Havis DS-PAN-1300 Series User manual

Owner’s Manual
Havis Docking Station
For Panasonic TOUGHBOOK L1 Tablet
DS-PAN-1300 Series
DS-PAN-1301
DS-PAN-1301-2
DS-PAN-1302
DS-PAN-1302-2
DS-PAN-1303
DS-PAN-1306
DS-PAN-1300-SERIES_OMN_9-19
Havis, Inc.
75 Jacksonville Road
Warminster, PA 18974

Before Beginning
Havis is pleased to provide this Owner’s Manual to aid in the proper installation and use of the
DS-PAN-1300 Series Docking Station for the Panasonic TOUGHBOOK L1 Tablet.
For questions regarding the set-up of your DS-PAN-1300 Series Docking Station,
please contact Havis at 1-800-524-9900 or visit www.havis.com for additional product support and information.
This Owner’s Manual applies to the following Part Numbers:
DS-PAN-1301
DS-PAN-1301-2
DS-PAN-1302
DS-PAN-1302-2
DS-PAN-1303
DS-PAN-1306
•NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE AIRBAG DEPLOYMENT ZONE.
•DO NOT USE COMPUTER WHILE DRIVING.
•READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
•DO NOT STORE, INSTALL, OR OPERATE THE DOCKING STATION WHERE WATER, MOISTURE, STEAM, DUST, ETC.
ARE PRESENT
•DO NOT DOCK OR UNDOCK YOUR COMPUTER UNLESS IT IS POWERED OFF. DOCKING OR UNDOCKING WITH YOUR
COMPUTER IN ON, STANDBY, HIBERNATION, OR SLEEP MODES CAN CAUSE PERMANENT DAMAGE.
•FOR THE DS-PAN-1301 & DS-PAN-1301-2 DOCKING STATIONS: DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE
SOURCE: This product requires a certified, automotive grade, Panasonic approved 10W power source rated for a
continuous, regulated 5 VDC output (Havis Part Number LPS-160 or equivalent). Failure to comply with this
requirement will cause product damage that is NOT repairable and is NOT covered under warranty.
•FOR THE DS-PAN-1303 DOCKING STATION: DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: The
Panasonic TOUGHBOOK L1 Tablet requires a certified, Panasonic approved power source rated for a continuous,
regulated 5 VDC output. Failure to comply with this requirement will cause product damage that is NOT
repairable and is NOT covered under warranty.
•DO NOT DOCK TABLET IN REVERSE POSITION, DOING SO CAN CAUSE PERMANENT DAMAGE.
•FOR DOCKING STATION MODELS EQUIPPED WITH A BUNDLED POWER SUPPLY (DS-PAN-1302, DS-PAN-1302-2,
& DS-PAN-1306) REFER TO THE SUPPLIED LIND POWER SUPPLY REFERENCE GUIDE.
•WHEN TABLET IS DOCKED, THE BATTERY WILL ONLY CHARGE BETWEEN 10°C to 35°C (50°F to 95°F).
PLEASE REFER TO PANASONIC TOUGHBOOK L1 OWNER’S MANUAL FOR MORE INFORMATION.
Precautions
•Do not place metal objects or containers of liquid on top of the Docking Station
•If a malfunction occurs, immediately unplug the Power Supply and remove the laptop
•Use only the specified Power Supply (Part # LPS-160) with this Docking Station
•Do not connect cables into ports other than what they are specified for
•Do not leave the Docking Station in a high temperature environment (greater than 60°C, 140°F) for a long period of time

Specifications
Docking Station Power Input 5 V DC-IN*
Dimensions 7.08” (17.98 cm) H x 7.89” (20.04 cm) W x 2.45” (6.22 cm) D
Weight 0.98 lbs. (0.45 kg)
Operating Environment -10° C to 50° C (14° F to 122° F)
Storage Environment -30° C to 60° C (-22° F to 140° F)
EC DECLARATION OF CONFORMITY in accordance with EN 50498
Manufacturers Name: Havis, Inc.
Manufacturers Address: 75 Jacksonville Road, Warminster, PA 18974 USA
Declares under our sole responsibility that the product:
Product name: Havis Docking Station For Panasonic TOUGHBOOK L1 Tablet Only
Model: DS-PAN-130X, where ‘X’ may be any alphanumeric character and which describes product options.
May be followed by any alphanumeric characters which describe product options.
Product Options: This declaration covers all options of the above product which bear the CE Marking.
Is in conformity with the following standards or other normative documents:
Automotive EMC Directive EN 50498:2010, Electromagnetic compatibility (EMC) -
2004/108/EC: Product family standard for aftermarket electronic equipment in vehicles
Directive 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
Supplementary Information:
The product herewith complies with the requirements of the Automotive EMC Directive 2004/108/EC, Annex I, 6.5, 6.6, 6.8, and 6.9. This product requires the
use of a recommended e-Marked automotive power supply when used within vehicles.
Warminster, PA, USA July 23, 2019 Bruce Jonik, Director of Engineering , Havis, Inc.
* A DC –DC power supply is required to convert from vehicle power to the 5 V Input to Docking Station
(refer to CAUTION section on page 2 for more information)

Parts Included
Barrel Lock
Docking Connector
Pass-Through Antenna
(Dual, optional)
Docking Station
Ports
Mounting Holes
VESA 75 (M4 x 0.7mm)
Strain Relief Points
Alignment Posts (x2)
Latch Handle

