0002
L700*W620*T=0.038
OFT BAG
erial label UB
VOT050005-0010
VPE003202-0020
L5000.0 2547#24 GRAY
L2000.0 2P
VW 312444-6000
L6000.0 2648#18
VW 312444-C000
L12000.0 2648#18
IVAA02035-0001
IVAA02036-0001
L280.0*W100.0*T0.038
L280.0*W180.0*T0.038
5
1
1
1
1
6
1
1
2
2
3
5
4
4
1
8
4
1
1
1
INFLZY001-0003
INFLZY001-0001
INFLZY001-0002
INFLZY001-0007
IVAA08008-0001
L400.0*W300.0*T=0.5
IVAA02054-0001
IVAA08007-0001
L480.0*W170.0*T=0.5
L480.0*W200.0*T=0.038
YLBA05086-0002
YLBA05086-0003
L296.0*W296.0*H296.0 MDF T=18
YLBA24030-0001
L20.4*W8.7 COPPER PAPER
ITFA30055-0002
ITFA30055-0001
L872.0*W542.0*H180.0 EP 50 󱉖󱣼
L872.0*W542.0*H200.0 EP 50 󱉖󱣼
ICCA00128-0001
29
26
30
27
28
29 CARTON
erial label AT
erial label CEN
1
1
1
28
Date label
30 1
31
Carton erial label
31 1
󰒄
󰒄
F176-0725D
YLBA21001-0001
YLBA07015-0002
󰒄
YLBA07015-0004
YLAB07015-0003
26
30
YLBA05088-0001
L20.4*W8.7 COPPER PAPER
Infinity
PHI / 230 service Manual
Page 5 of 16
Infinity PHI 5.1 Package List and Parts

1
2
3
0
Checked ByDrawn By Approved By
PLHZ Model NO.
ize
heet 1/1
Item NO. Description Qty.
Part NO.
Part Name
00
AT Out Baffle
AT GRILLE
EVA PAD
NON-WEAVE
NON-WEAVE
AT Baffle
13
12
11
10
9
7
6
5
4
3
2
1
16
15
14
17
21
20
19
18
22
23
Bracket
PACER UPPORT
INFINITY 5.1
INFLZY001-0003
Frank
08.04.28
08.04.28
Frank
G NA05003-0001
IV A10021-0002
D 10009-0003
A LA00242-0002
IV A10021-0001
BPQA00012-0001
1
2
2
1
4
7.5g
1
1
2
1
4
1
1
2
16
16
1
2
1
1
L342.2*W82.2*H28.1 AB
L344.9*W84.9*H26 AL-1100 T=1.2
1
BPFA00037-0001
8
BPHA00024-0001
24
BINDING PO T(RED) HOT008032-0002
1
25
1
26
peaker Terminal
BPVA00017-0002
1
4
Inset nut 1
27
Hexagon nut
1
1
Item NO. Description Qty.
Part NO.
Part Name
FOOT
BPZA00006-0001
Weight Base
crew
Desk tand COVER
Desk tand Hinge
crew
BPUA00004-0001
G PA00076-0001
1
1
1
1
1
4
1
5
FT3.0*L6.0 P1.27
29
30
31
32
33
34
35
36
1 2 3 4 7 8 9 10 11 12 13 14 15 16 17 18 19 20 216
22
23
24
25
26
27
28
29
36
35
34
33
32
31
30
5
ANZAINF17-4310
crew
A Glue
B Glue
UXAA05900-0001
UXAA06000-0001
Y358 A
Y358 B
7.5g
EVA PAD
EVA PAD
2 Inch Woofer
19# Tweeter
crew
crew
crew
Crossover
Acoustic Absorb
AT Enclosure
AT OUT Enclosure
A LA00242-0001
HOT008032-0001
BINDING PO T(BLK)
Terminal Cover
BPVA00017-0001
crew
28
BPVA00022-0001
Desk tand Clamp
crew FT3.5*L6.0 P1.41
BM4.0*L12 P0.7
FM6.0*L12 P1.0
BT3.5*L10 P1.41
BWT3.5*L6 P1.41
BT3.0*L12 P1.27
FT3.5*L14 P1.41
H P050074-4120
H P050074-4060
H F053133-1120
H F050204-4030
H B053103-4120
HOT002021-0001
HOT005007-0001
IVMA50005-0002
IVEA00113-0001
IVEA00114-0001
IVEA00115-0001
Ø120.0*H16.0 AB
L345*W85*H28 AL-1100 T=1.2
L100*W60*H20 Yellow
󱤰󲐙󰸾
L342.2*W82.2*H26.1 AB
L30*W32.5*H62.1 AB
L29.7*W13.4*H62.0 AB
L60.2*W40.0*H7.8 AB
L53.0*W32.5*H10.5 AB
Ø111*T2.0 PCC
Ø8.6*10.0 M6.0
L10*W6 M4.0
L22.5*Ø`10 M4.0 Brass
L22.5*Ø`10 M4.0 Brass
L113.5*W56.0*T=1.5 BLACK
L95.0*W3.5 T=1.0 BLACK
L800.0*W3.2*T=2.0 BLACK
L290.0*W6.0*T=0.3 BLACK
L39.0*W6.0*T=0.3 BLACK
Ø8.5*Ø6.3*L5.0 NYLON66
L286.5*W64.5 PCCT=0.5 429C
BRFA00037-0001 Ø110.5*2.0 ilicon 60-70°
󱷡󰐛
APEA00510-0001
L76*W47*T1.6 PCB
H W050074-1060
H P140054-3120
L50.0*W13.0*H3.5 AB
H F050073-4140
F AA21220-0G01
F AA42043-0402
F176-0725D
Infinity
PHI / 230 service Manual
Page 6 of 16
Infinity PHI Satellite Exploded View

1
2
3
0
F176-0725B
Checked ByDrawn By Approved By
PLHZ odel NO.
Size
Sheet 1/1
Item NO. Description Qty.
Part NO.
Part Name
00
13
12
11
10
9
7
6
5
4
3
2
1
16
15
14
17
21
20
19
18
22
23
INFINITY
INFLZY001-0002
Frank
08/04/28
08.04.28
Frank
1
8
24
25
26
27
1 2 3 4 5 6 8 9 10 12 13 14 15 16 17 19 20 21 22 23 24 25 26 27 28
29
30
31
32
33
34
35
36
11 187
Item NO. Description Qty.
Part NO.
