EasyStand Evolv PNG50162-1 User manual

262 West 1st St.
Morton, MN 56270 USA
Toll Free: 800.342.8968 or 507.697.6393
Fax Free: 877.342.8968 or 507.697.6900
email: [email protected]
easystand.com
Please ensure the Assembly Manual stays with the unit at all times.
Standing technology should only be used under the guidance of a physician with recommendations for standing program protocol and any
medical precautions. Standing programs should be monitored by the attending therapist. AMI maintains a policy of continual product
improvement and reserves the right to change features, specications, and prices without prior notication. Check with AMI for latest info.
FORM EVOLVASSEMMAN 012623 REV A Copyright © 2023 Altimate Medical, Inc. All rights reserved. Printed in the U.S.A.
Assembly Manual
Assembly Manual
PNG50162-1 Medium, PNG50084-1 Large & PNG50209-1 XT
®
Medical Product Service GmbH
Borngasse 20
35619 Braunfels
Deutschland
MPS Medical Product Service UK Ltd
Northgate House
Northgate Street
Devizes
Wiltshire England SN10 1JX
MPS Medical Product Service Switzerland, CO/Accumed Sagl
Morbio Inferiore
Viale Serfontana 10
CH-6834 Switzerland
EC REP
UK REP
EC REP
UK REP
EC REP
UK REP

SYMBOL/LABEL LEGEND
CAUTION/WARNING/ATTENTION
PINCHPOINT
SERIAL NUMBER
SN
TEMPERATURE
DATE OF MANUFACTURE
Waste of electrical and electronic equipment must not be disposed as unsorted municipal waste. It must be
collected separately, and must be disposed as per local regulations. Contact your authorized representative
for information concerning the decommissioning of your equipment.
SEE INSTRUCTIONS FOR USE
TYPE BF APPLIED PART
MANUFACTURER
HUMIDITY ATMOSPHERIC PRESSURE
MEDICAL DEVICE
CONFORMITÈ EUROPËENNE PRESCRIPTION ONLY
POTENTIALLY HOT SURFACE
Accessible surfaces which may
exceed 105˚F/41˚C and could be a
hazard to persons with skin damage
or not having sensation.
CERTIFICATION LABEL/UNIQUE DEVICE IDENTIFICATION LABEL
Serial Number
Item Number
Item Description
Unique Identier
24

Table of Contents
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Options & Parts Detail ...........................21
Date Purchased Serial #
Contact Altimate Medical for any information required prior to purchase. This owner’s manual along
with other information is freely available by request or by downloading from easystand.com.
Note: The serial number is located
under the seat on the seat column.
23
Evolv Options & Parts Detail (rear)
®

EasyStand Evolv Assembly
®®
Videos of EasyStand Evolv assembly & tting can be viewed at
www.easystand.com/videos
FIG. 3B
FIG. 2A
FIG. 1 FIG. 3A
FIG. 2B
Front Frame
Seat Assembly
1 22

FIG. 2A
For Mobile assembly refer to p. 9.
If the Evolv XT was ordered, the unit will be fully
assembled except for the tray and back option. Refer to p.
11 for the back option assembly, p. 16 for the tray
assembly and p. 7 for the Shadow Tray. For any other
option assembly, please refer to pp. 11-19.
FIG. 1- Attach the standard front wheel frame to the front
frame with bolts and tighten securely.
FIG. 2A- Remove nut and at washer from the bolt on the
caster. A at washer will remain on the bolt on the caster. Place
caster, bolt, and at washer into rear caster frame as shown.
Place second at washer that was removed onto the bolt.
Place nut onto bolt and tighten securely with wrench and hex
wrench provided in the tool kit. Repeat steps for other caster.
Ensure the casters are ush with the rear base frame.
FIG. 2B- Place the front frame and the seat assembly on it’s
side, slide the front frame into the opening of the seat
assembly as shown. Line up holes and insert all four bolts
rst, then place nuts onto bolts and tighten securely with hex
wrench and 19mm open-ended wrench. Place unit upright on
its wheels.
If the Swing-Away Front option was ordered, slide the front
frame into the opening of the seat assembly as shown on p. 5,
FIG. 7. To help with installation, place folded cardboard or a
block of wood underneath the frame for support. Start the four
bolts by going in a criss-cross pattern (ex: Start back left bolt
then front right bolt followed by back right and front left bolts).
Start all four bolts rst, then tighten securely.
For more Swing-Away Front assembly, refer to p. 5.
FIG. 2C- To ip foot plates down, lift the seat up. Then
insert ratchet handles, (located in bag with assembly manual)
tighten securely.
FIG. 3A- Attach the pump handle to the pump on the seat
assembly with bolts and nuts, tighten securely.
FIG. 3B- Insert top of handle into pump handle and tighten
bolts securely.
Nut
Flat Washer
Caster Frame
Bolt
21 2
Evolv Options & Parts Detail (front)
®
FIG. 3A
FIG. 2C
Flat Washer

