HAUL MASTER 95831 Parts list manual

5/8” HITCH PIN LOCK
Model 95831
ASSEMBLY AND OPERATION INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from the product described herein.
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND
ALL WARNINGS AND INSTRUCTIONS BEFORE USE.
Copyright©2007 by Harbor Freight Tools®. All rights reserved. No portion of
this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools.
Fortechnicalquestionsorreplacementparts,pleasecall1-800-444-3353.

Page 2SKU 95896 For technical questions, please call 1-800-444-3353.
SPECIFICATIONS
Weight 1.3 Pounds
Construction All steel components w/chromed brass keys
Dimensions 6-15/16” Overall length x 30mm diameter
USE PRODUCT ONLY WITH CORRECT SIZE (2 X 2) AND
STYLE OF HITCH (CLASS III, IV & V), FITTING THE 5/8”
DIAMETER OF HITCH LOCK.
Save This Manual
You will need this manual for the safety warnings and precautions, assembly, operat-
ing, inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Write the product’s serial number in the back of the manual near the assembly
diagram, or write month and year of purchase if product has no number. Keep this manual
and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in electric shock,
fire, and/or serious injury.
Stay alert. Do not attach while tired or under the influence of drugs, alcohol,
or medication. A moment of inattention while attaching Hitch Lock may result in
serious personal injury.
Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep
your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry,
or long hair can be caught in moving parts.
Maintain Hitch Lock with care. When properly cleaned, the Hitch Lock is easier to
lock and unlock. Do not use if damaged. Store in dry location.
Check for misalignment or binding of lock, breakage of parts, and any other
condition that may affect operation. If damaged, have Hitch Lock serviced before
using. Many accidents are caused by poorly maintained tools.
1.
2.
3.
4.

Page 3SKU 95896 For technical questions, please call 1-800-444-3353.
WARNING: The brass components of this product contain lead, a chemical
known to the State of California to cause birth defects (or other reproductive
harm). (California Health & Safety code § 25249.5, et seq.)
Always read and adhere to all safety warnings and instructions in the manual
of the trailer being used.
Unpacking
When unpacking, check to make sure that the item is intact and undamaged. If any
parts are missing or broken, please call Harbor Freight Tools at the number shown on the
cover of this manual as soon as possible.
OPERATION
BEFORE EACH USE, inspect the general condition of the tool. Check for misalignment
or binding of moving parts, cracked or broken parts, and any other condition that
may affect its safe operation. If abnormal noise or vibration occurs, have the problem
corrected before further use. Do not use damaged equipment.
Unlock the Hitch Lock.
Slide the Hitch Pin Lock through receiver on trailer/hitch (be careful not to pinch
fingers).
Lock securely and store keys in safe place.
To remove Hitch Pin Lock, unlock using the key, remove it, and store both Hitch Pin
Lock and Keys in a safe and secure area that is out of reach of any children.
Note: No replacement parts are available for this product.
5.
6.
1.
2.
3.
4.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.

Page 4SKU 95896 For technical questions, please call 1-800-444-3353.
