Haslux Exideal Deux User manual

Thank you for purchasing our product “Exidéal Deux”.
Please read this manual carefully and use our product.
The warranty is included on the back side of this manual. Please keep it safe.
Haslux Co., Ltd.
Warranty attached
P.1-P.2
P.3
P.4
P.5
P.6
P.7
P.8
P.9
P.10
Safety & Notes
Items included and name of each part / name of button
Product features
Program List / Custom Program
Program ×Optional functions Combination List
Temperature sensor / Distance sensor
Before Using / How to Use
Q&A
Troubleshooting
After-sales service / Specifications
Manual / Warranty
This warranty guarantees that if a failure occurs within the following period from the date of purchase, free
repair will be served as described below.
The purpose of use of the personal information you have written is described below. Please refer.
【Regulation for free repair】
1) If the product fails during the warranty period under the correct usage according to the instruction manual and the
label attached to the main body, free repair will be served based on the contents of this warranty card.
●Please bring the warranty when you need the free repair. Shipping charges for all warranty repairs are at the
owner's expense when you send it to our customer service or original distributor.
●Please contact our customer service if you do not ask for free repair at the original distributor.
2) Please contact our customer service about free repair when you move to another place.
3) Please contact our customer service when you can not receive free repair service at the original distributor due to
the product being given as a gift.
4) This warranty does not apply:
●The damage caused by misuse, Informal repair, informal alteration
●The damage caused by relocation of storage, transport, drop after purchasing
●The damage caused by fire, earthquake, flood, lightning, other natural disasters, abnormal voltage, unspecified
power supply (voltage/frequency), etc.
●Shipping damage or damage caused by mishandling by the freight carrier
●The damage caused by use other than home use (Example: business purpose)
●Not provide this warranty
●Not provide proof-purchase day, distributor name, your name and reformatted in this warranty
5) consumable items are not covered by the warranty.
6)This warranty is only valid in Japan.
7)We do not reissue this warranty.
■Purpose for usage of the personal information
*We will maintain and use customer information (copy of warranty) for free repair support and safety inspection
within the warranty period.
*This warranty guarantees that if a failure occurs under the period from the date of purchase, free repair
will be served. It does not limit the customer‘s legal rights and obligations to the person responsible for warranty
and other business partners, issuing this warranty. Please contact our customer service when you have questions
about repair after the warranty period.
*For after-sales service after the warranty period has expired, refer to "After-sales service" in the manual.
Haslux Co.,Ltd.
ZIP:105-6306
6F TORANOMON HILLS Mori Tower, 1-23-1 Toranomon, Minato-ku, Tokyo, Japan
TEL:[phone] FAX:[phone]
http://www.exideal.jp
Stock Number
Serial Number
Warranty Term one year after shipment
Purchase Date
Customer
Information
ZIP
ADDRESS
NAME
TELL
Distributor
Warranty certificate Exidéal Deux
H-2212

Safety & Notes
Please read this instruction manual carefully and use the product safely and correctly.
■These notes provide instruction on the safe and correct use of our product and to prevent injury and damage.
■Below are the classifications for these notes.
1 2
Caution classification
Danger
Warning
Caution
This symbol indicates an imminently hazardous situation which, if not avoided, result in death or
serious injury.
This symbol indicates that the user risks of death or serious injury if not avoided.
This symbol indicates a potentially hazardous situation, which, if not avoided, may result in personal
injury or damage to the equipment.
Explanation of Figure
This symbol indicates acts prohibited.
This symbol indicates a mandatory action that must be followed.
Danger
Persons who use a heart pacemaker or electro-medical apparatus that may cause malpractice. Please do not use this product.
Warning
Please close your eyes during irradiation with or with out goggles. Please do not use anything other than Exidéal dedicated
goggles. When using this product, do not look directly into LED light.
Do not use this product for any other purposes than doing skincare of your face and body. Or do not use the broken product. If
you have any concerns about your skin and physical condition when using, please consult a doctor before using.
For those who have any skin problems listed below, please
do not use this product. It may worsen skin problems.
・Photosensitivity
・Those who have skin disease or medical history of skin problems
・Dermatitis (Atopic dermatitis, Contact dermatitis, excessive
sunburn, etc.)