FIG. 6
FIG. 4
FIG. 5
3 20
Pow’r Up Lift Hand Pendent Assembly
Evolv Medium/Large-PNG50010
Evolv XT-PNG50321
Place hand pendent assembly onto unit and line up bracket with holes on unit. Place lock
washers onto bolts. Insert bolts into holes on the unit and tighten securely.

FIG. 5
FIG. 4
Spacer
If the Swing-Away Frame was ordered, please refer to pp. 5-6.
If the Independent Kneepads were ordered refer to p. 18.
FIG. 4- Remove ratchet handle and hardware from the knee
bracket. Place the bracket and hardware onto the column in
the order shown. Ensure the spacer is placed between the
two steel brackets. Place the washer and bracket bolt into the
bracket assembly. Tighten the bolt leaving it just loose enough
for the knee bracket to slide freely. Do NOT overtighten bolt.
Insert hex bolt into clamp. Place the washer and ratchet handle
into the bracket assembly, screw ratchet handle onto hex bolt.
Tighten ratchet handle once desired position is reached.
Remove the three bolts from the kneepad making sure the
plastic insert stays in place. Place the kneepad onto the
bracket and insert top two bolts before inserting the middle
bolt. Tighten securely. If the independent kneepads were or-
dered, place pads into knee bracket, the narrow end of the
slotted washer for the knee pads will be inserted into the
bracket, make sure the larger end of the pad is on the
outside of the unit (see drawing on p. 18).
If the Shadow Tray Frame was ordered, please refer to pp. 7-8.
FIG. 4/5- Insert the tray post into the front column with the
holes in the post facing upward. The tray clamp on the front
frame may need to be adjusted to t the tray post into the
frame. Place tray onto the tray post, insert nut into slot and bolt
into hole, tighten securely.
If any additional options were ordered, please refer to the draw-
ings on pp. 11-19.
FIG. 6- Install the seat onto the seat assembly after all other
options are added. For easier installation, pump the seat
halfway up. Start all four bolts rst, then tighten securely.
For Evolv adjustments, see the Instructions for Use
Manual.
Hip Supports
Evolv Medium
PNG50161 9"-15"
PNG50198 11"-17"
Evolv Large/XT
PNG50161 10"-15"
PNG50198 12"-17"
Slide hip supports onto notch and
knob under seat. Tighten knob
securely.
If adding hip supports o-unit, remove
hole covers from top and bottom of the
seat frame.
Install the seat onto the
seat assembly after all the
other options are added.
Tighten the bolts securely.
Roho®Seat
Evolv Medium-PNG30183
Evolv Large/XT-PNG30023
Rotating Seat
Evolv Medium-PNG50324
Evolv Large/XT-PNG50318
Transfer Seat
Evolv Medium-PNG30269
Evolv Large/XT-PNG30270
Push the lever under the seat to
rotate. Ensure seat is locked into
position prior to transferring.
19 4

