Haws 9001EXPC1D1 Guide

08/17 Model 9001EXPC1D1 Page 1 of 7
No. 2077071(11)
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [e-mail]  website: www.hawsco.com
Model 9001EXPC1D1 Alarm
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any goods,
or part thereof, which shall appear to the Company upon inspection to be of defective
material or not of first class workmanship, provided that claim is made in writing to Haws
within a reasonable period after receipt of the product. Where claims for defects are made,
the defective part or parts shall be delivered to the Company, prepaid, for inspection. HAWS
will not be liable for the cost of repairs, alterations or replacements, or for any expense
connected therewith made by the owner or his agents, except upon written authority from
HAWS, Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer agrees
that Haws has made no other warranties either expressed or implied in addition to those
above stated, except that of title with respect to any of the products or equipment sold
hereunder and that HAWS shall not be liable for general, special, or consequential
damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for the
purpose for which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions, Haws cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED
OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

08/17 Model 9001EXPC1D1 Page 2 of 7
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
Alarm horn and lamp do not
operate.
1a.
Check incoming circuit for power and power
from flow switch.
b.
Check that the direction of water flow
corresponds to the arrow on the flow switch
body.
c.
Check that water flow is sufficient.
d.
Check all electrical connections for security,
including those in alarm base.
e.
Faulty flow switch. Replace entire switch
assembly.
f.
Faulty flasher module in alarm. Replace
flasher module.
2.
Horn sounds but lamp does not
flash.
2a.
Only replace lamp with Haws P/N
0003225505. (See Sheet 3 of Installation
drawing)
b.
Should replacement lamp also fail to operate,
replace flasher module.
3.
Lamp replacement.
3a.
Remove the guard/globe assembly from the
light fixture to replace the lamp. Only replace
lamp with Haws P/N 0003225505. (See Sheet
3 of Installation drawing)
4.
Alarm stays on.
4a.
Check wiring connections.
b.
Disconnect flow switch wires and test for
continuity.
RECOMMENDED TOOLS: Pipe joint sealant, screwdriver, pipe wrench, 14 AWG wire,
3/4” conduit and basic electricians’ tools for power connection.
LOCATION OF UNIT: The Model 9001EXPC1D1 Alarm may be mounted directly to the
upper stand pipe of a safety shower or wall mounted next to a shower or eyewash. The
alarm should be clearly visible from several directions.
ELECTRICAL SUPPLY: 120 VAC 50/60 HZ, 23 Watts average power consumption.
Suitable for use in Class I, Division 1, Group C, D areas; Temperature rating T4 (135°C).
WARNING: Power shall be supplied by a dedicated circuit through a 10 AMP maximum
breaker or fuse and should not supply any power to any other devices.
WATER SUPPLY: The flow switch requires a minimum of 2.4 GPM to activate. Mount
flow switch in supply line with flow in horizontal direction and switch stem extending
vertically from tee. Mount switch with at least 6” of straight pipe on both sides to minimize
turbulence in switch.

08/17 Model 9001EXPC1D1 Page 3 of 7
INSTALLATION PROCEDURE
*WARNING: EXPLOSION HAZARD – SUBSTITUTION OF COMPONENTS MAY
IMPAIR SUITABILITY FOR CLASS 1, DIVISION 1.
STEP 1: Choose a location for mounting the flow switch in the water supply line. The inlet
and outlet ports of the flow switch must be a minimum of 6 inches from any tees
or elbows in the water supply line. See attached installation drawing.
STEP 2: Mount the flow switch assembly in the water supply line. The switch body must
be in the vertical position with the water pipe horizontal. The water flow must be
in the direction marked by the arrow on the flow switch body. Use pipe sealing
compound on all water pipe connections.
STEP 3: Choose a location for mounting the alarm assembly. The alarm housing should
be positioned along a vertical axis at least 7 feet above ground for best visibility.
The alarm may be mounted directly to a water pipe using the supplied brackets.
The alarm can also be bolted to a flat surface such as a wall, using flanges with
appropriate fasteners (not supplied).
STEP 4: Using wire nuts, connect the flow switch to the alarm and power. The pink and
orange wires are connected to the second normally closed contact of the flow
switch and may be used for remote alarm activation. The signal from the pink
wire will be supply voltage, to be provided to orange wire by customer, when no
water is flowing and zero voltage when the flow switch and local alarm are
activated. If a remote alarm is not used, the pink and orange wires must be
insulated at their free ends. Power to be routed using rigid conduit and a seal
fitting or Class 1, Division1 rated armored cable and an appropriate gland fitting.
See Electrical Wiring Diagram provided on installation drawing. Follow all
instructions in installation drawing and NEC code when installing unit.
OPERATION AND TEST INSTRUCTIONS
Test weekly. Instruct all employees in the use of emergency showers and eyewashes.
STEP 1: Apply power to the alarm branch circuit. The alarm should remain OFF.
STEP 2: Open the shower or eyewash flow valve. The alarm should sound and the light
should flash shortly after water flows from the system.
STEP 3: Shut off the flow valve. The alarm should turn off.
For more information about Haws products see our website: www.hawsco.com
© 2017 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

PARTS BREAKDOWN
PENDANT
LIGHT FIXTURE
GUARD 0002627451
HORN 0000091345
SP154DPDT FLOW SWITCH
FLASHER 0002469722
(INSIDE)
0002325488;
LED LAMP
0003225505
0004261000
APPROVED
DRAWN
PART NUMBER
DRAWING NO.
SCALE: SHEET OF
REV
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
SLS
7/15/08
A11
0002077071
9001EXPC1D1
1:1
11
FV 09/25/17
GC
4 of 7
PARTS BREAKDOWN
5197
2017