・Metal allergy
・Areas with purulence due to acne and pimple
・Eczema, swelling, and warts (including virus)
・Purpura
・Melasma
For those who have any disease listed below, please do not
use this product. It may cause unexpected accidents or skin
and body problems.
・Acute disease
・Blood disease (hemorrhagic disease, hemophilia, etc.)
・Those who are being under treatment or being followed up for
abnormal blood pressure
・Febrile disease
・Malignant tumor
・Epidemic (Infectious diseases)
・Facial neuropathy
・Head and ophthalmologic sequelae due to traffic accidents
Do not use this product on the skin and the areas that
follow below. It may cause unexpected accidents or skin
and body problems.
・Sensitive skin
・Cut
For those who have any of the following , please do not use
this product. It may cause unexpected accidents or skin and
body problems.
・Those who have epileptic seizures that respond to blinking lights
・Allergic constitution
・Those who have telangiectasis due to long-term use of steroid
hormones or due to liver dysfunction
・Those who are during menstruation
・Those who are pregnant, one month after childbirth, and during
nursing
・Those who are after drinking alcohol or taking medicine (especially
medicine that induces sleep)
・Those who are very tired, who do not feel well, and who need rest
・Those who are with body temperature of 38℃or higher (fever period)
Please use electricity rated at 100-240V outlet and use the Exidéal dedicated AC adaptor. Or there is a risk of fire, electric shock,
or malfunction.
Do not use if the cord or adaptor is damaged, hot, or loosely plugged into an electrical outlet. Or there is a risk of fire, electric
shock, short circuit, and burns.
Please do not damage, bend, pull, stretch, kink, or place heavy objects on power cords. Or There is a risk of fire, electric shock,
short circuit, and burns.
Remove Accessories such as earrings or necklaces for use. It may cause accidents or problems.
Warning
Do not store this product in a bathroom or in a humid place, and do not place it on where is subject to water (such as a
washbasin). There is a risk of fire or electric shock due to deterioration.
Do not throw this product into fire or heat it or leave it alone at a high temperature. If not, it may cause heating and fire, burst.
Do not use this product near any flammable object (alcohol, thinner, benzine, liquid remover, spray, etc.) If not, It may
cause fire or electric shock, or injury.
In the following cases, please stop using this product, turn the power off, and unplug the dedicated AC adaptor from the
outlet. There is a risk of fire or burns due to abnormal output. ●Smoke from this product ●Abnormal heating from this
product ●Abnormal noise from this product ●Odor from this product
Do not soak this product in water. There is a risk of electric shock or short circuit.
Be sure to turn the power off by unplug the dedicated AC adaptor from the outlet when not in use. If not, it may cause electric
shock, short circuit, or fire due to insulation deterioration.
Do not remove AC adaptor with wet hands. It could cause a short circuit or result in an electric shock.
This product contains a very strong infrared irradiation pulse program, infrared remote control devices such as television
or air conditioner may not work. If any malfunction occurs or remote control cannot be used arises, please turn off the power
of this product.
Keep this product out of the reach of children. If not, it may cause accidents and problems.
Do not use with pets or young children, and do not let them play with this product. If not, it may cause accidents or injury.
For those who use this product for the first time or who have sensitive skin, shorten usage time to use it while checking
the skin condition. If not, it may cause accidents and problems.
Follow the instruction manual for usage time and frequency. If not, it may cause accidents or problems.
If you feel pain or discomfort, stop using this product. If not, it may cause accidents and problems.
Caution
On the day of hair removal or shaving process, do not apply this product on the same area. There is a risk of swelling and
redness.
When adjusting the height and angle of the dedicated stand, be sure to remove the main body of this product. Also, adjust the
stand with your hand on the base plate.
Be sure to use this product on a flat surface. Do not use this product in an unstable place. , as it is extremely dangerous.
Do not use the stand with the screws loosened. If not, it may cause accidents and problems.
If the screws become loose, use the hexagonal wrench provided to adjust them. If not, it may cause accidents and problems.
Do not use the dedicated stand for any purpose other than its intended use.
Do not drop, throw, and give a strong shock on this product. If not, it may cause accidents and problems.
Do not place anything on this product.
When unplugging the dedicated AC adaptor, be sure to hold the adaptor plug and not to pull on the cord.
Not to store this product in the following places.