Part Name
29
30
31
32
33
34
35
36
ANZAINF17-4310
1
Terminal Cover
BPVA00017-0001
L29.7*W13.4*H62.0 ABS
Speaker Terminal
BPVA00017-0002 1
L30*W32.5*H62.1 ABS
Inset nut 1
HOT005007-0001
Ø8.6*10.0 6.0
1
HOT008032-0001
BINDING POST(BLK)
L22.5*Ø`10 4.0 Brass
BINDING POST(RED) HOT008032-0002
1
L22.5*Ø`10 4.0 Brass
7.5g
A Glue
B Glue
UXAA05900-0001
UXAA06000-0001
Y358 A
Y358 B
7.5g
Hexagon nut 1
HOT002021-0001
L10*W6 4.0
Screw 1
B 4.0*L12 P0.7
HSB053103-4120
2
Acoustic Absorb
IV A50005-0002
L100*W60*H20 Yellow󱤰󲐙󰸾
1
Crossover
IVEA00114-0001
L76*W47*T1.6 PCB
4
Screw BT3.5*L10 P1.41
HSP050074-4120
1
EVA PAD IVEA00114-0001
L800.0*W3.2*T=2.0 BLACK
2
Screw BT3.0*L12 P1.27
HSP140054-3120
Bracket 1
BPHA00024-0001
L50.0*W13.0*H3.5 ABS
1
19# Tweeter
FSAA42043-0402
EVA PAD 1
IVEA00115-0001
L95.0*W3.5 T=1.0 BLACK
16
Screw BWT3.5*L6 P1.41
HSW050074-1060
SPACER SUPPORT
DSS10009-0003
16
Ø8.5*Ø6.3*L5.0 NYLON66
4
2 Inch Woofer
FSAA21220-0G01
2
EVA PAD
IVEA00113-0001
L113.5*W56.0*T=1.5 BLACK
4
Screw FT3.5*L14 P1.41
HSF050073-4140
28
NON-WEAVE
NON-WEAVE
IVSA10021-0002
IVSA10021-0001
2
2
L290.0*W6.0*T=0.3 BLACK
L39.0*W6.0*T=0.3 BLACK
Desk Stand COVER
1
BPVA00022-0002 Ø120.0*H16.0 ABS
FOOT 1 BRFA00037-0001 Ø110.5.0*H2.0 Silicon 60-70°
󱷡󰐛
Desk Stand Hinge
BPUA00004-0001
1
L53.0*W32.5*H10.5 ABS
1
Screw F 6.0*L12 P1.0
HSF053133-1120
BPZA00006-0001
1
Desk Stand Clamp L60.2*W40.0*H7.8 ABS
4
Screw FT3.5*L6.0 P1.41
HSP050074-4060
Weight Base GSPA00076-0001
1
Ø111*T2.0 SPCC
Screw 5
FT3.0*L6.0 P1.27
HSF050204-4030
CEN OUT BAFFLE
ASLA00242-0003
L345.0*W85.0*H21.0 T=1.2 AL-1100 1
CEN OUT Enclosure
ASLA00242-0004
L344.9W84.9*H26 T=1.2 AL-1100 1
CEN Enclosure
BPQA00013-0001
L342.2W82.2*H28.1 ABS 1
CEN BAFFLE L342.0*W82.2*H24.0 ABS 1
CEN GRILLE
GSNA05003-0002
BPFA00038-0001
L324.5*W64.5*H13.5 T=0.5 SPCC 1
Infinity
PHI / 230 service Manual
Page 7 of 16
Infinity PHI Center Speaker Exploded View

1
2
3
0
Checked ByDrawn By Approved By
PLHZ Model NO.
ize
heet 1/1
Item NO. Description Qty.
Part NO.
Part Name
00
AIR Chimney B
GRILLE
POWER PANEL
EDGING WOOD
GRILLE CONE
EVA PAD
RUBBER CAP
WOOD BOX
AMP-REAR
stand off
13
12
11
10
9
7
6
5
4
3
2
1
16
15
14
17
FOOT
Acoustic Absorb
NET CLOTH
8 INCH WOOFER
INFINITY
INFLZY001-0001
Frank
08.04.29
08.04.29
Frank
BPGA00024-0001
IVEA00123-0001
DPP025648-1030
WMAA00114-0001
H B050071-1200
IVNA00017-0001
L262.6*W262.6*H17.7 AB 2
8
L210*W12*T1.0 Black
Ø50.0*L113.0 AB
1
1
1
8
12
1
1
1
2
4
4
2
1
8
2
Ø50*L125.5 PAPER+AB
BT3.5*L20 P1.41
BT4.0*L18 P1.58
L382*W382 RC-265-31
A LA00224-0002
L296*W296*H260 MDF=18
8
IVMA50005-0001
BRFA00033-0001
12
4
56789
10 11
14 15
16
17
13
3
ANZAINF17-4310
AIR Chimney A
crew
crew
L250.0*W230 T35 Yellow
Ø25*12.2 I
L176*176*T1.5 PCC
12
N T855051-8200
A LA00124-0001
D 100038-0001
EVA PAD
IVEA00116-0001
2
Ø25*H8.0 EVA
EVEA20002-1201
L12*W12*H30
BRGA00004-0001
Ø13*H8.8 RUBBER BLACK
HOT007003-0001
Ø10.5*Ø6.0*H17.5 BRA
A LA00182-0009
A LA00224-0005
󰍚
F176-0725D
A LA00224-00 02
Infinity
PHI / 230 service Manual
Page 8 of 16
Infinity PHI Subwoofer Exploded View

1
2
3
0
Checked ByDrawn By Approved By
PLHZ Model NO.
ize
heet 1/1
Item NO. Description Qty.
Part NO.
Part Name
00
tand Base Weight
BA E COVER
FOOT
crew
tand Column
tand Top Fitting
10
9
7
6
5
4
3
2
1
INFINITY
INFLZY001-0004
Frank
08.04.29
08.04.29
Frank
BRFA00049-0001
H F053123-4150
G PA00081-0001
BPBA00016-0001
GALA00179-0001
HOT008034-0001
H B053123-4150
H F050073-4080
Ø20.0*H6.0 RUBBER 4
FT3.5*L7.0 P1.41 8
FM5.0*L15 P0.8
Ø264.5*T6.0 󳓜󰳴
L800*W60.0*T1.5 AL-6063
2
1
1
1
1
1
2
Ø270*H14.0 AB
BM6.0*L62 P1.0
BPCA00005-0001
L60*W57.4*H79.4 AB
8
ANZAINF17-4310
1234
5
6
7
8
9
crew
crew
crew BM5.0*L15 P0.8
PREMIUM LOUDSPEAKERS(HUIZHOU)CO.LTD
F176-0725D
Infinity
PHI / 230 service Manual
Page 9 of 16
Infinity PHI Floor Stand Exploded View

INFINITY PHI 5.1 and 2.1 SPEAKER SYSTEM WITH STAND
S
Electrical and mechanical parts list
Component No. Description Size/Dimensions UOM Qty.
