Haulotte COMPACT 8 User manual

Operator's manual
C
OMPACT
8 (C 2032E) - C
OMPACT
8W (C 2047E) - C
OMPACT
10 (C 2747E) -
C
OMPACT
10N (C 2632E) - C
OMPACT
10N-1 - C
OMPACT
12 (C 3347E) -
C
OMPACT
14 (C 3947E)
4001001030 E 06.20 USA / GB
Operator's manual
Compact 8 (Compact 2032E)
Compact 8W (Compact 2047E)
Compact 10 (Compact 2747E)
Compact 10N (Compact 2632E)
Compact 10N-1
Compact 12 (Compact 3347E)
Compact 14 (Compact 3947E)
24203 0
X
For online reference and to download the manuals for your
machines HAULOTTE®, go to :
https://www.e.technical-information.com
or, scan the QR Code below :

2 4001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
USA

3
CONTENTS
Operator's manual
CONTENTS
A
FOREWORD
1 - User responsibility. . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1 - Owner's responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 - Employer's responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3 - Trainer's responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4 - Operator's responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 - Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 - Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1.1 - Misuse Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1.2 - Falling Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.3 - Overturning / Tip-over Hazards . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1.4 - Electric Shock Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.1.5 - Explosion / Fire Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1.6 - Crushing / Collision Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1.7 - Uncontrolled movement Hazards . . . . . . . . . . . . . . . . . . . . . . . . 16
3 - Safety inquiries . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4 - Incident notification. . . . . . . . . . . . . . . . . . . . . . . . . 17
5 - Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.1 - Product modification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.1.1 - Implementing manufacturer safety campaigns. . . . . . . . . . . . . . 18
5.2 - Product specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.3 - Change of Ownership Notification . . . . . . . . . . . . . . . . . . . . . . . . 19
B
FAMILIARIZATION
1 - General safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1.1 - Intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1.2 - Decal content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1.3 - Symbols and colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
1.4 - Level of severity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
1.5 - Symbols legend and definitions . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2 - Models description . . . . . . . . . . . . . . . . . . . . . . . . . 25
3 - Primary machine components . . . . . . . . . . . . . . . . 26
3.1 - Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.2 - Maintenance support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.3 - manual extension. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.4 - Ground control box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.4.1 - Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.5 - Platform control box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.5.1 - Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4 - Performance Specifications . . . . . . . . . . . . . . . . . . 34
4.1 - Technical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.2 - Working area / Range of motion. . . . . . . . . . . . . . . . . . . . . . . . . . 40
5 - Decals and markings locations . . . . . . . . . . . . . . . 48

4
Operator's manual
C
PRE-OPERATION INSPECTION
1 - Recommendations. . . . . . . . . . . . . . . . . . . . . . . . . . 63
2 - Working area assessment. . . . . . . . . . . . . . . . . . . . 63
3 - Inspection and Functional test . . . . . . . . . . . . . . . . 64
3.1 - Daily inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
4 - Safety functional checks. . . . . . . . . . . . . . . . . . . . . 67
4.1 - E-Stop button check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
4.2 - Activation of controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
4.3 - Fault detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
4.3.1 - Buzzers test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
4.4 - Overload sensing system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
4.5 - Slope warning device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
4.6 - Travel speed limitation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
4.7 - Electronic variable speed drive. . . . . . . . . . . . . . . . . . . . . . . . . . . 70
4.8 - Pothole protection system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
4.9 - On-board charger. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
4.10 - Battery discharge indicator-Hour meter. . . . . . . . . . . . . . . . . . . . 72
4.10.1 - Hour meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
4.10.2 - Alarm codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
D
OPERATION INSTRUCTIONS
1 - Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
1.1 - Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
1.2 - Operation from the ground control box . . . . . . . . . . . . . . . . . . . . 74
1.3 - Operation from the platform control box . . . . . . . . . . . . . . . . . . . 75
2 - Ground control box . . . . . . . . . . . . . . . . . . . . . . . . . 76
2.1 - To start and stop the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
2.2 - Movement control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
2.3 - Additional controls from the ground control box . . . . . . . . . . . . . 77
3 - Platform control box . . . . . . . . . . . . . . . . . . . . . . . . 78
3.1 - To start and stop the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
3.2 - Drive and steer control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
3.2.1 - Control box - Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
3.3 - Movement control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
3.3.1 - Control box - Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
3.4 - Additional controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
4 - Rescue and emergency procedures . . . . . . . . . . . 80
4.1 - In case of power loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
4.2 - To rescue operator in platform . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