CUSTOMER ELECTRICAL HOOKUP ON TOP POWER NOT SUPPLIED) CONDUIT ENTRY FOR
ARMORED CABLE; MINIMUM BEND
152mm
6"MIN.
ARROW
MAIN JUNCTION BOX (120 VAC INCOMING
NOTES:
NOT SUPPLIED)
(RECOMMENDED
1-1/4" UNIONS
DIRECTION NOTE FLOW
WATER SUPPLY
1-1/4" IPS
STRAIGHT
152mm
6"MIN.
STRAIGHT
CAUTION:
THIS ASSEMBLY AT ANY JOINT
AS DAMAGE WILL OCCUR
DO NOT DISASSEMBLE OR ROTATE
SWITCH MUST BE MOUNTED IN HORIZONTAL POSITION
FLOW SWITCH
1. AUDIBLE AND VISIBLE ALARM ACTIVATED WHEN
SHOWER OR EYEWASH IS IN USE.
2. ALL ELECTRICAL COMPONENTS UL CERTIFIED. 120VAC
SUPPLY VOLTAGE REQUIRED, APPROXIMATELY 100VA ALL ELECTRICAL HOOKUPS TO MAIN JUNCTION BOX.
3. SUITABLE FOR CLASS I, DIV. 1 GROUPS C, D
TEMPERATURE RATING T4 (135°C) LOCATION.
4. LIGHT MUST BE ORIENTED IN A VERTICAL POSITION
AS SHOWN IN ORDER TO MEET NEMA 4 RATING.
5. INSTALLER MUST USE THREAD SEALANT, SUCH AS
APPLETON TLC3, RECOMMENDED FOR USE IN HAZARDOUS LOCATIONS ON ALL ELECTRICAL NPT CONNECTIONS.
HORN 6
SHOWER
RADIUS 5"; DO NOT CUT OR MODIFY.
SEE SHEET 2 FOR ELECTRICAL WIRING DIAGRAM
2X 1-1/4" PIPE CLAMP
2X WALL MOUNT FLANGE
MOUNTING HARDWARE NOT SUPPLIED. SEE
BELOW MOUNTING HOLE PATTERN 4X 1-5/8"
8 1/2"±1/2"
4X1-5/8"
8X Ø1/4"
2X 3/4" NIPPLE
SEE MOUNTING SYSTEM DETAIL
MOUNTING SYSTEM DETAIL
(FOR PIPE OR WALL MOUNT)
FLASHING LIGHT SEE SHEET 3 FOR
LAMP REPLACEMENT
APPROVED: DRAWN:
PART NUMBER
DRAWING NO.
SCALE: SHEET OF
REV
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
SLS
07/08
15361A00 11
0002077071.D
9001EXPC1D1 ALARM
1:1
13
FV
09/25/17
4140 GC
5 of 7
INSTALLATION
5197
2017
(MAX PIPE SIZE Ø1 7/8")

(COPPER)
(BLK)
(ORG)
(PINK)
(110 VOLT)
(NEUTRAL)
NC 1
COMPONENT DESIGNATION:
FLSH - FLASHER RELAY
LT1 - RED LIGHT
FS - FLOW SWITCH
AH - ALARM HORN
COM 2
NC 2
NO 2 (WHT)
(BLK)
AH
(BLK)
(BLUE)
COM 1
NO 1
FS
(RED) FLSH
(WHT)
(WHT)
(RED) G
LT1
120 VAC POWER SOURCE
(CUSTOMER)
(CUSTOMER)
POWER SOURCE
LOAD
(CUSTOMER)
G
ELECTRICAL WIRING DIAGRAM
(GROUND)
APPROVED: DRAWN:
PART NUMBER
DRAWING NO.
SCALE: SHEET OF
REV
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
SLS
07/08
15361A00 11
0002077071.D
9001EXPC1D1 ALARM
1:1
23
FV
09/25/17
4140 GC
6 of 7
INSTALLATION
5197
2017

PENDANT MOUNT
GUARD/GLOBE
ASSEMBLY
NOTES: (CONTINUED FROM SHEET 1)
6 LIGHT REPLACEMENT INSTRUCTIONS: 1) REMOVE GUARD/GLOBE ASSEMBLY: FIRST LOOSEN SET SCREW (LOCATED ON GUARD WHERE SHOWN). NEXT, ROTATE ASSEMBLY COUNTER CLOCKWISE UNTIL GUARD IS FREE FROM PENDANT MOUNT AND LAMP IS EXPOSED. 2) ONLY REPLACE LAMP WITH HAWS P/N 0003225505. WARNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS 1, DIVISION 1. 3) REPLACE GUARD/GLOBE ASSEMBLY: ROTATE ASSEMBLY CLOCKWISE ONTO THE PENDANT MOUNT UNTIL TIGHT AND TIGHTEN SET SCREW.
LAMP
SET SCREW
APPROVED: DRAWN:
PART NUMBER
DRAWING NO.
SCALE: SHEET OF
REV
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
SLS
07/08
15361A00 11
0002077071.D
9001EXPC1D1
1:1
33
FV
09/25/17
4140 JP
7 of 7
INSTALLATION
5197