Swing-Away Frame Assembly
FIG. 7
FIG. 9
FIG. 8
Tray Frame
H-Frame
Front Wheel Frame
Tray
Kneepad
Bracket
FIG. 8
FIG. 7
Swing-Away Frame
for Shadow Tray
Crossbar
Tube Insert
Lateral Supports
with Curved Pads
11”-19.5”W
PNG50176
Lateral Supports
with Flat Pads
11”-19.5”W
PNG50536
Independent
Knee Pads PNG50384
Independent Roho®
Knee Pads PNG50385
Remove ratchet handle and hardware from the knee bracket. Place onto the column in the order as
shown. Make sure spacer is placed between the two steel brackets. Leave the bolt just loose enough to
allow bracket to slide freely. Note the position of the grey brackets, the curve must go up. The narrow
end of the slotted washer for the knee pads will be inserted into the bracket.
Swing-Away Front
Independent Knees PNG50425
Curve Up
Lateral Supports
with Curved Pads
8”-16.5”W
PNG50224
Lateral Supports
with Flat Pads
8”-16.5”W
PNG50535
Slide each lateral support onto notch
and knob on the accessories mounting
bracket. Tighten knobs securely.
Slotted Washers
5 18

FIG. 7- Insert the H-frame into the front wheel frame. Insert
pins into the holes provided (crossbar should face seat). Make
sure the tube insert is in place as shown.
If the Front Swivel Casters were ordered refer to p. 17.
If the Independent Kneepads were ordered refer to p. 18.
FIG. 8- Place the knee pad bracket onto the H-frame. Remove
the three bolts from the knee pad making sure the plastic insert
stays in place. Place the knee pad onto the bracket and insert
the top two bolts before inserting the middle bolt. Tighten se-
curely.
To use the Swing-Away Front:
To swing away the front for transferring, remove pull pins from
the bottom of the H-frame. Lift collar and swing away. After
positioning client in stander, swing front back into front caster
frame and replace pins, making sure the collar is secure.
Caution: Collar and pins must be securely in place before the
user transitions into the standing position.
For Evolv adjustments, see the Instruction for Use Manual.
If the Shadow Tray was ordered, skip to p. 7.
FIG. 9- Insert the tray frame into the H-frame, tighten knobs
securely. Place the tray onto the tray frame, install knobs.
Tighten nuts securely.
Note: Tray will not move if nuts are overtightened.
FIG. 8
FIG. 9
Front Swivel Casters for
Column Fronts
Evolv Medium/Large-PNG51052/ PNG51053
Evolv XT-PNG51056/ PNG51057
FIG. A- Place a block of wood under the unit to
raise the caster frame to line up caster brackets
to frame. Place hardware onto the unit as shown-
bolt, washer, frame, spacer, caster assembly,
washer, then nut.
FIG. B- It is important to ensure the brackets are
assembled as shown, with the angular portion of
the bracket pointing outward and away from each
other. Tighten securely.
Evolv Medium/Large-PNG51044R/PNG51044L
Evolv Medium/Large-PNG51048R/PNG51048L
Front Swivel Casters for
Swing-Away Fronts
FIG. B
FIG. A
17 6

Shadow Tray Assembly
®
These assembly instructions are shown for the right side mounted Shadow Tray, for the left side
mounted Shadow Tray, installation will be on the opposite side.
Required Tools:
-13mm open end wrench -Hex Wrench
Mobile Frame
Narrow Clear Angle
Adjustable Tray for Mobile
PNG50327-1
Place tray onto the tray post, insert nut into
slot and bolt into hole, tighten securely.
NOTE: Raise the Angle Tray by pulling up on the front of the tray and it will lock into
position, to lower the tray, angle the tray all the way up and the mechanism will be-
come free to lower the tray.
Column Frame
Black Molded Angle
Adjustable Tray
PNG50368-1
Column Frame
Angle Adjustable Clear Tray
PNG50366-1
Swing-Away Frame
Black Molded Angle
Adjustable Tray
PNG50490-1
Swing-Away Frame
Clear Angle
Adjustable Tray
PNG50489-1
Swing-Away Front
Oversized Angle
Adjustable
Clear Tray
PNG50491-1
7 16
1. Remove nut and lock
washer from the bolt on the
support arm
2. Insert bolt and support arm
onto unit as shown, making
sure notch is in the groove on
the support arm.
3. Start the bolt by hand.
4. Place lock washer and nut
onto bolt. Using a hex tool and
wrench tighten securely.
5. Place the tray bracket on
the unit as shown. Insert one
bolt and hand tighten.
6. Insert second bolt and tighten
both bolts securely.

