Hatteras Hammocks ADIRONDACK ROCKER HHAC1TQ User manual

ADIRONDACK ROCKER
INSTRUCTIONS
• CHAIR BACK
• CHAIR SEAT
• LEFT CHAIR ARM
• RIGHT CHAIR ARM
• SPREADER BAR
• LEFT RUNNER
• RIGHT RUNNER
• RUBBER MALLET
• PHILLIPS HEAD SCREWDRIVER
• DRILL
Hardware Pack Weight: 6.4 oz.
(8) BARREL NUTS
(8) 1.5” BARREL BOLTS
(4) 2” SCREWS
(2) PEGS
(1) ALLEN WRENCH
(1) SQUARE-HEAD BIT
HARDWARE PACK
CHAIR PARTS
SUGGESTED TOOLS
STEP 1. Place Chair Back on Chair Seat, push back up against notch
on seat. Use (2) 2” screws to attach chair back to chair seat.
ASSEMBLY
CHAIR
BACK
2” SCREWS
CHAIR
SEAT

Congratulations on purchasing this Adirondack Rocker. QUESTIONS
REGARDING THIS PRODUCT? Call our customer service team, 252-758-
0641.
RESIDENTIAL WARRANTY - This quality product includes a FULL
LIFETIME WARRANTY for RESIDENTIAL CUSTOMERS. In the unlikely event
any splintering, rotting, cracking, peeling, chipping, insect infestation or
other damage should ever occur, The Hammock Source will replace this
furniture, at no charge to you. Note that an original sales receipt must
accompany any returned product, along with a Return Authorization
Number from Hammock Source customer service; call toll-free at 252-758-
0641.
CONTRACTOR WARRANTY - CONTRACTORS receive a FULL 7-YEAR
WARRANTY. Follow the same steps outlined above.
ASSEMBLY
1.5”
BARREL
BOLT
PEG BARRELBARREL
NUTNUT
#6113
STEP 4. Place and secure spreader bar using
(2) 2” screws.
STEP 3. Use (2) 1.5” barrel bolts and (2) barrel
nuts to attach right & left chair arm to chair
back.
STEP 5. Use (4) 1.5” barrel bolts and (4) bar-
rel nuts to attach right & left chair rockers to
chair seat and chair legs. Tighten all bolts.
STEP 2. Place chair on it’s side and use (1) peg,
(1) barrel bolt and (1) barrel nut to attach the
first arm to the chair seat. Flip chair over and
repeat on other side. Do not tighten bolts until
after step 5. LEFTLEFT
CHAIRCHAIR
ARMARM
1.5”
BARREL
BOLT
LEFT RUNNER
RIGHT RUNNER
BARRELBARREL
NUTNUT
1.5”
BARREL
BOLT
2” SCREW
SPREADER
BAR
