INSTRUCTIONS FOR USE
Shower chair with backrest – tool free
Product code: TGR-R KP 350L
1. Characteristics
Shower chair consists of aluminium frame, backrest and wide seat
which are made of durable PVC. The chair is equipped with height
adjustable legs with anti-sliding rubber tips, and integrated handles
which facilitate using the product. Specially designed rubber tips
prevent the chair from sliding on wet surfaces. The chair is additionally
supplied with Tool-Free (TF) system facilitating the assembly.
The set includes:
•backrest – 1 pc
•seat – 1 pc
•chair base – 2 pcs
•height adjustable legs – 4 pcs
•backrest tubes – 2 pcs
•mounting screws (wing screws) – 9 pcs
Elements of the shower chair:
a. backrest
b. backrest tubes
c. seat
d. base tubes
e. height adjustment – TF system
f. anti-sliding tips
2. Application
The shower chair is ancillary equipment which helps the user to
perform hygienic activities. The chair is recommended to people with
reduced mobility which prevents or hinders the unassisted

2
performance of daily living activities. The chair can be used in the
shower, in the bath, in bathrooms and other humid rooms at home and
in hospitals.
3. Assembly
Step 1. Place seat upside down on a flat surface.
Step 2. Fix crossed base tubes with seat in the middle using one wing
screw with washer.
Step 3. Join base tubes with legs.
Step 4. Screw backrest tubes to base tubes using four wing screws with
washers.
Step 5. Place assembled shower chair on the legs and tighten the
backrest using four wing screws with washers.
HEIGHT ADJUSTMENT
•To adjust the height of the shower chair, press metal pin, select
appropriate height of the leg, and lock the position of the tubes
relative to each other with the use of metal pin. The legs are
adjustable in 2.5 cm increments.
Note! The pins must be set on the same level in each leg.
4. Technical data
Width 49 cm
Depth 44 cm
Seat height 36-46 cm
Overall height 64-74 cm
Seat dimensions 49 x 29 cm
Weight 3 kg
Maximum capacity 100 kg

3
5. Notes
Timago International Group does not bear responsibility of improper
use of the shower chair, failure to comply safety regulations and
misuse.
6. Maintenance
•Clean the shower chair regularly using only water, sponge and
mild detergents for plastic materials such as soap. Dry thoroughly.
•Do not use for cleaning: strong detergents, abrasive agents,
bleach, petrol or solvents (it may cause frame damage, visible
defects and in consequence - loss of warranty rights).
•At least once every three months check:
-tightening of wing screws
-condition of locking pins
-condition of tubes (if cracks)
It is recommended to check rubber tips regularly. In case of worn-
out, replace the tips with the new ones.
7. Storage and transport conditions
Device should not be exposed to direct sunlight, water or moisture.
8. Warranty information
All products distributed by our company are covered by a warranty, the
terms of which are described in the warranty card available on our
website. Please contact the retailer from whom you purchased the
product. Please, keep in mind that for warranty purposes, the proof of
purchase (receipt or invoice) should be retained
9. Labels
Reference
number
Manufacturer
LOT number Manufacture date

4
Serial number Medical device
Note
Please read the
instruction
The manufacturer checked for compliance with
essential medical devices requirements.
Our complete line of products is available from our distributors.
Learn more at: www.timago.com. Thank you for choosing Timago!
Timago International Group
Spółka z o.o. i Spółka – Spółka komandytowa
ul. Karpacka 24/12
43-316 Bielsko-Biała, Polska
T.: [phone]
F.: [phone]
E.: [e-mail]
Rev. II, date 20.05.2021