10. Place washer onto bolt. 11. Place nut onto bolt. 12. Using hex wrench and 13mm
wrench tighten securely.
X-Style Chest Vest
PNG30170 11"L-9.5"W
PNG30056 14.5"L-10.5"W
Large Contoured
Chest Pad
PNG30000
Column Frame
Oversized Tray
PNG50194-1
Padded Tray Cover
PNG30295
Chest Strap
PNG50192 30"-46"
PNG50193 34"-54"
PNG50504 46"-66"
Remove bolts from chest
pad and place onto tray.
Tighten bolts securely.
Y-Style Chest Vest
PNG30171 17.5"L-11.5"W
PNG30021 20.5"L-12.5"W
Non-Stretch Y-Style Chest Vest
PNG30320 17.5"Lx11.5"W
PNG30324 20.5"Lx12.5"W
Non-Stretch X-Style Chest Vest
PNG30318 11"Lx9.5"W
PNG30322 14.5"Lx10.5"W
7. Place the cloth protection
sleeve on the tray bracket as
shown.
8. Insert tray tube into the tray
bracket.
9. Insert bolt into desired hole.
Note: You may need assis-
tance lining up the hole from a
partner.
15 8
10. Place black protective cap
onto nut. Pull the cloth protection
sleeve on the tray tube.
Your Shadow Tray is now completed.
Please refer to the Instructions For Use
manual for adjustments and usage.

FIG. 19
Mobile Assembly
FIG. 18
FIG. 20
Mobile
Assembly
Mobile
Bracket
Mobile
Bracket
Knee Pad
Bracket
Wheel Frame
FIG. 21
FIG. 22
Airline Buckle Hip
Belt
PNG30028 26"-55"
Velcro Hip Belt
PNG30029 26"-55"
PNG30306 38"-67"
High Mount Chest
Vest Bracket
PNG11212
High Mount Chest Vest Bracket
with Head Support
PNG11212
If you ordered the high
mount chest vest bracket
and head support, place
the head support bracket
and the high mount chest
vest bracket on the unit
as shown. Insert 4 bolts
and nuts and tighten se-
curely. See p.12 for head
support assembly.
9 14
Nut
Flat Washer
Caster Frame
Bolt
Flat Washer

FIG. 18- Place the front frame onto the wheel frame. Line up
the two bolts with the holes on the wheel frame, start both
bolts before tightening securely.
FIG. 19- Remove nut and at washer from the bolt on the
caster. A at washer will remain on the bolt on the caster. Place
caster, bolt, and at washer into rear caster frame as shown.
Place second at washer that was removed onto the bolt.
Place nut onto bolt and tighten securely with wrench and hex
wrench provided in the tool kit. Repeat steps for other caster.
Ensure the casters are ush with the rear base frame.
FIG. 20- Place the front frame and the seat assembly on its
side, slide the front frame into the opening of the seat
assembly as shown. Line up holes and insert all four bolts
rst, then place nuts onto bolts and tighten securely with hex
wrench and 19mm open-ended wrench. Place unit upright.
FIG. 21- Place the left-side mobile assembly onto the wheel
frame. Line up holes and insert top bolt through the inside as
shown. Place the nut onto the bolt and hand tighten. Line up
holes and insert bottom bolt through the outside, as shown.
Hand tighten the nut onto the bolt, then tighten both bolts se-
curely with a 19mm wrench and hex wrench. Repeat on the
opposite side before continuing to the next step.
FIG. 22- Place mobile bracket onto the kneepad bracket. Place
kneepad onto the mobile bracket. Insert three bolts into the
back of the kneepad. Tighten bolts securely. Remove bolts
from mobile bracket. Flip down kneepad and align bracket on
mobile assembly. Tighten bolts and nuts securely with 13mm
wrench and hex wrench. Repeat steps on the opposite side
before continuing to the next step.
Lift seat up and ip foot plates down. Then insert ratchet
handles into foot plates. Tighten securely.
FIG. 23- The Mobile is equipped with wheel locks for safety
while transferring and stability while performing stationary
activities. Note the directional arrows imprinted in the center
hub of each handrim.
To assemble the tray and seat, go to p. 4, FIG. 5.
Wheel
Locks
Front Frame
Wheel Frame
FIG. 18
FIG. 21
FIG. 22
FIG. 23
A
B
CDE
A
Standard
Actuator
Left Handle
PNG50126
B
Standard
Actuator
Right Handle
PNG50059
C
Adjustable/
Removable Handle
Universal Left/Right
PNG50328
D
T-Style
Handle
Extension
PNG50070
Remove the nuts and bolts from the pump handle. Insert the handle onto the
pump. Line up holes and insert bolts, place nuts onto bolts. Tighten securely.
E
Quad Grip
Handle
Extension
PNG50044
13 10