5
CONTENTS
Operator's manual
5 - Transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
5.1 - Putting in transport position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
5.2 - Machine layout — COMPACT 8/ 8W / 10N / 10 /
COMPACT 12 / COMPACT 14 . . . . . . . . . . . . . . . . . . . . . . . . . .
82
5.3 - Unloading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
5.4 - Towing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
5.4.1 - Free wheel mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
5.4.2 - Automatic brake release (Option). . . . . . . . . . . . . . . . . . . . . . . . 85
5.5 - Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
5.6 - Loading by ramp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
5.7 - Unloading by ramp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
5.8 - Lifting operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
5.8.1 - Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
5.8.2 - Preliminary procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
5.8.3 - Loading and unloading with forklift . . . . . . . . . . . . . . . . . . . . . . . 89
5.8.4 - For: COMPACT 8 - COMPACT 2032E -
COMPACT 10N - COMPACT 2632E . . . . . . . . . . . . . . . . . . . . 90
5.8.5 - For COMPACT 8W - COMPACT 2047E -
COMPACT 10 - COMPACT 2747E -
COMPACT 12 - COMPACT 3347E -
COMPACT 14 - COMPACT 3947E . . . . . . . . . . . . . . . . . . . . . . 92
6 - Cold Weather Recommendations. . . . . . . . . . . . . . 94
6.1 - Environmental conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
6.1.1 - Hydraulic oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
7 - Battery care and maintenance . . . . . . . . . . . . . . . . 95
7.1 - Battery charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
E
GENERAL SPECIFICATIONS
1 - Machine dimensions . . . . . . . . . . . . . . . . . . . . . . . 100
2 - Major component masses. . . . . . . . . . . . . . . . . . . 102
3 - Acoustics and vibrations . . . . . . . . . . . . . . . . . . . 103
4 - Wheel/Tire assembly . . . . . . . . . . . . . . . . . . . . . . . 104
4.1 - Technical specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
4.2 - Inspection and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
4.2.1 - Procedure of replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
5 - Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
5.1 - Pipe holder option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
5.1.1 - Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
5.1.2 - Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
5.1.3 - Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
5.1.4 - Pre-operation inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
5.1.5 - Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
5.1.6 - Disassembly - Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
5.1.6.1 - Without option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
5.1.6.2 - Work light or platform supply option . . . . . . . . . . . . . . . . . . . . . 109
5.1.7 - Specific decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
5.2 - Swing gate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
5.2.1 - Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
5.2.2 - Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
5.2.3 - Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
5.2.4 - Pre-operation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

6
Operator's manual
F
MAINTENANCE
1 - General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
2 - Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . 114
3 - Inspection program . . . . . . . . . . . . . . . . . . . . . . . . 115
3.1 - General program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
3.2 - Daily inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
3.3 - Periodic inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
3.4 - Reinforced inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
3.5 - Major inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
4 - Repairs and adjustments . . . . . . . . . . . . . . . . . . . 118
G
OTHER INFORMATION
1 - Conditions of warranty . . . . . . . . . . . . . . . . . . . . . 119
2 - Subsidiary contact information . . . . . . . . . . . . . . 120
2.1 - California warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
H
INTERVENTION REGISTER
1 - Intervention register . . . . . . . . . . . . . . . . . . . . . . . 123

