Harvest TEC 453 Service manual

INSTALLATION AND OPERATION INSTRUCTION MANUAL
MODEL 453 FLOW METER
INTRODUCTION
The model 453 flow meter is designed to be installed with the Harvest Tec hay preservative
applicators designed to apply acid based preservatives using 1/2 I.D. hose. The flow meter is
accurate in applications from 40 to 400 pounds per hour (.1 to 1.5 gallons per minute).
INSTALLATION:
1. MOUNTING THE FLOW METER
A. Place flow meter in line as far away from the pump as possible.
B. Make sure the arrow on sensor box is in the same direction as the flow of product.
C. Keep flow meter as low as possible to eliminate air bubbles.
D. Remove filter bowl and cover. Mark two holes from the backside of meter housing to baler
frame.
E. Drill two 3/16 holes and secure with two 1/4 self-tapping screws provided.
F. Re-install cover and filter bowl.
G. Do not replace the fittings on the flow meter with metal, for it will interfere with the meters
accuracy.
2. PLUMBING
A. Cut into preservative line next to flow meter’s inlet if installing on a used applicator, or run a
line from the pump to the flow meter on a new applicator.
B. Connect inlet hose to pump side of the flow meter. Be sure that fluid is flowing in the same
direction as the arrow on the meter.
C. Connect outlet side of meter to hose running towards tips.
D. Secure with hose clamps provided.
3. CONTROL
A. Mount display box on tractor and hook up to a 12 volt source. Make sure to hook the positive,
the green lead, to the hot terminal on the starter or battery and the black wire to an appropriate
ground. Check with a volt meter before installation. REVERSING THE POLARITY WILL
CAUSE DAMAGE TO CONTROL BOX!
B. Run wires to baler and keep away from any moving or hot areas.
OPERATION:
1. RATE PER HOUR
Press the select button “SEL” on the display until the letter R appears on the left side of the
display. The number displayed on the right of the display represents pounds per hour. Use this
display to monitor your rate of flow.
Example:
Baling rate
- 10 ton per hour
Multiply by desired application rate
- 10 lb per ton
Display read-out in lbs per hour
- R 100

2. ACCUMULATED POUNDS:
Press the select button “SEL” on the display until the left side of the display is blank. The number
displayed to the right of the display represents total pounds used. This number will increase as
product is used.
Example:
Make 4 round bales at 1000 pounds each
- 2 tons
Multiple by desired application rate
- 10 lb per ton
Display read out in total lbs. Used
- 20.0
3. RESETTING METER
Press the reset button “RST”only if you want to zero out your accumulated pounds. The reset
button will work in either pounds per hour or accumulated pounds screen so make sure you record
that number before you press “RST”.
MAINTENANCE
A. Keep flow meter clean.
B. Clean filter bowl after 10 hours of use.
TROUBLE SHOOTING:
Problem:
Possible Cause:
Solution:
1. Meter reading is inaccurate
1. Plugged filter on meter
1. Clean
2. Meter is not in low spot, air
bubbles are forming in meter.
2. Move meter to low spot in
line.
3. Screen is plugged
3. Back flush with water, do not
use air.
4. Meter is not receiving a full
12 volts.
4. Check with volt meter for
under voltage problems.
2. Display shows dull
background with no numbers
1. Positive and negative wires
are reversed.
1. Have new display put into
cab control box.

MODEL 453 FLOW METER
Ref
Description
Part#
Qty
Ref
Description
Part#
Qty
1
Cub 5 meter
006-2023
1
12
Nipple fitting
003-M1212
1
2
15 amp rocker switch
006-2198
1
13
Filter bowl assembly
002-4315
1
3
Flow meter box base
001-2014A
1
14
Filter bowl only
002-4315F
1
4
Flow meter box cover
001-2014B
1
15
Screen –200 mesh
002-4315E
1
5
Power lead with fuse
006-4723
1
16
Gasket
002-4315D
1
6
8’ lead to box
006-4726C
1
17
3/8” Hose
002-9003
1ft
7
16’ jumper cable
006-4726B
1
18
Hose clamp
003-9003
4
8
Flow sensor holder
001-2013A
1
19
Flow meter
006-4726A
1
9
Flow sensor cover
001-2013B
1
20
Straight fitting
003-A1212F
1
10
Straight fitting
003-A1212
3
21
Hose clamp
003-9004
1
11
Ball valve
002-2212
1
*Purchase common hardware locally
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
18

Harvest Tec, LLC. Warranty and Liability Agreement.
Harvest Tec, LLC. will repair or replace components that are found to be defective within 12 months
from the date of manufacture. Under no circumstances does this warranty cover any components
which in the opinion of Harvest Tec, LLC. have been subjected to negligent use, misuse, alteration,
accident, or if repairs have been made with parts other than those manufactured and obtainable from
Harvest Tec, LLC.
Our obligation under this warranty is limited to repairing or replacing free of charge to the original
purchaser any part that in our judgment shows evidence of defective or improper workmanship,
provided the part is returned to Harvest Tec, LLC. within 30 days of the failure. Parts must be
returned through the selling dealer and distributor, transportation charges prepaid.
This warranty shall not be interpreted to render Harvest Tec, LLC. liable for injury or damages of any
kind, direct, consequential, or contingent, to persons or property. Furthermore, this warranty does not
extend to loss of crop, losses caused by delays or any expense prospective profits or for any other
reason. Harvest Tec, LLC. shall not be liable for any recovery greater in amount than the cost or
repair of defects in workmanship.
There are no warranties, either expressed or implied, of merchantability or fitness for particular
purpose intended or fitness for any other reason.
This warranty cannot guarantee that existing conditions beyond the control of Harvest Tec, LLC. will
not affect our ability to obtain materials or manufacture necessary replacement parts.
Harvest Tec, LLC. reserves the right to make design changes, improve design, or change
specifications, at any time without any contingent obligation to purchasers of machines and parts
previously sold.
Revised 6/22