Removable Back Option
PNG50171, PNG50172,
PNG50173, PNG50174
To attach the Removable Back to the
unit, slide the back assembly into the
seat assembly as shown. Insert
hardware into back tubes with tabs
facing upward and toward the back.
Tighten securely with knobs provided.
NOTE: Make sure
hardware is placed
into back as shown.
Back Option
PNG50062, PNG50066,
PNG50067, PNG50068
To assemble the back option, remove the
2 bolts from the back, slide the back as-
sembly into the seat assembly as shown.
Tighten securely with bolts provided, then
add the swing-away arms. Remove the nut
and lock washer from the arm. Place the
arm onto the unit keeping the arm assem-
bly together. Place nut and lock washer
onto bolt on the inside of the unit. Tighten
securely to desired level of tension.
Option Assembly
Secure Foot
Straps
PNG30031-15"L
PNG50506-21"L
Standard Foot
Straps
PNG30030-15"L
PNG50505-21"L
If you ordered the high mount chest vest bracket see p. 14.
FIG A- Place head support bracket onto accessories mounting bracket as shown. Insert 4 bolts
and nuts and tighten securely.
FIG B- Insert the head support onto the unit and tighten securely.
FIG B
FIG A
Head Support-Short
21"-30"H
PNG50240
Head Support-Tall
25"-34"H
PNG50037
11 12

Removable Back Option
PNG50171, PNG50172,
PNG50173, PNG50174
To attach the Removable Back to the
unit, slide the back assembly into the
seat assembly as shown. Insert
hardware into back tubes with tabs
facing upward and toward the back.
Tighten securely with knobs provided.
NOTE: Make sure
hardware is placed
into back as shown.
Back Option
PNG50062, PNG50066,
PNG50067, PNG50068
To assemble the back option, remove the
2 bolts from the back, slide the back as-
sembly into the seat assembly as shown.
Tighten securely with bolts provided, then
add the swing-away arms. Remove the nut
and lock washer from the arm. Place the
arm onto the unit keeping the arm assem-
bly together. Place nut and lock washer
onto bolt on the inside of the unit. Tighten
securely to desired level of tension.
Option Assembly
Secure Foot
Straps
PNG30031-15"L
PNG50506-21"L
Standard Foot
Straps
PNG30030-15"L
PNG50505-21"L
If you ordered the high mount chest vest bracket see p. 14.
FIG A- Place head support bracket onto accessories mounting bracket as shown. Insert 4 bolts
and nuts and tighten securely.
FIG B- Insert the head support onto the unit and tighten securely.
FIG B
FIG A
Head Support-Short
21"-30"H
PNG50240
Head Support-Tall
25"-34"H
PNG50037
11 12