PHI 8" ACTIVE BASS REFLEX SUBWOOFER
APEA00431-0002 MAIN PCB ASS'Y 21 51 PHI SUB (Digital Amp) 1.000,00
APEA00432-0002 CONTROL PCB ASS'Y 21 51 PHI SUB Input PCB) 1.000,00
BRFA00033-0001 SI FOOT Φ25*H12.2MM SILICON PC 4.000,00
NST855051-8200 SCREW #8X#4X20L BIND HEAD,A,BLK PC 8.000,00
DPP025648-1030 PLASTIC TUBE ABS BLACK OD56xID48xL103 DH-1250 PC 1.000,00
WMAA00114-0001 AIR CHIMNEY A L125.5*Φ53.1 PAPER+ABS PC 1.000,00
BRGA00004-0001 RUBBER CAP MIRCOVEE 6 Φ13*H8.8 BLACK PC 8.000,00
HOT007003-0001 GRILL CONE OD10.5xID6xH17.5 COPPER PC 8.000,00
IVEA00116-0001 EVA FOR CX SUB POWER BOARD Φ25*8MM 25度單面背膠 PC 2.000,00
EVEA20002-1201 EDGING WOOD FOR CX SUB 12*12*30MM MDF T=12MM PC 4.000,00
EVLA20002-1201 M.D.F BOARD 2440LX1220WX12T MDF E1 PC 0,888
TPS220200-0401 OPEN FRAME SPS 2 O/P 200W HYS4A200-GG-2 HIGHWAY I/P 180-265V O/P +/-22V PC 1.000,00
HSB050071-1200 SCREW T3.5x1.41PxL20mm NICKEL BINDIN HEAD D7.3TYPE AB PC 12.000,00
IVEA00123-0001 EVA L210*W12*T1.0 BLACK PC 1.000,00
ASLA00224-0002 CABINET ASSY FOR INF17 PC 1.000,00
EVMA00011-0002 WOOD BOX FOR INF7 SUB L296*W296*D260MM MDF T=18MM PC 1.000,00
EVMA00011-0003 WOOD BOX FOR INF7 SUB L296*W296*D260MM MDF T=18MM PC 1.000,00
DSS100038-0001 SPACER SUPPORT A=6.8 NYLON 66 UL 94V-2 PINGOOD:WCB-6 PC 4.000,00
ASLA00224-0003 MAIN SPEAKER ASSY FOR INF17 SUB PC 1.000,00
FSBA2A080-0450 PHI 8"WOOFER 100W 4.5OHM PC 1.000,00
UFRA02156-0001 FRAME Φ216XΦ56XT63.5 0.8 STEEL PC 1.000,00
UPLA09500-0001 WASHER Φ95XΦ43.4X6.0T SPHC PC 1.000,00
UYKA09000-0001 T-YOKE Φ90XΦ37.95X6.0TX29.0 SWRM-1008 PC 1.000,00
UMGA01100-0001 MAGNET Φ110XΦ45X20T FERRITE/Y30 PC 1.000,00
UMGA01100-0002 MAGNET Φ110XΦ70X20T FERRITE/Y30 PC 1.000,00
UVCA04220-0002 VOICE COIL Φ42.2*Φ38.75*4.5ΩPC 1.000,00
UCPA02110-0001 CONE PAPER Φ212XΦ39.5X31EH 0.9MM PPC NBR PC 1.000,00
DCN020250-0001 PAPER CAP OD50xID39.2xH4.0MM PC 1.000,00
UDPA01350-0001 DAMPER PC Φ135XΦ39.0X3.3 0.4/50G PC 1.000,00
UDCA09800-0002 DUST CAP Φ98X18.5HX0.6T PP PC 1.000,00
UDCA06000-0001 DUST CAP Φ60X5H PAPER PC 1.000,00
UTE840600-0013 TERMINAL L29.0*#110*#205 PC 1.000,00
HSBA73123-2600 SCREW M5XL6 STEEL PC 4.000,00
UGAA13800-0001 PAPER GASKET Φ138XΦ125X3H PAPER PC 1.000,00
UGAA13800-0002 PAPER GASKET Φ138XΦ125X7H PAPER PC 1.000,00
UXBA03005-0001 EVA GASKET Φ215XΦ181X1.5T EVA PC 1.000,00
QCF045010-0000 GP CHIP RES. 0 OHM 1/4W 5% 1206 PC 2.000,00
QCF081020-3002 CHIP RES. 30K OHM 1/8W 1% 0805 PC 1.000,00
PYL456470-1040 GP CHIP CAP 0.1uF 50V 10% 0805 TYPE X7R PC 1.000,00
PYL410370-2210 GP CHIP CAP 220pF 50V 5% 0805 TYPE NPO PC 4.000,00
QCF041010-1009 CHIP RES. 10 OHM 1/4W 1% 1206 PC 4.000,00
QCF081020-1001 GP CHIP RES. 1K OHM 1/8W 1% 0805 PC 2.000,00
QCF081020-4701 GP CHIP RES. 4.7K OHM 1/8W 1% 0805 PC 1.000,00
QCF081020-5601 GP CHIP RES. 5.6K OHM 1/8W 1% 0805 PC 1.000,00
QCF081020-1002 GP CHIP RES. 10K OHM 1/8W 1% 0805 PC 5.000,00
QCF081020-1602 CHIP RES. 16K OHM 1/8W 1% 0805 PC 1.000,00
QCF081020-2002 GP CHIP RES. 20K OHM 1/8W 1% 0805 PC 2.000,00
QCF081020-4702 GP CHIP RES. 47K OHM 1/8W 1% 0805 PC 1.000,00
QCF081020-5602 CHIP RES. 56K OHM 1/8W 1% 0805 PC 1.000,00
QCF081020-1503 GP CHIP RES. 150K OHM 1/8W 1% 0805 PC 1.000,00
QCF081020-6803 CHIP RES. 680K OHM 1/8W 1% 0805 PC 1.000,00
QCF081020-1004 GP CHIP RES. 1M OHM 1/8W 1% 0805 PC 2.000,00
QCF041010-1009 CHIP RES. 10 OHM 1/4W 1% 1206 PC 2.000,00
QCF101250-2209 CHIP RES. 22 OHM 1W 1% 2512 PC 2.000,00
PYL410370-2210 GP CHIP CAP 220pF 50V 5% 0805 TYPE NPO PC 1.000,00
PYL410370-3310 GP CHIP CAP 330pF 50V 5% 0805 TYPE NPO PC 2.000,00
PYL456470-1030 GP CHIP CAP 0.01uF 50V 10% 0805 TYPE X7R PC 2.000,00
PYL456470-1240 CHIP CAP 0.12uF 50V 10% 0805 TYPE X7R PC 1.000,00
PYL456470-1530 GP CHIP CAP 0.015uF 50V 10% 0805 TYPE X7R PC 2.000,00
PYL456470-1040 GP CHIP CAP 0.1uF 50V 10% 0805 TYPE X7R PC 13.000,00
PYL456470-2240 GP CHIP CAP 0.22uF 50V 10% 0805 TYPE X7R PC 1.000,00
PZL456470-1040 GP CHIP CAP 0.1uF 50V 10% 1206 TYPE X7R PC 8.000,00
RCD104148-1010 GP DIODE SW LL4148 TELEFUNKEN SOD80 SMT TYPE PC 2.000,00
RCZ005005-0060 CHIP ZENER 5.1V 5% 0.5W TTL-34 MINI MELF CTAK:TCLLZ5V1 PC 1.000,00
RCN201623-1001 GP XISTR NPN 2SC1623 HFE:200-400 L6 PC 2.000,00
RCI004558-0003 GP IC 8PIN TEXAS RC4558D SOIC DR401 DR420 DR610 DR620 PC 1.000,00
RCI008920-1002 GP IC 24P TDA8920BTH HSOP24 PHILIPS 2X100W CLASS-D POWER AM PC 1.000,00
QCF105250-1210 CHIP RES. 120 OHM 1W 5% 2512 PC 1.000,00
QCF081020-6801 GP CHIP RES. 6.8K OHM 1/8W 1% 0805 PC 1.000,00
PZL4564A0-1040 GP CHIP CAP 0.1uF 100V 10% 1206 TYPE X7R PC 2.000,00
PFN226380-6840 GP COND METAL 0.68uF 63V 5%MINIBOX CAMEL:MEM AI-RADIAL PC 2.000,00
PLE499572-1020 COND ELECT 1000uF 50V 20% 16x25xP7.5mm HIGH RIPPLE CURRENT TM PC 2.000,00
SIN002705-2200 INDUCTOR 22uH 20% 4.3A W/FERRITE CASE PC 2.000,00
RHI007815-1001 DC 3 PIN 7815CV 15V 1A REGULATOR PC 1.000,00
Infinity
PHI / 230 service Manual
Page 10 of 16

Component No. Description Size/Dimensions UOM Qty.