●Place exposed to direct sunlight ●Place with high humidity ●Place with a lot of dust ●Place where there is a risk of
ignition ●Place exposed to wind and rain ●Place at high temperature or below zero ●Place where chemicals or gas are
generated ●Place with violent vibration
Do not wipe this product with chemicals such as alcohol, thinner, benzine, alkaline detergent, bleach, neutral detergent,
or disinfectant. If not, it may cause malfunction such as deformation, discoloration, crack, or damage.
*Please keep this warranty in an accessible place for easy reference.
*Misuse and incorrect storage of this product are not covered by the warranty, and repair is subject
to charge even during the warranty period.
Prohibit
Prohibit
Prohibit
Strict
observe
Do not get
wetting
Unplug the
adaptor
No
disassembling
Strict
observe
Never modify, disassemble or repair this product except by repair service engineers designated by us. There is a risk of fire or
injury due to abnormal operation.

3 4
*The selected button will light up green.
*If you wear goggles, select the goggle button. The button will light up green.
Items included and name of each part Product features
Main body
Temperature
sensor
Distance
sensor
LED irradiation panel
Operate panel
AC adaptor
connection port
Accessories
Dedicated AC adaptor
Arm
Base plate
Claw
Name of button
Program button
Press each icon to select the program
Skincare program Scalp care
program
Texture /
Resilience
Adolescent
skin
Rough skin /
Dry skin
Bright skin
care
Scalp care
Optional button
Press each icon to select the optional function
Temperature sensor
Distance sensor
Goggles button
Timer / Pause button
Press the button to set the irradiation time.(5 Min → 10 Min
→ 15 Min → 20 Min → 25 Min → 30 Min → 5 Min)
Press the button during irradiation to pause the irradiation.
Timer display panel
Displays the irradiation time.
Start / Stop button
Press the button to start the program.
Press button during irradiation to end irradiation.
—More stylish, more personal, more efficient —
Next generation personal facial device created by a pioneer in LED facial device.
A unique combination of specific light (wavelengths) is used to compose a program for
each of your concerns. It also measures your skin condition on that day and supports
your daily skin care with treatments that are best suited for you.
Equip with high luminance and high output LED (280pcs of 4 wavelengths).
The calculated LED placement and angled circle optical design prevents shadows from
forming, delivering light to the nose and unevenness of the skin to provide salon-level
treatment at home.
Unique LED program
Custom program
Temperature sensor and Distance sensor
Equipped with purpose-specific programs composed of a unique combination of
specific light (wavelengths) specialized for skin problems. The program combines four
wavelengths (red, yellow, blue, and near-infrared) to achieve efficient treatment.
Customize your original treatment from 4 skin care programs. No need to switch
between programs, you can get all the care you want at once.
Not only your face, but also your entire body from head to toe can be cared for.
The scalp care program also approaches scalp concerns.
Equipped with sensors that measure your skin temperature and irradiation distance.
It automatically adjust the power and program of the LEDs to provide personalized
care for you today.
* Only skin care programs are supported
Dedicated stand
Dedicated goggles
Attention
The type of dedicated AC
adaptor included in the
package differs depending
on the sales region.
A Type BF Type
High luminance, High output LEDs and the calculated arrangement
Stand that can be adjusted up and down, back and forth
Height and angle can be freely adjusted. Two movable axes allow fine angle adjustment.
You can focus on the area you want to irradiate while relaxing in your favorite location
and posture.
Whole Body Care
Power button
Long Press to turn on the power.
Long press again to turn off the power.
Hexagonal wrench

5
LED Program Features Time
Skin care
program
Texture /
Resilience For age-appropriate care, aim for textured skin
with tense.
Adolescent
skin Support skin that becomes unstable due to
disturbed life rhythms and dietary habits to
smooth skin.
Rough skin /
Dry skin Care for dry and rough skin that is bothering all
year round, and fluctuating skin due to irregular
life.
Bright skin
care For the skin that is affected by external
environment when going out, this aftercare
program makes your skin bright.
Scalp care
program
Scalp care Age-appropriate care to keep the scalp and hair
in good condition.
Used to care repeated coloring and UV-exposed
scalp.
*Scalp care program and Skin care programs cannot be used together.
*An error tone will sound if the Skin care program button is pressed when Scalp care program is
selected.
*Please close your eyes during irradiation regardless of whether the Goggles button is on or off.