FIG. 18- Place the front frame onto the wheel frame. Line up
the two bolts with the holes on the wheel frame, start both
bolts before tightening securely.
FIG. 19- Remove nut and at washer from the bolt on the
caster. A at washer will remain on the bolt on the caster. Place
caster, bolt, and at washer into rear caster frame as shown.
Place second at washer that was removed onto the bolt.
Place nut onto bolt and tighten securely with wrench and hex
wrench provided in the tool kit. Repeat steps for other caster.
Ensure the casters are ush with the rear base frame.
FIG. 20- Place the front frame and the seat assembly on its
side, slide the front frame into the opening of the seat
assembly as shown. Line up holes and insert all four bolts
rst, then place nuts onto bolts and tighten securely with hex
wrench and 19mm open-ended wrench. Place unit upright.
FIG. 21- Place the left-side mobile assembly onto the wheel
frame. Line up holes and insert top bolt through the inside as
shown. Place the nut onto the bolt and hand tighten. Line up
holes and insert bottom bolt through the outside, as shown.
Hand tighten the nut onto the bolt, then tighten both bolts se-
curely with a 19mm wrench and hex wrench. Repeat on the
opposite side before continuing to the next step.
FIG. 22- Place mobile bracket onto the kneepad bracket. Place
kneepad onto the mobile bracket. Insert three bolts into the
back of the kneepad. Tighten bolts securely. Remove bolts
from mobile bracket. Flip down kneepad and align bracket on
mobile assembly. Tighten bolts and nuts securely with 13mm
wrench and hex wrench. Repeat steps on the opposite side
before continuing to the next step.
Lift seat up and ip foot plates down. Then insert ratchet
handles into foot plates. Tighten securely.
FIG. 23- The Mobile is equipped with wheel locks for safety
while transferring and stability while performing stationary
activities. Note the directional arrows imprinted in the center
hub of each handrim.
To assemble the tray and seat, go to p. 4, FIG. 5.
Wheel
Locks
Front Frame
Wheel Frame
FIG. 18
FIG. 21
FIG. 22
FIG. 23
A
B
CDE
A
Standard
Actuator
Left Handle
PNG50126
B
Standard
Actuator
Right Handle
PNG50059
C
Adjustable/
Removable Handle
Universal Left/Right
PNG50328
D
T-Style
Handle
Extension
PNG50070
Remove the nuts and bolts from the pump handle. Insert the handle onto the
pump. Line up holes and insert bolts, place nuts onto bolts. Tighten securely.
E
Quad Grip
Handle
Extension
PNG50044
13 10

FIG. 19
Mobile Assembly
FIG. 18
FIG. 20
Mobile
Assembly
Mobile
Bracket
Mobile
Bracket
Knee Pad
Bracket
Wheel Frame
FIG. 21
FIG. 22
Airline Buckle Hip
Belt
PNG30028 26"-55"
Velcro Hip Belt
PNG30029 26"-55"
PNG30306 38"-67"
High Mount Chest
Vest Bracket
PNG11212
High Mount Chest Vest Bracket
with Head Support
PNG11212
If you ordered the high
mount chest vest bracket
and head support, place
the head support bracket
and the high mount chest
vest bracket on the unit
as shown. Insert 4 bolts
and nuts and tighten se-
curely. See p.12 for head
support assembly.
9 14
Nut
Flat Washer
Caster Frame
Bolt
Flat Washer

10. Place washer onto bolt. 11. Place nut onto bolt. 12. Using hex wrench and 13mm
wrench tighten securely.
X-Style Chest Vest
PNG30170 11"L-9.5"W
PNG30056 14.5"L-10.5"W
Large Contoured
Chest Pad
PNG30000
Column Frame
Oversized Tray
PNG50194-1
Padded Tray Cover
PNG30295
Chest Strap
PNG50192 30"-46"
PNG50193 34"-54"
PNG50504 46"-66"
Remove bolts from chest
pad and place onto tray.
Tighten bolts securely.
Y-Style Chest Vest
PNG30171 17.5"L-11.5"W
PNG30021 20.5"L-12.5"W
Non-Stretch Y-Style Chest Vest
PNG30320 17.5"Lx11.5"W
PNG30324 20.5"Lx12.5"W
Non-Stretch X-Style Chest Vest
PNG30318 11"Lx9.5"W
PNG30322 14.5"Lx10.5"W
7. Place the cloth protection
sleeve on the tray bracket as
shown.
8. Insert tray tube into the tray
bracket.
9. Insert bolt into desired hole.
Note: You may need assis-
tance lining up the hole from a
partner.
15 8
10. Place black protective cap
onto nut. Pull the cloth protection
sleeve on the tray tube.
Your Shadow Tray is now completed.
Please refer to the Instructions For Use
manual for adjustments and usage.