PHI 8" ACTIVE BASS REFLEX SUBWOOFER
RHI007915-1001 IC 3 PIN AN7915T SAMSUNG REGULATOR PC 1.000,00
CCN250000-0106 GP CONNECTOR B6B-XH-A 6 PIN POST BASE TOP P=2.5 PC 1.000,00
VWA300011-0002 C/W 3P 260mm 1015#22 RED-WHITE-BLACK A=3.96MM B=3.96SDN PC 1.000,00
VWT130121-0420 GP WIRE TERM 2P 420mmRD/BK B:STP4 1007#18 A:+6.4/-3.7 PC 1.000,00
SFB005002-6000 BEAD FERIT 60 OHM 100MHz 3.5x6mm WBRH-35608 PC 2.000,00
QNO205000-1210 RES. MOF 120 OHM 2W 5% HI MINI SIZE W/O KINK PC 2.000,00
SIL017009-1210 COMMON COIL 120uH ±10% D1.0 5.0Ts DCR<6M OHM 10X17 PC 1.000,00
DHU109001-0001 PCB HOUSING L11.5xW8.5xH11.2xT0.8 STEEL WHITE ZINC PC 1.000,00
VWT190421-0300 TERM. WIRE 300mm 2468#18 RED/BLACK A=+6.4/-3.7 W/TUBE B=STP 5MM PC 1.000,00
PLE099570-1000 COND ELECT 10uF 50V 20% 105' 5x11mm PC 3.000,00
PLE099550-1010 COND ELECT 100uF 25V 20% 105' 6.3x11mm PC 2.000,00
PLE099570-2290 COND ELECT 2.2uF 50V 20% 105' 5x11mm PC 2.000,00
PLE099570-2200 COND ELECT 22uF 50V 20% 105' 5x11mm PC 2.000,00
PLE099580-4700 COND ELECT 47uF 63V 20% 105' 6.3x11 LONG LEAD PC 1.000,00
HSB053083-1120 SCREW M3.0XP0.5XL12MM NICKEL BINDIN HEAD TYPE B PC 4.000,00
GALA00085-0001 HEAT SINK ALUMINIUM 55*20*38.5MM PC 1.000,00
DSS100017-0001 SPACER SUPPORT OD5xID3.1xH3.3mm NYLON 66 WHITE PC 4.000,00
HWFA18040-6050 GP WASHER FIB OD8.0xID4.0xT0.5mm OD8.0XID4.0XT0.5MM PC 4.000,00
HIS000003-0001 SI RUBBER 16x11xT0.3mm PC 1.000,00
APEA00432-0002 CONTROL PCB ASS'Y INFINITY PC 1.000,00
APEA00432-4002 CONTROL PCB ASS'Y (HI) INFINITY PC 1.000,00
APEA00432-6002 CONTROL PCB ASS'Y (SMT-BOTTOM) INFINITY PC 1.000,00
LFMA00432-0201 GP CONTROL PCB FR-4 NO MATERIAL COST 125*65MM INFINITY/CX PC 1.000,00
PYL410370-1010 GP CHIP CAP 100 pF 50V 5% 0805 TYPE NPO PC 6.000,00
PYL410370-4700 GP CHIP CAP 47pF 50V 5% 0805 TYPE NPO PC 3.000,00
PYL456470-1040 GP CHIP CAP 0.1uF 50V 10% 0805 TYPE X7R PC 3.000,00
QCF085020-1020 GP CHIP RES. 1K OHM 1/8W 5% 0805 PC 5.000,00
QCF085020-2730 GP CHIP RES. 27K OHM 1/8W 5% 0805 PC 3.000,00
QCF085020-1030 GP CHIP RES. 10K OHM 1/8W 5% 0805 PC 8.000,00
QCF085020-1040 GP CHIP RES. 100K OHM 1/8W 5% 0805 PC 4.000,00
QCF085020-4730 GP CHIP RES. 47K OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-2440 GP CHIP RES. 240K OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-2230 GP CHIP RES. 22K OHM 1/8W 5% 0805 PC 4.000,00
QCF085020-5620 GP CHIP RES. 5.6K OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-6820 GP CHIP RES. 6.8K OHM 1/8W 5% 0805 PC 3.000,00
QCF085020-1230 GP CHIP RES. 12K OHM 1/8W 5% 0805 PC 2.000,00
QCF085020-4720 GP CHIP RES. 4.7K OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-2020 GP CHIP RES. 2K OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-2250 GP CHIP RES. 2.2M OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-3900 GP CHIP RES. 39 OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-2740 GP CHIP RES. 270K OHM 1/8W 5% 0805 PC 2.000,00
QCF085020-5640 GP CHIP RES. 560K OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-2240 GP CHIP RES. 220K OHM 1/8W 5% 0805 PC 2.000,00
QCF085020-1050 GP CHIP RES. 1M OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-6840 GP CHIP RES. 680K OHM 1/8W 5% 0805 PC 4.000,00
QCF085020-2220 GP CHIP RES. 2.2K OHM 1/8W 5% 0805 PC 3.000,00
QCF085020-3920 GP CHIP RES. 3.9K OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-1520 GP CHIP RES. 1.5K OHM 1/8W 5% 0805 PC 1.000,00
QCF085020-0000 GP CHIP RES. 0 OHM 1/8W 5% 0805 PC 3.000,00
QCF085020-1520 GP CHIP RES. 1.5K OHM 1/8W 5% 0805 PC 1.000,00
QCF045010-5610 GP CHIP RES. 560 OHM 1/4W 5% 1206 PC 1.000,00
QCF085020-1240 GP CHIP RES. 120K OHM 1/8W 5% 0805 PC 2.000,00
QCF081020-6801 GP CHIP RES. 6.8K OHM 1/8W 1% 0805 PC 1.000,00
