Hatco Drawer Warmers are built
to excel in a tough kitchen environment.
There is a model to fit your operation
perfectly, from freestanding to built-in,
standard to narrow widths.
The Brains
Each drawer has its own recessed
thermostat control, temperature
monitor, and illuminated power
switch. You control the humidity
with the adjustable sliding vents.
The Brawn
They’re made of rugged stainless steel,
heavier than our competition. The
drawers return smoothly, with a positive
close due to the 12-gauge stainless
steel slides, heavy-duty hardware,
and maintenance free nylon rollers.
The tough, solid, chrome handles
are angled to avoid glances from
passing carts.
The Versatility
Our standard width drawer warmers
accommodate half-size and third-size
food pans. Options include Designer
color drawer fronts, oversized drawer
frame and pan, biscuit pan drawer,
chip guard, and ITC electronic control.
FREESTANDING MODELS
Model HDW-2
with optional 6" (152 mm)
stainless steel legs
PERFORMANCE. DURABILITY. DEPENDABILITY.
HATCO DRAWER WARMERS. PUT THE BEST TO WORK FOR YOU.
Drawer Warmer
Options & Accessories
Choose a Designer color to
enhance your drawer front.
Navy
Blue
Printed colors are a representation
and may not exactly match our
Designer colors.
White
Granite
Hunter
Green
Gray
Granite
Black
Warm
Red
*Excludes HDW-1R2.
u
Options not available for retrofit.
Model HDW-1R2
with standard 4" (102 mm) legs
Model HDW-1
with standard 4" (102 mm) legs
SPLIT DRAWER MODEL
Expand holding capacities with more pans of
food in the same space as a single standard
drawer model using Hatco’s Split Drawer
Warmer. Ideal for casseroles, pot pies, rolls,
nacho chips, potatoes, vegetables, poultry,
meat, and desserts in 2
1⁄2
" (64 mm) deep
food pans that lift straight out.
MODEL* DESCRIPTION TYPE
HDW-ITC ITC Electronic Control (Required on all drawers) (120V only) Optionu
OS-PAN Oversized Drawer Frame and Pan 20"D x 15"W x 5"H (508 x 381 x 127 mm) in lieu of
Standard Drawer with Pan (Standard width models only) Optionu
BIS DRAWER Biscuit Pan Drawer (Accommodates two 18"D x 13"W (457 x 330 mm) Half-Size Sheet Pans –
not included) in lieu of Standard Drawer with Pan (Standard width models only) Optionu
HDW-CHIP Chip Guard (Standard width models only) Optionu
HDW 6" LEG 6" (152 mm) Adjustable Stainless Steel Legs (Standard on HDW-4) Accessory
HDW-CASTER-2 2" (51 mm) Dia. Swivel Casters (Adds 21⁄2" (64 mm) to height of unit) (HDW-1, -2,-3 models only) Accessory
HDW-CASTER-3 3" (76 mm) Dia. Locking Casters (Adds 41⁄4" (108 mm) to height of unit) (HDW-1, -2, -3 models only) Accessory
HDW-CASTER-4 4" (102 mm) Dia. Locking Casters (Adds 51⁄4" (133 mm) to height of unit) Accessory
HDW-CASTER-5 5" (127 mm) Dia. Locking Casters (Adds 61⁄4" (159 mm) to height of unit) Accessory
HDW-SPILL Water/Spillage Pan Accessory
HDW-SPLASH Splash Baffle Accessory
ST PAN 2 Stainless Steel Food Pans 203⁄4"D x 123⁄4"W x 21⁄2"H (527 x 324 x 64 mm) Accessory
HA99010_DWarmerBro 4/13/07 8:34 AM Page 3

NARROW MODEL
BUILT-IN MODELS
Model HDW-3
with optional casters
Model HDW-4
with standard 6" (152 mm)
stainless steel legs
Model HDW-1BN and Model HDW-1B
built-in units; trim ring included for
easy installation
ITY.
Hatco Drawer Warmers are available in 1-, 2-,
and 3-drawer freestanding or built-in models.
A 4-drawer freestanding model is also available
in standard width only. Freestanding models are
shipped with a 6' (1829 mm) cord set. Built-in units
are shipped with a 4' (1219 mm) flexible conduit.
