Haven K Series User manual

K SERIES - CLASSIC WHITE MINI LED CONTROLLER
QUICK START GUIDE
What’s in the Box?
1 x K Series – Classic White Mini LED
Controller
4 x Wood Mounting Screws w/ Anchors
1 x Wireless Wall Switch w/ Screws
1 x Wireless Wall Switch Cover w/ Screws
2 x Double Sided Tape (for non-screw
mounting option)
1 x Power Supply
Wiring
Lighting Controller Wireless Wall Switch
Feedback LED
Pairing Button
Feedback
Fuse 1
24 VDC Power
Light Control
Light Control
Antenna
Note: Fuse light should be
on for proper operation.
Vents
(Do not cover)
ON
OFF
Brightness:
6Down / Up5
COM +
Lighting Connectors
RevA

Storage and Mounting
Installation on dry wall Installation with wall receptical Installation with double sided tape
STEP 1: Connect Antenna STEP 2: Connect wires to connectors STEP 3: Plug in connectors STEP 4: Mount controller
Mounting the switch
STEP 5: Connect to power
COM +
Note: DO NOT CONNECT TO POWER
UNTIL STEP 5
(Dry wall mounting optional with
included anchors and screws or
double-sided tape)
Note: Mounting in this way may cause damage
to your wall upon removal.