A
B
C
D
E
F
G
H
I
74001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
Foreword
You have just purchased a HAULOTTE® product and we would like to thank you for your business.
The aerial work platform is a device for lifting people designed and manufactured with the intent to enable users
to access overhead elevated temporary workplaces with the necessary tools and equipment. All other uses or
alterations/modifications to the aerial work platform must be approved by HAULOTTE®.
This manual shall be considered a permanent component of the machine and shall be kept with the aerial work
platform in the designated Manual Holder, at all times.
Safe operation of this product can only be assured if you follow the operating instructions contained in this
manual. To ensure proper and safe use of this equipment, it is strongly recommended that only trained and
authorized personnel operate and maintain the aerial work platform.
We would particularly like to draw your attention to 2 essential points :
• Comply with safety instructions.
• Use the equipment within the specified/published performance limits.
With regard to the designation of our equipment, we stress that this is purely for commercial purposes and not to
be confused with the technical specifications. Only the specifications in this manual should be used to study the
suitability of the equipment for the intended use.
This operator's manual is specific to the HAULOTTE® products listed on the cover page of this manual.
The operator's manual does not replace the basic training required for equipment operators. HAULOTTE® has
compiled this manual to assist in safe and efficient operation of the products covered in the manual.
The manual must be available to all operators and must be kept in a legible condition. Additional copies can be
ordered from HAULOTTE Services®.
Stay Safe and keep working with HAULOTTE® !
For online reference and to download the manuals for your machines HAULOTTE®, go to :
https://www.e.technical-information.com
or, scan the QR Code below :
Original language and version :
Manuals in English and French are the original instructions. Manuals in other languages are translations
of the original instructions.

8 4001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
1 - User responsibility
1.1 - O WNER ' S RESPONSIBILITY
The owner (or hirer) has the obligation to :
• To inform operators of the instructions contained in the Operator's Manual.
• Follow local regulations regarding operation of the machine.
• To replace all manuals or decals that are either missing or not legible. Additional copies can
be ordered from HAULOTTE Services®.
• To establish a preventive maintenance program in accordance with the manufacturer's
recommendations, taking into account the environment and severity of use of the machine.
• To perform periodic inspections in accordance with HAULOTTE® recommendations and
local regulations.
All malfunctions and problems identified during the inspection shall be corrected before the
aerial work platform is returned to service.
1.2 - E MPLOYER ' S RESPONSIBILITY
The employer has the obligation :
• To authorize the operator to use the machine.
• To inform and familiarize the operator with the local regulations.
Forbid anyone from operating the machine if :
• Under the influence of drugs, alcohol, etc.
• Subject to fits, loss of motor skills, dizziness, etc.
1.3 - T RAINER ' S RESPONSIBILITY
The trainer must be qualified to provide training to operators in accordance with applicable
local regulations. The training must be given in an obstacle-free area until the trainee is
considered competent as defined by the training program undertaken.

A
B
C
D
E
F
G
H
I
94001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
1.4 - O PERATOR ' S RESPONSIBILITY
The operator has the obligation to :
• Read and understand the contents of this manual and familiarize himself with the decals
affixed on the machine.
• To inspect the machine before use according to HAULOTTE®'s recommendations..
• Inform the owner (or hirer) if the manual or any decals are missing or are not legible.
• To inform of any malfunctioning of the machine.
Operators must ensure that the inspections have been carried out by the owner and that they
can use the machine for the purpose intended by the manufacturer.
Only authorized and qualified operators may operate HAULOTTE® machines.
All operators must become familiar with and fully understand the emergency controls and be
able to operate the machine in an emergency.
The operator has the obligation to stop using the machine in the event of malfunction or safety
problems on the machine or in the work area and report the problem immediately to his/her
supervisor.

10 4001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
2 - Safety
2.1 - S AFETY INSTRUCTIONS
2.1.1 - Misuse Hazards
• Do not attach overhanging loads when raising or lowering the platform.
• Do not tie the platform to an adjacent fixed or mobile structure.
• Do not use/operate the machine when alone. A survey person or immediate Supervisor must
be present on the ground in case of emergency.
• Do not use a faulty or poorly maintained machine. Remove defective/damaged machine
from service.
• Do not climb onto the compartment covers of the machine.
• Do not replace items critical to machine stability with items of different weight or specification.
• Do not replace factory-installed tires with tires of different specifications or ply rating.
• Do not alter or disable machine components that in any way affect safety and stability.
• Do not disable the safety devices.
• Do not deface, modify or obscure any decals or markings on the aerial work platform.
• Do not use the machine for other purposes than to lift
people, their tools and equipment to the desired position.
• Do not use the machine as a crane, material lift or elevator.
Only use the machine as it was intended.

