Safety Information
WARNING: ENTRAPMENT HAZARD. Entrapment
of head, neck, limb or torso can occur in gaps
between the Titan pole and furniture and/or
xtures. Entrapment could result in death or
serious injury.
When positioning the Titan pole, ensure the
gap between it and any furniture and/or xtures
complies with Entrapment Guidelines which
state that gaps must be less than 4.75” (12cm) or
greater than 12” (30cm).
The Titan pole must never be used as a restraint
or to prevent users from failing out of bed.
IMPORTANT: If you are unsure that you can
install this product correctly, hire a qualied
professional.
If you have any questions, please contact Customer Care at:
[email protected]. For warranty details, please visit
https://SafetyGrip.com/customer-care/#warranty.
TITAN BALANCE ASSIST POLE with SafetyGrip®
TSG600
Assembly/Installation Instructions

Page 2 | TITAN BALANCE ASSIST POLE with SafetyGrip® TSG600
KIT CONTENTS
For regular installations, all tools are included in the Kit.

www.SafetyGrip.com | Page 3
PRODUCT INFORMATION
Titan Balance Assist Pole comes with our patented Interlocking SafetyGrip®.
Titan poles are protected by AlphaSan®technology, which provides lasting protection against microbial
contamination to all Hartmobility Inc products, delivering unrivalled anti-microbial performance.
•Titan poles are assistive products that may be afxed between oors and ceilings.
•The Titan pole is a tension mount stability and positioning aid that will be subjected to signicant lateral
(sideway) loads when in use. It is your responsibility to ensure that the Titan pole is correctly installed and
maintained as per these ASSEMBLY INSTRUCTIONS provided.
•Titan poles have 6 inches of height adjustment and are designed for installation where the ceiling height is
between 7’-9” to 8’-3” (235 – 250cm). For higher ceilings see the TSGA604 Height Extension Kit.
•The Titan pole is designed to assist with balance, positioning and stability support for persons weighing up to
300lbs (136kg) and is not designed to bear the full weight of the user.
•The Titan pole is not suitable for use by persons over 300lbs (136kg). Please refer to TSG650 Safety Grip®
pole for our 500lbs (230kg) rated weight capacity pole.
•Do not use the Titan pole with a waterbed or inatable bed.
INSTALLATION
Floor & Ceiling Requirements
The oors must be solid level oors. The ceilings are a solid structure or have ceiling joists. The Titan pole
must only be installed in locations where the construction of the ceilings and oors are structurally sound.
1. Titan transfer poles should never be installed on loose oors (rugs, mats) or irregular oors.
2. When the Titan poles are installed in wet or slippery conditions, or where base could move the Floor
Base item 4 should be permanently xed to the oor. Additional Securing methods
are shown below.
3. Do not install near heating/cooling vents or lighting where the structural integrity
of the ceiling has been compromised by the holes cut for these vents and lighting
4. Do not install Titan poles on any suspended ceilings.
STEP 1: Join the Ceiling Disc with the Upper Tube
Put the Ceiling Disc Item 3 on the oor. Take the Upper Pole Tube Item 1 and screw it into
the Ceiling Disc clockwise and tighten rmly.
STEP 1

Page 4 | TITAN BALANCE ASSIST POLE with SafetyGrip® TSG600
STEP 2: Join the Bottom and Top Tubes together using the Connection Tube
Join the Top Pole Tube and Bottom Pole Tube together
using the Connecting Tube Item 6.
INSTALLER CAUTION: Make sure that the inter-connecting
slots in the Pole Tubes are correctly lined up.
Slide the Bottom Cover Tube Item 5 onto the Bottom Pole
Tube.
You are now ready to stand the Pole Assembly up. Put it
into the Base Item 4 between the oor and ceiling. The next
step is easier with two people.
STEP 3: Pole Height Adjustment and alignment
A. Slide the Bottom Cover Tube Item 5 up out of your way while you are doing
this step.
B. You can adjust the height of the Titan pole by turning the screw until the
Ceiling Disc is touching your ceiling. Use the Adjusting Bar supplied to
help you do this. Before you nally tighten the Titan pole check that it is
perpendicular (90 degrees) to the oor in all directions. You can use the level
supplied. When it is perpendicular and where you want it to be, tighten the
Titan pole using the Adjustment Bar.
INSTALLER CAUTION: Do not over tighten the Titan pole because it can
damage your ceiling.
STEP 4: Final Checks
Ensure the Titan pole is safe and secure by grasping the Titan pole mid-height then push and pull vigorously. The
Ceiling Disc and Base should not slide or move if the Titan pole is tensioned correctly. If the Ceiling Disc or Base
moves or slips in any way, increase tension on the pole by tightening the screw. Double check that the Titan pole is
still perpendicular. When the Titan pole is tight and secure, tighten the Locking Nut against the bottom of the Titan
pole Tube. Slide the Cover Tube down over the screw.
Additional Securing methods (Optional)
The Titan pole base can be xed permanently onto the oor with two fasteners (Not Supplied). This will provide a more
secure installation. This method should be used in any of the following conditions exist:
• If the Titan pole will be subject to heavy usage. Heavy usage is dened as when the Titan pole is used for
more than normal balance assistance for stability.
• The ceiling or oor is subject to exion or movement.
• The oor surface is smooth or polished making it easy for the Base to move or slip.
• There is a chance that the oor in the area where the Titan Pole is installed could get wet.
3
BOTTOM POLE TUBE
BASE
BOTTOM LOCKING NUT
STEP 3
STEP 2

www.SafetyGrip.com | Page 5
MAINTENANCE AND CLEANING
• The Titan pole can loosen with use. It should be checked weekly.
◊ Check that neither the Base nor the Ceiling Disc has moved and that the Pole is still perpendicular (90
degrees) to the oor.
◊ If necessary, repeat Step 4.
• To clean your Titan pole, simply wipe with a clean cloth and any commercially available cleaning solution.
LIMITED WARRANTY
Hartmobility Inc. product(s) are covered by a limited lifetime parts warranty. This warranty covers against defects
in design and workmanship. Hartmobility Inc. will correct any defects in parts or workmanship at no charge.
The warranty does not cover product failure due to installation error, owner misuse, abuse, negligence or normal
wear and tear.
For more information on what our Limited Lifetime Warranty covers and does not cover, please visit the
Hartmobility Inc. website at www.Hartmobility.com or scan the following QR Code.
