HARVIL INFERNO 20-IN-1 MULTI-GAME
TABLE ASSEMBLY INSTRUCTIONS

2
We work around the clock and around the globe to ensure that Harvil
products maintain the highest possible quality. However, in the rare
instance that your product is defective or missing parts, PLEASE DO
NOT RETURN IT TO THE STORE. Contact us through one of the
following methods:
Manufacturer
6700 Fallbrook Ave Ste 203A
West Hills, CA 91307
USA
Phone: [phone]
Fax: [phone]
www.harvil.com
Please have your model number and part number available for
Customer Service Representatives prior to calling. These numbers
are available in these assembly instructions.
IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS
IN ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.
CONTACT INFORMATION

PARTS IDENTIFIER (NOT TO SCALE)
3

PARTS IDENTIFIER (NOT TO SCALE)
4

PARTS IDENTIFIER (NOT TO SCALE)
5

ASSEMBLY TIPS
1. Find a clean, level surface to begin the assembly of your game table. The table will
be partially assembled upside down and then turned over onto its legs. This is a heavy
game and turning it over will require at least two strong adults.
2. Remove all of the contents from box and verify that you have all of the parts shown
on the Parts Identifier before you begin assembly. Note: Some parts may be pre-
installed or pre-assembled.
3. Some figures or drawings may not look exactly like your product. Please read and
understand the text before beginning each assembly step.
4. When installing parts that have more than one screw or bolt, hand tighten all screws
or bolts in place before finishing tightening with screwdriver or hex wrench.
5. Electric screwdrivers may be helpful during assembly; however, please set a low
torque and use extreme caution because screws may be stripped or overtightened if
the electric screwdriver's torque is set too high.
WARNINGS!
READ AND FOLLOW ALL ASSEMBLY, OPERATION AND SAFETY INSTRUCTIONS
CAREFULLY.
CHOKE HAZARD - THIS TABLE CONTAINS SMALL BALLS AND PARTS - NOT
SUITABLE FOR CHILDREN UNDER 3 YEARS OF AGE.
6

ASSEMBLY INSTRUCTIONS
1. To assemble SOCCER TABLE, insert pre-assembled AWAY PLAYER RODS #35,
36 and 37 and HOME PLAYER RODS #38, 39 and 40 into one SIDE PANEL #18 as
shown below. Note: You may choose either color for home or away teams.
2. Insert PLAYER RODS into remaining SIDE PANEL #18.
3. Slide SOCCER PLAYFIELD #19 with field markings facing down into the SIDE PAN-
EL grooves. Note: The table is assembled upside down.
7

ASSEMBLY INSTRUCTIONS (CONT.)
4. Attach one END PANEL #17 to each end of the table with 1-3/4" FLAT SCREW #6.
5. Attach one CORNER #21 to each corner of the table with 1-1/8" BOLT #2 and 5/16"
FLAT WASHER #5.
6. Attach each PLAYFIELD SUPPORT BRACE #20 underneath SOCCER PLAYFIELD
as shown by fastening to SIDE PANELS with 1-3/4" ROUND SCREW #1.
7. Carefully turn SOCCER TABLE over. Attach one MANUAL SCORER #31 to each
end of the table with 1" FLAT SCREW #8.
8. Attach one HAND GRIP #29 to the marked end of each PLAYER ROD. Attach ROD
END CAP #30 to the opposite end of PLAYER RODS. Note: SOCCER TABLE will be
placed on top of assembled BILLIARD TABLE. Follow instructions below to assemble
BILLIARD TABLE.
8

ASSEMBLY INSTRUCTIONS (CONT.)
9
9. To assemble BILLIARD TABLE, attach RIGHT LEGS #23 and LEFT LEGS #24 to
the corners of the BILLIARD TABLE BODY #22 as shown below using 1-1/8" BOLT #2
and 5/16" FLAT WASHER #5 or 1-1/2" WING BOLT #3. Note: 1-1/2" WING BOLT #3
is also used to assemble BASKETBALL GAME.
10. Attach one LEG PANEL #25 to each side of the table with 1" BOLT #15 and 1/4"
FLAT WASHER #16.
11. Thread one LEG LEVELER #9 onto each LEG. Carefully turn table over.

