Harvil NGD2515 User manual

HARVIL GALAXY POOL TABLE
ASSEMBLY INSTRUCTIONS
NGD2515/NGD2520

2
Thank you for your purchase of this Harvil product.
We work around the clock and around the globe to ensure that Harvil
products maintain the highest possible quality. However, in the rare
instance that your product is defective or missing parts, contact your
retailer to submit parts requests or warranty claims. Please read the
warranty information at the back of these assembly instructions for
further details.
IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS IN
ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.
THANK YOU!

PARTS IDENTIFIER (NOT TO SCALE)
ADDITIONAL EQUIPMENT REQUIRED:
3

ASSEMBLY TIPS
1. Find a clean, level surface to begin the assembly of your game table. The table will be
partially assembled upside down and then turned over onto its legs. This is a heavy game
and turning it over will require at least two strong adults.
2. Remove all of the contents from box and verify that you have all of the parts shown on the
Parts Identier before you begin assembly. Note: Some parts may be pre-installed or
pre-assembled.
3. Some gures or drawings may not look exactly like your product. Please read and
understand the text before beginning each assembly step.
4. When installing parts that have more than one screw or bolt, hand tighten all screws
or bolts in place before nishing tightening with screwdriver or hex wrench.
5. Electric screwdrivers may be helpful during assembly; however, please set a low torque
and use extreme caution because screws may be stripped or overtightened if the electric
screwdriver's torque is set too high.
WARNINGS!
READ AND FOLLOW ALL ASSEMBLY, OPERATION AND SAFETY INSTRUCTIONS CAREFULLY.
CHOKE HAZARD - THIS TABLE CONTAINS SMALL BALLS AND PARTS - NOT
SUITABLE FOR CHILDREN UNDER 3 YEARS OF AGE.
4

ASSEMBLY INSTRUCTIONS
1. Begin LEG assembly by loosely attaching two LEG SIDES #2 to the inside edge of one LEG
PANEL #3 with SMALL BOLT #7 and 1/4” FLAT WASHER #8. Attach LEG BASE #4 to each LEG
SIDE with 1-3/4” SCREW #16. Attach remaining LEG PANEL #3 with SMALL BOLT #7 and 1/4”
FLAT WASHER #8. Tighten all bolts and screws. Repeat assembly for remaining LEG.
2. Attach each assembled LEG to the bottom of the TABLE BODY #1 with LARGE BOLT #5 and
5/16” FLAT WASHER #6.
3. Thread two LEG LEVELERS #14 into the bottom of each LEG.
5

CONGRATULATIONS!
You have now assembled your Harvil Game Table.
Please note the Care and Use instructions below to
ensure years of trouble free use of your game table.
CARE AND USE
1. This product is intended for INDOOR use only.
2. Do NOT sit, climb or lean on the table.
3. Do NOT drag the table when moving it as this will damage the legs.
6

90-DAY LIMITED WARRANTY
This Harvil product is warranted to the original purchaser to be free from defects in material or work-
manship for a period of ninety days from the date of the original retail purchase.
This warranty does not cover defects or damage due to improper installation, alteration, accident or
any other event beyond the control of the manufacturer. Defects or damage resulting from misuse,
abuse or negligence will void this warranty. This warranty does not cover scratching or damage that
may result from normal usage.
This product is not intended for institutional or commercial use; Harvil does not assume any liability
for such use. Institutional or commercial use will void this warranty.
This warranty is nontransferable and is expressly limited to the repair or replacement of the defec-
tive product. During the warranty period, Harvil shall repair or replace defective parts at no cost to
the purchaser. Shipping charges and insurance are not covered and are the responsibility of the pur-
chaser. Labor charges and related expenses for removal, installation or replacement of the product or
components are not covered under this warranty.
Harvil reserves the right to make substitutions to warranty claims if parts or unavailable or obsolete.
Harvil shall not be liable for loss of use of the product or other consequential or incidental costs,
expenses or damages incurred by the consumer of any other use. The user assumes all risk of injury
resulting from the use of this product.
This warranty is expressly in lieu of all other warranties, expressed or implied, including warranties of
merchantability or tness for use to the extent permitted by Federal or state law. Neither Harvil nor
any of its representatives assumes any other liability in connection with this product.
All warranty claims must be made through the retailer where the product was originally
purchased. A purchase receipt or other proof of date of purchase will be required to pro-
cess all warranty claims. The model number and part numbers found within the assem-
bly instructions will be required when submitting any parts requests or warranty claims.
For further warranty information or inquiries, please call 800-759-0977
7