Program List Program ×Optional functions Combination List
Custom Program
*When Temperature sensor is selected, Distance sensor and the Goggles button are
automatically turned on.
*An error tone will sound if the button that cannot be used together is pressed.
*If Scalp care program is selected, Optional functions cannot be used.
Custom program can be selected from the Skin care programs (Texture and Resilience /
Adolescent skin / Rough and Dry skin / Bright skin care). You can select more than one program.
Scalp care program cannot be selected.
The selected program will automatically switch within the set time for uniform irradiation.
－LED Facial device for your skin problems －
About the Temperature sensor
Measure your skin temperature and automatically adjust the LED balance based on
the skin temperature! Treatments can be tailored to suit the conditions of the day.
・The measurement range of the Temperature sensor is within about 10 cm to 20 cm from the
facial device.
・The LED balance is automatically adjusted according to the measurement results.
・After the temperature measurement is completed, the Temperature sensor button will blink
until the end of the program.
*When using the Temperature sensor, the Distance sensor and the Goggles button are automatically turned on.
Please wear goggles and close your eyes.
About the Distance sensor
Measure the irradiation distance and automatically adjust the power of the LED
according to the distance! LED treatment is possible with appropriate power.
・At the same time as the program starts, the Distance sensor operates.
・The recommended irradiation distance is within 10 cm to 40 cm.
・The LED irradiation output is automatically adjusted according to
the measurement results.
*More than 40 cm, the LED irradiation output will be weak for safety reasons.
*Measurement results will vary depending on the angle and reflectance of the irradiated area.
Approximately 10 cm to 20 cm Weak
Approximately 21 cm to 30 cm Medium
Approximately 31 cm to 40 cm Strong
6
With Goggles
Without Goggles
5 Min
10 Min
5 Min
10 Min
5 Min
10 Min
5 Min
10 Min
10 Min

87
Before Using
How to Use
Q&A
Frequency of use This product can be used daily.
The recommended irradiation time for each program is 5 Min with
goggles on and 10 Min with goggles off.
About skin After removing makeup and washing your face, use this product while
preparing your skin with your skin care products.
Use this product while checking your skin condition.
*If skin problems occur, please stop using and consult a doctor.
Dedicated Stand When adjusting the height and angle of the dedicated stand, be sure to
remove the main body of this product. Also, adjust the stand with your
hand on the base plate.
Be sure to use this product on a flat surface. Do not use this product in an
unstable place.
Accessories Before using, please remove the accessories around your face and neck
such as earrings.
Question Answer
Q1 Does it affect my eyes? It does not affect your eyesight directly. However, if you
look a very strong light for a moment, the surroundings
may temporarily feel dark, so be sure to wear goggles
when the Goggle button is turned on. Also, regardless of
whether the Goggle button is on or off, be sure to close
your eyes during irradiation.
Q2 Is it possible to irradiate an entire
body?
No problem. Not only the face, but the entire body from
head to toe can be treated.
Q3 Can I use it if I have acne? Do not use if the inflammation is severe. When the
inflammation has subsided, please restart while
observing the situation gradually.
Q4 Will I feel tingling during use? This product is a non-contact facial device, so it does not
cause any electrical stimulation and is safe and secure.
Q5 Can I use it if I am tingling right
after sunburn?
Please do not use it for more than three days when your
epidermis is burned by ultraviolet light. You can use it if
there is no stiffness or any other trouble with your skin
after cleansing your face.
Q6 Is there a time limit for use? Basically, you can use it for any Length of time, but we
recommend that you continue to use the treatment a
little bit each day. Please refer to the program
description (P5) for the recommended time for each
program.
Q7 Can I use it in other countries? Yes. This product is compatible with 100-240V, if you
check the voltage of the country you use and match the
shape of the outlet, you do not need to have a voltage
converter.
Q8 How do this clean after use? If you are concerned about dirt on the LED irradiation
panel or operation panel, wipe it with a soft cloth. Do
not use alcohol, thinner, Do not use bright liquid, etc., as
it may cause deformation or malfunction.
Q9 Can I purchase only the
accessories?
Yes. You can purchase them at the store where you
purchased the product or from the official Online store.
(1) Turn on the power
→Connect the dedicated AC adaptor into the main body and long press the Power button to turn
the power on.
(2) Select the program
→Press the Program button to select the program of your choice.