10
12. To play HOCKEY, place HOCKEY PLAYFIELD #32B into assembled BILLIARD
TABLE.
13. To play TABLE TENNIS, flip HOCKEY PLAYFIELD over. Place TABLE TENNIS
PLAYFIELD #32A into assembled BILLIARD TABLE. Insert one TABLE TENNIS NET
POST #53 into each side of the TENNIS TABLE PLAYFIELD at the center line. Attach
the TABLE TENNIS NET #52 to each POST.
ASSEMBLY INSTRUCTIONS (CONT.)

11
14. For other GAMES, place GAME BOARD #33 or BASEBALL/FOOTBALL PLAY-
FIELD #34 into assembled BILLIARD TABLE.
15. To assemble BASKETBALL GAME, attach LOWER BASKETBALL ARM #12 to the
back of BILLIARD TABLE with 1-1/2" WING BOLT #3. Note: 1-1/2" WING BOLT #3 is
already part of BILLIARD TABLE assembly.
16. Attach one UPPER BASKETBALL ARM #13 to each LOWER BASKETBALL ARM
and secure with 1/4" SCREW #14.
17. Attach BASKETBALL BACKBOARD #26 to UPPER BASKETBALL ARMS with
5/32" NUT & BOLT #10.
ASSEMBLY INSTRUCTIONS (CONT.)

12
18. Attach BASKETBALL RIM #27 to BASKETBALL BACKBOARD with 5/8" SCREW
#7.
19. Attach BASKETBALL SIDE NET #28 by securing to BASKETBALL ARMS as
shown with fastening strap. Attach BASKETBALL SIDE NET #28 to BILLIARD TABLE
BODY as shown with 3/4" WING BOLT #4.
ASSEMBLY INSTRUCTIONS (CONT.)

CONGRATULATIONS!
You have now assembled your Harvil Game Table.
Please note the Care and Use instructions below to
ensure years of trouble free use of your game table.
CARE AND USE
1. This product is intended for INDOOR use only.
2. Do NOT sit, climb or lean on the table.
3. Do NOT drag the table when moving it as this will damage the legs.
13

90 DAY LIMITED WARRANTY
This consumer warranty extends to the original consumer purchase of any HARVIL Product
(hereinafter referred to as the "Product").
WARRANTY DURATION: This Product is warranted to the original consumer purchase of a
period of 90 days from the original purchase.
WARRANTY PERFORMANCE: During the 90 day warranty period, HARVIL shall repair, or re-
place with a comparable model, the Product, or component thereof, which may prove defective
under normal use and proper care, and which our examination shall disclose to our satisfaction
to be thus defective.
A purchase receipt or other proof of date of purchase will be required before warranty service
is performed.
Attn: Warranty Dept
6700 Fallbrook Ave Ste 203A
West Hills, CA 91307
USA
Phone: [phone]
Fax: [phone]
Email: [email protected]
Other than shipping requirements no charge will be made for such repair or replacement of in-
warranty Products. HARVIL strongly recommends that the Product is insured for value prior to
shipping/mailing.
WARRANTY DISCLAIMERS: ANY IMPLIED WARRANTIES ARISING OUT OF THIS SALE,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE
ABOVE 90 DAY PERIOD. HARVIL SHALL NOT BE LIABLE FOR LOSS OF USE OF THE
PRODUCT OR OTHER CONSEQUENTIAL OR INCIDENTAL COSTS, EXPENSES OR DAM-
AGES INCURRED BY THE CONSUMER OF ANY OTHER USE.
Some states do not allow the exclusion or limitation of implied warranties or consequential or
incidental damages, so the above limitations or exclusions may not apply to you.
LEGAL REMEDIES: This warranty gives you specific legal rights and you may have other
rights which may vary from state to state