A
B
C
D
E
F
G
H
I
114001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
2.1.2 - Falling Hazards
Before commencing operation :
• Ensure that guard rails are correctly installed and secured.
• Remove oil or grease from the steps, floor, handrail and the guardrails.
• Clean the floor of the platform (no debris).
To enter or exit from the platform :
• The machine must be completely stowed.
• Face the machine to access the entry opening to the
platform.
• Keep 3 points of contact (both hands and a foot) on the
steps and the guardrail.
• Keep fingers away from moving parts near entry gate.
• Ensure that gate or sliding bar is in it’s proper closed
position.
When in the platform :
• If local regulations require the wearing of a harness, use
only the anchor points provided for this purpose.
• The correct use of the harness requires the lanyard to be
connected to an anchorage point designated by the decals.
Refer to this decal located on the platform.
• Hold on securely to the guardrails.
• Always keep your feet firmly on the floor of the platform.
• Do not sit, stand, or climb on the platform guard rails.
• Do not lean over the guard rails or climb over them. Only
work in the platform area within the guard rails.
• Do not exit the platform until it is in the completely stowed
position.
• Do not use the guardrail as a means of access to climb in or
out of the platform.
307P216290 b
x 1

12 4001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
2.1.3 - Overturning / Tip-over Hazards
Before positioning and operating the machine :
• Ensure that the surface is capable of supporting the machine weight including the rated
capacity.
• Place the loads uniformly distributed on the platform floor.
• Do not replace components critical to stability with components of different weight or
specification.
• Do not pull or push towards any object outside of the platform. Do not exceed the maximum
allowable side force stated in the performance specifications.
• Do not use the machine to support any external structure.
• Do not use the machine to tow other machines or to drag materials.
• Do not exceed the maximum rated capacity that includes
the weight of both material and allowed number of occu-
pants. Do not exceed the allowable number of occupants.
• Do not increase the working height (using extensions, lad-
der, etc.).
• Do not place ladders or scaffolds in the platform or against
any part of this machine.
• Do not use the machine in winds exceeding the permissible
limit.
• Do not increase the surface area of the platform exposed to
wind. This includes adding panels, mesh, banners. Be
aware when working with materials with a large surface
area. This will add to the wind load on the machine.
• Do not raise the platform or drive with platform elevated on
an incline exceeding the rated slope for the machine.
• Do not drive the machine on slopes or grades exceeding the
specified limits.
• Never use the machine with material or objects suspended
from the guard-rail.

A
B
C
D
E
F
G
H
I
134001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
• Using a machine on a slope :
WIND : The aerial work platform can operate up to a maximum wind speed as indicated in the
specifications. To identify the local wind speed, use the Beaufort scale below, use a wind
gauge or an anemometer.
N.B.-:-THE BEAUFORT SCALE OF WIND FORCE IS ACCEPTED INTERNATIONALLY AND IS USED WHEN
COMMUNICATING WEATHER CONDITIONS. A WIND SPEED RANGE AT 10 M(32 FT 9 IN) ABOVE FLAT,
CLEAR LAND IS ASSOCIATED WITH EACH DEGREE.
Beaufort scale
Do not drive the machine on slopes with gradients exceeding the authorised transversal and lateral limits
for the machine. Section B 4.1 - Technical specifications.
Force Meteorological description Observed effects m/s km/h mph
0 Calm Smoke rises vertically. 0 - 0,2 0 - 1 0 - 0,62
1 Very light breeze Smoke indicates the wind direction. 0,3 - 1,5 1 - 5 0,62 - 3,11
2 Light breeze Wind felt on the face. Leaves rustle.
Weather vanes turn. 1,6 - 3,3 6 - 11 3,72 - 6,84
3 Slight breeze Leaves and small twigs in constant
motion. Flags move slightly. 3,4 - 5,4 12 - 19 7,46 - 11,8
4 Nice breeze Raised dust and loose papers. Small
branches are moved. 5,5 - 7,9 20 - 28 12,43 - 17,4
5 Nice breeze Small trees in leaf to sway. Crested
wavelets form on inland waterways. 8,0 - 10,7 29 - 38 18,02 - 23,6
6 Cool wind
Large branches in motion. Power
lines and chimneys 'sing'. Umbrellas
used with difficulty.
10,8 - 13,8 39 - 49 24,23 - 30,45
7 Near gale Whole trees in motion. Inconvenience
felt when walking against wind. 13,9 - 17,1 50 - 61 31 - 37,9
8Gale Some branches break. Generally we
cannot walk against the wind. 17,2 - 20,7 62 - 74 38,53 - 45,98
9 Strong gale
The wind causes slight damage to
buildings. Tiles and chimney stacks
are blown off.
20,8 - 24,4 75 - 88 46,60 - 54,68