QCF105250-2210 CHIP RES. 220 OHM 1W 5% 2512 PC 2.000,00
RCD104148-1010 GP DIODE SW LL4148 TELEFUNKEN SOD80 SMT TYPE PC 5.000,00
RCI000720-0001 IC 8P TL072CDR SOIC ST OPER.AMP PC 2.000,00
RCI000740-1001 GP IC 14P TL074CDT PLASTIC MICRO PACKAG PC 1.000,00
QCF085020-6230 GP CHIP RES. 62K OHM 1/8W 5% 0805 PC 1.000,00
PYL456470-1020 GP CHIP CAP 0.001uF 50V 10% 0805 TYPE X7R PC 2.000,00
MVR002234-5030 CNTL ROTRY 6P 50K OHM L=15mm T=7mm ALPHA:RV0620DF-46E3-15B-B50K-901 PC 1.000,00
MVR002215-1030 CNTL ROTRY 3P 10K OHM L=15mm T=7mm ALPHA:RV0600DF-43E3-15B-A10K9020 PC 1.000,00
CJB004302-0020 BINDING JACK 4P RED-RED/BLK-BLK GOLD A CLASS:A432C半KPC 1.000,00
MSW007013-0010 ROCKER SW 6P 2A 250V JINMINHAO:MS-202-A1 PC 1.000,00
MSW007009-0010 ROCKER SW 3P 2A 250V JINMINHAO:MS-102-A1 PC 1.000,00
PLE099570-4790 COND ELECT 4.7uF 50V 20% 105' 5x11mm PC 5.000,00
PLE099570-1090 COND ELECT 1uF 50V 20% 105' 5x11mm PC 1.000,00
PLE099540-2210 COND ELECT 220uF 16V 20% 105' 6.3x11mm PC 2.000,00
PLE099570-2290 COND ELECT 2.2uF 50V 20% 105' 5x11mm PC 1.000,00
PLE099570-1000 COND ELECT 10uF 50V 20% 105' 5x11mm PC 3.000,00
PLE099540-1010 COND ELECT 100uF 16V 20% 105' 5x11mm PC 1.000,00
PLE099570-2200 COND ELECT 22uF 50V 20% 105' 5x11mm PC 1.000,00
PLM0373A0-1240 COND MYLAR 0.12uF 100V 5% LONG LEAD PC 2.000,00
PLM0373A0-3330 COND MYLAR 0.033uF 100V 5% LONG LEAD PC 2.000,00
PLM0373A0-5130 COND MYLAR 0.051uF 100V 5% PEI P=5mm LONG LEAD PC 2.000,00
RAN201815-0001 GP XISTR NPN 2SC1815-GR TO-92 TOSHIBA HFE:200-400 PC 4.000,00
CJM035045-3010 PHONE JACK D3.5 4P BLACK L17.6xW9.9xH9.9 CYC:H-D3.5DIP-52 PC 1.000,00
CJR002501-0010 RCA JACK 2P RED/WHITE STAND GOLD ZHONG ZHOU:HPJ-202H-05-G-W PC 1.000,00
VWA020006-0003 C/W 10/6&4P 180/280mm 1007#24 A=2512V B1B2=2.5 W/REVERSE B2 PC 1.000,00
CCN250000-0502 GP CONNECTOR S2B-XH-A 2 PIN POST BASE SIDE P=2.5 PC 1.000,00
ASLA00203-0001 GP WIRE CONN PH2.5 2468/24AWG WITH 2P 210MM GREEN/RED LED PC 1.000,00
Infinity
PHI / 230 service Manual
Page 11 of 16

Component No. Description Size/Dimensions UOM Qty.
PHI 8" ACTIVE BASS REFLEX SUBWOOFER
HSP053083-3080 SCREW M3.0x0.5PxL8mm PAN HEAD BLK TYPE B PC 4.000,00
HSP040053-3080 GP SCREW T3.0x1.06PxL8mm PAN HEAD BLK B PC 3.000,00
DKN001004-0001 VR KNOB RUBBER+ABS OD16xH15 BLACK PC 2.000,00
MSW108001-0015 LEVER SW W/"-"MARK LIGHT COUNTRY R19A PC 1.000,00
IVEA00001-0001 EVA L700XW20XT1.0 BLACK PC 4.000,00
CFC021002-1001 FUSE HOLDER MF528(ROHS) FOR 5.2X20MM FUSE PC 1.000,00
CJP012009-0030 AC SOCKET 2P D2.36 2.5A 250V VDE BLACK TECX:SO-222-GB-023-RS PC 1.000,00
KSA020250-0120 GP FUSE 2.5A 250V SLOW 5X20MM RUL/CSA/VDE CONQUER PC 1.000,00
VWA300012-0008 C/W 3P 300mm 1617#22 RED-NC-WHITE A=3.96MM B=STP 10MM PC 1.000,00
VWR0332EE-0080 LEAD WIRE 80mm 1617#22 BROWN A,B=STP 10MM PC 2.000,00
MSW004009-0020 SILD SW SL14-22AM-5AN 115/230V CANAL UL/CSA/VDE PC 1.000,00
VWA300012-0009 C/W 3P 300mm 1617#22 BROWN-NC-BROWN A=3.96MM B=STP 10MM PC 1.000,00
DTB020000-0400 GP TUBING SRK DIA=20 L=40mm BLACK 50% SHRINKAGE VINYL PC 2.000,00
DTB135000-0400 SHRINKING TUBE DIA=35 L=40mm BLK SA2420 SANYO PC 1.000,00
DTB050000-0500 HEAT SHRINKABLE TUBE ID50xL50mm BLACK PC 1.000,00
DWT000032-1600 GP WIRE TIE L160xW2.5xT1.1mm NYLON 66UL PG YJ-160 PC 4.000,00
IVEA10017-0001 SPONGE EVA 43*39*1MM 單面背膠 PC 1.000,00
BPRA30012-0001 O RING RUBBER BLACK Φ6.4*Φ3.2*1.6 PC 1.000,00
IVEA00016-0001 GASKET POLYETHYLENE FOAM RUBBER ADHESIVE 180X170X2MM PC 1.000,00
ASLA00224-0005 TRANSFORMER ASSY AND CABLES FOR INF17 PC 1.000,00
VPE003202-0020 PWR CORD 2P 2000mm BK VDE WIRE:H03VVH2-F KE-21+KE-22C PC 1.000,00
ASLA00224-0006 WADDING ASSY FOR INF17 PC 1.000,00
IVMA50005-0001 WADDING L250*W230*H35MM 黃色玻纖棉 PC 3.000,00