Shadow Tray Assembly
®
These assembly instructions are shown for the right side mounted Shadow Tray, for the left side
mounted Shadow Tray, installation will be on the opposite side.
Required Tools:
-13mm open end wrench -Hex Wrench
Mobile Frame
Narrow Clear Angle
Adjustable Tray for Mobile
PNG50327-1
Place tray onto the tray post, insert nut into
slot and bolt into hole, tighten securely.
NOTE: Raise the Angle Tray by pulling up on the front of the tray and it will lock into
position, to lower the tray, angle the tray all the way up and the mechanism will be-
come free to lower the tray.
Column Frame
Black Molded Angle
Adjustable Tray
PNG50368-1
Column Frame
Angle Adjustable Clear Tray
PNG50366-1
Swing-Away Frame
Black Molded Angle
Adjustable Tray
PNG50490-1
Swing-Away Frame
Clear Angle
Adjustable Tray
PNG50489-1
Swing-Away Front
Oversized Angle
Adjustable
Clear Tray
PNG50491-1
7 16
1. Remove nut and lock
washer from the bolt on the
support arm
2. Insert bolt and support arm
onto unit as shown, making
sure notch is in the groove on
the support arm.
3. Start the bolt by hand.
4. Place lock washer and nut
onto bolt. Using a hex tool and
wrench tighten securely.
5. Place the tray bracket on
the unit as shown. Insert one
bolt and hand tighten.
6. Insert second bolt and tighten
both bolts securely.

FIG. 7- Insert the H-frame into the front wheel frame. Insert
pins into the holes provided (crossbar should face seat). Make
sure the tube insert is in place as shown.
If the Front Swivel Casters were ordered refer to p. 17.
If the Independent Kneepads were ordered refer to p. 18.
FIG. 8- Place the knee pad bracket onto the H-frame. Remove
the three bolts from the knee pad making sure the plastic insert
stays in place. Place the knee pad onto the bracket and insert
the top two bolts before inserting the middle bolt. Tighten se-
curely.
To use the Swing-Away Front:
To swing away the front for transferring, remove pull pins from
the bottom of the H-frame. Lift collar and swing away. After
positioning client in stander, swing front back into front caster
frame and replace pins, making sure the collar is secure.
Caution: Collar and pins must be securely in place before the
user transitions into the standing position.
For Evolv adjustments, see the Instruction for Use Manual.
If the Shadow Tray was ordered, skip to p. 7.
FIG. 9- Insert the tray frame into the H-frame, tighten knobs
securely. Place the tray onto the tray frame, install knobs.
Tighten nuts securely.
Note: Tray will not move if nuts are overtightened.
FIG. 8
FIG. 9
Front Swivel Casters for
Column Fronts
Evolv Medium/Large-PNG51052/ PNG51053
Evolv XT-PNG51056/ PNG51057
FIG. A- Place a block of wood under the unit to
raise the caster frame to line up caster brackets
to frame. Place hardware onto the unit as shown-
bolt, washer, frame, spacer, caster assembly,
washer, then nut.
FIG. B- It is important to ensure the brackets are
assembled as shown, with the angular portion of
the bracket pointing outward and away from each
other. Tighten securely.
Evolv Medium/Large-PNG51044R/PNG51044L
Evolv Medium/Large-PNG51048R/PNG51048L
Front Swivel Casters for
Swing-Away Fronts
FIG. B
FIG. A
17 6