Parts Included (continued)
Hardware Kit (HWK-0042)
This Hardware Kit includes:
1. Zip Ties (5)
2. Keys (2)
3. M4 x 0.7 x 12mm long Pan Head Screws (5)
4. Split Lock Washers (5)
5. Washers, M4 (5)
Tools required for installation:
• #2 Phillips (For M4 Pan Head Screws)
j
Antenna Identification
DS-PAN-1301-2, DS-PAN-1302-2
k
m
l
n
Antenna Connectors (TNC) Tablet Interface
TOUGHBOOK L1 Tablet
A
B
A B
AB
A –CELLULAR
B –GPS

Port Replication Capability
DS-PAN-1301, DS-PAN-1301-2
Antenna (TNC)
Optional: Part IDs
DS-PAN-1301-2
USB 2.0 Power Input
DC IN 5 V
External Antenna
Switch
ON / OFF

1) Align Docking Station mounting holes with the hole pattern on mounting device. Using the
four (4) M4 0.7 x 12mm Pan Head Screws (Hardware Kit Item 3), four (4) Washers, M4
(Hardware Kit Item 4), and four (4) Lock Washers, M4 (Hardware Kit Item 5), secure the
Docking Station to device. Torque screws to 20 in-lbs (2.3Nm) ± 10%
A) Havis Desktop Stand installation (sold separately, Part # DS-DA-218).
B) In-Vehicle mounting system installation (not included).
Installation
Washer, M4
M4 x 0.7 x 20mm
Pan Head Screws
Lock Washer, M4
Desktop Stand
(VESA 75 mm)
Washer, M4
M4 x 0.7 x 20mm
Pan Head Screws
Lock Washer, M4
Mounting Device
(Not included)

1) Tip the Docking Station to a position that is comfortable to work with.
2) Install all cables that are necessary for computing needs.
3) Use Zip Ties (Hardware Kit Item 1) and the Strain Relief Points to secure cables and reduce risk of
accidental disconnects.
4) Create a service loop with cables to ensure that no tension is on the connectors and to enable
intended motion.
5) Tie off cables onto a stationary part of the mounting system.
Cable Management
4
5
This loop must be large enough to allow
full range of expected rotation and
extension without stressing connections.
Collect cables to secure to the
mounting system.
(Note: mounting system not included)

Operation - Docking
DO NOT FORCE TABLET ONTO DOCKING STATION.
IF THERE IS RESISTANCE, CHECK ALIGNMENT OF TABLET ON DOCKING STATION
AND/OR THE ORIENTATION OF HAND STRAP.
NOTE: Ensure a proper connection by aligning the tablet’s
Alignment Sockets with the Docking Station’s Alignment Posts
Alignment Posts on the
DS-PAN-1300 Series Docking Station
Alignment Sockets on the bottom of
Panasonic TOUGHBOOK L1 Tablet
Hand Strap Model Standard Battery
Side Bar Code Top Bar Code No Bar Code
Panasonic Rotating (FZ-VSTL11U) N/A N/A NO
Panasonic Rotating (FZ-VSTL12U) N/A NO N/A
Panasonic Rotating (FZ-VSTL13U) NO N/A N/A
Infocase Standard (TBCL1HDSTP-P) YES YES YES
Infocase Enhanced (TBCL1EHDSTP-P) YES YES YES
Infocase Mobility Bundle (TBCL1MBBDL-P) YES YES YES
No Hand Strap YES YES YES
Docking Station and Accessory Compatibility

1) Ensure Docking Station is unlatched by lifting Latch Handle.
2) Hold tablet in landscape orientation, with bottom mounted docking connector angled toward Docking
Station. Lower tablet into the bottom of the Docking Station.
3) Pivot tablet so it sits flush in the Docking Station and hold while lowering the Latch Handle to secure
tablet in place.
4) For theft deterrence, secure tablet by locking Docking Station with supplied key (Hardware Kit Item 2).
Operation - Docking (continued)
Do not dock TOUGHBOOK L1 in reverse
position or damage can occur.

3) Pivot tablet so it sits flush in the Docking Station and hold while lowering the Latch Handle to secure
tablet in place.
4) For theft deterrence, secure tablet by locking Docking Station with supplied key (Hardware Kit Item 2).
Operation - Docking (continued)

1) If previously locked, unlock Docking Station using supplied key.
2) Secure tablet to avoid inadvertent ejection from Docking Station. Unlatch by lifting Latch Handle.
3) Once unlatched grab both sides of tablet, rock the top forward and carefully lift out of Docking Station,
top end first.
Operation - Undocking

Related Products
Havis offers a wide variety of accessory products specifically for use with your Docking Station.
For more information or to order, please visit www.havis.com.
LPS-160
10W Power Supply
External in-vehicle power supply and cable for Panasonic
TOUGHBOOK L1.
DS-DA-218
Desktop Stand for Tablet Docking Stations
Durable stand for mounting tablet Docking Stations for use in
the home or office.
DS-DA-243
Barcode Blocker Bracket
Bracket accessory used to block the tablet’s barcode reader in
either top or side orientation.
DS-DA-503
Replacement Keys
Set of two (2) replacement keys for DS-PAN-1300 Series
Docking Stations.
