Harvil AH1010 User manual

1
AH1010
Assembly Instructions
Model AH1010
Model AH1010

1
AH1010
Harvil Action Game Tables
We work around the clock and around the globe to ensure that
Harvil products maintain the highest possible quality. However,
in the rare instance that your product is defective or missing parts,
PLEASE DO NOT RETURN TO THE STORE
, and contact us through one
of the following methods:
Toll Free: 866-507-3861
Email: [email protected]
Web: www.harvil.com
Mail: Harvil Products
Customer Service Department
555 4th St.
San Fernando, CA 91340
Please have your model number and part number available for
Customer Service Representatives prior to calling. These numbers
are available on the product packaging as well as in this owner’s
manual.
IMPORTANT! PLEASE READ THIS MANUAL IN ITS ENTIRETY BEFORE
ASSEMBLING YOUR GAME.

2
AH1010
TOOLS REQUIRED:
Allen Key –
Included
Phillips Screwdriver -
Not Included
Electric Screwdrivers may be helpful during assembly; however, please
set a low torque and use extreme caution because screws may be
stripped or overtightened if the electric screwdriver’s torque is set too
high.
ASSEMBLY TIPS:
1-
When installing parts that have more than one bolt, hand
tighten all bolts before tightening individual bolts with a
screwdriver or allen key.
2-
Some fi gures or drawings may not look exactly like your
product. Please read and understand the text before
beginning each assembly step.
WARNINGS!
READ AND FOLLOW ALL ASSEMBLY, OPERATION, AND SAFETY
INSTRUCTIONS CAREFULLY. AT LEAST TWO ADULTS ARE NEEDED
FOR THE ASSEMBLY OF THIS TABLE.
CHOKE HAZARD - TABLE CONTAINS SMALL PUCKS AND/OR SMALL
PARTS. NOT FOR CHILDREN UNDER 3 YEARS OLD.

3
AH1010
PARTS IDENTIFIER (Not to Scale)
PARTS IDENTIFIER (Not to Scale)
ASSEMBLY INSTRUCTIONS
1. Find a clean, level place for the assembly of your Air Hockey Table.
The table will be assembled upside down and then turned over onto
its legs.
2. Remove all of the contents from the box and verify that you have
all of the listed parts shown on the Parts Identifi er.
NOTE:
Some parts
are pre-assembled. Carefully cut or tear the four carton corners so that
the bottom of the box can act as your work area.
#1
#1
#2
#2
#3
#3
#4
#4
#5
#6
#6
#7
#7
#8
#8
#9
#9
#10

4
AH1010
3. Using Bolt (
#3
) and Washer
(
#5
) attach the leg as shown in
Fig. 1
Fig. 1
.
Repeat this step for the remaining
3 legs.
4. Using Screw (
#4
) attach the
goal (
#6
) as shown in
Fig. 2
Fig. 2
.
Repeat this step for the remaining
goal.
5. Attach the Felt (
#8
) to the
bottom of the Hockey Striker (
#7
).
Congratulations!
You have now assembled your Air
Hockey Table.
FIG. 1
FIG. 2
FIG. 3

5
AH1010