Each individual drawer includes:
A. Recessed controls – protected from
accidental damage.
B. Illuminated power switch.
C. Drum thermometer – accurately
displays drawer temperature.
D. Thermostat – for precise and
repeatable temperature settings.
E. Complete insulation wrap – energy efficient,
isolated temperatures per drawer.
F. Adjustable vents – allow individual
humidity control.
Metal sheathed heating elements and
12-guage stainless steel drawer slides
feature a two-year warranty.
Adjustable stainless steel legs, casters,
and food holding pans are available as optional
equipment.
All models, except narrow, hold standard size pans
up to 6" (152 mm) deep (will lift straight out in
standard models).
Positive-closing drawers feature nylon rollers,
12-guage stainless steel slides, and removable
drawer frame for ease of cleaning.
Spillage pan and splash baffle for
additional humidity.
Long-lasting durability is assured by rugged
stainless steel construction inside and out, plus
heavy-duty chrome handles.
1
2
3
4
5
6
7
1C
1E
1A
1D
1B
4
3
2
5
6
7
1F
The Difference
Model HDW-1N
with standard 4" (102 mm) legs
ITC Electronic
Control
ADDITIONAL
HUMIDITY
A. Stainless Steel
Food Pan
B. Splash Baffle
C. Water/Spillage Pan
(add
1⁄4
" of water)
A
B
C
Biscuit Pan Drawer
PREVENTS CHIPS FROM
REACHING THE ELEMENT
D. Heat Shield
E. Heating Element
F. Chip Guard
D
E
F
HA99010_DWarmerBro 4/13/07 8:34 AM Page 4

s1-, 2-, and 3-drawer freestanding and split drawer units are standard
with 4" (102 mm) legs; four drawer freestanding units with 6" (152 mm)
stainless steel legs. Accessory 6" (152 mm) stainless legs, or 2" (51 mm),
3" (76 mm), or 5" (127 mm) diameter casters available on 1-, 2-, and 3-
drawer units, or 4" (102 mm) diameter casters available on all units.
HBased on 120 volts.
Freestanding – (Without legs or casters)
HDW-1: 291⁄2"Wx225⁄8"D x 11"H (749 x 575 x 279 mm)
HDW-1N: 207⁄8" W x 27"D x 11"H (530 x 686 x 279 mm)
HDW-2: 291⁄2" W x 225⁄8"D x 211⁄8" H (749 x 575 x 537 mm)
HDW-2N: 207⁄8"Wx27"D x 211⁄8"H(530 x 686 x 537 mm)
HDW-3: 291⁄2"W x 225⁄8"D x 311⁄4"H (749 x 575 x 794 mm)
HDW-3N: 207⁄8"W x 27"D x 311⁄4"H (530 x 686 x 794 mm)
HDW-4: 291⁄2"W x 225⁄8"D x 413⁄8"H (749 x 575 x 1051 mm)
Built-In – (Excluding front mounting flange)
HDW-1B: 281⁄8"W x 223⁄8"D x 93⁄4"H (714 x 568 x 248 mm)
HDW-1BN: 191⁄2"W x 263⁄4"Dx9
3⁄4"H (495 x 679 x 248 mm)
HDW-2B: 28
1⁄8
" W x22
3⁄8
" D x20"H (714 x 568 x 508 mm)
HDW-2BN: 191⁄2 " W x26
3⁄4
" D x20"H (495 x 679 x 508 mm)
HDW-3B: 28
1⁄8
" W x 22
3⁄8
" D x 30
1⁄8
"H (714 x 568 x 765 mm)
HDW-3BN: 191⁄2 " W x26
3⁄4
" D x30
1⁄8
"H (495 x 679 x 765 mm)
Split Drawer – (Without legs or casters)
HDW-1R2: 293⁄8"W x 165⁄8"D x 107⁄8"H (746 x 422 x 276 mm)
120 volts, single phase, freestanding, split 1-, 2-, 3-, and 4-drawer
models use NEMA 5-15P. 4-drawer model not available for Canada.
208 and 240 volts available, freestanding models use NEMA 6-15P.
Export voltages available (except HDW-1R2).