ASLA00224-0007 GRILLE AND TRIM ASSY FOR INF17 PC 1.000,00
BPGA00024-0001 GRILLE ABS L262.6*W262.6*H17.7MM BLACK PC 2.000,00
IVNA00017-0001 GRILLE CLOTH FOR INF17 L382*W382MM RC-265-31 PC 2.000,00
IVNA00017-M000 GRILLE CLOTH RC-265-31 幅寬1727MM M 186
ASLA00223-0002 SATELLITE ASSY FOR INF17 SATELLITE PC 4.000,00
ASLA00228-0001 MAIN ASSY FOR PHI SATELLITE PC 4.000,00
BPFA00037-0001 SAT BAFFLE L342.2*W82.2*H26.1MM ABS 757 PC 4.000,00
BPQA00012-0001 ENCLOSURE L338*W82*H25.3MM ABS 757 PC 4.000,00
BPVA00022-0001 SAT DESK STAND Φ120*H16MM ABS 757 PC 4.000,00
BPZA00006-0001 DESK STAND CLAMP L60.2*W40*H7.8MM ABS 757 PC 4.000,00
BPUA00004-0001 DESK STAND HINGE L53*W32.5*H10.5MM ABS 757 PC 4.000,00
BPVA00017-0002 TERMINAL COVER L62.1*W29.2*H30MM ABS 757 PC 4.000,00
HOT008032-0002 BINDING POST M4.0xL22 BRUSS GOLD RED PC 4.000,00
HOT008032-0001 BINDING POST M4.0xL22 BRUSS GOLD BLACK PC 4.000,00
BPVA00017-0001 TERMINAL COVER ABS 757 L62*W29.7*H13.4MM BLACK PC 4.000,00
HOT005007-0001 INSERT NUT M6.0x1.0PxH10 BLACK ZINC PC 4.000,00
IVEA00113-0001 EVA L113.5*W56 30度BLACK PC 8.000,00
BRFA00037-0001 SILICON PAD Φ110*T2MM BLACK 背膠 PC 4.000,00
HSF050073-4140 SCREW T3.5x1.41PxL14mm BLACK ZINC FLAT HEAD D7.0 TYPE B PC 16.000,00
IVSA10021-0002 NON-WEAVE L290*W6*T0.3 BLACK PC 8.000,00
IVSA10021-0001 NON-WEAVE L39*W6*T0.3 BLACK PC 8.000,00
BPHA00024-0001 BRACKET L50*W13MM ABS 757 PC 4.000,00
GSPA00076-0001 WEIGHT BASE SPCC Φ111*T2.0MM PC 4.000,00
HSF050204-4030 SCREW T3.0x1.27PxL6 BLACK ZINC FLAT HEAD D6XH1.8 TYPE TRIANGLE PC 20.000,00
IVEA00114-0001 EVA L800*W3.2MM 30度PC 4.000,00
HSW050074-1060 SCREW T3.5x1.41PxL6 NICKEL WASHER HEAD D9XH2.3TYPE TRIANG PC 80.000,00
DSS100009-0003 SPACER SUPPORT OD8.5xID6.3xH5 PINGOOD:6305 PC 64.000,00
HSP050074-4120 SCREW T3.5x1.41PxL12 BLACK ZINC PAN HEAD D7.3XH2.2 TYPE TRIANGLE PC 16.000,00
HSF053133-1120 SCREW M6.0x1.0PxL12mm NICKEL FLAT HEAD D11.8XH3.5 TYPE B PC 4.000,00
HOT002021-0001 COPPER SPACER M4.0x0.7PxL11mm BRASS HEXAGON B=6MM PC 4.000,00
HSP140054-3120 GP SCREW T3.0xL12xP1.06mm BLACK OXIDE PC 8.000,00
HSB053103-4120 SCREW M4.0x0.7PxL12mm BLACK ZINC BINDIN HEAD D8.3 TYPE B PC 4.000,00
IVEA00115-0001 EVA L950*W3.5MM*1.0MM 30度PC 4.000,00
ASLA00228-0002 MAIN SPEAKER FOR PHI SATELLITE PC 4.000,00
FSAA21220-0G01 INFINITY 2"WOOFER 12W 16OHM PC 16.000,00
UFRA05600-0001 FRAME 2" SPCC BLACK PAINT T=0.7MM 2"56*56*H19.5*T0.7MM PC 16.000,00
UDCA02500-0004 DUST CAP Φ25.2*Φ22.5*H5.0MM PC 16.000,00
UCPA05300-0002 CONE PAPER RUBBER EDGE+PAPER BODY BLACK Φ53.5*Φ21*H10.5MM PC 16.000,00
UDPA04550-0001 DAMPER 1.05/50G CONEX6070 Φ45.5XΦ20.6XH2.0 PC 16.000,00
UVCA02040-0007 VOICE COIL Φ20.4*19.0*13Ω*2L PC 16.000,00
UMGA01900-0002 MAGNET N35H PLATING Cr3+ Φ18.5*H4.0MM PC 16.000,00
UPLA02000-0002 WASHER SPHC PLATING Cr3+ Φ19.95*T2.5MM PC 16.000,00
UMGA02000-0001 MAGNET N35H PLATING Cr3+ Φ19.5*H4.0MM PC 16.000,00
UYKA03200-0001 U-YOKE SPHC PLATING Cr3+ Φ32*Φ14*H17.6*T10.5MM PC 16.000,00
UTEA00016-0001 TERMINAL 23.0*8.0*PIN5.2*2.8*0.5T PC 16.000,00
FSAA42043-0402 INFINITY 19MM TWEETER 20W 4OHM PC 4.000,00
BPRA30016-0001 MID-PLATE ABS 20蕊內磁音膜座 PC 4.000,00
UYKA02140-0002 YOKE Φ26XΦ21.4X4.5H（內高）X7.0H PC 4.000,00
UPL800600-0001 TOP PLATE-OD19.95*ID6.0*T1.5 OD19.95*ID6.0*T1.5 PC 4.000,00
UMG801900-0003 MAGNET OD19*ID6.0*T3.0/NEO N35 PC 4.000,00
UVCA02040-0002 VOICE COIL Φ20.4*3.6H*3.6Ω*0.11/2L SV線PC 4.000,00
UCPA02940-0001 DIAPHRAGM Φ29.5X20.7X4.4H SILK PC 4.000,00
UTEA06502-0001 TERMINAL PIN5.0*14.4L*0.5T PC 8.000,00
ASLA00228-0003 CROSSOVER ASSY FOR INF17 PC 4.000,00
APEA00510-0001 CROSSOVER ASSY FOR INF17 CROSSOVER ASSY PC 4.000,00
Infinity
PHI / 230 service Manual
Page 12 of 16

Component No. Description Size/Dimensions UOM Qty.