14 4001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
2.1.4 - Electric Shock Hazards
The machine is not electrically insulated and does not provide protection from contact or
proximity to electrically charged conductors.
Always position the lift at a safe distance from electrically charged conductors to ensure that
no part of the machine is within an unsafe area.
Respect the local rules and the minimum safety distance from power lines.
Minimum safe approach distances
N.B.-:-USE THIS TABLE EXCEPT WHERE LOCAL REGULATIONS INDICATE OTHERWISE.
Electric voltage Minimum safety distance
Mètre Feet
0 - 300 V Avoid contact
300 V - 50 kV 3 10
50 - 200 kV 5 15
200 - 350 kV 6 20
350 - 500 kV 8 25
500 - 750 kV 11 35
750 - 1000 kV 14 45
• Do not operate the machine when close to live power lines,
consider the movement of the machine and the sway of the
electric power lines particularly in windy conditions.
• Do not operate the machine during lightning, thunder-
storms, snow/ice or any weather condition that could com-
promise operator safety.
• The machine must not be used while charging the batteries.
• When using the platform AC power supply, ensure it is
protected with a circuit breaker and residual current device.
• Do not use the machine as a ground for welding.
• Do not weld on the machine without first disconnecting the
battery terminals.
• Always disconnect ground cable first.
Keep away from the machine if it contacts energized power
lines. Personnel on the ground or in the platform must not
touch or operate the machine until energized power lines are
shut off.

A
B
C
D
E
F
G
H
I
154001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
2.1.5 - Explosion / Fire Hazards
2.1.6 - Crushing / Collision Hazards
• Always cordon off the area around the base of the machine to keep personnel and other
equipment away from the machine while in use.
• Warn personnel not to work, stand, or walk under a raised boom/platform.
• Do not drive in reverse direction (opposite the field of vision).
• Always ensure that the chassis is never driven any closer than 1 m (3 ft 3 in) to holes,
bumps, slopes, obstructions, debris and ground coverings that may hide holes and other
dangers.
• Keep non-operating personnel at least 5 m (16 ft 5 in) away from the machine when driving.
Always wear protective clothing and eye wear when working
with batteries and power sources/systems.
N.B.-:-ACID IS NEUTRALIZED WITH SODIUM BICARBONATE AND
WATER.
• Do not work on or operate a machine in an explosive or
flammable atmosphere / environment.
• Do not touch hot components.
• Do not bridge the battery terminals with metallic objects.
• Do not service the battery in proximity of spark, open flame,
lit cigarettes.
• ALWAYS avoid contact with battery acid. Battery acid
causes serious burns and should be kept away from skin or
eyes. If contact occurs, flush with water and consult a
physician immediately.
When in the platform :
• Check the work area for overhead clearance, for any
obstacles besides and below the platform when raising/
lowering the platform and or before driving.
• During movement, keep all the parts of the body inside the
platform. Hold onto the guardrails on the opposite side to
any surrounding structures. Take care to avoid trapping
hands whilst holding the guardrails.
• To position machine close to a building/structure, use
extension deck feature, instead of driving machine closer to
structure.

16 4001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
• Be aware of driving direction.
• Check the driving direction with the help of the red or green arrow on the chassis relative to the red and green
arrows on the platform control box.
• Also note that when changing the driving direction (Forward <> Reverse) the joysticks or switches must return
to the neutral position before reversing the drive direction and for movement to occur.
• When driving, position the platform so as to provide the best possible visibility and to avoid
any blind spots.
• Hold on securely to the guardrails.
• Personal fall protection equipment (PFPE) :
• Occupants must wear a safety harness, personal protective equipment and comply with the applicable national
regulations. Attach the safety harness lanyard to the designated anchorage points provided for this purpose on
the work platform.
• Operators must comply with the safety standards of the job site and the employer, as well as the applicable
state regulations relating to the use of personal protective equipment.
• All personal fall protection equipment (PFPE) must comply with current regulations, must be inspected and
used in accordance with the manufacturer's instructions.
• Avoid contact with fixed or mobile obstacles (other machines).
• Other machines (crane, aerial work platform, etc.) operating in the work area increase the
risk of crushing or collision. Restrict the operation of machines moving within the aerial work
platform work area.
• Take into consideration the stopping distance, reduced visibility and blind spots of the ma-
chine.
• Limit travel speed to suit the ground surface condition, slope (incline), and people in the vi-
cinity.
2.1.7 - Uncontrolled movement Hazards
Never use a damaged or malfunctioning machine.
Always respect the following rules :
• Maintain clearance from high voltage lines.
• Maintain clearance from generators, radar, electromagnetic fields.
• Never expose the batteries or electrical components to water (high pressure washer, rain).