If you use Custom program, select all the programs you wish to irradiate.
*Custom program can be selected from the Skin care programs ( Texture and Resilience / Adolescent skin /
Rough and Dry skin / Bright skin care ).
*You can select more than one program. Scalp care program cannot be selected.
*To switch to the Skin care program when Scalp care program is selected, press the Scalp care button again
to deselect it.
(3) Select of the Optional functions
→Press the Temperature sensor button, the Distance sensor button, or the Goggles button to select ON/OFF
for each Optional function.
*The selected button lights up green.
*When the Temperature sensor is selected, the Distance sensor and the Goggles button are automatically
turned on.
*To select the Distance sensor and the Goggles button separately, press the temperature sensor button again
to deselect them.
(4) Setting irradiation time
→Select the irradiation time with the Timer/Pause button. (5 Min / 10 Min / 15 Min / 20 Min / 25 Min / 30 Min)
(5) Start irradiation
→Press the Start/Stop button to start irradiation.
*If the Goggles button is turned on, wear goggles. After 3 counts, irradiation will start.
*Please close your eyes during irradiation regardless of whether the Goggles button is on or off.
*At the end of the program, beeping sounds to indicate the end of irradiation.
*During irradiation, press the Timer/Pause button to pause the program. To resume irradiation, press the
Timer/Pause button again.
*During irradiation, the power button can be long pressed to force termination.
*If there is no operation for 10 Min, the power turn off automatically．

109
Troubleshooting After-sales service
Specifications
Symptom of trouble Possible causes How to deal with
Cannot power on. The Dedicated AC adaptor is
not connected properly into
the device.
Please confirm to connect the
dedicated AC adaptor.
LED does not light on. /
Partly does not light on.
It occur the error in the device. Please try to power on again.
If your issue is not solved,
please contact customer
service.
Near-infrared light color is
clear and can not see in
irradiation.
Not using the dedicated AC
adaptor.
Be sure to use the dedicated
AC adaptor.
TV and Air conditioner
remote control do not
operate.
There might be an infrared
influence between the device
and the TV receiver or AC
remote control.
Use the product in a
direction where the
irradiated surface does not
shine directly on TVs, air
conditioners, or lighting
fixtures.
“E1” error massage on
display.
The internal temperature has
risen due to use.
Please turn off the power and
wait about an hour before
using it again.
“E2” error massage on
display.
The temperature of the main
body has become high due to
prolonged exposure to direct
sunlight or heat from a heater,
etc.
If the temperature of the
main body is high, unplug the
dedicated AC adaptor and
place it in a cool place for a
while, and use it after the
temperature of the main
body has cooled sufficiently.
Caution
Please contact our customer service if this troubleshooting guide does not apply
your problems.
Product
Dimension
Length: 273mm
Width: 195mm
Height: 17mm
LED drive output 17W (Max)
Weight About 620g Power
Dissipation
20W (Max)
Powe supply type Dedicated AC
adaptor
Power
consumption
Under 1W
Rated voltage AC100V-240V
50/60Hz 1A (Max)
Rated Input
Power
DC24V 1A
■Warranty
The warranty is attached to the back cover. Please fill in all necessary information such as location
purchased and the date of purchase and keep it safe. Please read this warranty description carefully.
■Warranty period
The guaranteed term is one year from the date of purchase.
■Request for repair
Please check the contents of the instruction manual before requesting service. If any abnormality is found,
remove the dedicated AC adaptor.
*Shipping costs shall be borne by the customer. We pay shipping costs after repair.
●During warranty period
We will repair without charge according to the regulations of warranty. Please bring or send the
product with this warranty and the proof-of-purchase, which can verify the date of purchase.
●After warranty period
When the product still performs after repairing, we will repair with charge based on the needs of
customers. Please contact the original distributor or our customer service.
■If any unsure about after service
Please contact our customer service.
*This product is a beauty device and no effects of medical equipment.
Haslux CO., LTD.
●Beauty Business Division
Zip 105-6306
6F Toranomon Hills Mori tower , 1-23-1, Toranomon, Minato-ku, Tokyo, Japan
TEL: [phone] FAX: [phone]
●Osaka Merchandise Center
Zip 566-0055
2-2-6 Shinzaike, Settsu-city, Osaka, Japan
TEL: [phone] FAX: [phone]