MAIN SPEAKER FOR PHI SATELLITE PC
QHE505000-1890 RESISTOR 1.8 OHM 5W 5% AXIAL L22XW10XD10MM WHITE PC 4.000,00
QHE505000-3390 RESISTOR 3.3 OHM 5W 5% AXIAL L22XW10XD10MM WHITE PC 4.000,00
PLE339370-3391 COND ELECT 3.3uF 50V 5% -40-85' 10x16 NON-POLAR DF<4%@1KHZ BLUE PC 4.000,00
PLE339370-8090 COND ELECT 8uF 50V 5% -40'-85' 10x16 NON-POLAR DF<4%@1KHZ BLUE PC 4.000,00
PLE339370-1500 COND ELECT 15uF 50V 5% -40'-85' 10x16 NON-POLAR DF<6%@1KHZ BLUE PC 4.000,00
SIL017021-7510 COMMON COIL 0.75mH 5% D0.4mm DCR0.6 OHM 10% 10X35X30 PC 4.000,00
SIL017020-1010 COMMON COIL 0.1mH 5% D0.9mm DCR 0.2 OHM 10% C30XB15XA35 PC 4.000,00
SIL017006-1511 COMMON COIL 0.15mH 5% D0.5mm DCR0.16 OHM 10% 10X23X30 PC 4.000,00
VWA350056-0001 C/W 2P 80mm 1015#20 RED A,B1=205#0.5T W/BOOT B2=STP 6MM PC 8.000,00
VWA350055-0001 C/W 2P 80mm 1015#20 BLACK A,B1=110#0.5T W/BOOT B2=STP 6MM PC 8.000,00
VWS351000-1600 WIRE L160MM RED/BK 26AWG UL2468 PC 4.000,00
VWA350047-0004 C/W 2P 220mm 2468#18 RED/BLACK A=205#/110#0.5T W/BOOT B=STP 4MM PC 4.000,00
LVSA00510-0201 CROSSOVER BOARD 1PANEL 2 PCS L76*W47MM PC 4.000,00
DTB001000-0100 TUBE SRK ID1.0xL10MM PVC BLACK PC 16.000,00
ASLA00228-0005 WADDING ASSY FOR INF17 SAT PC 4.000,00
IVMA50005-0002 WADDING L100*W60MM*H20MM 黃色玻纖棉 PC 8.000,00
ASLA00228-0006 GRILLE AND TRIM FOR INF17 SAT PC 4.000,00
GSNA05003-0001 SAT GRILLE L286*W64.5*12.5*Φ1.0MM PC 4.000,00
ASLA00229-0001 MAIN ASSY FOR PHI CENTER PC 1.000,00
ASLA00223-0003 CENTER ASSY FOR INF17 CENTER PC 1.000,00
BPFA00038-0001 CEN BAFFLE L342.2*W82.2*H24 ABS757 PC 1.000,00
BPQA00013-0001 ENCLOSURE L338*W82.2*H28.1MM ABS 757 PC 1.000,00
BPVA00022-0002 CEN DESK STAND WITH SILKSCREEN Φ120*H16MM ABS 757 PC 1.000,00
BPZA00006-0001 DESK STAND CLAMP L60.2*W40*H7.8MM ABS 757 PC 1.000,00
BPUA00004-0001 DESK STAND HINGE L53*W32.5*H10.5MM ABS 757 PC 1.000,00
BPVA00017-0002 TERMINAL COVER L62.1*W29.2*H30MM ABS 757 PC 1.000,00
HOT008032-0002 BINDING POST M4.0xL22 BRUSS GOLD RED PC 1.000,00
HOT008032-0001 BINDING POST M4.0xL22 BRUSS GOLD BLACK PC 1.000,00
BPVA00017-0001 TERMINAL COVER ABS 757 L62*W29.7*H13.4MM BLACK PC 1.000,00
HOT005007-0001 INSERT NUT M6.0x1.0PxH10 BLACK ZINC PC 1.000,00
IVEA00113-0001 EVA L113.5*W56 30度BLACK PC 2.000,00
BRFA00037-0001 SILICON PAD Φ110*T2MM BLACK 背膠 PC 4.000,00
HSPA43103-4160 SCREW M4XL16 STEEL BLACK PC 1.000,00
HSF050073-4140 SCREW T3.5x1.41PxL14mm BLACK ZINC FLAT HEAD D7.0 TYPE B PC 4.000,00
IVSA10021-0002 NON-WEAVE L290*W6*T0.3 BLACK PC 2.000,00
IVSA10021-0001 NON-WEAVE L39*W6*T0.3 BLACK PC 2.000,00
GALA00177-0001 CEN FRONT BAFFLE L345*W85*H21*T0.8 AL-5052 PC 1.000,00
GALA00177-0002 CEN REAR BAFFLE L345*W85*H26*T0.8 AL-5052 PC 1.000,00
BPHA00024-0001 BRACKET L50*W13MM ABS 757 PC 1.000,00
GSPA00076-0001 WEIGHT BASE SPCC Φ111*T2.0MM PC 1.000,00
HSF050204-4030 SCREW T3.0x1.27PxL6 BLACK ZINC FLAT HEAD D6XH1.8 TYPE TRIANGLE PC 5.000,00
IVEA00114-0001 EVA L800*W3.2MM 30度PC 1.000,00
HSW050074-1060 SCREW T3.5x1.41PxL6 NICKEL WASHER HEAD D9XH2.3TYPE TRIANG PC 16.000,00
DSS100009-0003 SPACER SUPPORT OD8.5xID6.3xH5 PINGOOD:6305 PC 16.000,00
HSP050074-4120 SCREW T3.5x1.41PxL12 BLACK ZINC PAN HEAD D7.3XH2.2 TYPE TRIANGLE PC 4.000,00
HSF053133-1120 SCREW M6.0x1.0PxL12mm NICKEL FLAT HEAD D11.8XH3.5 TYPE B PC 1.000,00
HSW050074-1060 SCREW T3.5x1.41PxL6 NICKEL WASHER HEAD D9XH2.3TYPE TRIANG PC 4.000,00
HOT002021-0001 COPER SPACER M4.0x0.7PxL11mm BRASS HEXAGON B=6MM PC 1.000,00
HSP140054-3120 GP SCREW T3.0xL12xP1.06mm BLACK OXIDE PC 2.000,00
HSB053103-4120 SCREW M4.0x0.7PxL12mm BLACK ZINC BINDIN HEAD D8.3 TYPE B PC 1.000,00
ASLA00228-0002 MAIN SPEAKER FOR PHI CENTER PC 1.000,00
FSAA21220-0G01 INFINITY 2"WOOFER 12W 16OHM PC 4.000,00
UFRA05600-0001 FRAME 2" SPCC BLACK PAINT T=0.7MM 2"56*56*H19.5*T0.7MM PC 4.000,00
UDCA02500-0004 DUST CAP Φ25.2*Φ22.5*H5.0MM PC 4.000,00
UCPA05300-0002 CONE PAPER RUBBER EDGE+PAPER BODY BLACK Φ53.5*Φ21*H10.5MM PC 4.000,00
UDPA04550-0001 DAMPER 1.05/50G CONEX6070 Φ45.5XΦ20.6XH2.0 PC 4.000,00
UVCA02040-0007 VOICE COIL Φ20.4*19.0*13Ω*2L PC 4.000,00
UMGA01900-0002 MAGNET N35H PLATING Cr3+ Φ18.5*H4.0MM PC 4.000,00
UPLA02000-0002 WASHER SPHC PLATING Cr3+ Φ19.95*T2.5MM PC 4.000,00
UMGA02000-0001 MAGNET N35H PLATING Cr3+ Φ19.5*H4.0MM PC 4.000,00
UYKA03200-0001 U-YOKE SPHC PLATING Cr3+ Φ32*Φ14*H17.6*T10.5MM PC 4.000,00
UTEA00016-0001 TERMINAL 23.0*8.0*PIN5.2*2.8*0.5T PC 4.000,00
FSAA42043-0402 INFINITY 19MM TWEETER 20W 4OHM PC 1.000,00
BPRA30016-0001 MID-PLATE ABS 20蕊內磁音膜座 PC 1.000,00
UYKA02140-0002 YOKE Φ26XΦ21.4X4.5H（內高）X7.0H PC 1.000,00
UPL800600-0001 TOP PLATE-OD19.95*ID6.0*T1.5 OD19.95*ID6.0*T1.5 PC 1.000,00
UMG801900-0003 MAGNET OD19*ID6.0*T3.0/NEO N35 PC 1.000,00
UVCA02040-0002 VOICE COIL Φ20.4*3.6H*3.6Ω*0.11/2L SV線PC 1.000,00
UCPA02940-0001 DIAPHRAGM Φ29.5X20.7X4.4H SILK PC 1.000,00
UTEA06502-0001 TERMINAL PIN5.0*14.4L*0.5T PC 2.000,00
ASLA00229-0002 TRANSFORMER ASSY AND CABLES FOR INF17 CENTER PC 1.000,00
VWS312444-6000 CABLE 6000mm 2468#18 TRANSPARENT A,B=CUT 60MM/STP 10MM PC 1.000,00
ASLA00228-0003 CROSSOVER ASSY FOR INF17 PC 1.000,00
APEA00510-0001 CROSSOVER ASSY FOR INF17 CROSSOVER ASSY PC 1.000,00
QHE505000-1890 RESISTOR 1.8 OHM 5W 5% AXIAL L22XW10XD10MM WHITE PC 1.000,00
QHE505000-3390 RESISTOR 3.3 OHM 5W 5% AXIAL L22XW10XD10MM WHITE PC 1.000,00
PLE339370-3391 COND ELECT 3.3uF 50V 5% -40-85' 10x16 NON-POLAR DF<4%@1KHZ BLUE PC 1.000,00
PLE339370-8090 COND ELECT 8uF 50V 5% -40'-85' 10x16 NON-POLAR DF<4%@1KHZ BLUE PC 1.000,00
Infinity
PHI / 230 service Manual
Page 13 of 16

Component No. Description Size/Dimensions UOM Qty.