291⁄2" (749 mm)
Standard Models
207⁄8" (530 mm)
Narrow Models
11"
(279 mm)
211⁄8"
(537 mm)
311⁄4"
(794 mm)
413⁄8"
(1051 mm)
FRONT VIEW
225⁄8" (575 mm)
Standard Models
27" (686 mm)
Narrow Models
SIDE VIEW
FOUR DRAWER
THREE DRAWER
TWO DRAWER
ONE DRAWER Location
of Cord
Cutout
Cutout
Locking Strip
Locking
Strip
Locking
Strip
1" (25 mm) Min.
Floor to Cutout
1/8"
(3 mm)
7/8"
(22 mm)
Cabinet Face
W
H
D
SIDE VIEW
FRONT VIEW
107⁄8"
(276 mm)
4" (102 mm)
293⁄8"(746 mm) 165⁄8" (422 mm)
•Add 11⁄2"(38 mm) for conduit connector.
Freestanding Models Built-In Models
Split Drawer Model
F
Fr re ee es st ta an nd di in ng g– –S St ta an nd da ar rd d
F
Fr re ee es st ta an nd di in ng g– –N Na ar rr ro ow w
B
Bu ui il lt t- -I In n– –S St ta an nd da ar rd d
B
Bu ui il lt t- -I In n– –N Na ar rr ro ow w
B
Bu ui il lt t- -I In nC Cu ut to ou ut tR Re eq qu ui ir re em me en nt ts s
V
Vo ol lt ta ag ge e
C
Co or rd dL Lo oc ca at ti io on n
D
Di im me en ns si io on ns s
P
Pl lu ug gC Co on nf fi ig gu ur ra at ti io on ns s
S
Sp pl li it tD Dr ra aw we er r
Back of unit, lower left corner.
P
.O. Box 340500
Milwaukee, WI 53234-0500 U.S.A.
[phone] •[phone]
Fax [phone]
Int’l. Fax [phone]
www.hatcocorp.com
E-mail: [email protected]
Printed in U.S.A. Form No. HDWB-0407 IN-JB
ModelsWatts AmpsHNo. of Drawers Shipping Weight
HDW-1 450 3.8 One 97 lbs. ( 44 kg)
HDW-2 900 7.5 Two 168 lbs. ( 76 kg)
HDW-3 1350 11.3 Three 232 lbs. (105 kg)
HDW-4 1800 15.0 Four 296 lbs. (134 kg)
ModelsWatts AmpsHNo. of Drawers Shipping Weight
HDW-1N 450 3.8 One 97 lbs. ( 44 kg)
HDW-2N 900 7.5 Two 168 lbs. ( 76 kg)
HDW-3N 1350 11.3 Three 232 lbs. (105 kg)
ModelsWatts AmpsHNo. of Drawers Shipping Weight
HDW-1B 450 3.8 One 88 lbs. ( 40 kg)
HDW-2B 900 7.5 Two 159 lbs. ( 72 kg)
HDW-3B 1350 11.3 Three 223 lbs. (101 kg)
ModelsWatts AmpsHNo. of Drawers Shipping Weight
HDW-1BN 450 3.8 One 88 lbs. ( 40 kg)
HDW-2BN 900 7.5 Two 159 lbs. ( 72 kg)
HDW-3BN 1350 11.3 Three 223 lbs. (101 kg)
Model Watts AmpsHNo. of Drawers Shipping Weight
HDW-1R2 525 4.4 Two 97 lbs. ( 44 kg)
Model “W” Dimension “D” Dimension•“H” Dimension
HDW-1B 281⁄4" (718 mm) 233⁄4" (603 mm) 101⁄8" (257 mm)
HDW-2B 281⁄4" (718 mm) 233⁄4" (603 mm) 201⁄4" (514 mm)
HDW-3B 281⁄4" (718 mm) 233⁄4" (603 mm) 303⁄8" (772 mm)
HDW-1BN 195⁄8" (498 mm) 281⁄8" (714 mm) 101⁄8" (257 mm)
HDW-2BN 195⁄8" (498 mm) 281⁄8" (714 mm) 201⁄4" (514 mm)
HDW-3BN 195⁄8" (498 mm) 281⁄8" (714 mm) 303⁄8" (772 mm)
NEMA 6-15P
CEE 7/7 Schuko
NEMA 5-15P
BS-1363
FREESTANDING UNITS ONLY
SPECIFICATIONS