A
B
C
D
E
F
G
H
I
174001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
3 - Safety inquiries
Inquiries relating to design criteria/specifications of a product, standards compliance, or overall
machine safety should be sent to the HAULOTTE® PRODUCT SAFETY department.
Each inquiry or request should include all relevant information; including contact name, telephone
number, mailing address, email address, plus the machine model and serial number.
The HAULOTTE® Product Safety department will evaluate each request/inquiry and will provide a
written response.
4 - Incident notification
Notify HAULOTTE® immediately when a HAULOTTE® product has been involved in an incident/
accident leading to personal injury or death, or when there is a major property damage.
Connect to our website : www.haulotte.com
HAULOTTE Group - EUROPE Product
Safety Department
Address : La Péronnière - BP 9 - 42152
L'Horme - France
Tel : [phone]
Email : [e-mail]
HAULOTTE Group - Australia, India and
Asia Product Safety Department
Address : No.26 Changi North Way -
Singapore 498812 - Singapore
Tel : [phone]
Email : [email protected]
HAULOTTE Group - North & South
America Product Safety Department
Address : 3409 Chandler Creek Rd. -
Virginia Beach, VA 23453 - United States
Tel : [phone]
Email : [e-mail]

18 4001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
5 - Compliance
5.1 - P RODUCT MODIFICATION
It is strictly forbidden to modify a HAULOTTE® product. Any modification may violate Haulotte
design parameters, local regulations and industry standards.
All modifications must be submitted in writing (form) and approved by the manufacturer.
Do not hesitate to contact HAULOTTE Services®, should you have any questions relating to
the issued bulletin(s) or with questions on the policy itself.
5.1.1 - Implementing manufacturer safety campaigns
It is essential to implement the safety campaigns issued by the manufacturer. All of these
campaigns are accessible on our website.
Connect to our website : www.haulotte.com
5.2 - P RODUCT SPECIFICATIONS
HAULOTTE® cannot be held liable for any changes to the technical characteristics/specifica-
tions contained in this manual. HAULOTTE® has a continuous improvement policy in place
for its product range. Given this policy, the Company reserves the right to modify products
technical characteristics / specifications without notice.
Certain options/accessories can modify the machine's operating characteristics and its' asso-
ciated safety. If your machine was originally delivered with options fitted, replacing a safety
component associated with a particular option does not require any particular precaution other
than those associated with the installation itself (static test).
Otherwise, it is essential to follow the manufacturer's recommendations as stated below :
• Installation by authorised HAULOTTE® personnel only.
• Update the manufacturer's identification plate.
• Have stability tests carried out by a certified agency/competent person.
• Ensure decals are updated.
Never place a machine on the market without having applied the Safety Bulletins.

A
B
C
D
E
F
G
H
I
194001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
5.3 - C HANGE OF O WNERSHIP N OTIFICATION
It is important and necessary to keep HAULOTTE Services® updated with current ownership
of the machine. This way, HAULOTTE® will be able to provide the necessary support for the
product. If you have sold or transferred this machine(s); it is your responsibility to notify
HAULOTTE Services®. It is not required to include Lessees/Renters of Leased/Rented
machines on this form.
Connect to our website. : www.haulotte.com

20 4001001030 E 06.20 USA / GB
Compact 8 (C 2032E) - Compact 8W (C 2047E) - Compact 10 (C 2747E) - Compact 10N (C 2632E) -
Compact 10N-1 - Compact 12 (C 3347E) - Compact 14 (C 3947E)
A- Foreword
Notes