MAIN SPEAKER FOR PHI CENTER
PLE339370-1500 COND ELECT 15uF 50V 5% -40'-85' 10x16 NON-POLAR DF<6%@1KHZ BLUE PC 1.000,00
SIL017021-7510 COMMON COIL 0.75mH 5% D0.4mm DCR0.6 OHM 10% 10X35X30 PC 1.000,00
SIL017020-1010 COMMON COIL 0.1mH 5% D0.9mm DCR 0.2 OHM 10% C30XB15XA35 PC 1.000,00
SIL017006-1511 COMMON COIL 0.15mH 5% D0.5mm DCR0.16 OHM 10% 10X23X30 PC 1.000,00
VWA350056-0001 C/W 2P 80mm 1015#20 RED A,B1=205#0.5T W/BOOT B2=STP 6MM PC 2.000,00
VWA350055-0001 C/W 2P 80mm 1015#20 BLACK A,B1=110#0.5T W/BOOT B2=STP 6MM PC 2.000,00
VWS351000-1600 WIRE L160MM RED/BK 26AWG UL2468 PC 1.000,00
VWA350047-0004 C/W 2P 220mm 2468#18 RED/BLACK A=205#/110#0.5T W/BOOT B=STP 4MM PC 1.000,00
LVSA00510-0201 CROSSOVER BOARD 1PANEL 2 PCS L76*W47MM PC 1.000,00
DTB001000-0100 TUBE SRK ID1.0xL10MM PVC BLACK PC 4.000,00
ASLA00229-0003 GRILLE AND TRIM FOR INF CENTER PC 1.000,00
GSNA05003-0002 CEN GRILLE L324.5*W64.5*H12.5*Φ1.0MM PC 1.000,00
ASLA00230-0001 MAIN ASSY FOR INF17 STAND PC 4.000,00
BPBA00016-0001 STAND BASE COVER ψ270*H14 T=2.5MM ABS 757 PC 4.000,00
GSPA00081-0001 STAND BASE WEIGHT Φ264.5*T6MM SPCC PC 4.000,00
GALA00179-0001 STAND COLUMNFLE AL-6063 L800*W60*H30 T=1.5MM PC 4.000,00
BPCA00005-0001 STAND TOP FITTING L79.4*W60*H56.8MM PC 4.000,00
BRFA00028-0001 SILICON FOOT Φ18*H9.5MM 單面背膠 PC 16.000,00
HSF050073-4080 SCREW T3.5x1.41PxL8mm BLACK ZINC FLAT HEAD D7 TYPE B PC 32.000,00
HSB053123-4150 SCREW M5.0x0.8PxL15mm BLACK ZINC BINDIN HEAD D9 TYPE B PC 8.000,00
ASLA00224-0008 ACCESSORY FOR INF17 5.1 PC 1.000,00
IVA802004-0001 BAG-SELF SEAL,TANNOY C.STAND L135*W95*T0.05 PC 4.000,00
BPHA00022-0001 WALL BRACKET L71.4*W37.7MM ABS 757 PC 5.000,00
HOT008034-0001 SCREW M6.0x1.0PxL30+35 NICKEL BINDIN HEAD D11 TYPE B PC 4.000,00
HSF053123-4150 SCREW M5.0x0.8PxL15mm BLACK ZINC FLAT HEAD D9 TYPE B PC 8.000,00
VWS312444-6000 CABLE 6000mm 2468#18 TRANSPARENT A,B=CUT 60MM/STP 10MM PC 2.000,00
VWS312444-C000 CABLE 12000mm 2468#18 TRANSPARENT A,B=CUT 60MM/STP 10MM PC 2.000,00
APKA00077-0002 PACKING ASSY 5.1 INFINITY 5.1 SYSTEM PC 1.000,00
ICCA00128-0001 CARTON L882*W552*H394 PC 1.000,00
ITFA30055-0001 POLYFORM TOP L872*W542*H200MM EPS 50倍發泡率 PC 1.000,00
ITFA30055-0002 POLYFORM BOTTTOM L872*W542*H180MM EPS 50倍發泡率 PC 1.000,00
ICD800000-3158 GP CORNER PAD L1100XW(60+60) 120P/5LAYER L1100XW(60+60) 120P/5LAYER PC 800
EVPA60001-0003 PARTICLE BOARD PALLET E1 L1200XW1000XT120MM PC 100
YOMA00074-0001 OWN MANUAL FOR PHI L290*W210 書寫紙80G PC 1.000,00
Infinity
PHI / 230 service Manual
Page 14 of 16

Volume
Control
Power Stage
(Philips
TDA8920B),
125 W @ 1%
THD
Analog
Input, 2 RCA, 2
Speaker level
PD125 Analog Subwoofer Amplifier
Switch Mode Power Supply
200 W SMPS, 200-264 / 90 –132 V ac input
+ 9 V standby
+/- 15 V liner regulators
+/- 22 V main
125 W @ 1% THD into 4 Ohms
Control PCBA Power PCBA
Phase
Toggle
Switch
2n
d
order
variable
cutoff &
2nd order
HP
Limiter
Standby Circuit: mini jack
trigger & toggle switch
disable
SMPS Low Power Standby
Trigger
Input sense
Power
Stage
Standby
Speaker
(4 Ohm)
+/- 15 V
Regulators
+9 V dc, standby
power +/- 22 V dc, main power
signal
+/- 15 V dc
Infinity
PHI / 230 service Manual
Page 15 of 16

Infinity
PHI / 230 service Manual
Page 16 of 16
