INDUCTION
Models IR1-3000, IR2-3000, IRW1-3000, IRG15-3000, IRB1-3000, IRBR2-6200
Hatco Induction Range lets you cook foods
instantly and precisely with minimal heat
loss. Used with cooking pans containing
magnetic properties, these units heat food
products safely, more economically, and
attractively in all kitchen or display cooking
stations, such as omelet bars, made-to-order
stir-fry stations or for catering and buffet
services.
FLEXIBILITY
The Induction models come in a number of
choices: Portable HOBS with a single coil for
an induction-ready pan, grill or wok, and
double coils for two induction-ready pans.
Drop-In HOBS are available in single or
double coils with separate or attached
control plates.
Cooking relies on heat created by a magnetic
field between the generator coils below the
glass surface of the unit and an induction-
ready pan* sitting on top of the glass surface.
By turning the unit off or by removing the
pan, heat is instantly stopped.
Power to the unit is controlled by both a
glass touch control panel (infinite controls on
Model IRBR2-6200 only) and the placement
of an induction-ready pan on the surface.
Controls have power presets and/or manual
settings. An integrated timer with visual
alarm and power shut down mode on all
models except Models IRG15-3000 and
IRBR2-6200. All units come with a 1829 (6’)
mm cord.
UALITY
The following features assure the finest
performance for years to come:
•Induction is 90% energy efficient compared
to 40-50% for gas cooking.
•Features cooking that is faster than
conventional methods — instantly applies
heat to the food products.
•Contributes to a safer more comfortable
work environment because of lower
cooktop temperatures and less wasted
heat in the kitchen.
•Ensures precise cooking temperatures that
will produce a superior food quality.
•Offers fast and easy cleanup due to the
cool, smooth ceramic glass surface.
*Induction-ready pans are enameled steel,
magnetic stainless steel, cast iron, or aluminum
with a ferrous base. Not for use with:
glass, earthware, ceramic, copper pans or
aluminum pans without a ferrous base.
ONE YEAR PARTS AND LABOR WARRANTY IN THE UK.
Model IR1-3000 (Countertop Single HOB)
Model IRW1-3000
(Induction Wok, shown without Wok Pan)
Model IR2-3000
(Countertop Dual HOB )
Model IRG15-3000
(Induction Griddle)
Model IRB1-3000
(Drop-In Single HOB)
Model IRBR2-6200
(Drop-In Dual HOB) with
a separate control panel)
Drop-In Induction HOBs:
Portable Induction HOBs:
The magnetic field creates heat only in the
induction-ready pan over it resulting in the ceramic
glass top remaining cool to the touch and the
surrounding air temperatures unchanged.
Electromagnetic Field
Ferromagnetic
Cookware
(induction-ready)
Coil

DIMENSIONS
IR1 -3000 Series: 392 W x 526 D x 91 H mm (15 . 43" x 20.71" x 3.59").
IR2
-3000 Series: 392 W x 526 D x 91 H mm (15 . 43" x 20.71" x 3.59").
IRW-3000 Series: 392 W x 526 D x 172 H mm (15 . 43" x 20.71" x 6.78").
IRG15-3000 Series :392 W x 531 D x 251 H mm (15 . 43" x 20.92" x 9.86").
IRB1-3000 Series :440 W x 580 D x 77 H mm (17.32" x 22.83" x 3.03").
Countertop Cut-Out Dimensions: 400 W x 540 H mm (15.75" x 21.26").
IRBR2-3000 Series :440 W x 580 D x 105 H mm (17.32" x 22.83" x 4.14").
Countertop Cut-Out Dimensions: 400 W x 540 D mm (15.75" x 21.26")
tolerance of ±1 mm.
Control P nel: 400 W x 110 H mm (15.75" x 4.33").
Control Cut-Out Dimensions: 370 W x 76 H mm (14.57" x 3").
tolerance of ±1 mm.
VOLTAGE
230 volts, single phase.
CORD LOCATION
IRI-3000, IR2-3000, IRG15-3000: Rear right bottom base corner. IRWI-3000: Rear
left bottom base corner. IRBI-3000: Right rear and IRBR2-6200 left rear bottom
attachment (cord without plug).
PLUG CONFIGURATIONS
Exception: IRBR2-6200 cord only,
no plug.
BRITISH BS-1363
Model Watts Amps kW Shipping Weight
IR1-3000 3000 13.0 3 10 kg (21 lbs.)
IR2-3000 3000 13.0 3 10 kg (21 lbs.)
IRW1-3000 3000 13.0 3 12 kg (27 lbs.)
IRG15-3000 3000 13.0 3 18 kg (40 lbs.)
SPECIFICATIONS
Portable Models
Model Watts Amps kW Shipping Weight
IRB1-3000 3000 13.0 3 11 kg (24 lbs.)
IRBR2-6200 6200 27.0 6.2 15 kg. (33 lbs.)
Drop-In Models
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone]
Fax [phone] • www.hatcocorp.com • E-mail: [e-mail]
ITEM#
INDUCTION
Models IR1-3000, IR2-3000, IRW1-3000, IRG15-3000, IRB1-3000, IRBR2-6200
Form No. IR U Spec Sheet
Printed in U.S.A.
August 2010
PRODUCT SPECS
Induction
The Induction Range shall be a Hatco Model .... as manufactured by the
Hatco Corporation, Milwaukee, WI 53234 U.S.A.
The Induction Range shall be rated at ....watts, ....volts, and be ....
millimeters (inches) in overall width. It shall consist of a stainless steel
casing with single or double generator coil(s) and a glass-ceramic top
surface or grill surface. Glass touch control panels (except IRBR2-6200
which has infinite controls) with a 1829 mm (6') cord and plug (except
IRBR2-6200 has cord only. no plug).
Model IR1-3000 Model IR2-3000
Model IRW1-3000
Model IRG15-3000
Model IRB1-3000
Model IRBR2-6200
392 mm (15.43")
526 mm
(20.71")
TOP VIEW
FRONT VIEW
91 mm
(3.59")
440 mm (17.32")
580 mm
(22.83")
TOP VIEW
504 mm (19.84") 77 mm
(3.03")
SIDE VIEW
369 mm
(14.53")
FRONT VIEW
392 mm (15.43")
526 mm
(20.71")
TOP VIEW
FRONT VIEW
91 mm
(3.59")
188 mm radius (7.40”) for Wok
392 mm (15.43")
526 mm
(20.71"
TOP VIEW
172 mm
(6.78")
FRONT VIEW
392 mm (15.43")
531 mm
(20.92")
TOP VIEW
SIDE VIEW
251 mm
(9.86")
Grease
Drain
SIDE VIEW
500 mm (19.69")
105 mm
(4.14")
FRONT VIEW
369 mm
(14.53")
440 mm (17.32")
580 mm
(22.83")
TOP VIEW
400 mm (15.75")
110 mm
(4.33")
CONTROL PANEL
